Prefix Hash Tree

An Indexing Data Structure over Distributed Hash Tables

Sriram Ramabhadran^∗

University of California, San Diego

Sylvia Ratnasamy

Intel Research, Berkeley

Joseph M. Hellerstein

University of California, Berkeley and

Intel Research, Berkeley

Scott Shenker

International Comp. Science Institute, Berkeley and

University of California, Berkeley

ABSTRACT

Distributed Hash Tables are scalable, robust, and self-organizing peer-to-peer systems that support exact match lookups. This paper describes the design and implementation of a Prefix Hash Tree - a distributed data structure that enables more so- phisticated queries over a DHT. The Prefix Hash Tree uses the lookup interface of a DHT to con- struct a trie-based structure that is both efficient (updates are doubly logarithmic in the size of the domain being indexed), and resilient (the failure of any given node in the Prefix Hash Tree does not affect the availability of data stored at other nodes).

Categories and Subject Descriptors

C.2.4 [Comp. Communication Networks]: Dis- tributed Systems—distributed applications; E.1 [Data Structures]: distributed data structures; H.3.1 [Info- rmation Storage and Retrieval]: Content Anal- ysis and Indexing—indexing methods

General Terms

Algorithms, Design, Performance Keywords

distributed hash tables, data structures, range queries 1. INTRODUCTION

The explosive growth but primitive design of peer- to-peer file-sharing applications such as Gnutella [7] and KaZaa [29] inspired the research community to invent Distributed Hash Tables (DHTs) [31, 24, 14, 26, 22, 23]. Using a structured overlay network, DHTs map a given key to the node in the network holding the object associated with that key; this lookup operation lookup(key) can be used to support the canonical put(key,value) and get(key) hash table operations. The broad applicability of

∗email [email protected]

this lookup interface has allowed a wide variety of system to be built on top DHTs, including file systems [9, 27], indirection services [30], event notification [6], content distribution networks [10] and many others.

DHTs were designed in the Internet style: scalability and ease of deployment triumph over strict semantics. In particular, DHTs are self-organizing, requiring no centralized authority or manual con- figuration. They are robust against node failures and easily accommodate new nodes. Most impor- tantly, they are scalable in the sense that both latency (in terms of the number of hops per lookup) and the local state required typically grow loga- rithmically in the number of nodes; this is crucial since many of the envisioned scenarios for DHTs involve extremely large systems (such as P2P mu- sic file sharing). However, DHTs, like the Internet, deliver ”best-effort” semantics; put’s and get’s are likely to succeed, but the system provides no guarantees. As observed by others [36, 5], this conflict between scalability and strict semantics appears to be inevitable and, for many large-scale Inter- net systems, the former is deemed more important than the latter.

While DHTs have enjoyed some success as a building block for Internet-scale applications, they are seriously deficient in one regard: they only directly support exact match queries. Keyword queries can be derived from these exact match queries in a straightforward but inefficient manner; see [25, 20]

for applications of this to DHTs. Equality joins can also be supported within a DHT framework;

see [15]. However, range queries, asking for all objects with values in a certain range, are particularly difficult to implement in DHTs. This is because DHTs use hashing to distribute keys uniformly and so can’t rely on any structural properties of the key space, such as an ordering among keys.

Range queries arise quite naturally in a number of

(2)

0 1

0 1 0 1

1

0 0 1

1 0

0 1

000001 000100 000100 001001 001010 001010 001010 001011 001011

010000 010101 100010 101011 101111 110000 110010 110011 110110 111000 111010 000*

00100*

001010*

001011*

0011*

01*

10*

110*

111*

3

0

1

2

4

6 5

Keys Leaf nodes

Figure 1: Prefix Hash Tree potential application domains:

Databases Peer-to-peer databases [15] need to support SQL-type relational queries in a distributed fashion. Range predicates are a key component in SQL.

Distributed computing Resource discovery requires locating resources within certain size ranges in a decentralized manner.

Location-aware computing Many applications want to locate nearby resources (computing, human or commercial) based on a user’s current location, which is essentially a 2-dimensional range query based on geographic coordinates.

Scientific computing Parallel N-body computations [34] require 3-dimensional range queries for accu- rate approximations.

In this paper, we address the problem of efficiently supporting 1-dimensional range queries over a DHT.

Our main contribution is a novel trie-based distributed data structure called Prefix Hash Tree (henceforth abbreviated as PHT) that supports such queries.

