Kaohsiung Medical University Institutional Repository:Item 310902000/15655

C

ULTURE

OF

R

ETINAL

P

IGMENT

E

PITHELIUM

FROM

E

VISCERATION

S

PECIMENS

Han-Yi Tseng, Wen-Chuan Wu, Ying-Hsien Kao,1 and Hong-Jun Wu

Departments of Ophthalmology and 1Dermatology, Kaohsiung Medical University Hospital, Kaohsiung, Taiwan.

Human retinal pigment epithelial (RPE) cell cultures are usually obtained from donor eyes; isolation and culture of RPE cells obtained by evisceration has not been reported previously. The present study attempted to isolate and cultivate RPE cells from evisceration specimens obtained from two cases with severe ocular trauma. Two different isolation methods, explantation and enzymatic dissociation, were used. In Case 1, RPE cells grew from the explants, but were contaminated with other cells such as fibroblasts and melanocytes, and no pure RPE cultures were obtained by explantation. In Case 2, RPE cells were separated from choroids using 0.25% trypsin before plating for culture, which effectively eliminated contaminating cells. A pure RPE culture was obtained and cultured with F12 medium supplemented with 30% fetal bovine serum. With this enzymatic dissociation method, cultured RPE cells grew to confluence in primary culture and could be maintained in culture for five passages. Cultured RPE cells were identified by the presence of cytokeratin expression, as shown by immunocytochemical staining. These isolation and culture methods provide alternative sources for human RPE cells and could be useful in studies of the cell biology and pathophysiology of human RPE cells.

Key Words: retinal pigment epithelial cells, explantation, enzymatic dissociation (Kaohsiung J Med Sci 2004;20:225–9)

Received: November 19, 2003 Accepted: March 10, 2004 Address correspondence and reprint requests to: Dr. Wen-Chuan Wu, Department of Ophthalmology, Kaohsiung Medical University Hospital, 100 Tzyou 1st Road, Kaohsiung 807, Taiwan.

E-mail: [email protected]

Isolation and cultivation of human retinal pigment epithe-lium (RPE) was first established three decades ago. The major source of human RPE cells is cadaveric eyes [1–8], although some RPE cells have been obtained from pre-retinal membranes excised during vitrectomy surgery for proliferative vitreoretinopathy [9–11]. To date, no report has discussed RPE cell isolation from samples obtained during evisceration surgery. We report two patients who were blinded due to severe ocular trauma and who underwent evisceration surgery. Primary RPE cells were obtained from these patients by explantation and enzymatic dissociation. These isolation and culture methods provide alternative sources for human RPE cells and could be useful

in studies of the cell biology and pathophysiology of human RPE cells.

M

M

Reagents

F12 nutrient mixture, fetal bovine serum (FBS), and penicil-lin/streptomycin were purchased from Life Technology (Grand Island, NY, USA). Antibodies against cytokeratin (mouse monoclonal antibody, AE1/AE3), S100 (rabbit polyclonal antibody), and vimentin (mouse monoclonal antibody, V9) were all purchased from Dako (Carpinteria, Denmark).

Explantation method

Case 1 was an 18-year-old male who lost vision due to trauma to the left eye and was primarily sutured. He underwent evisceration surgery 1 week later. The cornea

was removed by limbal excision and the lens was extracted. The iris and vitreous gel were also removed. The retinal and choroidal membranes were stored in F12 medium for cell culture. The membrane was cut into small pieces (1 × 1 mm) that were plated into a 35 mm Falcon dish (Becton Dickin-son, Oxnard, CA, USA), with 0.5 mL F12 medium contain-ing 20% FBS. Additional culture medium (0.5 mL) was added 1 to 2 hours later, and again after 24 hours (1 mL). Cells were cultured in a humidified atmosphere of 5% CO2 in air at 37°C. The media were renewed every 3 days

until confluency.

Enzymatic dissociation method

Case 2 was a 45-year-old male who had lost vision in his right eye 19 years previously when it was pierced by a met-al rod, and his eye gradumet-ally shrank. He underwent evis-ceration surgery as described for Case 1. The choroidal membrane was dipped in F12 medium and kept for further primary culture. The membrane was immersed in 0.25% trypsin solution (Gibco, Grand Island, NY, USA) and in-cubated at 37°C for 30 minutes until the RPE detached from the stroma. The isolated cells were collected by centrifuga-tion and resuspended in culture medium (F12 medium containing 10% FBS). Cells were cultured in a humidified atmosphere of 5% CO2 in air at 37°C. The media were

renewed every 3 days until confluency.

