A cascade energy band structure enhances the carrier energy
in organic vertical-type triodes
Shiau-Shin Cheng
a, Mohan Ramesh
b,c, Guan-Yuan Chen
a, Chun-Lin Fung
a, Li-Ming Chen
a,
Meng-Chyi Wu
a, Hong-Cheu Lin
b, Chih-Wei Chu
c,d,⇑ aDepartment of Electrical Engineering, National Tsing-Hua University, Hsinchu 30013, Taiwan, ROC
bDepartment of Materials Science and Engineering, National Chiao Tung University, Hsinchu 30010, Taiwan, ROC cResearch Center for Applied Sciences, Academia Sinica, Taipei 11529, Taiwan, ROC
d
Department of Photonics, National Chiao-Tung University, Hsinchu 30010, Taiwan, ROC
a r t i c l e
i n f o
Article history: Received 4 April 2013
Received in revised form 8 May 2013 Accepted 11 May 2013
Available online 4 June 2013 Keywords: Organic semiconductor Vertical-type transistor Cascade-type Transport factor Current gain Current mirror
a b s t r a c t
Organic vertical-type triodes (OVTs) based on the cascade energy band structure as emitter layer are studied. The electric characteristics were dramatically enhanced while incorpo-rating the cascade energy under current driving and voltage driving modes. The improve-ment is attributed to that injection carriers can obtain higher energy through a stepwise energy level. When the device has a layered structure of F16CuPC (10 nm)/PTCDI
(10 nm)/pentacene (100 nm) in emitter, it exhibits a common-base transport factor of 0.99 and a common-emitter current gain of 225 under current driving mode and exhibits a high current modulation-exceeding 520lA for a low collector voltage of 5 V and a base voltage of 5 V and the current on/off ratio of 103under voltage driving mode.
Fur-thermore, we realized first organic current mirror that exhibited out/in current ratio of 0.75 and output resistance of 105Xby using the OVTs.
Ó 2013 Published by Elsevier B.V.
1. Introduction
The study of organic thin film transistors (OTFTs) has attracted much interest for their potential use in high-va-lue, low-cost electronics, such as displays, sensors, radio frequency identifications, and e-papers[1–4]. Recently, or-ganic semiconductors with mobilities comparable with that of amorphous silicon have been realized[5–8]; never-theless, OTFTs possessing the typical metal–oxide–semi-conductor field effect transistor structure exhibit low output currents and low frequencies of operation because of their high resistivities and low carrier mobilities, which restrict their practical applications. Although shortening the channel length can further improve the device
perfor-mance, this approach requires that state-of-art litho-graphic techniques, which are not practical for fabricating low-cost flexible electronics, be performed prior to organic semiconductor growth; in addition, the contact resistance between the source/drain electrodes and the organic semi-conductor will dominate the device performance[9,10]. To realize the incorporation of OTFTs in most proposed appli-cations, it will be necessary to improve not only the electri-cal properties of the organic materials but also the device structures. Organic vertical-type transistors are a promis-ing technological option for improvpromis-ing device performance
[11–16]because their channel lengths can be controlled
precisely by varying the thickness of the active layer. In the early days of inorganic semiconductor develop-ment, bipolar-junction transistors (BJTs)—the most impor-tant inorganic vertical-type transistors—were formed using n–p–n or p–n–p double homojunctions[17]. Due to their larger minority-carrier diffusion and base resistance, the operation speeds of BJTs are limited by the transition 1566-1199/$ - see front matter Ó 2013 Published by Elsevier B.V.
http://dx.doi.org/10.1016/j.orgel.2013.05.018
⇑ Corresponding author at: Department of Photonics, National Chiao-Tung University, Hsinchu 30010, Taiwan (ROC). Tel.: +886 2 27898000x70; fax: +886 2 27826680.
E-mail address:[email protected](C.-W. Chu).