As a corollary, the PHT can also support heap queries (“what is the maximum/minimum ?”), prox- imity queries (“what is the nearest element to X

?”), and, in a limited way, multi-dimensional ana- logues of the above, thereby greatly expanding the querying facilities of DHTs. PHT is efficient, in that updates are doubly logarithmic in the size of the domain being indexed. Moreover, PHT is self-organizing and load-balanced. PHT also toler- ates failures well; while it cannot by itself protect

against data loss when nodes go down¹, the failure of any given node in the Prefix Hash Tree does not affect the availability of data stored at other nodes.

But perhaps the most crucial property of PHT is that it is built entirely on top of the lookup interface, and thus can run over any DHT. That is, PHT uses only the lookup(key) operation common to all DHTs and does not, as in SkipGraph [1] and other such approaches, assume knowledge of nor require changes to the DHT topology or routing behavior. While designs that rely on such lower- layer knowledge and modifications are appropriate for contexts where the DHT is expressly deployed for the purpose of supporting range queries, we address the case where one must use a pre-existing DHT. This is particularly important if one wants to make use of publicly available DHT services, such as OpenHash [18].

The remainder of the paper is organized as follows. Section 2 describes the design of the PHT data structure. Section 3 presents the results of an experimental evaluation. Section 4 surveys related work and section 5 concludes.

2. DATA STRUCTURE

This section describes the PHT data structure, along with related algorithms.

2.1 PHT Description

For the sake of simplicity, it is assumed that the domain being indexed is {0, 1}^D, i.e., binary strings

1But PHT can take advantage of any replication or other data-preserving technique employed by a DHT.

(3)

of length D, although the discussion extends naturally to other domains. Therefore, the data set indexed by the PHT consists of some number N of D-bit binary keys.

In essence, the PHT data structure is a binary trie built over the data set. Each node of the trie is labeled with a prefix that is defined recursively:

given a node with label l, its left and right child nodes are labeled l0 and l1 respectively. The root is labeled with the attribute being indexed, and downstream nodes are labeled as above.

The following properties are invariant in a PHT.

1. (Universal prefix ) Each node has either 0 or 2 children.

2. (Key storage) A key K is stored at a leaf node whose label is a prefix of K.

3. (Split) Each leaf node stores atmost B keys.

4. (Merge) Each internal node contains atleast (B + 1) keys in its sub-tree.

5. (Threaded leaves) Each leaf node maintains a pointer to the leaf nodes on its immediate left and and immediate right respectively.²

Property 1 guarantees that the leaf nodes of the PHT form a universal prefix set ³. Consequently, given any key K ∈ {0, 1}^D, there is exactly one leaf node leaf (K) whose label is a prefix of K. Prop- erty 2 states that the key K is stored at leaf (K).

Figure 1 provides an example of a PHT containing N = 20 6-bit keys with B = 4. The table on the right in Figure 1 lists the 20 keys and the leaf nodes they are stored in.

Properties 3 and 4 govern how the PHT adapts to the distribution of keys in the data set. Fol- lowing the insertion of a new key, the number of keys stored at a leaf node may exceed the threshold B, causing property 3 to be violated. To restore the invariant, the node splits into two child nodes, and its keys are redistributed among the children according to property 2. Conversely, following the deletion of an existing key, the number of keys contained in a sub-tree may fall below (B +1), causing property 4 to be violated. To restore the invariant, the entire sub-tree is merged into a single leaf node, where all the keys are aggregated. Notice the shape of the PHT depends on the distribution of keys; it is ”deep” in regions of the domain which are densely populated, and conversely, ”shallow”

2A pointer here would be the prefixes of neighboring leaves and, as a performance optimization, the cached IP address of their corresponding DHT nodes.

3A set of prefixes is a universal prefix set if and only if for every infinite binary sequence b, there is exactly one element in the set that is a prefix of b.

in regions of the domain which are sparsely populated. Finally, property 5 ensures that the leaves of the PHT form a doubly linked list, which enables sequential traversal of the leaves for answer- ing range queries.

As described this far, the PHT structure is a fairly routine binary trie. The novelty of PHT lies in how this logical trie is distributed among the peers in the network; i.e., in how PHT vertices are assigned to DHT nodes. This is achieved by hashing the prefix labels of PHT nodes over the DHT identifier space. A node with label l is thus assigned

4 to the peer to which l is mapped by the DHT, i.e., the peer whose identifier is closest to HASH(l).

This hash-based assignment implies that given a label, it is possible to locate its corresponding PHT node via a single DHT lookup. This “direct access”

property is unlike the successive link traversals associated with typical data structures and results in the PHT having several desirable features that are discussed subsequently.

2.2 PHT Operations

This section describes algorithms for PHT operations.

