High output power density from GaN-based two-dimensional nanorod

light-emitting diode arrays

Ya-Ju Lee,1,a兲Shawn-Yu Lin,2,a兲 Ching-Hua Chiu,3Tien-Chang Lu,3Hao-Chung Kuo,3 Shing-Chung Wang,3Sameer Chhajed,4Jong Kyu Kim,4and E. Fred Schubert4

1

Institute of Electro-Optical Science and Technology, National Taiwan Normal University, 88, Sec. 4, Ting-Chou Road, Taipei 116, Taiwan

2

Department of Physics, Applied Physics and Astronomy, The Future Chips Constellation, Rensselaer Polytechnic Institute, Troy, New York 12180, USA

3

Department of Photonics, National Chiao Tung University, 1001 Ta Hsueh Road, Hsinchu 300, Taiwan

4

Department of Electrical, Computer, and Systems Engineering, The Future Chips Constellation, Rensselaer Polytechnic Institute, Troy, New York 12180, USA

共Received 24 February 2009; accepted 20 March 2009; published online 10 April 2009兲

Here we propose and realize a scheme for making a direct contact to a two-dimensional nanorod light-emitting diode 共LED兲 array using the oblique-angle deposition approach. And, more importantly, we demonstrate highly efficient electrical carrier injection into the nanorods. As a result, we show that at a 20 mA dc current injection, the light output power density of our nanorod LED array is 3700 mW cm−2. More general, this contact scheme will pave the ways for making direct contacts to other kinds of nanoscale optoelectronic devices. © 2009 American Institute of Physics. 关DOI:10.1063/1.3119192兴

The developments of advanced gallium nitride 共GaN兲-based 共light-emitting diode兲 LED structures are critical to a wide range of applications that include intelligent interior lighting and optical communication module in automobiles, backlighting units for liquid crystal displays, and general lighting.1,2For energy-saving reasons, a LED structure must be designed to yield high internal quantum efficiency and light extraction efficiency. For a GaN-based blue LED, the internal quantum efficiency is determined primarily by growth and the associated defect formation.3 On the other hand, the light extraction efficiency is limited by total inter-nal reflection at the interface of GaN and air.4 Recently, a GaN-based nanorod LED array with dislocation-free and large sidewall-surface-area characteristics was demonstrated.5The nanorod LED array showed an enhanced internal quantum efficiency and light extraction efficiency. However, the major challenge of making electrical contacts to nanorod LEDs having a typical diameter of 10–100 nan-ometer size has remained unsolved. The main difficulty of making such an electrical contact is related to depositing a continuous layer of electrode on top of nanorod LEDs with-out creating an electrical short between the p- and n-regions. Hence, most researches are constrained to use optical pump-ing to study the optical properties of nanorod LEDs.6–8 How-ever, for practical day-to-day use of LEDs, a feasible scheme for electrical pumping is essential. So far, a common ap-proach is to use polymers, such as spin-on glass 共SOG兲,5 SU-8,9 and polymethyl methacrylate,10 to isolate individual nanorod LEDs, especially in the n-contact and the quantum well region. Subsequently, a planar conductive layer is de-posited to form p-contacts to the p-type nanorods. This ap-proach has several drawbacks. First, since the typical thick-ness of the p-type nanorod region is only 100–200 nm due to the difficulty in achieving high carrier density in p-type GaN, it is demanding to control both the thickness and uniformity

of the polymer. Second, the filling of the polymer is often not complete when the rod-to-rod interval is smaller than 80–100 nm, thus creating an undesirable leakage electrical path. Fi-nally, an additional coating process of polymer will not only add fabrication cost but also reduce production yields in the LED industry. Therefore, a much improved method for mak-ing a direct electrical contact to the nanorods is necessary. Here we demonstrate a general strategy involving oblique-angle deposition growth that makes a direct and selective contact to the top surfaces of a two-dimensional共2D兲 nano-rod LED array. This method allows us to overcome the limi-tations of using a polymer as mentioned above.

The 2D nanorod LED array was fabricated by using self-assembled nickel共Ni兲 cluster as inductively coupled plasma dry etching hard mask. The fabrication detail for nanorod LED arrays is described elsewhere.11 Figure1共a兲presents a scanning electron microscopy共SEM兲 image of our 2D nano-rod LED array. The filling fraction共FF兲 of the nanorod array is 20%⫾4% and is determined by the spatial arrangement of

a兲_{Authors to whom correspondence should be addressed. Electronic}

ad-dresses: [email protected] and [email protected]. FIG. 1. A SEM image of randomly arranged 2D nanorod LED array.