Immunocytochemical stain

Cultured cells were seeded on chamber slides for overnight incubation to detect intracellular antigen expression. Cells on slides were fixed with a mixture of acetone and methanol (1:1) at –20°C for at least 30 minutes. Following washes with phosphate-buffered saline (PBS), the cells were treated with 50 µL of primary antisera against cytokeratin, S100, and vimentin, respectively, at 1:50 dilution at room temperature for 1 hour. After washes with PBS, the immunoreactive signal was linked to secondary fluorescein isothiocyanate-conjugated goat anti-rabbit or anti-mouse immunoglobulin G antibodies (Chemicon, Temecula, CA, USA) at 1:1,000 dilution, and incubated at room temperature for 1 hour. The cells were finally washed five times with PBS, mounted in 10% glycerol in PBS, and observed under a fluorescence microscope.

R

After incubation for 7 days, component cells from Case 1 were migrating out from and colonizing around the excised

tissues. These outgrowing cells revealed heterogeneity in morphology, including pigmented epithelioid cells, un-pigmented fibroblast-like cells, and un-pigmented cells with dendrites (Figure 1). Most were fibroblast-like cells, which are capable of propagating. The fibroblast-like cells out-numbered RPE cells after 10 days of culture, and reached confluency after 23 days of incubation.

Using the enzymatic dissociation method (Case 2), we observed a large quantity of pigmented cells attached to the culture dish after seeding overnight. The attached cells started to spread in polygonal or epithelioid shapes after 3 days of incubation. There was a round transparent zone in the cell nucleus and a large number of pigmented brownish granules in the cytoplasm. The attached cells started to grow after 5 days of incubation and the pigment content of each cell significantly decreased, possibly due to the dilu-tion effect of mitosis (Figure 2). The cells reached confluence

Figure 1. Photomicrograph of primary retinal pigment epithelial cells obtained by the explantation method.

Figure 2. Photomicrograph of primary retinal pigment epithelial cells obtained by the enzymatic dissociation method.

after 15 days of incubation and were subcultured. The subcultured cells continued to grow and remained epithe-lioid in morphology, while the intracellular pigmented granules continued to decrease due to mitosis. The cells became senescent and the doubling time was longer than 5 days after six passages.

Immunocytochemical staining indicated that the cells from Case 2 in all passages were cytokeratin-positive (Figure 3). The positivity percentage of all staining was higher than 90% of isolated cells (data not shown). They all displayed characteristics typical of epithelial cells.

D

RPE plays multiple physiologic roles in the retina, such as phagocytosis of photoreceptor outer segment, metabo-lism of vitamin A, regulation of transportation of water and electrolytes, and production of various growth factors, neurotrophic factors, and cytokines [6–8,12–15]. Melanin molecules in RPE, serving as anti-oxidant agents and free-radical scavengers, can absorb visible light and block the deleterious effects of ultraviolet light [16]. In addition, RPE plays an important role in maintaining the physiologic functions of the retina, exchanging metabolites through the choroidal blood circulation. Pathogenic alteration in RPE cells is strongly associated with several ocular diseases, such as age-related macular degeneration, proliferative vitreoretinopathy, Usher syndrome type 1B, and Sorsby macular dystrophy [17–19].

The isolation and culture of human RPE cells are im-portant in the study of cell biology and pathophysiology. In this paper, we report two cases in which tissues from evisceration surgery were used to culture primary RPE

cells. We chose evisceration specimens because they are the most accessible sources of human RPE cells for clinical ophthalmologists. In the first case, it proved difficult to obtain pure RPE cells using the explantation method due to the fact that the choroidal membrane contains different types of cells, including melanocytes, fibroblasts, vascular endothelial cells, and pericytes. Flood et al [2] and Newsome [5], in their retrospective history of RPE cell culture, indicated that many investigators have tried to isolate RPE cells using the explantation method but failed. Primary RPE cell culture with a high degree of purity was impossible until Mannagh et al proposed enzymatic digestion as an isolation method [1]. Since then, enzymatic microdissection has become, without exception, the most common method of isolating RPE from cadaveric eyes [2–8].