2.2.1 Lookup

Given a key K, a PHT lookup operation returns the unique leaf node leaf (K) whose label is a prefix of K. Because there are (D + 1) distinct prefixes of K, there are (D + 1) potential candidates; an obvious algorithm is to perform a linear scan of these (D + 1) nodes until the required leaf node is reached. This is similar to a top-down traversal of the trie except that a DHT lookup is used to locate a PHT node given its prefix label. Pseudocode for this algorithm is given below.

Algorithm: PHT-LOOKUP-LINEAR

input : A key K output: leaf (K) for i ← 0 to D do

/*Pi(K) denotes prefix of K of length i */

node← ^DHT-LOOKUP(Pi(K));

if (node is a leaf node) then return node ; end

return f ailure;

How can this be improved ? Given a key K, the above algorithm tries different prefix lengths until the required leaf node is reached. Clearly, linear search can be replaced by binary search on prefix

4Assignment implies that the peer maintains the state associated with the PHT node assigned to it. Henceforth, the discussion will use PHT node to also refer to the peer assigned that node.

(4)

lengths. If the current prefix is an internal node of the PHT, the search tries longer prefixes. Al- ternatively, if the current prefix is not an internal node of the PHT, the search tries shorter prefixes.

The search terminates when the required leaf node is reached. The decision tree to the left in Fig- ure 1 illustrates the binary search. For example.

consider a lookup for the key 001100. The binary search algorithm first tries the 3-bit prefix 001*

(internal node), then the 5-bit prefix 00110* (not an internal node), and then finally the 4-bit prefix 0011*, which is the required leaf node. Pseudocode for this algorithm is given below.

Algorithm: PHT-LOOKUP-BINARY

input : A key K output: leaf (K) lo← 0;

hi← D;

while(lo ≤ hi) do mid ← (lo + hi)/2;

/*Pmid(K) denotes prefix of K of length mid */

node← ^DHT-LOOKUP(Pmid(K));

if (node is a leaf node) then return node ; else

if (node is an internal node) then lo ← mid + 1;

else hi← mid- 1;

endend

returnf ailure;

Binary search reduces the number of DHT lookups from (D + 1) to blog (D + 1)c + 1 ≈ log D. Never- theless, linear search is still significant for atleast two reasons. First, observe that the (D + 1) DHT lookups in linear search can be performed in parallel, as opposed to binary search, which is inherently sequential. This results in two modes of operation viz. low-overhead lookups using binary search, and low-latency lookups using parallel search. Second, binary search may fail ,i.e., be unable to correctly locate the leaf node, as a result of the failure of an internal PHT node ⁵. On the other hand, linear search is guaranteed to succeed as long as the leaf node is alive, and the DHT is able to route to it, and therefore provides a failover mechanism.

Note that both algorithms are contingent on the fact that the DHT provides a mechanism to locate any PHT node via a single lookup.

2.2.2 Range Query

Given two keys L and H (L ≤ H), a range query returns all keys K contained in the PHT satisfying

5Binary search will not be able to distinguish between the failure of an internal node and the absence of an internal node.

0 1

0 1 0 1

1

0 0 1

1 0

0 1

Sequential Parallel

Figure 2: Range queries

L ≤ K ≤ H. Range queries can be implemented in a PHT in several ways; we present two simple algorithms.

The first algorithm is to locate leaf (L) using the PHT lookup operation. Now the doubly linked list of threaded leaves is traversed sequentially until the node leaf (H) is reached. All values satisying the range query are retrieved. This algorithm is simple and efficient; it initially requires log D DHT lookups to locate leaf (L). It cannot avoid travers- ing the remaining nodes to answer the query. The disadvantage of this algorithm is that a sequential scan of the leaf nodes may result in a high latency before the query is completely resolved.

The second algorithm is to parallelize. Using the DHT, locate the node whose label corresponds to the smallest prefix range that completely covers the specified range. If this is an internal node, then recursively forward the query onward to those children which overlap with the specified range. This process continuues until the leaf nodes overlapping with the query are reached. If this is not an internal node, the required range query is covered by a single leaf node, which can be located by binary search.

Figure 2 shows an example of range search. Con- sider a query for the range [001001, 001011]. In the sequential algorithm, a PHT lookup is used to locate the node containing the lower endpoint, i.e., node 00100∗. After this a traversal of the linked list forwards the query to the next two leaves 001010∗

and 001011∗, which resolves the query. In the parallel algorithm, we first identify the smallest prefix range that completely covers the query, which is

(5)

0010∗. A single DHT lookup is used to directly jump to this node, after which the query is for- warded in parallel within the sub-tree, until all leaf nodes that overlap with the search range are reached.

