https://doi.org/10.1007/s12105-020-01271-8 ORIGINAL PAPER

Primary and Secondary/ Metastatic Salivary Duct Carcinoma Presenting within the Sinonasal Tract

Abbas Agaimy¹ · Sarina K. Mueller² · Justin A. Bishop³ · Simion I. Chiosea⁴

Received: 30 November 2020 / Accepted: 10 December 2020 / Published online: 11 January 2021

Abstract

Traditionally, sinonasal adenocarcinomas have been subdivided into intestinal (ITAC) and non-intestinal (non-ITAC) categories. The latter encompasses salivary-type adenocarcinomas originating from the seromucinous glands of the sinonasal mucosa and non-salivary adenocarcinomas. The non-salivary adenocarcinoma category is further subdivided into low-and high-grade variants. Among salivary-type sinonasal adenocarcinomas, tumors recapitulating salivary duct carcinoma (SDC) are exceedingly rare, but some might have been lumped into the high-grade non-ITAC category. To date, only three primary SDCs originating in the sinonasal tract have been reported. We herein describe 7 cases of SDC including one previously reported case (4 primary sinonasal, 3 metastatic/ extension from parotid gland SDC). The primary tumors affected 3 males and one female aged 60 – 75. Different sites were involved by the primary tumors while the secondary tumors affected the sphenoidal (2) and the frontal + maxillary (1) sinuses. Three primary tumors were de novo high-grade SDC and one was confined to contours of a pre-existing pleomorphic adenoma. All 3 secondary tumors were SDC ex pleomorphic adenoma of the parotid with a long history of recurrences, ultimately involving the sinonasal tract. Androgen receptor was positive in 7/7 cases. Four of 6 cases were strongly HER2/neu + (either score 3 + or with verified amplification). This small case series adds to the delineation of primary sinonasal SDC highlighting that almost half of invasive SDC presenting within sinonasal tract indeed represents extension or metastasis from a parotid gland primary. There is a tendency towards overrepresenta- tion of HER2/neu-positive cases in both categories (primary and metastatic), but this needs clarification in larger studies.

Keywords Salivary duct carcinoma · Ductal adenocarcinoma · Non-intestinal adenocarcinoma · Carcinoma ex pleomorphic adenoma · Sinonasal tract · HER2/neu

Introduction

As a consequence of extensive molecular studies utilizing innovate next generation sequencing tools, the classification of sinonasal carcinomas has received significant attention

in recent years [1, 2]. Although most of recent studies were devoted mainly to sinonasal undifferentiated carcinoma (SNUC) and related poorly differentiated carcinomas, adenocarcinomas have received some attention as well.

Traditionally, primary sinonasal adenocarcinomas have been subdivided into two major categories: intestinal type (ITAC), related to occupational wood dust exposure, and non-intestinal (non-ITAC) adenocarcinomas [3, 4]. The non- ITAC category encompasses salivary-type adenocarcinomas originating from seromucinous glands of the sinonasal mucosa and non-salivary adenocarcinomas. The latter are further subdivided into low-and high-grade variants [3, 4].

With more studies, it became evident that the non-ITAC category is heterogeneous and reproducible diagnostic cri- teria have not been established yet [5]. Among salivary-type sinonasal carcinomas, adenoid cystic carcinoma significantly outnumbered other rare types while pleomorphic adenoma is the main benign tumor encountered [6]. To our knowledge,

* Abbas Agaimy

abbas.agaimy@uk-erlangen.de

1 Institute of Pathology, Friedrich-Alexander-University Erlangen-Nürnberg, University Hospital Erlangen, Erlangen, Germany

2 Department of Otorhinolaryngology, Head and Neck Surgery, Friedrich-Alexander-University Erlangen-Nürnberg, University Hospital Erlangen, Erlangen, Germany

3 Department of Pathology, University of Texas Southwestern Medical Center, Dallas, TX, USA

4 Department of Pathology, University of Pittsburgh Medical Center, Presbyterian Hospital, Pittsburgh, PA 15213, USA

(2)

only three cases of genuine salivary duct carcinoma (SDC)- type sinonasal adenocarcinoma have been reported before, one by our group [7–9]. We herein present clinicopathologic and molecular features of 7 SDC-type adenocarcinomas presenting in the sinonasal tract and diagnosed via transnasal biopsies. Tumors were included irrespective of being primary or secondary, de novo or ex pleomorphic adenoma.