We therefore used the enzymatic dissociation method in Case 2. It appeared that some, if not all, of the RPE cells could be successfully separated from choroidal membranes, and that the enzymatic treatment was optimized so as not to hamper cell viability, so that isolated cells were able to attach, spread, and proliferate after inoculation to culture dishes. The morphology of the attached cells was apparently different from that of fibroblasts, in that they contained high amounts of pigment granules in the cytoplasm. Since adult RPE cells lack de novo melanogenesis, the intracellular con-tent of pigment granules becomes increasingly diluted throughout the progression of cellular mitosis, particularly when they are isolated and maintained ex vivo. Nevertheless, cell morphology remained the same as the typical pattern of epithelium, and cells continued to grow for at least five passages. The expression of cytokeratins is considered the most reliable differentiation marker for the epithelium, and should not be present in fibroblasts and melanocytes. The cells cultivated in Case 2 were definitely RPE, as confirmed by positive staining for cytokeratin.

In summary, we successfully isolated primary RPE cells using the enzymatic digestion method from a patient who had undergone evisceration surgery. This is the first case in which human RPE cells were cultured from non-cadaveric materials. Compared with the explantation method, the en-zymatic dissociation method is the better one for retrieving experimental materials from clinical subjects, in terms of efficiency and cell purity.

A

We thank Dr. Dan-Ning Hu for his valuable comments on culture technique. This study was supported by an

intramural grant from the Kaohsiung Medical University (KMU89-2314-B037-147).

R

1. Mannagh J, Ayra DV, Irvine AR. Tissue culture of human retinal pigment epithelium. Invest Ophthalmol 1973;12:52–64. 2. Flood MT, Gouras P, Kjeldbye H. Growth characteristics and ultrastructure of human retinal pigment epithelium in vitro.

Invest Ophthalmol Vis Sci 1980;19:1309–20.

3. Hu DN, Del Monte MA, Liu S, et al. Morphology, phagocytosis, and vitamin A metabolism of cultured human retinal pigment epithelium. Birth Defects Orig Artic Ser 1982;18:67–79. 4. Pfeffer BA. Improved methodology for cell culture of human

and monkey retinal pigment epithelium. Prog Retinal Res 1991;10:251–91.

5. Newsome DA. Retinal pigmented epithelium culture: current applications. Trans Ophthalmol Soc UK 1983;103:458–66. 6. Pfeffer BA, Clark VM, Flannery JG, et al. Membrane receptors

for retinal-binding protein in cultured human retinal pigment epithelium. Invest Ophthalmol Vis Sci 1986;27:1031–40. 7. Sternfeld MD, Robertson JE, Shipley GD, et al. Cultured

hu-man retinal pigment epithelial cells express basic fibroblast growth factor and its receptor. Curr Eye Res 1989;8:1029–37. 8. Kennedy BG. Na+-K+-Cl– cotransport in cultured cells derived

from human retinal pigment epithelium. Cell Physiol 1990;28: 29–34.

9. Jiang DY, Hiscott PS, Grierson I, et al. Growth and

contracti-bility of cells from fibrocellular epiretinal membranes in primary tissue culture. Br J Ophthalmol 1988;72:116–26. 10. Hiscott PS, Grierson I, Hitchins CA, et al. Epiretinal membranes

in vitro. Trans Ophthalmol Soc UK 1983;103:89–102.

11. Muldoon TO, Hu DN, McCormick SA, et al. Antiproliferative activity of chemotherapeutic agents on cultured retinal pig-ment epithelium derived from preretinal membrane. Invest

Oph-thalmol Vis Sci 1993;34:S950.

12. Bok D. The retinal pigment epithelium: a versatile partner in vision. J Cell Sci 1993;17:189–95.

13. Jaffe G, Roberts WL, Wong HL, et al. Monocyte-induced cytokine expression in cultured human retinal pigment epithelial cells. Exp Eye Res 1995;61:533–43.

14. Ishida K, Yoshimura N, Yoshida M, et al. Expression of neurotrophic factors in cultured human retinal pigment epithelial cells. Curr Eye Res 1997;16:96–101.

15. Kociok N, Heppekausen H, Schraermeyer U, et al. The mRNA expression of cytokines and their receptors in cultured iris pigment epithelial cells: a comparison with retinal pigment epithelial cells. Exp Eye Res 1998;67:237–50.

16. Sarna T. Properties and function of the ocular melanin: a photobiophysical view. J Photochem Photobiol B 1992;12: 215–58.

17. Campochiar PA. Pathogenic mechanisms in proliferative vitreoretinopathy. Arch Ophthalmol 1997;117:237–41. 18. Ciulla TA, Danis RP, Harris A. Age-related macular

degenera-tion: a review of experimental treatments. Surv Ophthalmol 1998;43:134–46.

19. Algvere PV. Clinical possibilities in retinal pigment epithelial transplantations. Acta Ophthalmol Scand 1997;75:1.