Note that in the parallel algorithm, it is sometimes desirable to break the search query into two, and treat these sub-queries independently. For example, a very small range that contains the midpoint of the space, will result in ∗ being the smallest prefix range containing it, thereby potentially over- loading the root. To prevent this, we observe that every range is contained in the union of two prefix ranges that are of roughly the same size as the query (within a factor of 2). By handling these separately, it is possible to ensure a search starts at a level in the PHT that is appropriate for the query i.e. smaller queries start lower down in the PHT.

2.2.3 Insert / Delete

Insertion and deletion of a key K both require a PHT lookup operation to first locate the leaf node leaf (K). Insertion of a new key can cause this leaf node to split into two children, followed by a redistribution of keys. In most cases, the (B + 1) keys are distributed among the two children such that each of them stores atmost B. However it is possible that all (B + 1) keys are distributed to the same child, necessitating a further split. In the worst case, an insertion can cause splits to cascade all the way to a depth D ⁶, making insertion costs proportional to D. Similarly, in the worst case, deletion can cause an entire sub-tree of depth D to collapse into a single leaf node, incurring a cost proportional to D.

It is possible to reduce update costs and avoid problems of multi-node coordination through stag- gered updates. Only one split operation is allowed per insertion, and similarly, only one merge operation is allowed per deletion. While this results in update costs reducing to log D DHT lookups (the cost of a PHT lookup to locate the leaf node), it also allows invariants 3 and 4 to be violated. A leaf node can now store upto (B + D) keys. This is not likely to be a problem because in most practical scenarios, B >> D.

2.3 Tries versus Trees

This section compares the merits of a trie-based index, such as the PHT, with balanced tree-based indices, such as the B-tree, with particular emphasis on implementation in a distributed setting. This paper has described how the PHT data structure can be built over a DHT; it is likewise conceivable that a B-tree could be built over a DHT, with the

6This process must terminate because in the worst case, all keys are identical, and it is assumed that identical keys are distinguished by padding random bits at the end, and appropriately increasing D.

DHT being used to distribute B-tree nodes across peers in the network. While the tree-based indices may be better in traditional indexing applications like databases, we argue the reverse is true for implementation over a DHT.

The primary difference between the two approaches is as follows: a trie partitions the space while a tree partitions the data set. In other words, a trie node represents a particular region of space, while a tree node represents a particular set of keys. Because a trie uses space, which is constant independent of the actual data set, there is some implicit knowledge about the location of a key. For example, in a trie, a key is always stored at a prefix of the key, which makes it possible to exploit the mechanism the DHT provides to locate a node via a single DHT lookup. In a tree, this knowledge is lacking, and it not possible to locate a key without a top- down traversal from the root. Therefore, a tree index cannot use the random access property of the DHT in the same manner. This translates into several key advantages in favor of the PHT when compared to a balanced tree index.

2.3.1 Efficiency

A balanced tree has a height of log N , and therefore a key lookup requires log N DHT lookups. In addi- tion, updates may require the tree to re-balanced.

The binary search lookup algorithm in the case of the PHT requires only log D DHT operations, and updates have the same cost as well. Comparing the cost of lookups in the case of an index consisting of a million 32-bit keys, a tree index would require 20 DHT lookups as compared to 6 for the PHT to retrieve a key. Of course, multiway indexing could be used to reduce the height of the tree, but this would also leave the tree more vulnerable to faults in the indexing structure.

2.3.2 Load Balancing

As mentioned before, every lookup in a tree must goes through the root, creating a potential bottleneck. In the case of a trie, binary search allows the load to be spread over 2^D² nodes (assuming uniform lookups), thus eliminating any bottleneck.

2.3.3 Fault Resilience

In a typical tree-based structure, the loss of an internal node results in the loss of the entire sub- tree rooted at the failed node. PHT however does not require top-down traversals; instead one can directly “jump” to any node in the PHT. Thus the failure of any given node in the PHT does not affect the availability of data stored at other nodes.

In some sense, the indexing state in the trie is used only as an optimization. For example, observe that correct operation of the PHT is achievable using only the integrity of the doubly-linked list of leaf

(6)

nodes⁷. Both updates (through linear search) and range queries (through sequential traversal of the list) can be handled without the help of the trie indexing structure. Contrast with a tree where the indexing structure is indispensible for both updates and queries, and is therefore vulnerable to failures.

2.4 PHT Enhancements

Until this point, we have discussed the use of PHTs for satisfying unidimensional range queries. In this section, we describe two refinements: functionality extensions to support multi-dimensional searching, and performance enhancements for scenarios with known or relatively static data distributions.