Contents lists available atSciVerse ScienceDirect
Organic Electronics
time[18]. To overcome this obstacle, unipolar hot-carrier transistors (HCTs) were developed, featuring a thin metal-lic base sandwiched between two semiconductors to serve as an emitter and a collector. If the depletion region at the metal–semiconductor junction of a Schottky diode is thin-ner than the junction capacitance of a pn diode, it results the lower resistance. To further improve their perfor-mance, cascade energy band structures, formed by the dif-ferent element concentration ratios, have been incorporated in HCTs. Such structures enhance the carrier energy in emitter–base (EB) diodes; therefore, the carriers can be inhibited from contributing to the recombination current at the base electrode and effectively approach the collector electrode to increase the output current. To con-trol the element concentration ratio accurately, the devices must be grown using expensive fabrication processes (e.g., molecular beam epitaxy, metal organic chemical vapor deposition). In addition, the carrier transport mechanism in such devices is based on band-type conduction and the carriers are affected by the acoustic phonons. There-fore, it is difficult to operate these devices at room temperature [19,20]. In contrast, organic thin films can be fabricated using simple processing techniques. In their corresponding devices, carrier transport occurs through tunneling between the localized states caused by defects and/or disorder states, with a conduction theory associated with phonon-activated hopping. Therefore, organic vertical transistors are readily operated at room-temperature and can be applied in low cost, flexible electronics[21,15,22]. Due to lower carrier mobility of the materials and the shorter mean free path in the base layer, the most of the carriers are recombined at the base electrode. Which lead to a lower common-emitter current gain and lack the apparent saturation region. Several approaches have been developed to improve these drawbacks (e.g.,) by inserting a hole injection enhancement layer (LiF or Al2O3) at the
emitter–base junction or using a metal-grid base electrode
[23–25]. When inserting a hole injection layer the
tunnel-ing barrier are formed, as a result of the emitter current being dominated by the tunneling current, with exhibiting a saturation region and enhanced current gain.
In this paper, we describe organic vertical triodes (OVTs) incorporating a cascade-type energy band structure that operate at pronounced saturation with high gain. The most injection carriers can obtain higher energy through a stepwise energy level, more carriers can surmount the thin metal base electrode and diffuse into the collector layer. Therefore, this device exhibits a larger transport factor and a current gain when operated in the current-driving mode. On the other hand, the device displays a larger cur-rent on/off ratio and a smaller offset voltage when oper-ated in the voltage-driving mode. The device exhibits a sufficiently large current gain; a current mirror operated at a greater out/in current ratio (Iout/Iin) and a greater
out-put resistance (ro) is achieved by integrating two p-channel
OVTs with a load resistor. 2. Experimental
Prior to deposition, the glass substrates were cleaned sequentially with detergent, acetone, and isopropyl alcohol
followed by treating in an ultraviolet (UV) ozone cleaner for 15 min. The gold (Au) (30 nm) layer was deposited on the glass substrate to serve as a collector electrode. The copper phthalocyanine (CuPC) (50 nm) layer (Lumines-cence Technology) was thermally deposited on the Au layer to smooth the surface morphology and then the pentacene (270 nm) layer (Luminescence Technology), serving as the collector of the p-channel triode, was ther-mally evaporated. The aluminum (Al) (10 nm) strip was thermally evaporated onto the pentacene layer to function as the base electrode. Next, a thin Al film (15 nm), operat-ing as the base electrode, was deposited on the strip. To study the effects of the materials with different highest occupied molecular orbital (HOMO) energy levels on the device performance, different organic semiconductor lay-ers were thermally evaporated onto the thin Al film as shown inTable 1. Finally, films of molybdenum(VI) oxide (MoO3) (30 nm) and Al (30 nm) were deposited onto the
emitter layers of the five OVTs mentioned above to func-tion as emitter electrodes. This process was performed with patterning through a metal mask. All organic materi-als and metal electrodes were deposited in a thermal evap-oration chamber at a base pressure of 10–6torr. The active area of the device (0.04 cm2) was defined by the
intersec-tion of the emitter and collector electrodes. The current– voltage (I–V) characteristics of the devices were measured using a Keithley 4200 semiconductor parameter analyzer. All of the electrical characteristics of these devices were measured in dark environments.
3. Results and discussion
Fig. 1a and b presents the device configuration and the
energy diagram of the emitter–base diodes, respectively
[26–29]. The device, fabricated from two Schottky diodes,
comprises a collector–base diode as the bottom diode and an emitter–base diode as the top diode. To form the Scho-ttky diode, the active layer was sandwiched between Au and Al. To reduce the leakage current and the energy barrier between the metal and the organics, a CuPC film was used as the buffer layer in the collector–base diodes and MoO3was
inserted as the carrier injection layer in the emitter–base diodes [30–33]. Several organic semiconductors–penta-cene, N,N0-bis(naphth-1-yl)-N,N0
-bis(phenyl)-benzi-dine(NPB), N,N8-dioctyl-3,4,9,10-perylene tetracarboxylic diimide(PTCDI), and copper(II) 1,2,3,4,8,9,10,11,15,16, 17,18,22,23,24,25-hexadecafluoro-29H,31H-phthalocya-nine (F16CuPC)—with different energy levels were
employed to form the cascade-type structure in the emit-ter–base diodes. To investigate the influence of the cas-cade-type energy structure in the emitter–base diodes, we fabricated five different devices by incorporating the vari-ous materials in the emitter–base diodes as shown in
Ta-ble 1. All five different devices configuration were
fabricated and characterized with same material in the col-lector–base diodes ((Au (30 nm)/CuPC (50 nm)/pentacene (270 nm)/Al (30 nm)/thin Al layer (10 nm)).Fig. 2a and c displays the common-base (CB) electrical characteristics of devices A and E, respectively;Fig. 2b and d present the common-emitter (CE) electrical characteristics of devices
Table 1
Parameters of the OVTs featuring various active layers in the EB diodes.