Material and Methods

Cases were identified in the routine and consultation files of the authors. One case (Case 2 in Table 1) has been previously reported [8], but follow-up has been updated and molecular testing performed. The tumor specimens were fixed in buffered formalin and embedded for routine histological examination. Immunohistochemistry (IHC) was performed on 3-µm sections cut from paraffin blocks using a fully auto- mated system (“Benchmark XT System”, Ventana Medical Systems Inc, 1910 Innovation Park Drive, Tucson, Arizona, USA) and the following antibodies: CK7 (OV-TL, 1:1000, Biogenex), CK5 (clone XM26, 1: 50, Zytomed), S100 pro- tein (polyclonal, 1:2500, Dako), SOX10 (polyclonal, 1:25, DCS), androgen receptor (clone AR441, 1:50, DAKO), HER2/neu (polyclonal, 1:1000, DAKO), and SMARCB1 (INI1) (MRQ-27, 1:50, Zytomed). HER2/neu expression status was assessed using methods established for breast cancer and is considered positive when the Dako Score is 3 + . Cases scored 2 + (equivocal) were then subjected to chromo- genic in situ hybridization (CISH) using a ZytoLight SPEC ERBB2/CEN 17 Dual Color Probe designed for the detec- tion of HER2/neu amplification (ZytoVision, Bremerhaven, Germany) following recommendations of the manufacturer.

Samples were used in accordance with ethical guidelines for the use of retrospective tissue samples provided by the local ethics committee of the Friedrich-Alexander Univer- sity Erlangen-Nuremberg (ethics committee statements 24.01.2005 and 18.01.2012).

Molecular Testing DNA Testing

Different molecular next generation sequencing (NGS) panels targeting DNA sequence variants (mutations) were used on different cases [for Cases 6 and 9 see ref. 10].

To analyze the mutational status of common cancer related genes, DNA was isolated from FFPE tissue sections (Case 8) using the Maxwell 16LEV Blood DNA kit (Promega, Madison, USA) and submitted to hybrid-capture enrichment-based sequencing analysis using the TruSight Tumor 170 (TST170) gene panel (Illumina, Inc., San Diego,

CA, USA) according to the manufacturer`s protocol. Librar- ies were sequenced on a Next Seq550 (Illumina) and analyzed for single nucleotide mutations, insertions, deletions and copy number variations using the TruSight Tumor 170 software (BaseSpace Sequence Hub, Illumina) with human genome hg19 as reference.

RNA Testing

For Cases 2 & 6—9, RNA was isolated from formalin-fixed paraffin embedded (FFPE) tissue sections using RNeasy FFPE Kit of Qiagen (Hilden, Germany) and quantified spec- trophotometrically using NanoDrop-1000 (Waltham, United States). Molecular analysis for gene fusions was performed using the TruSight RNA Fusion panel (Illumina, Inc., San Diego, CA, USA) with 500 ng RNA as input according to the manufacturer`s protocol. Libraries were sequenced on a MiSeq (Illumina, Inc., San Diego, CA, USA) with > 3 mil- lion reads per case, and sequences were analyzed using the RNA-Seq Alignment workflow, version 2.0.1 (Illumina, Inc., San Diego, CA, USA). The Integrative Genomics Viewer (IGV), version 2.2.13 (Broad Institute, REF) was used for data visualization. Case 5 was tested for gene fusions and sequence variants using the method described recently [11].

Results

Of 8 cases identified initially for this study (Cases 2 and 4–9 in Table 1), one HER2/neu-amplified, androgen receptor-negative high-grade adenocarcinoma was excluded due to lacking detailed clinical data and imaging to rule out a salivary gland tumor or other primary. This tumor showed extensive colonization of adjacent seromucinous glands and ducts suggesting a primary sinonasal origin. Four of the remaining 7 tumors (57%) were primary sinonasal and 3 represented discontinuous metastasis or contiguous extension from SDCs of the parotid gland.

Primary Sinonasal Salivary Duct Carcinomas

The 4 patients with definite primary sinonasal SDC were 3 males and one female aged 60 – 75 years. Site of origin was maxillary sinus (2), sphenoid sinus (1) and nasal cavity (1).

None had evidence of another primary tumor in the head and neck or other organs at the time of diagnosis. Three tumors were invasive high-grade de novo SDC and one was a high-grade SDC confined to the contours of the preexisting pleomorphic adenoma. This latter patient had a con- current inverted sinonasal papilloma in the maxillary sinus not related to the site of his SDC ex pleomorphic adenoma.

