(2)

Electrically controlled surface plasmon resonance frequency of gold nanorods

K. C. Chu,^a^兲C. Y. Chao, and Y. F. Chen

Department of Physics, National Taiwan University, Taipei 106, Taiwan, Republic of China Y. C. Wu and C. C. Chen

Department of Chemistry, National Taiwan Normal University, Taipei 116, Taiwan, Republic of China 共Received 20 January 2006; accepted 25 June 2006; published online 6 September 2006兲

We have presented the voltage-controlled tuning of plasmonic response of absorption spectra of gold nanorods in liquid crystals. We observe that gold nanorods can be aligned along the rubbed polyimide substrate before applying external voltage. It is found that the transverse mode of gold nanorods shows a blueshift or a redshift when rotating the analyzer parallel or perpendicular to the rubbing direction, respectively, while all longitudinal modes display a redshift behavior. This work offers an easy way to tune the transverse and longitudinal modes of gold nanorods simultaneously, which makes it feasible to establish the color tunable devices. © 2006 American Institute of Physics.

关DOI:10.1063/1.2335812兴

The effect of surface plasmon resonance共SPR兲 at inter- faces has been the focus of intense research due to its spe- cific optical properties and wide applications.^1,2 The field called plasmonics is of interest in small particles, wires, rods, and thin films, where the major appearance generated by optical excitations is the collective coherent oscillation of electrons locally along the interface.³Therefore, the absorption peak wavelength caused by the SPR is dependent on the size and the shape of the metallic nanocrystals. Besides, the dielectric environment surrounding the metallic nanostruc- tures plays another important role to affect the absorption peak of SPR, varying the effective dielectric medium surrounding the nanocrystals would shift the SPR modes.^4,5

Liquid crystals 共LCs兲 are an outstanding material with easily controllable optical properties via external parameters such as electric field or temperature.^6,7 Some works have shown the electrically controlled tuning of plasmonic response of a single gold nanoparticle⁸and gold nanoparticle arrays⁹ by altering the effective dielectric constant environment of LCs.

Gold nanorods possess peculiarly drastic absorption spectra of both transverse and longitudinal plasmon resonances.^2,3,10–13However, the effect of SPR of gold nanorods by LCs is not under study until now. In this letter, we report the demonstration to incorporate gold nanorods with LCs for observing the changes of the transverse and longitudinal absorption peak wavelengths by adjusting the external voltage to reorient the LCs.

A schematic of the side-view structure of the LC cell with and without external voltage is shown in Fig. 1. To achieve the purpose of voltage-controlled absorption spectra, LC cells are fabricated, consisting of two counter indium tin oxide 共ITO兲-coated glass substrates with a PI alignment layer. First, we drop the suspension solution of gold nanorods onto the rubbed PI layer until gold nanorods are dried to settle down in the clearing room. After the combination of top and bottom treated substrates in the same rubbing direction, the nematic LC E7 from Merk is injected into the as- sembled substrates at the isotropic temperature of the LCs.

The average thickness of the cell gap is about 9␮^{m. An} alternating electric voltage at 1 kHz frequency is applied across the sample共z axis兲 to avoid the induced separation of charged impurities. A 100 W Xe lamp is focused onto the cell with a condenser, where the illumination light is unpo- larized to excite all plasmonic response direction simultaneously. An analyzer in front of the entrance slit of the spec- trometer is used to distinguish the direction of the dipole oscillation for advanced analyses. All experiments are per- formed at room temperature.

Figure 2共a兲 shows the UV-visible absorption spectra of gold nanorod solution used in this work. The detailed de- scription of the synthesized approach can be found elsewhere.^14,15 The inset in Fig. 2共a兲 shows the absorption spectrum results of different gold nanorod doses dried on PI substrate 共2, 4, and 12 drops兲. According to the result, the