Device Layer 1 Layer 2 Layer 3 aa
bb Offset voltage
A Pentacene (100 nm) 0.0025 0.0056 1.7 V
B Pentacene (100 nm) NPB (20 nm) 0.45 0.74 1.7 V
C Pentacene (100 nm) PTCDI (20 nm) 0.85 3.69 1.4 V
D Pentacene (100 nm) F16CuPC (20 nm) 0.77 1.24 1.5 V
E Pentacene (100 nm) PTCDI (10 nm) F16CuPC (10 nm) 0.99 20.83 0.8 V
a
Operated under the CB mode at values of VCBand IEBof 5 V and 100lA, respectively. b
Operated under the CE mode at values of VCEand IBEof 7 V and 100lA, respectively.
Fig. 1. (a) Schematic representation of the OVT configuration featuring a stepwise increase in the energy level, between the emitter electrode and base electrode, in the EB diode. (b) Energy level diagram of the organic semiconductors and metal in the EB diodes.
0 -20 -40 -60 -80 -100 -120
(c)
IEB = 0 A IEB = 20 µA IEB = 40 µA IEB = 60 µA IEB = 80 µA IEB = 100 µA ICB ( µ A) VCB (V) 0 -400 -800 -1200 -1600 -2000 ICE ( µ A)(d)
I BE = 0 A I BE = - 20 µA I BE = - 40 µA I BE = - 60 µA IBE = - 80 µA IBE = - 100 µA VCE (V) 0 -1 -2 -3 -4 -5 -6 -7 0.0 -0.1 -0.2 -0.3 -0.4 -0.5 -0.6 ICE ( µ A)(b)
I BE = 0 ~ - 40 µA IBE = - 60 µA IBE = - 80 µA IBE = - 100 µA VCE (V) 3 2 1 0 -1 -2 -3 -4 -5 0 -1 -2 -3 -4 -5 -6 -7 3 2 1 0 -1 -2 -3 -4 -5 0.1 0.0 -0.1 -0.2 -0.3(a)
IEB = 0 ~ 40 µA IEB = 60 µA IEB = 80 µA I EB = 100 µA ICB ( µ A) VCB (V)Fig. 2. (a and c) CB electrical characteristics of devices (a) A and (c) E for values of IEBranging from 0 to 100lA with a step of 20lA. (b and d) CE electrical characteristics of devices (b) A and (d) E for values of IBEranging from 0 to 100lA with a step of 20lA. The CB mode featured the base electrode grounded and the input current applied from the emitter electrode; the CE mode featured the emitter electrode grounded and the input current applied from the base electrode.