The invasive tumors were T2-4; two of them had extensive synchronous cervical node metastases (N2b-N3). Treatment

(3)

Table 1 Clinicopathological features of current and reported salivary duct carcinoma presenting within sinonasal tract (n = 9) *Clinical data incomplete to reliably rule out a salivary gland primary aCRT adjuvant chemoradiotherapy, aCT adjuvant chemotherapy, ANED alive with no evidence of disease, AWD alive with disease, CRT chemoradiotherapy, CT chemotherapy, DOD died of disease, F female, M male, mets metastasis, NA not available, PA pleomorphic adenoma, SDC salivary duct carcinoma, Rt right

NoCase Ref.Age/ GenderInvolved sinonasal sitesHistologySite of primary tumorOther tumorsTNM primary sinonasal SDCTreatmentOutcome 1Higo et al. [7]73/MRt maxillary/ ethmoidSDC, high-grade, de novoSinonasalNoNAPaliativeMultiple lung mets, AWD (6 mo) 2Current (Mueller et al.) [8]60/MRt maxillarySDC, high-grade, de novoSinonasalNo

pT2 pN2c (45/55) L1 V1 Pn0

Surgery + aCRT Bone metastasis, DOD (35 mo) 3Vallabh, et al. [9]76/MRt inferior turbinateSDC, high-grade, de novoSinonasalNoNASurgery + aCTANED (18 mo) 4Current75/MNasal cavity (primary)SDC, high-grade, de novoSinonasalNoT2NxMxSurgeryNA 5Current71/MRt sphenoid sinusSDC ex PA (confined to the PA)SinonasalConcurrent inverted sinonasal papilloma, maxillary sinus

TisNxMxSurgeryANED (24 mo) 6Current62/FMaxillary sinus/ nasal floorSDC, high-grade, de novoSinonasalNA

pT4 N2b (AJCC 7) or N3b (AJCC 8)

Surgery + CRT NA 7Current57/MLeft sphenoidal sinus

SDC ex PA, high- gradeParotidSDC ex PA parotid–CRT 1994: parotid gland

PA 1998 and 2005: P

A recurrences 2020: SDC ex PA with sinonasal involvement 8Current56/MLeft sphenoidal sinus

SDC ex PA, high- gradeParotidSDC ex PA parotid–Surgery and CRT SDC ex PA parotid (surgery + CRT) Bone mets (9 mo

later) Pterygopalatine fossa spread and sinonasal involvement (24 mo later) 9Current64 /FFrontal and maxil-SDC ex PA, high-ParotidSDC ex PA parotid–Surgery and CRT 2009: parotid SDC ex lary sinusesgradePA (surgery + CRT) 2014: recurrence in pre-molar/buccal

space 2018: sinonasal involvement and distant mets to lung

(4)

was surgery in all cases; two received adjuvant chemoradia- tion. Follow-up was available for two patients. One patient developed bone metastases; he died of his disease 35 months from initial diagnosis. The patient with SDC ex pleomorphic adenoma remained disease-free 24 months later.

Pathological and Immunohistochemical Findings Histologically, all primary invasive SDC showed classical histology of the entity with predominance of ductal, cribriform-like and irregular nests invading through the sinonasal mucosa with high-grade apocrine cytology and prominent foci of comedonecrosis (Fig. 1a-f). In addition to the classical SDC pattern, foci of variant histology were seen in all three cases, but to variable extent, including sieve-like solid growth in two cases (Fig. 2a, b), small nested pattern in one (Fig. 2c) and minor pleomorphic poorly cohesive foci in all cases (Fig. 2d). All tumors, expressed diffusely and strongly CK7 (Fig. 2e main image) and the androgen receptor (Fig. 2f), but lacked expression of CK5, S100 and SOX10 (Table 2). Mammaglobin was positive in a few single cells or group of cells in 3 of 3 cases (Fig. 2e, inset). Two of 3 tumors tested for HER2/neu showed strong membranous expression indicating amplification (score 3 + ; Fig. 2g). The third tumor (scored 2 +) revealed no amplification by CISH.

All 4 tumors showed retained expression of SMARCB1/

INI1. An intraductal/intraepithelial component was seen only in the one SDC ex pleomorphic adenoma and was so prominent, suggesting an initial diagnosis of oncocytic sinonasal papilloma by the submitting pathologist (Fig. 3).