2.4.1 Multi-dimensional Indexing via Linearization There are a plethora of centralized indexing schemes for supporting multidimensional range and near- neighbor queries; multiple surveys have been pub- lished in this area (e.g., [11, 28]). One class of heuristic multidimensional indexing schemes maps multidimensional data to a single dimension. This approach is sometimes called linearization, or space- filling curves, and well-known examples include the Hilbert, Gray code, and “Z-order” curves [16]. A multidimensional query is mapped to a unidimensional range query that spans from the lowest to highest linearization points of the original query.

In general, linearized queries return a superset of the matching data, which has to be post-filtered.

Recent linearization schemes like the Pyramid [3]

and iDistance [35] techniques have been shown em- pirically to outperform traditional space-filling curves as well as popular multidimensional tree structures in high-dimensional scenarios.

Though work on multidimensional indexing via linearization schemes is largely heuristic, it has a strong practical attraction: linearization can be implemented as an overlay upon existing unidimensional range search structures, which are typically more frequently implemented and carefully debugged than specialized multidimensional indexes. This argu- ment holds for PHTs as well as for any distributed range search technique. PHTs have the added advantage that their underlying substrate, DHTs, are rapidly emerging as a leading distributed building block.

After mapping a d-dimensional query Qd into a unidimensional query Q⁰, a PHT finds the answer set in O(log D + d|Q⁰|/Be) network hops, where

|Q⁰| is the size of the result set returned for the unidimensional query Q⁰. Note that we have given no bound on the difference between |Q⁰| and |Qd|, and in the worst case |Q⁰| = n. This difference captures the inefficacy of the chosen linearization scheme; it is not particular to PHTs per se.

7This is somewhat similar to Chord whose correct operation depends only on the integrity of the successor pointers

2.4.2 Indexing Known Distributions

Relative to tree-based indexes, a disadvantage of PHTs is that their complexity is expressed in terms of the log of the domain size, D, rather than the size of the data set, N . In many scenarios, however, data is from a known distribution: for example, keywords in text search follow well-known Zipfian distributions, and range search queries (e.g. text- prefix queries like “Cali*”) are quite natural. Here we informally argue that for known distributions, the PHT can be modified to run in O(log log N ) expected hops.

We begin by examining the simple uniform distribution over D-bit keys. For N data items drawn from this distribution, the expected depth of a leaf in the PHT is O(log N ), with low variance. Hence for uniform distributions, the expected number of hops with PHT-LOOKUP-BINARY is O(log log N ).

This search algorithm can be improved further via a search algorithm that starts at prefix-length log N , and proceeds upward or downward as necessary.

For known but non-uniform distributions, similar performance can be achieved by “warping” the space appropriately, remapping the original distribution to a uniform distribution. For each data point drawn from the original distribution, its first bit is remapped to be 0 if it is lower than the midpoint of the distribution’s PDF, and 1 otherwise;

this assignment proceeds recursively through all D bits. The resulting set of mapped points are essentially drawn from the uniform distribution, and a PHT built on these points will have path lengths as described above. Queries in the original space are mapped accordingly, and will perform with O(log log N ) expected hops.

For globally well-known distributions (e.g. terms in spoken English), the warping function is more or less fixed and can be distributed as part of the PHT code. However, in practice many data sets come from distributions that do change, but quite slowly. For example, the distribution of terms in filesharing applications will shift slightly as pop- ularity shifts; some terms may suddenly become popular when a new popular file is released, but most terms’ frequency will remain relatively static for long periods of time. For such slowly-changing distributions, a gossip-based scheme can be used to disseminate compressed representations of the distribution to all nodes, and any changes to the distribution can be reflected via periodic remapping of the data and queries (perhaps as part of soft-state refresh.)

We close this section by observing a general dual- ity. A tree index is actually quite analogous to the pairing of a trie-based scheme with a known distribution: the “split-keys” in a tree index capture the data distribution, and the pointers in the tree index serve the same function as the bits in the trie

(7)

encoding. An advantage of the PHT approach is the ability we noted above to “jump” into any point of the trie via hashing; global knowledge of the distribution provides this uniformity in addressing. A similar trick could be achieved in tree indexes as well, if every searcher had a fair approximation of the split keys in the tree and the locations of the tree nodes in an identifier space.

3. EVALUATION

This section presents a simulation-based evaluation of the PHT data structure. Although these simulation results are by no means comprehensive, we present them as preliminary experimental evidence that the PHT is a viable solution. A more complete evaluation, along with gaining experience with deployment of a working prototype, is the focus of our current efforts.