APPLIED PHYSICS LETTERS 94, 141111共2009兲

(3)

the Ni cluster. Due to the self-assembly nature of the Ni cluster, our 2D nanorod array is randomly arranged. The diameter of an individual nanorod is 100–150 nm, which may be controlled by varying the Ni film thickness. The nanorod has an etch depth of 700 nm, which exposes the active layer to the air, and thus allows for an easier coupling of LED light emission into the air. The nanorod has a large height-to-diameter aspect ratio共Fig.1兲 and thus is ideal for achieving the so called “shadowing effect” by oblique-angle depositions.12 In this work, we recognize the selective growth aspect of the method and grow the slanted indium tin oxide 共ITO兲 to make contact to our 2D nanorod LED array. ITO is chosen because of its high electrical conductivity, low contact resistance with GaN, and high optical transparency. The slanted ITO was grown by oblique-angle deposition us-ing electron beam evaporation. The apparatus used in our oblique-angle deposition has a sample stage, on which the substrate is loaded, with controllable polar-angle rotation. For each layer, the sample stage is at a fixed polar angle so that the substrate has a certain tilt angle with respect to the vapor-flow direction.

The vapor flow共the red arrows兲 is incident at an angle␪, which is defined as the angle between the surface normal and the incident flow direction, as shown in Fig. 2共a兲. The inci-dent vapor flow is to be deposited preferentially on top of p-GaN nanorod. Due to the shadowing effect, no vapor flow is allowed to be deposited on the sidewall, i.e., the multiple-QWs region and the n-GaN regions. This approach provides for a more effective way to bring p-GaN nanorod in contact with a p-electrode without involving polymer processing. In Fig.2共b兲, we show an SEM side-view image of ITO grown on the 2D nanorod LED array. The incident angle of vapor flow is ␪= 70° and the deposited ITO thickness is 500 nm. Indeed, the ITO branch was selectively grown on top of the 2D nanorod array with a tilt angle of⬃40°. The sidewall of the nanorods is clean and free from ITO deposition, indicat-ing a successful implementation of a direct nanocontact scheme.

Next, we apply the oblique-angle-deposition to realize an electrically injected 2D nanorod LED arrays. In Fig.3共a兲, we show a schematic cross section of our proposed slanted ITO multicontact layers to the 2D nanorod LED arrays. The advantage of this contacting scheme is that it is compatible with standard chip process widely adopted in the LED indus-try. The oblique-angle deposition process was repeated three times, having incident angles of ␪= 85°, ⫺85°, and 0°, re-spectively. This repeated deposition is needed to join to-gether the individual ITO branches, to form a continuous blanket ITO film. In Fig. 3共b兲, we show a cross-sectional

SEM image of the completed ITO stack grown on the mesa of 2D nanorod LED arrays, i.e., the 85°-ITO, the⫺85°-ITO, and the 0°-ITO film, respectively. An enlarged SEM image of the ITO stack was shown in Fig. 3共c兲. The function of the intermediate layer 共⫺85°兲 is to prevent the successive blan-ket layer 共0°兲 from filling into rod-to-rod intervals and thus causing undesirable electrical short circuits. The slanted ITO layers 共85°/⫺85°兲 connect with each other well. And, more importantly, a flat and continuous surface morphology was observed on the top surface of the blanket ITO layer. This planar surface serves as a platform for a subsequent deposi-tion of the p-electrode. As a result, the electrical current from p-electrode is spread out uniformly within the blanket ITO layer and injected evenly into each individual nanorod LED through slanted ITO layers.

As a result of our new electrical contact scheme, we are able to inject up to I = 100 mA of bias current into a chip-size scale 共300⫻300 ␮m2_{兲 2D nanorod LED array. In the} FIG. 2. 共Color online兲共a兲 A schematic of incident vapor flow selectively

growing on top surfaces of nanorod array.共b兲 A cross-sectional view SEM images of ITO grown on the 2D nanorod array by oblique-angle deposition with a tilt angle of 40°.

FIG. 3. 共Color online兲共a兲 The cross-section schematic of our proposed slanted ITO multicontact layers to 2D nanorod LED array. 共b兲 A cross-sectional view SEM image of an ITO stack grown on the mesa of 2D nanorod LED array by oblique-angle deposition with incident angles of 85°, ⫺85°, and 0°, respectively. 共c兲 An enlarged SEM image of the ITO stack.

