Magnetic effects on crystal growth rate of calcite in a constant-composition environment

(1)

Magnetic effects on crystal growth rate of calcite in a constant-composition

environment

Clifford Y. Tai

a,

, Meng-Chun Chang

a

, Rong-Jong Shieh

a

, Ted G. Chen

b a

Department of Chemical Engineering, National Taiwan University, Taipei, Taiwan

b_{Pro-Service Water Technologies Corp., Taipei, Taiwan}

a r t i c l e

i n f o

Article history:

Received 23 November 2007 Received in revised form 25 February 2008 Accepted 20 May 2008 Communicated by J. de Yoreo Available online 24 May 2008 PACS:

61.66.Fn 81.10.Dn

Keywords:

A1. Constant-composition A1. Magnetic effect A2. Crystal growth B1. Calcium carbonate

a b s t r a c t

The crystal growth rates of calcite in a constant-composition environment were measured in the presence of a magnetic ﬁeld. The magnetic effect to be inﬂuenced by any one of the solution variables, including pH, degree of relative supersaturation (s), ionic strength (I), Ca2+_{to CO}

3

2_{ionic activity ratio}

(R), and superﬁcial velocity (v), was investigated while keeping the other variables constant. The growth rate was suppressed completely in the presence of the magnetic ﬁeld under low pH and supersaturation conditions. By contrast, the growth rate seemed to increase at high pH and relative supersaturation. A more surprising result is that the magnetic suppression effect on CaCO3growth was observed except at

unity activity ratio. The information gathered in this experiment might be used as a reference for understanding the performance of the anti-scale magnetic treatment device.

1. Introduction

Cooling water accounts for a large proportion of industrial process water, exchanging energy with the process material stream in a heat exchanger. After a long period of circulation in a cooling system, some of the water will evaporate, increasing the Ca2+concentration. This causes sparingly soluble salts (CaCO3in

majority) precipitate on the wall of pipes or exchangers to form scale, due to the solubility change caused by temperature and acidity variations[1,2]. To lower the Ca2+_{concentration, generally}

a portion of the process water is discharged and replaced by fresh water. Hence, the use of an efﬁcacious water-saving measure will help solve the water shortage problem.

A number of scale prevention techniques have been adopted. Acid treatment, often called pH control, is a common technique in large plants. An adequate amount of acid is added to the makeup water to lower its pH, and most of the dissolved CO32and HCO3

ions are then transformed to gaseous CO2and removed. The chief

defect of this approach is that corrosion problem may result if too much acid is added [1]. Addition of certain chemical agents (usually polyelectrolytes or copolymers) of low concentration to process water is another scale-control technique [3,4]. This

technique has been widely practiced in recent years because of low cost and low rate of piping corrosion. The main disadvantage is the thermal instability of added chemicals and the contamina-tion problem from discharge. Ion exchange technology has also been reported as successful for scale prevention[1], but is not popular due to its high installation cost and regular regeneration requirement. In addition to chemical scale prevention techniques, physical methods have also been adopted. Mechanical cleaning is often carried out when pipes become plugged by scale, which is an expensive and time-consuming method. Electromagnetic and ultrasonic waves have also been used for scale removal, but the results have not been satisfactory[5,6].

Magnetic water treatment for scale prevention has been around for more than a century[1,7–9], and has been reported as being effective in many instances [10–12]. For example, Tye reported that magnetic treatment showed remarkable scale-prevention performance in systems with heated surfaces, such as heat exchangers[10]. Donaldson and Grimes monitored studies on the magnetic treatment in a wide range of systems, and pointed out that the magnetic treatment lessened the scale build-up signiﬁcantly[11]. Another example has been reported by Kobe et al.[12]that a magnetic device was constructed and installed in a pilot plant. They found that it reduced the weight gains of the pipeline due to scale deposition.

To explore the magnetic effect on scale prevention, several mechanisms have been proposed. Researchers have reported that Contents lists available atScienceDirect