Our simulation setup is as follows. A PHT that indexes 30-bit keys is created on top of a DHT consisting of 1000 nodes. Our focus is on evalu- ating the performance of the data structure; for that reason we abstract away many of the details of the DHT by using a stripped-down version of the Chord protocol. 2¹⁶ artificially generated keys are inserted into the PHT coming from a uniform distribution over the entire 2³⁰ keyspace. We use an artificially low block size of B = 20 in order to generate a non-trivial instance of the PHT.

3.1 Range queries

Recall that a range query is evaluated by travers- ing the leaf nodes of the PHT. The complexity (and latency) of the range query operation depends on the number of such leaves, which is a function of the output, i.e., how many keys actually satisfy the given query. In the ideal case, if the output size is O and the block size is B, the number of nodes traversed should be about d^O_Be. To see how well the PHT distributes keys among the leaf nodes, we generate 1000 randomly generated queries of size varying from 2²² to 2²⁶, measured how many leaf nodes were required to be traversed. The results normalized to the optimal number d^O_Be are shown in figure 3. The number of leaf nodes required to be traversed is roughly the same in all cases: about 1.4 times the optimal value. To evaluate the effect of skewed distributions on the PHT structure, this experiment was repeated with a Gaussian distribution centered at the midpoint of the space to generate input keys. For ranges that are close to the mean, where keys are densely clustered, the PHT does well, actually out-performing the uniform case. For sparser regions, the PHT does not do as well, but no worse than 1.6 the optimal value.

These results indicate that the PHT incurs only a reasonably small constant factor of overhead (in terms of nodes visited) more than the theoretically optimal value.

3.2 Load balance

The next experiment attempts to verify the asser- tion that the PHT spreads network load evenly, and therefore does not have a bottleneck, unlike a binary tree. To test this hypothesis, we generated 100,000 PHT lookups on uniformly distributed keys and observed the distribution of lookup traffic. By lookup traffic, we mean the DHT queries generated by the binary search algorithm, and not the underlying DHT routing traffic. Figure 4 shows the distribution of lookup traffic over all the nodes in the DHT. It can be seen that about 80 % of the nodes see less than 400 lookups (out of 100,000). The rest of the nodes, which correspond to PHT leaf nodes, receive more traffic, but in no case higher than 1800. Contrast this with a B-tree where each of the 100,000 messages must necessarily go through the root. To test the effect of network size, the experiment was repeated for 1000, 2000 and 3000 nodes respectively. As expected, a larger number of nodes reduces the amount of per-node traffic, as PHT prefixes are distributed among more nodes.

However the actual PHT leaf nodes continue to receive higher amounts of traffic than the rest of the nodes.

1.25 1.3 1.35 1.4 1.45 1.5 1.55 1.6

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Sub-optimality factor

Fraction of ranges Range search efficiency

Uniform distribution Gaussian distribution

Figure 3: Efficiency of range queries 4. RELATED WORK

Building efficient data structures for searching is one of the fundamental problems in computer science; [19, 8] are good references. Our PHT pro- posal is particularly reminiscent of Litwin’s Trie Hashing [21], but has an added advantage that the

“memory addresses” where buckets of the trie are stored are in fact the DHT keys obtained by hashing the corresponding prefixes.

With respect to the problem of implementing range search over peer-to-peer systems, Aspnes and Shah [1] have proposed skip graphs, a distributed data structure based on the skiplist that provides a range search solution. However they do not provide a mapping from keys to peers in a network; such a mapping is provided by Awerbuch and Scheideler

(8)

0 200 400 600 800 1000 1200 1400 1600

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Number of lookups

Cumulative distribution of nodes Distribution of lookup traffic B = 20

n=1000 n=2000 n=3000

Figure 4: Cumulative distribution of PHT lookup traffic

[2] by essentially building a skip graph on top of a DHT. Lookup times and per data item state in a skip graph are O(log N ), where N is the number of items.

In recent work, Karger and Ruhl [17] propose a randomized protocol called item balancing that bal- ances the distribution of items by having DHT nodes adaptively change their identifiers. While providing excellent theoretical properties, their solution relies on more than just the hashtable interface of the underlying DHT, which could potentially create a barrier to deployment. A related protocol has been proposed by Ganesan and Bawa [12].

Other related work includes a DHT-based caching scheme [13] and a technique specifically for the CAN DHT based on space-filling curves [32].

Cone [4] is a trie-based data structure that is used to evaluate aggregation operators, such as MIN, MAXand SUM, over keys in a DHT. Although the PHT is also based on a trie, it differs from Cone in three significant respects. First, Cone builds a trie over uniformly distributed node identifiers.