141111-2 Lee et al. Appl. Phys. Lett. 94, 141111共2009兲

(4)

background of Fig. 4, we show a photograph of our 2D na-norod LED arrays at a forward bias of I = 20 mA. A uniform light emitting intensity was observed over the entire chip area. This observation indicates that we have achieved a good current spreading in the p-contact layers and, more importantly, an exceedingly uniform current-injection effi-ciency into all the nanorod LEDs. Previously, an electrically injected nanorod LED array was realized by using polymer to isolate individual nanorod LEDs and a planar conductive layer to form a p-contact. Because of the difficulty in achiev-ing a uniform polymer fillachiev-ing, a localized current-injection often occurs. As a result, either severe leakage paths were observed9or an extremely low current was injected 共approxi-mately microampere兲 into the devices.11

We now examine the light output power characteristics of our 2D nanorod LED arrays. In Fig. 4, we show the light output power density L 共the solid dots兲 and the bias voltage V 共the square dots兲 versus the forward bias current I of our sample. Both the L-I and the I-V curve exhibit a typical functional dependence of a p-n junction, similar to that of a planar LED sample. We observe a slight increase in output power at I is increased to I = 5 – 10 mA and a stronger and linear increase for I⬎10 mA. At I=20 mA, the light output power density of our 2D nanorod LED array is as high as 3700 mW cm−2_{. The random arrangement of the nanorod}

array can alter the mechanism by which the emitted light is coupled into the free space.13Thus this extraction effect can also be a contributing factor to the large output power

den-sity of our electrically injected nanorod LED arrays. The low turn-on voltage共⬃2 V兲 in our work may be due to the col-lapse of nanorods in certain regions of the sample during device fabrication. Within these regions, the incident ITO vapor flow would be deposited directly to the n-type regions without shadowing. A more careful fabrication process will need to be designed in the future to overcome this issue.

In summary, we have demonstrated a scheme for the efficient injection of carriers into a 2D nanorod LED array by an oblique-angle deposition method. Cross-sectional SEM studies reveal that oblique vapor flow was selectively grown on the top surfaces of the p-type nanorod LED array. This 2D nanorod LED array exhibits an high light output power density of 3700 mW cm−2 at I = 20 mA, and that is attrib-uted mainly to the selective and nonleaky electrical contact to the 2D nanorod LED array, as well as light scattering due to the random arrangement of the nanorods.

S.Y.L. gratefully acknowledges financial support from DOE-BES under Grant No. DE-FG02-06ER46347 and par-tial support from Sandia National Laboratories. This work was supported in part by the National Science Council of Republic of China 共ROC兲 in Taiwan.

1_{M. R. Krames, O. B. Shchekin, M. M. Regina, G. O. Mueller, L. Zhou, G.} Harbers, and M. G. Craford,J. Disp. Technol. 3, 160共2007兲.

2_{E. F. Schubert, Light-Emitting Diodes}_{共Cambridge University Press,} Cam-bridge, 2006兲.

3_{S. Nakamura,}_Science _{281, 956}_共1998兲.

4_{M. Boroditsky and E. Yablonovitch,}_{Proc. SPIE} _{3002, 119}_共1997兲. 5_{H. Kim, Y. Cho, H. Lee, S. Kim, S. R. Ryu, D. Y. Kim, T. W. Kang, and}

K. S. Chung,Nano Lett. 4, 1059共2004兲.

6_{Y. Sun, Y.-H. Cho, H. M. Kim, and T. W. Kang,}_{Appl. Phys. Lett.} _87, 093115共2005兲.

7_{Y. He, L. Chen, Y.-K. Song, A. V. Nurmikko, S.-R. Jeon, Z. Ren, M.} Gherasimova, and J. Han,Phys. Status Solidi C 2, 2740共2005兲. 8_{S. Keller, C. Schaake, N. A. Fichtenbaum, C. J. Neufeld, Y. Wu, Y.}

Mc-Groddy, A. David, S. P. Denbaars, C. Weisbuch, J. S. Speck, and U. K. Mishra,J. Appl. Phys. 100, 054314共2006兲.

9_{M. Y. Hsieh, C. Y. Wang, L. Y. Chen, M. Y. Ke, and J. J. Huang,}_{IEEE J.} Quantum Electron. 44, 468共2008兲.

10_{X. W. Sun, J. Z. Huang, J. X. Wang, and Z. Xu,} _{Nano Lett.} _{8, 1219} 共2008兲.

11_{C. H. Chiu, M. H. Lo, C. F. Lai, T. C. Lu, H. W. Huang, Y. A. Chang, T.} H. Hsueh, C. C. Yu, H. C. Kuo, S. C. Wang, C. F. Lin, and Y. K. Kuo, Nanotechnology 18, 335706共2007兲.

12_{K. Robbie, J. C. Sit, and M. J. Brett,}_{J. Vac. Sci. Technol. B} _{16, 1115} 共1998兲.

13_{I. Schnitzer, E. Yablonovitch, C. Caneau, T. J. Gmitter, and A. Scherer,} Appl. Phys. Lett. 63, 2174共1993兲.

FIG. 4. 共Color online兲 The light output power density 共mW/cm2_{兲 vs} for-ward current and current vs voltage of 2D nanorod LED array. Background: A photograph image taken under an injection current of 20 mA.