Molecular Results

RNA fusion panel was tried in 3 primary tumors with suf- ficient material; but it failed in two cases due to poor RNA quality (Table 2). The case of primary SDC ex pleomorphic adenoma revealed no fusion but sequence assessment showed a HRAS mutation (p.Q61K).

Secondary Sinonasal Salivary Duct Carcinomas The three patients with parotid gland SDC involving the sinonasal tract were 2 males and one female aged 56, 57 and 64 years (Cases 7–9 in Table 1). All three had high-grade SDC ex pleomorphic adenoma. They all experienced at least one locoregional recurrence before presentation with sinonasal manifestation. One patient with a history of parotid gland pleomorphic adenoma for more than 20 years had resec- tion of recurrent pleomorphic adenoma 15 years ago. He then presented with extensive disease with involvement of the parapharyngeal space and the left sphenoidal sinuses (Fig. 4). The diagnosis of SDC ex pleomorphic adenoma

was rendered on sinonasal biopsies. One patient had distant spread to the lung.

Pathological and Immunohistochemical Findings Histologically, all secondary SDC showed very similar histology as their primary counterparts with predominance of ductal, cribriform-like and irregular nests invading through the sinonasal mucosa (Fig. 5a-d). Intraductal/intraepithelial growth was not seen in any case. All three tumors expressed diffusely and strongly CK7 and the androgen receptor (Fig. 5e), but lacked expression of CK5, S100 and SOX10.

Two tumors showed strong HER2/neu overexpression (score 3 + ; Fig. 5f); CISH was performed on one of them (upon clinical request) and confirmed a high level HER2/

neu amplification. All tumors showed retained expression of SMARCB1/INI1.

Molecular Results

The three secondary tumors were tested for gene mutations and gene fusion by different DNA and RNA panels (see Table 2). The RNA panel failed in two cases due to poor RNA quality of the available paraffin material. One tumor showed an HFM1-ETV1 fusion which has not been reported previously so that its oncogenic role remains unclear. DNA testing revealed typical gene mutations involving p53 (one case) and PIK3CA + HRAS (one case). PLAG1 and HMGA2 status was assessed by FISH in one case of SDC ex pleomorphic adenoma and was negative for rearrangements.

Discussion

Due to the lack of defining genetic markers, precise sub- typing of sinonasal non-intestinal adenocarcinomas (non- ITAC) is still challenging. This significantly heterogeneous group encompasses bland looking low-grade (frequently tubulopapillary) adenocarcinomas and poorly characterized high-grade adenocarcinomas [5, 12, 13]. Recently, recurrent ETV6-NTRK3 fusions have been described in a small subset of tumors in the spectrum of low-grade non-ITAC. Morphological characterization of the ETV6- fusion positive tumors revealed two different phenotypes:

(1) tumors indistinguishable from (mammary-analogue) salivary gland secretory carcinomas which have been classified as primary sinonasal salivary-type secretory carcinomas [14, 15], thus adding to the list of salivary-type sinonasal carcinomas, and (2) tumors that belong to the spectrum of low-grade tubulopapillary adenocarcinoma and are distinct from secretory carcinomas, but harbor the same ETV6 gene fusion [16]. The latter may harbor other

(5)

rare gene fusions, though their molecular pathogenesis is still emerging [17].

With the recent characterization of the SMARCB1-deficient sinonasal carcinoma [18], a variant showing frankly glandular growth and occasional yolk sac-like pattern has been proposed as a distinctive variant in the spectrum of SWI/SNF-deficient sinonasal carcinomas [19]. This rare

tumor has been likely included in the spectrum of high- grade non-ITAC in the past, although some might have been included in the oncocytic or myoepithelial carcinoma category due to their frequent “pink cytology” [19].

Salivary duct carcinoma (SDC; synonym: high-grade ductal carcinoma) is a highly aggressive malignancy of the excretory duct system accounting for up to 10% of salivary

Fig. 1 Representative images of primary sinonasal salivary duct carcinomas. At low power, SDC infiltrates and replaces the lamina propria with retained respiratory epithelial covering at the surface with variable reactive squamous metaplasia. Note variation from dif- fuse solid and sieve-like growth a to well defined large DCIS-like

nests with extensive comedo-type necrosis. b Destructive invasion of underlying bone c and perineural and angioinvasion d are seen. e transition from classical SDC pattern (left) to solid/adenoid pattern (right). f high-grade apocrine cytology is appreciated at high power