Second, Cone does not support range queries. Fi- nally, Cone is a DHT augmentation where as the PHT builds on top of the DHT.

Waldvogel et al [33] have proposed an IP lookup algorithm based on binary search of prefixes organized into hashtables based on prefix length. Al- though they are solving longest prefix match, a different but related problem, their binary search technique is similar to the PHT lookup algorithm.

The key distinguishing characteristic is that the PHT operates in a distributed setting, with an entirely different set of constraints and issues, as opposed to an IP lookup algorithm that is implemented in hardware in a high-speed router.

5. CONCLUSION

In their short existence, DHTs have become a widely used tool for building large-scale distributed systems. While the lookup interface offered by DHTs is broadly applicable, it does not naturally support a very common feature in database and other information processing systems: range queries. Our goal was to address this shortcoming but, contrary to early efforts in the field, subject to the constraint that these queries only use the lookup interface and not rely on changes to or knowledge of the underlying DHT routing algorithm. This would ensure that the solution would apply to any DHT, not just those specifically engineered for the task. To this end, we presented the design and evaluation of Pre- fix Hash Trees (PHT), a data structure designed to support range queries. PHT has the properties tra- ditionally required of large-scale Internet systems:

self-organizing, scalable, and robust in the presence of failures. While it does not prevent loss of data due to node outages, such failures do not prevent it from producing results from the other nodes.

In short, we believe that PHT will enable general- purpose DHTs to support a wider class of queries, and then broaden the horizon of their applicability.

6. REFERENCES

[1] Aspnes, J., and Shah, G. Skip graphs. In Fourteenth Annual ACM-SIAM Symposium on Discrete Algorithms (Baltimore, MD, Jan 2003).

[2] Awerbuch, B., and Scheideler, C.

Peer-to-peer Systems for Prefix Search. In ACM Symposium on Principles of Distributed Computing (Boston, MA, July 2003).

[3] Berchtold, S., B¨ohm, C., and Kriegel, H.-P. The pyramid-technique: Towards breaking the curse of dimensionality. In Proc.

ACM SIGMOD International Conference on Management of Data (Seattle, WA, June 1998), pp. 142–153.

[4] Bhagwan, R., Voelker, G., and

Varghese, G. Cone: Augmenting DHTs to Support Distributed Resource Discovery.

Tech. Rep. UCSD CS2002-0726, Computer Science Department, University of California, San Diego, November 2002.

[5] Blake, C., and Rodrigues, R. High Availability, Scalable Storage, Dynamic Peer Networks: Pick Two. In HotOS IX (May 2003).

[6] Cabrera, L., Jones, M. B., and Theimer, M. Herald: Achieving a Global Event Notification Service. In HotOS VIII (May 2001).

[7] Clip2. The Gnutella Protocol Specification v.0.4, March 2001.

(9)

[8] Cormen, T., Stein, C., Rivest, R., and Leiserson, C.Introduction to Algorithms.

McGraw-Hill Higher Education.

[9] Dabek, F., Kaashoek, M. F., Karger, D., Morris, R., and Stoica, I.Wide-area Cooperative Storage with CFS. In

Proceedings of the 18th ACM Symposium on Operating Systems Principles (SOSP 2001) (Lake Louise, AB, Canada, October 2001).

[10] Freedman, M. J., Freudenthal, E., and Mazieres, D.Democratizing Content Publishing with Coral. In Proceedings of the USENIX/ACM Symposium on Networked Systems Design and Implementation (NSDI), 2004 (San Francisco, CA, March 2003).

[11] Gaede, V., and G¨unther, O.

Multidimensional access methods. ACM Computing Surveys 30, 2 (June 1998), 170–231.

[12] Ganesan, P., and Bawa, M. Distributed Balanced Tables: Not Making a Hash of it All. Tech. rep., Computer Science

Department, Stanford University, 2003.

[13] Gupta, A., Agrawal, D., and Abbadi, A. E.Approximate Range Selection Queries in Peer-to-Peer Systems. In Proceedings of the First Biennial Conference on Innovative Data Systems Research (CIDR) (Asilomar, CA, January 2003).

[14] Hildrum, K., Kubiatowicz, J. D., Rao, S., and Zhao, B. Y.Distributed Object Location in a Dynamic Network. In 14th ACM Symposium on Parallel Algorithms and Architectures (Aug. 2002).

[15] Huebsch, R., Hellerstein, J. M., Lanham, N., Loo, B. T., Shenker, S., and Stoica, I. Querying the Internet with PIER. In Proceedings of VLDB 2003 (Berlin, Germany, September 2003).