A and E, respectively. Both devices A and E could be oper-ated with a pronounced saturation mode at low operating voltages. When devices A and E were operated under the CB mode at a collector-to-base current (ICB) of 100
l
A anda collector-to-base voltage (VCB) of 5 V, the value of ICBof
device E (99
l
A) was larger than that (0.25l
A) of device A; on the other hand, when devices A and E were operated under the CE mode at a base-to-emitter current (IBE) of100
l
A and a collector-to-emitter voltage (VCE) of –7 V,the collector-to-emitter current (ICE) of device E
(2083
l
A) was larger than that (0.56l
A) of device A. The output current of device E was several orders of magni-tude greater than that of device A in both the CB and CE modes. Presumably, the cascade energy structure of device E can create the higher energy carrier compare to device A. And it would also be easier to accelerate the carriers to achieve the ballistic velocity in the collector–base diode when it was operated under a low electrical field. In CB mode, the VCBof device E was greater than 1 V, a positivecollector current can be observed; which indicates that the carriers were ballistically transported into the collector and their velocity was almost constant, because the output current was independent of the applied electrical field. When the VCBwas less than 1 V would lead to the negative
collector current. Which means that the carriers could not ballistically transported into the collector part, because the emitter current bend the energy band of the active layer in the collector–base diode. Therefore, the output current was proportional to the applied electrical field, when char-acteristics of the device were observed under the linear re-gion (active rere-gion). The output current of the cascade energy structure operated under the saturation region at lower values of VCB. In addition, carriers of higher energy
could be transported into the collector layer efficiently to enhance the CB transport factor (
a
) and the CE current gain (b), which determine the device performance. The values ofa
and b, are given by the following the equations[17]:a
¼ICB ICBðIEB¼ 0AÞIEB ð1Þ
b¼ICE ICEðIBE¼ 0AÞ
IBE
ð2Þ
Using Eqs.(1) and (2), the values of
a
for devices A and E were 0.0025 and 0.99, respectively, at a value of VCB of5 V and a value of IEB of 100
l
A; the values of b were0.0056 and 20.83, respectively, at a value of VCE of 7 V
and a value of IBEof 100
l
A. Thus, the OVT incorporatingthe cascade energy structure exhibited significant enhancements in its values of both
a
and b.Table 1 sum-marizes the values ofa
and b of the OVTs incorporating the various emitter–base diodes.The difference between the energy level of HOMO (F
16-CuPC) and the work-function of the Al layer (2 eV) in de-vice E, fewer holes become part of the recombination current at the base layer and most could pass through the base layer. Therefore, the CB transport factor
a
was close to unity and a larger CE current gain b was obtained. A larger carrier energy cannot only reduce carrier recombi-nation at the base electrode but also increase the hoppingrate. The probability of carriers hopping from the initial state to the next state is provided by the equation[34]
c
ij¼c
0f ðEiÞ exp Ei Ej kT exp 2Rij a ð3Þwhere f(Ei) is the Fermi function of the initial state,
c
0is aconstant related to the carrier–phonon coupling term, k is the Boltzmann constant, and T is the temperature; Eiand Ej
are the energies of the initial state and the next state respectively and Rijis the distance between them. In
organ-ic electronorgan-ics, charge transfer across at the metal–organorgan-ic semiconductor heterojunction. The redistribution of elec-tron cloud and the interfacial chemical reactions result in an interface dipole forming immediately by increasing the barrier height between the metal and organic semicon-ductor[35,36]. Therefore, previous studies have found that the Schottky energy barrier exhibits the resultant energy barrier at the metal–organic semiconductor heterojunc-tion, when the barrier height is greater than 0.4 eV
[37,38]. In contrast, when an organic semiconductor is
deposited on the organic thin film, the dipole forces would be weaker—or even negligible, because the organic semi-conductor–organic semiconductor junction would feature weak intermolecular van der Waals forces[39,40]. There-fore, the energy level would be aligned with a flat energy at the interface junction and the carriers could be activated thermally by the electrical field to pass through the barrier into the next organic semiconductor layer. According to Eq.
(3), a larger difference in energy between the initial state and the next state would lead to a higher hopping rate; nevertheless, a larger barrier between the two states would block the carrier transport. In device D, the energy barrier between pentacene and F16CuPC is 1.2 eV and
accordingly, the performance of this device was poorer than that of device C. Therefore, to further enhance the hole energy, we increased the HOMO energy levels of the materials in device E in a stepwise manner, resulting in this device exhibiting the highest performance. Presumably, the performance could be further improved by selecting a new material with a larger HOMO energy level to replace the F16CuPC layer or through its insertion in the F16CuPC/
Al heterojunction.
Fig. 3presents the values of
a
and b of device E as afunction of the input current. The value of
a
varied from as low as 0.6 at an input current of 0.2l
A to as high asFig. 3. Transport factor (a,d, left axis) and current gain (b, h, right axis) of device E, plotted as a function of the input current.