(6)

gland malignancies [20]. It mainly originates in the parotid gland and much less frequently from the submandibular gland [21]. Exceedingly rare reports from other sites include the minor salivary glands (mainly of the palate) [22], the Stensen duct [23], the lacrimal glands [24] and the larynx [25–27]. About 40–45% of SDC cases originates from

primary or recurrent pleomorphic adenomas as carcinoma ex pleomorphic adenoma variant [10, 20, 21]. Defining features of SDC includes prominent ductal proliferation with comedo-type necrosis (high-grade DCIS-like growth pattern) admixed with other diverse patterns that recapitulate the different morphologies of high-grade invasive ductal

Fig. 2 Variant SDC patterns were seen to variable extent in most of cases including diffuse solid-sieve-like mimicking secretory carci- noma a, b, small nested pattern c and less differentiated poorly cohe- sive small nests and single cells amid desmoplastic stroma d. By

immunohistochemistry, all cases expressed diffusely CK7 (e, main image), androgen receptor (f) and HER2/neu (g). Mammaglobin was positive in scattered cells or cluster of cells (E, subimage)

(7)

Table 2 Immunohistochemical and molecular features of current and reported salivary duct carcinoma presenting within sinonasal tract (n = 9)

ND not done

No Case Ref CK7 CK5 AR HER2neu S100 SOX10 RNA Panel DNA testing

1 Higo et al. [7] ND + + ND ND ND ND ND

2 Current (Mueller et al.) [8] + − + 2 + (CISH-) − − Failed (poor RNA quality) ND

3 Vallabh, et al. [9] + Focal ND ND ND ND ND ND

4 Current + − + 3 + − − ND ND

5 Current + − + ND − − No fusions but HRAS

p.Q61K ND

6 Current + − + 3 + − − Failed (poor RNA quality) Wild type PIK3CA

7 Current + − + 3 + − − Failed (poor RNA quality) ND

8 Current + − + 3 + (CISH +) − − HFM1/ETV1 fusion TST170: p53 mutation

(p.Gly245Ser)

9 Current + − + − − − Failed (poor RNA quality) PLAG1 & HMGA2 intact

by FISH, 150 gene panel:

PIK3CA E542K and HRAS Q61K mutations;

Fig. 3 The single case of SDC ex pleomorphic adenoma showed areas of classical pleomorphic adenoma blending with extensive scle- rosis a and confluent areas of highly atypical apocrine-type cells con- fined to the contours of the preexisting adenoma b and surrounded

by intact layer of smooth muscle actin + /p40 + basal/myoepithelial cells (c; p40 immunostain). d the carcinoma cells are strongly posi- tive with the androgen receptor

(8)

breast cancer [28, 29]. Their cytology is frequently apocrine or oncocytoid [28, 29]. Expression of the androgen receptor is detected in 70% and HER2/neu is overexpression in 25–30% of cases, reflecting gene amplification [28–32].

SDC originating primarily in the sinonasal tract is rare but might be underecognized or misclassified in the generic spectrum of high-grade non-ITAC in the past. To date, only three genuine cases have been reported [7–9]. Among 115 sinonasal and nasopharyngeal pleomorphic adenomas and carcinomas ex pleomorphic adenoma identified in a recent literature review, 10 cases of carcinoma ex pleomorphic adenoma involved sinonasal sites; 5 of them were reported as “adenocarcinomas, NOS” [33]. There was no mention of SDC in that review study. These observations suggest that primary sinonasal SDC are likely more common than the reported cases suggest and some might have been either included in the high-grade non-ITAC group or misclassified as other entities.

Hence, the current series adds to the growing spectrum of salivary-type sinonasal adenocarcinoma. The demo- graphic features and the clinicopathological characteristics of primary sinonasal SDC cases are comparable to those of salivary gland SDC. Moreover, metastatic and secondary SDC within the sinonasal tract are indistinguishable from primary tumors by morphology alone and the clinical history and imaging are mandatory for correct diagnosis. Study of additional cases is needed to shed light on possible over- representation of de novo origin (seen in 1 of 4 primary tumors) and of HER2/neu overexpression (observed in 2 of 3 primary tumors) in sinonasal SDC. The low number of cases in our study does not allow for conclusive results regarding these two points.

Our study highlights the frequency of sinonasal involvement by SDC originating primarily in the parotid gland with 3 of our 7 collected cases with complete clinical data being secondary SDC. We are not aware of similar docu- mentation of SDC secondarily involving the sinonasal tract.