[16] Jagadish, H. V. Linear clustering of objects with multiple atributes. In Proc. ACM SIGMOD International Conference on Management of Data (Atlantic City, NJ, May 1990), pp. 332–342.

[17] Karger, D., and Ruhl, M. Simple Efficient Load Balancing Algorithms for Peer-to-Peer Systems. In Proceedings of the Third International Peer-to-Peer Systems Workshop (IPTPS) (Feb. 2004).

[18] Karp, B., Ratnasamy, S., Rhea, S., and Shenker, S.Spurring Adoption of DHTs with OpenHash, a Public DHT service. In Proceedings of the Third International

Peer-to-Peer Systems Workshop IPTPS 2004 (Feb. 2004).

[19] Knuth, D. The Art of Computer Programming. Addison-Wesley.

[20] Li, J., Loo, B. T., Hellerstein, J. M., Kaashoek, F., Karger, D., and Morris, R. On the Feasibility of Peer-to-Peer Web Indexing and Search. In Proceedings of the 2nd International Workshop on Peer-to-Peer Systems (IPTPS). (Berkeley, CA, Feb. 2003).

[21] Litwin, W. Trie Hashing. In Proceedings of ACM SIGMOD (Ann Arbor, MI, 1981).

[22] Malkhi, D., Naor, M., and Ratajczak, D. Viceroy: A Scalable and Dynamic Emulation of the Butterfly. In ACM Symposium on Principles of Distributed Computing (July 2002).

[23] Maymounkov, P., and Mazi`eres, D.

Kademlia: A peer-to-peer information system based on the xor metric. In 1st International Workshop on Peer-to-Peer Systems

(Cambridge, MA, Mar. 2002).

[24] Ratnasamy, S., Francis, P., Handley, M., Karp, R., and Shenker, S. A Scalable Content-Addressable Network. In ACM SIGCOMM (San Diego, CA, August 2001), pp. 161–172.

[25] Reynolds, P., and Vahdat, A. Efficient Peer-to-Peer Keyword Searching. In

Proceedings of the IFIP International

Conference on Distributed Systems Platforms and Open Distributed Processing

(Middleware) (June 2003).

[26] Rowstron, A., and Druschel, P. Pastry:

Scalable, Distributed Object Location and Routing for Large-s cale Peer-to-peer Systems. In Proceedings of the 18th IFIP/ACM International Conference on Distributed Systems Platforms (Middleware 2001) (Nov. 2001).

[27] Rowstron, A., and Druschel, P. Storage management and caching in PAST, a

large-scale, persistent peer-to-peer storage utility. In 18th ACM Symposium on Operating Systems Principles (Banff, Canada, Oct. 2001).

[28] Salzberg, B., and Tsotras, V.

Comparison of access methods for

time-evolving data. ACM Computing Surveys 31, 2 (1999), 158–221.

[29] Sharman Networks Ltd. KaZaA Media Desktop, 2001.

[30] Stoica, I., Adkins, D., Zhuang, S., Shenker, S., and Surana, S. Internet Indirection Infrastructure. In ACM SIGCOMM (Pittsburgh, PA, Aug. 2002).

(10)

[31] Stoica, I., Morris, R., Liben-Nowell, D., Karger, D., Kaashoek, M. F., Dabek, F., and Balakrishnan, H.Chord:

A Scalable Peer-to-peer Lookup Protocol for Internet Applications. IEEE/ACM

Transactions on Networking 11, 1 (Feb.

2003), 17–32.

[32] Tang, C., Xu, Z., and Dwarkadas, S.

Peer-to-Peer Information Retrieval using Self-organizing Semantic Overlay Networks.

In ACM SIGCOMM (Karlsruhe, Germany, Aug. 2003).

[33] Waldvogel, M., Varghese, G., Turner, J., and Plattner, B. Scalable Best

Matching Prefix Lookups. In ACM Symposium on Principles of Distributed Computing (Puerto Vallarta, Mexico, June 1998).

[34] Warren, M., and Salmon, J.

Astrophysical N-body Simulations Using Hierarchical Tree Data Structures. In Proceedings of Supercomputing (Sept. 1992).

[35] Yu, C., Ooi, B. C., Tan, K.-L., and Jagadish, H. V.Indexing the distance: An efficient method to knn processing. In Proc.

27th International Conference on Very Large Data Bases (VLDB) (Roma, Italy, Sept.

2001), pp. 421–430.

[36] Yu, H., and Vahdat, A. The Costs and Limits of Availability for Replicated Services.

In Proceedings of the 18th ACM Symposium on Operating Systems Principles (SOSP) (Lake Louise, AB, Canada, October 2001).