0.99 at an input current of 100
l
A. The value of b also var-ied upon changing the input current by reaching a maxi-mum value of 225 at an input current of 2l
A. When the device was operated at lower input currents, the induced input voltage was too low to turn on the emitter–base diode of the OVT and lower values ofa
and b were ob-tained. Increasing the input current would increase the in-duced input voltage, causing the emitter–base diode to be turned on. If the value of b too large an input current would cause space-charge effects in the emitter and collector, resulting in increased series resistance in these devices[41]. In our case, b reached its maximum value at an input current of 2
l
A. To the best of our knowledge, this value of bis the highest ever reported for an organic vertical-type transistor[42,43].The OVTs employ operation procedures similar to those of both BJTs and planar-type OTFTs.Fig. 4a and b presents the output characteristics of devices A and E, respectively. Between them, device E exhibited a lower offset and a much higher output current. The value of ICE of the OVT
reached as high as 521
l
A with an offset voltage of 0.8 V when the base-to-emitter voltage (VBE) and VCEwere both applied at 5 V. The current on/off ratio, defined as ICE(VBE= –5 V)/ICE(VBE= 0 V), was approximately 103at
a value of VCEof 5 V. Because the value of ICEis the sum of
the output currents of the emitter–base and collector–base diodes, when the collector–base diode was operated at a low value of |VCE| under a forward bias, the leakage current
observed was mainly attributed to the emitter–base diode. The positive current was proportional to VBEat low values
of VCE. Upon increasing the value of VCE, the value of ICE
transformed from a positive current into a negative cur-rent. The offset voltage is defined as the value of VCE at
which ICEis equal to zero. At low values of VCE, the leakage
current was 3.16 nA and the offset voltage was 0.8 V. Decreasing the leakage current, which can be performed by increasing the value of
a
, would lead to a lowering of the offset voltage.Table 1lists the offset voltages of de-vices featuring different active layers in the emitter–base diode.Although the electrical applications of OVTs operated under the voltage-driving mode in integrated circuits have
been realized[44], to the best of our knowledge, no aca-demic or industrial research has been performed regarding the electrical applications of OVTs operated in the current-driving mode. A current mirror is an elemental cell in ana-log circuits, because it possesses lower input resistance and larger output resistance. Current mirrors have been fabricated using two or more transistors operated in the current-driving mode; they are designed to copy the rent through one elemental cell by applying the input cur-rent into another elemental cell[45]. Therefore, the factors affecting the Iout/Iinratio and the value of ro(output
resis-tance) play important roles in determining the perfor-mance of the current mirror. Having realized an OVT exhibiting a large value of b, we fabricated a current mirror by connecting the two OVTs with the base electrode in ser-ies and a resistor across the base and collector electrodes of a single OVT.Fig. 5a presents a schematic representation of the load-resistor current mirror incorporating the organic vertical-type triode;Fig. 5b displays Ioutplotted with
re-spect to Iinfor devices with the various resistors at an
out-put voltage (Vout) of 3 V. The resistor could support the
bias voltage across the collector and base layer to drive the collector–base diode of the OVT. The larger resistor would drop the value of Vin in collector–base diode and
the emitter–base diode could not be turned on; in addition, the smaller resistor would not drive the collector–base diode. Therefore, the largest Iout/Iin ratio, obtained when
both OVTs were connected to a 100-X resistor, was approximately 0.75 and ro(defined as Vout/Ioutat a value
of Iin of 0 A) was approximately 105. The input current
can be defined using the equation
Iin¼ ICBþ bIBE ð4Þ when the current mirror is applied for input current, the OVT Q1 would induce the base voltage. Because the base electrode of OVT Q1 was connected to the base electrode of OVT Q2, the base voltage of Q2 was the same as that of Q1 and the output current was equal to the base current of Q2 multiplied by b. In the ideal case, the larger value of b and the smaller off current would result in an output cur-rent similar to the input curcur-rent. We found that the OVT exhibited an off current that caused the output current to
0 -100 -200 -300 -400 -500 V BE = 0 to -5 V Step -0.5 V
(b)
ICE ( µ A) V CE (V) 0 -1 -2 -3 -4 -5 0 -1 -2 -3 -4 -5 0.00 -0.01 -0.02 -0.03 V B= 0 to -5 V Step -0.5 V(a)
ICE ( µ A) V CE (V)Fig. 4. Plots of ICEversus VCEfor devices (a) A and (b) E for values of VBEranging from 0 to 5 V at a step of 0.5 V. The offset voltage (0.8 V) for device E was less than that (1.7 V) for device A.
be different from the input current. Therefore, the Iout/Iin
ratio and the value of rocould be further improved by
low-ering the off current and/or increasing the value of b of the device.
4. Conclusion
In conclusion, we have realized a significant improve-ment in the electrical characteristics of OVTs by employing an appropriate cascade-type energy structure. Relatively high output currents and operation at low voltage were possible in both the current-driving and voltage-driving modes of the OVTs. We suspect that these properties might be improved further by optimizing the thickness of the or-ganic layer or by choosing appropriate oror-ganic materials. Such high performance should increase the applicability of organic transistors.
Acknowledgments
We thank the National Science Council (NSC) of Taiwan (99-2221-E-001-012 and 99-2221-E-007-044-MY2) and Academia Sinica for financial support.