Although larger series are needed for conclusive results, it is likely that SDC ex pleomorphic adenoma are more prone to sinonasal involvement (in the setting of multiple locoregional recurrences with ultimate extension or spread to the sinonasal tract) than de novo parotid gland SDC. In addition to metastasis from SDC of salivary gland origin, metastatic adenocarcinoma from different organs should always be considered in any sinonasal carcinoma not fitting the common types encountered as this site [34]. Given the predominance of older males, the major differential diagnostic considera- tion of primary and secondary sinonasal SDC is metastatic high-grade prostatic adenocarcinoma, as the two entities may share some morphological features and both express the androgen receptor [35]. In the appropriate clinicopathological context, inclusion of highly sensitive and specific prostate markers such as NKX3.1 is highly valuable com- pared to the traditional less sensitive prostate markers [36].

Extensive growth along preexisting glands (seen in the primary sinonasal SDC ex pleomorphic adenoma case) may closely mimic oncocytic sinonasal papilloma or carcinoma ex oncocytic sinonasal papilloma, underlining the neces- sity of careful assessment to rule out preexisting papilloma.

Indeed, this case was initially submitted with a diagnosis of oncocytic sinonasal papilloma. The misleading pattern of carcinomatous growth along preexisting glands and ducts in the sinonasal mucosa was observed in other types of sinonasal carcinoma as well, frequently suggesting a “carcinoma ex sinonasal papilloma” [18].

Fig. 4 Representative imaging of SDC ex pleomorphic adenoma with secondary involvement of the sinonasal tract (Case 7). Axial T2-weighted MRI scans showing a heterogeneous tumor in the left parotid region a extending into the nasopharynx and into the sinona-

sal tract. b The nodules with high signal intensity correspond to the recurrent pleomorphic adenoma, while the mass with attenuated signal intensity extending into the sinonasal cavities represents the SDC component (verified by histology)

(9)

In summary, we described a series of 4 primary and 3 secondary/metastatic sinonasal salivary duct carcinomas and reviewed previously reported single cases. Together, a total of 6 definite primary sinonasal SDC have been documented to date; all but one case originating de novo. Inclusion of salivary duct carcinoma in the differential of high-grade non-intestinal adenocarcinoma should facilitate recognition and hence bet- ter characterization of this rare highly aggressive malignancy.

Funding Open Access funding enabled and organized by Projekt DEAL. No external funding was obtained for this study.

Compliance with Ethical Standards

Conflict of interest All authors declare that they have no conflict of interest as it relates to this research project.

Ethical Approval All procedures performed in this retrospective data analysis involving human participants were in accordance with the ethical standards of the institutional review board.

Open Access This article is licensed under a Creative Commons Attri- bution 4.0 International License, which permits use, sharing, adapta- tion, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if changes were made. The images or other third party material in this article are included in the article’s Creative Commons licence, unless indicated otherwise in a credit line to the material. If material is not included in the article’s Creative Commons licence and your intended use is not Fig. 5 Secondary/ metastatic SDCs within the sinonasal sinuses are

essentially indistinguishable from primary tumors with diffuse infil- tration beneath eroded surface epithelium a, extensive bone invasion b and high-grade apocrine cell morphology with prominent come-

donecrosis. c Micropapillary-like poorly differentiated foci are seen and might be misinterpreted as other-type high-grade carcinoma on biopsies. d All cases expressed the androgen receptor (e) and two of three cases HER2/neu (f)

(10)

permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this licence, visit http://creat iveco mmons .org/licen ses/by/4.0/.

References

1. Bishop JA. Newly Described Tumor Entities in Sinonasal Tract Pathology. Head Neck Pathol. 2016;10:23–31.

2. Thompson LDR, Franchi A. New tumor entities in the 4th edition of the World Health Organization classification of head and neck tumors: Nasal cavity, paranasal sinuses and skull base. Virchows Arch. 2018;472:315–30.

3. Stelow EB, Mills SE, Jo VY, Carlson DL. Adenocarcinoma of the upper aerodigestive tract. Adv Anat Pathol. 2010;17:262–9.

4. Leivo I. Sinonasal Adenocarcinoma: Update on Classification, Immunophenotype and Molecular Features. Head Neck Pathol.

2016;10:68–74.

5. Stelow EB, Jo VY, Mills SE, Carlson DL. A histologic and immunohistochemical study describing the diversity of tumors classified as sinonasal high-grade nonintestinal adenocarcinomas. Am J Surg Pathol. 2011;35:971–80.

