H u a n gOhmic contacts of AuBe to p-ZnTe show a minimum specific contact resistance of 3.0 X 10-6Qcm2 for ap-doping level of 1.6 X 1019m-3 and at an annealing temperature of 200°C. The beryllium is very effective at improving the electrical properties of p-type contacts to ZnTe.
11-VI wide bandgap semiconductors are being widely studied for optoelectronic devices [l]. ZnTe is a promising material because it can be doped with nitrogen in the region of 1019m-3. Much effort has been devoted to minimising the contact resistance [2 - 41. To date, a minimum specific contact resistance of 1.1 x 1Ck6!2cm2 has been obtained for ZnTe with an effective hole concentration 3 x 1019crr-3 with Au/Pt/TdNi metals by using an electron-beam coater [3]. In this Letter, we propose that gold-beryllium alloy (AuBe, 99:1, atm %), which can be evaporated easily in the thermal coater, is a good Ohmic metal for p-type ZnTe. The introduction of Be atoms led to a dramatic improvement in the Ohmic proper- ties of p-type ZnTe.
ZnTe
f h
was grown on a (001) semi-insulating GaAs substrate by MBE at 280°C. The source material was Zn(6N) and Te(6N). The p-type doping was carried out using a nitrogen plasma source. The hole concentration and mobility measured by the van der Pauw method were 2.0 x 1019cm3 and 27cm21Vls. The thickness was 0.66 pm. The specific contact resistance was measured by transmission line model (TLM) measurement. Before the forma- tion of the TLM pattern, the sample was cleaned with methanol and de-ionised water. The TLM pattem was formed by a photore- sist process. ZnTe mesa etching was carried out with K2Cr,0, :H,SO, : H,O solution with an over-etch into the semi-insulating GaAs substrate. Using a normal lift-off process, the AuBe metal was deposited using a thermal coater after the surface oxide was removed by HF : H,O = 1 : 200 (volume ratio).
The length of the TLM pattern was 5, 8, 11, 13, 16, 19, 22, 27pm with a width of l o o p . Annealing was performed at various temperatures for lOmin in
a
nitrogen gas ambient in a conven- tional furnace. The specific contact resistance was measured by using an hp3457A multimeter. The four-probe technique was used to avoid probe resistance effects.0.06
I
annealing temperature=200’~ 0.04-
0.02-
6 i P 0 - 3 -0.02-
-0.04 -0.06 -2 -1 0 1 2 3 voltage, V m Fig. 1 Current-voltage (I- V) characteristic of top contact pad on pattern of transmission line model ( T L M ) measurement with linewidth I O O p and length 2 7 p -2 10 3 (U 10 c: aiz
-4 9 10 P 96
.- (0 +-1 6 ~
0=
G) .- a ( 0 6 10 -7 10 annealing temperature, ‘C mm Fig. 2 Specific contact resistance of sample at different annealing tem- peraturesAu
AuBe
Fig. 1 shows the current-voltage (I-V) characteristic of the top contact pad on the pattern of the transmission line measurement with 27pm linewidth. The variations in the I-V characteristics caused by the annealing can be clearly observed in this Figure. Good Ohmic behaviour can be clearly observed in the as-depos- ited f h as shown in Fig. 1. The specific contact resistance decreases as we increase the annealing temperature. Yet, as shown in Fig. 2, only a small decrease in the specific contact resistance ( 6 . 4 ~ l e 6 - 3.0 x 106Qcm2) occurs while the annealing tempera- ture is increased from the as deposited case to 250°C. While the
annealing temperature is > 300”C, the specific contact resistance increases dramatically and some kinks in the I-V characteristic around 0.3V can also be observed. Thus, inferior Ohmic proper- ties occurred under these annealing conditions. Since the Te out- diffusion behaviour can be observed in the X P S analysis, the deg- radation in Ohmic properties may be caused by the lack of Te in the ZnTe film. Further investigation is necessary to identify these characteristics.
We also compared the annealing effect of Au and AuBe. As shown in Fig. 2, the specific contact resistance of Au on p-type ZnTe varies in the range 3.5 x lV3 - 3.0 x 1v4Qcmz with different annealing temperatures. This result explains why different specific contact resistances were achieved in previous work [2, 31 with a similar layer structure. After the introduction of Be, an improve- ment in specific contact resistance of more than two decades was observed. The AuBe alloy is very effective at improving the electri- cal properties of p-type contacts to ZnTe.
In conclusion, Ohmic contacts formed from AuBe alloy provide a very low resistance to p-ZnTe. Specific contact resistances as low as 3 x 1V6L2cmz have been obtained after a 200°C annealing process.
