A BEAM-FORMING TECHNIQUE FOR

LEAKY-WAVE ANTENNAS

I-Yu Chen,1Chien-Jen Wang,1Shih-Jeng Liu,1and Christina F. Jou1

1_{Institute of Communication Engineering}

National Chiao-Tung University Hsinchu, Taiwan, R.O.C. Recei¨ed 18 July 2000

ABSTRACT: A beam-forming technique for leaky-wa¨e antennas (LWAs which can switch electronically in three different radiation) patterns is de¨eloped in this letter. A simple two-terminal feeding mi-crostrip-line LWA works as a radiating element. By¨arying the phase of the two injection signals from 0 to 180T, the emitting power from the LWA can produce three different radiation modes: the normal mode (one sharp beam , the difference mode) ( )⌬ , and the sum mode ⌺ . The( ) antenna displays large-bandwidth characteristics, and can be useful near crossroads for collision a¨oidance or in the radio location of¨ehicles. 䊚 2001 John Wiley & Sons, Inc. Microwave Opt Technol Lett 28: 108_{᎐110, 2001.}

Key words: leaky-wa¨e antennas; switched-beam antennas; beam steering

I. INTRODUCTION

Ž .

Recently, leaky-wave antennas LWAs have become popular, and there is a growing interest in various types of leaky-wave

w x antennas used as frequency-scanning elements 1᎐2 . Leaky-wave antennas possess the advantages of low profile, fabri-cation simplicity, easy matching, narrow beamwidth, and frequency-scanning capability. As is known, the one-beam

w x w x

scanning LWA 1 and the dual-beam scanning LWA 2 have been studied intensively. However, the above-mentioned re-search cannot change the beam mode electronically, such as from a one-beam mode jumping into a dual-beam mode. Lin

w x

et al. 3 proposed a class of short LWAs with coaxial-to-mi-crostrip transitions on which the differential signals propa-gate. The sum and difference radiation patterns must be shown by using two different circuit structures, such as the end-fed and center-fed LWAs.

In this study, we present an alternative approach to achieve ⌬᎐⌺ radiation patterns using a simple two-terminal feeding

Ž .

microstrip-line leaky-wave antenna design see Fig. 1 . When a short LWA is excited in phase from the two-terminal feeds, a great amount of electromagnetic energy of the leaky mode will survive when it travels down to the other end of the antenna. The remaining power reflects and offsets against the other injection signal, creating the sum pattern. It is a broad-side pattern. When the LWA is excited out of phase, the reflected wave will be added into the other injection signal, creating the difference pattern. It is a dual-beam pattern. The advantage of this design is not only that the ⌬᎐⌺ patterns can be chosen electronically, not mechanically, but the antenna can also perform as a traditional beam mode by controlling the phase of the input signals.

II. ANTENNA DESIGN

The geometry and coordinate system for this leaky-wave antenna design are shown in Figure 2. Each slot radiates the

w x

same field as the magnetic dipole 4 , with the equivalent magnetic current density M_RSfor the right injection and M_LS for the left injection. The RTrDuroid substrate used has a

Figure 1 Simple two-feeding microstrip-line leaky-wave antenna

Figure 2 Geometry and coordinate system for the topology of this designed leaky-wave antenna

MICROWAVE AND OPTICAL TECHNOLOGY LETTERS / Vol. 28, No. 2, January 20 2001 108

thickness of 0.635 mm and a dielectric constant of ␧ s 2.2.r

To excite the first higher order mode within the operating range of frequency, this microstrip leaky-wave antenna is fed asymmetrically, and the width W and length L of the

radiat-Ž .

ing element are empirically chosen to be 0.61 cm 240 mil

Ž .

and 2.794 cm 1100 mil , respectively.

III. THEORETICAL AND EXPERIMENTAL RESULTS

The microstrip leaky-wave antenna is operated at 15.5 GHz. Figure 3 shows a comparison between the measured and theoretical H-plane patterns of a broadside sum pattern, as

Ž

the two feeds have in-phase current excitation the phase .

difference is 0⬚ with a maximum directivity of 8.3 dBi. Figure 4 shows the pattern of a difference pattern, as the two feeds

Figure 3 Measured and theoretical broadside sum pattern as the excited injection signals are in phase

Figure 4 Measured and theoretical dual-beam difference pattern as the excited injection signals are out of phase

Ž

have out-of-phase current excitation the phase difference is .

180⬚ with a maximum directivity of 8.5 dBi. Note that the main beam positions of the out-of-phase mode are at ␪ s "26⬚. Figure 5 shows a comparison between the measured and theoretical prediction of the traditional one-beam radia-tion pattern. The antenna radiates a pencil beam for a phase difference of 90⬚ between the two injection signals. It can be observed that reasonable agreement between the simulation and experimental results is obtained. The measured results prove that this beam-forming technique allows one to choose the sum pattern, the difference pattern, or the traditional one-beam radiation pattern electronically. The radiation pat-tern of this antenna design depends on the phase difference of the two injection signals, instead of different circuit struc-tures. Figure 6 shows a comparison of the measured and theoretical S-parameters of this designed antenna, and the results show that the bandwidth is at least 2 GHz.

IV. CONCLUSIONS

It is demonstrated that the sum, the difference, and the traditional one-beam radiation patterns can be chosen

elec-Figure 5 Measured and theoretical one-beam traditional pattern as the excited injection signals have a phase difference of 90⬚

Figure 6 Comparison of the measured and theoretical S-parame-ters of this designed antenna

tronically by using a simple two-terminal feeding leaky-wave antenna structure. This beam-forming technique for leaky-wave antennas exhibits the properties of flexible beam switch-ing and large bandwidth, and will be a suitable candidate for applications such as mobile communication and satellite com-munication.

REFERENCES

1. W. Menzel, A new traveling wave antenna, Proc 8th European Microwave Conf, 1978, pp. 302᎐306.

2. C.J. Wang, C.F. Jou, and J.J. Wu, A novel two-beam scanning

Ž .

leaky-wave antenna, IEEE Trans Antennas Propagat 47 1999 , 1314᎐1317.

3. J.M. Lin, C.K. Tzuang, G.J. Chou, and S. Su, Short leaky wave

Ž .

antenna of sum and difference patterns, Electron Lett 32 1996 , 1247᎐1249.

4. C.A. Balanis, Antenna theory analysis and design, Wiley, New York, 1997, 2nd ed.