6. Manning JT, Batsakis JG. Salivary-type neoplasms of the sinonasal tract. Ann Otol Rhinol Laryngol. 1991;100:691–4.

7. Higo R, Takahashi T, Nakata H, Harada H, Sugasawa M. Sali- vary duct carcinoma in the sinonasal tract. Eur Arch Otorhi- nolaryngol. 2007;264:561–3.

8. Müller S, Mantsopoulos K, Iro H, Agaimy A. Salivary duct carcinoma of the sinonasal cavity: A case report and review of the literature. Head Neck. 2016;38:E2464–6.

9. Vallabh N, Srinivasan V, Hughes D. Agbamu D (2017) Salivary duct carcinoma arising from the inferior turbinate. J Surg Case Rep. 2017;7:rjx090.

10. Chiosea SI, Thompson LD, Weinreb I, Bauman JE, Mahaffey AM, Miller C, Ferris RL, Gooding WE. Subsets of salivary duct carcinoma defined by morphologic evidence of pleomorphic adenoma, PLAG1 or HMGA2 rearrangements, and common genetic alterations. Cancer. 2016;122:3136–44.

11. Bishop JA, Gagan J, Baumhoer D, et al. Sclerosing polycystic

‘adenosis’ of salivary glands: a neoplasm characterized by PI3K pathway alterations more correctly named sclerosing polycystic adenoma. Head Neck Pathol. 2020;14:630–6.

12. Jo VY, Mills SE, Cathro HP, Carlson DL, Stelow EB. Low- grade sinonasal adenocarcinomas: the association with and distinction from respiratory epithelial adenomatoid hamartomas and other glandular lesions. Am J Surg Pathol. 2009;33:401–8.

13. Purgina B, Bastaki JM, Duvvuri U, Seethala RR. A subset of sinonasal non-intestinal type adenocarcinomas are truly seromucinous adenocarcinomas: a morphologic and immunopheno- typic assessment and description of a novel pitfall. Head Neck Pathol. 2015;9:436–46.

14. Xu B, Aryeequaye R, Wang L, Katabi N. Sinonasal Secretory Carcinoma of Salivary Gland with High Grade Transformation:

A Case Report of this Under-Recognized Diagnostic Entity with Prognostic and Therapeutic Implications. Head Neck Pathol.

2018;12:274–8.

15. Baneckova M, Agaimy A, Andreasen S, Vanecek T, Steiner P, Slouka D, Svoboda T, Miesbauerova M, Michal M Jr, Skálová A. Mammary Analog Secretory Carcinoma of the Nasal Cavity:

Characterization of 2 Cases and Their Distinction From Other Low-grade Sinonasal Adenocarcinomas. Am J Surg Pathol.

2018;42:735–43.

16. Andreasen S, Skálová A, Agaimy A, Bishop JA, Laco J, Leivo I, Franchi A, Larsen SR, Erentaite D, Ulhøi BP, von Buchwald C,

Melchior LC, Michal M, Kiss K. ETV6 Gene Rearrangements Characterize a Morphologically Distinct Subset of Sinonasal Low-grade Non-intestinal-type Adenocarcinoma: A Novel Translocation-associated Carcinoma Restricted to the Sinonasal Tract. Am J Surg Pathol. 2017;41:1552–60.

17. Soon GST, Chang KTE, Kuick CH, Petersson F. A case of nasal low-grade non-intestinal-type adenocarcinoma with aberrant CDX2 expression and a novel SYN2-PPARG gene fusion in a 13-year-old girl. Virchows Arch. 2019;474:619–23.

18. Agaimy A, Hartmann A, Antonescu CR, Chiosea SI, El-Mofty SK, Geddert H, Iro H, Lewis JS Jr, Märkl B, Mills SE, Riener MO, Robertson T, Sandison A, Semrau S, Simpson RH, Stelow E, Westra WH, Bishop JA. SMARCB1 (INI-1)-deficient Sinona- sal Carcinoma: A Series of 39 Cases Expanding the Morpho- logic and Clinicopathologic Spectrum of a Recently Described Entity. Am J Surg Pathol. 2017;41:458–71.

19. Shah AA, Jain D, Ababneh E, Agaimy A, Hoschar AP, Grif- fith CC, Magliocca KR, Wenig BM, Rooper LM, Bishop JA.

SMARCB1 (INI-1)-deficient adenocarcinoma of the sinonasal tract: a potentially under-recognized form of sinonasal adenocarcinoma with occasional yolk sac tumor-like features. Head Neck Pathol. 2020;14:465–72.

20. Nagao T, Licitra L, Loening T, Vielh P, Willimas MD, et al.

Salivary duct carcinoma. In: El-Naggar AK, Chan JKC, Grandis JR, et al., editors. In: WHO Classification of Head and Neck Tumours. 4th ed. Lyon: IARC Press; 2017. p. 173–4.

21. Jaehne M, Roeser K, Jaekel T, Schepers JD, Albert N, Löning T. Clinical and immunohistologic typing of salivary duct carcinoma: a report of 50 cases. Cancer. 2005;103:2526–33.

22. van Heerden WF, Raubenheimer EJ, Swart TJ, Boy SC. Intraoral salivary duct carcinoma: a report of 5 cases. J Oral Maxillofac Surg. 2003;61:126–31.

23. Noda K, Hirano T, Okamoto T, Suzuki M. Primary salivary duct carcinoma arising from the Stensen duct. Ear Nose Throat J. 2016;95:E15–7.

24. Rahimi S, Lambiase A, Brennan PA, Abdolrahimzadeh S. An Androgen Receptor-positive Carcinoma of the Lacrimal Drain- age System Resembling Salivary Duct Carcinoma: Case Report and Review of the Literature. Appl Immunohistochem Mol Morphol. 2016;24:e69-71.

25. Hsu CC, Li WY, Chu PY. Salivary duct carcinoma of the supra- glottis with a distinct presentation: A case report and literature review. Medicine (Baltimore). 2018;97:e0095.

26. Goel MM, Agrawal SP, Srivastava AN. Salivary duct carcinoma of the larynx: report of a rare case. Ear Nose Throat J.

2003;82:371–3.

27. Jeong HS, Son YI, Ko YH, Kim SY. Sarcomatoid salivary duct carcinoma of the larynx. J Laryngol Otol. 2006;120:154–7.

28. Udager AM, Chiosea SI. Salivary Duct Carcinoma: An Update on Morphologic Mimics and Diagnostic Use of Andro- gen Receptor Immunohistochemistry. Head Neck Pathol.

2017;11:288–94.

29. Williams L, Thompson LD, Seethala RR, Weinreb I, Assaad AM, Tuluc M, Ud Din N, Purgina B, Lai C, Griffith CC, Chio- sea SI. Salivary duct carcinoma: the predominance of apocrine morphology, prevalence of histologic variants, and androgen receptor expression. Am J Surg Pathol. 2015;39:705–13.

30. Kleinsasser O, Klein HJ, Hübner G. Speichelgangcarcionom:

Ein dem Milchgangscarcinom der Brustdrüse analoge Gruppe von Speicheldrüsentumoren. Arch Klin Exp Ohren Nasen Kehlkopfheilkd. 1968;192:100–5.

31. Simpson RH. Salivary duct carcinoma new developments morphological variants including pure in situ high grade lesions; proposed molecular classification. Head Neck Pathol.

2013;7(1):S48-58.

(11)

32. Di Palma S, Simpson RH, Marchiò C, Skálová A, Ungari M, Sandison A, Whitaker S, Parry S, Reis-Filho JS. Salivary duct carcinomas can be classified into luminal androgen receptor- positive, HER2 and basal-like phenotypes. Histopathology.

2012;61:629–43.

33. Li W, Lu H, Zhang H, Lai Y, Zhang J, Ni Y, Wang D. Sinonasal/

nasopharyngeal pleomorphic adenoma and carcinoma ex pleomorphic adenoma: a report of 17 surgical cases combined with a literature review. Cancer Manag Res. 2019;11:5545–55.

34. López F, Devaney KO, Hanna EY, Rinaldo A, Ferlito A.

Metastases to nasal cavity and paranasal sinuses. Head Neck.

2016;38:1847–54.

35. Barbosa EB, Ferreira ECMF, Mariano FV, Altemani AMAM, Sakuma ETI, Sakano E. Metastasis to Paranasal Sinuses from

Carcinoma of Prostate: Report of a Case and Review of the Literature. Case Rep Otolaryngol. 2018;2018:5428975.

36. Gurel B, Ali TZ, Montgomery EA, Begum S, Hicks J, Goggins M, Eberhart CG, Clark DP, Bieberich CJ, Epstein JI, De Marzo AM.

NKX3.1 as a marker of prostatic origin in metastatic tumors. Am J Surg Pathol. 2010;34:1097–105.
