Big Data Processing Technologies

Big Data Processing Technologies

Chentao Wu

Associate Professor

Dept. of Computer Science and Engineering [email protected]

Schedule

• lec1: Introduction on big data and cloud computing

• Iec2: Introduction on data storage

• lec3: Data reliability (Replication/Archive/EC)

• lec4: Data consistency problem

• lec5: Block storage and file storage

• lec6: Object-based storage

• lec7: Distributed file system

• lec8: Metadata management

Collaborators

Contents

Object-based Data Access

1

The Block Paradigm

The Object Paradigm

File Access via Inodes

•

Inodes contain file attributes

Object Access

•

Metadata:

 Creation data/time; ownership; size …

•

Attributes – inferred:

 Access patterns; content; indexes …

•

Attributes – user supplied:

 Retention; QoS …

Object Autonomy

•

Storage becomes autonomous

 Capacity planning

 Load balancing

 Backup

 QoS, SLAs

 Understand data/object grouping

 Aggressive prefetching

 Thin provisioning

 Search

 Compression/Deduplication

 Strong security, encryption

 Compliance/retention

 Availability/replication

 Audit

 Self healing

Data Sharing

homogeneous/heterogeneous

Data Migration

homogeneous/heterogeneous

Strong Security Additional layer

•

Strong security via external service

 Authentication

 Authorization

 …

•

Fine granularity

 Per object

Contents

Object-based Storage Devices

2

Data Access (Block-based vs. Object- based Device)

•

Objects contain both data and attributes

 Operations: create/delete/read/write objects, get/set attributes

OSD Standards (1)

•

ANSI INCITS T10 for OSD (the SCSI Specification, www.t10.org)

 ANSI INCITS 458

 OSD-1 is basic functionality

 Read, write, create objects and partitions

 Security model, Capabilities, manage shared secrets and working keys

 OSD-2 adds

 Snapshots

 Collections of objects

 Extended exception handling and recovery

 OSD-3 adds

 Device to device communication

 RAID-[1,5,6] implementation between/among devices

OSD Standards (2)

OSD Forms

• Disk array/server subsystem

 Example: custom-built HPC systems predominantly deployed in national labs

• Storage bricks for objects

 Example: commercial supercomputing offering

• Object Layer Integrated in Disk

Drive

OSDs: like disks, only different

OSDs: like a file server, only different

OSD Capabilities (1)

• Unlike disks, where access is granted on an all or nothing basis, OSDs grant or deny access to individual objects

based on Capabilities

• A Capability must accompany each request to read or write an object

 Capabilities are cryptographically signed by the Security Manager and verified (and enforced) by the OSD

 A Capability to access an object is created by the Security

Manager, and given to the client (application server) accessing the object

 Capabilities can be revoked by changing an attribute on the object

OSD Capabilities (2)

OSD Security Model

• OSD and File Server know a secret key

 Working keys are periodically generated from a master key

• File server authenticates clients and makes access control policy decisions

 Access decision is captured in a capability that is signed with the secret key

 Capability identifies object, expire time, allowed operations, etc.

• Client signs requests using the capability signature as a signing key

 OSD verifies the signature before allowing access

 OSD doesn’t know about the users, Access Control Lists (ACLs), or whatever policy mechanism the File Server is using

Contents

Object-based File Systems

3

Why not just OSD = file system?

•

Scaling

 What if there’s more data than the biggest OSD can hold?

 What if too many clients access an OSD at the same time?

 What if there’s a file bigger than the biggest OSD can hold?

•

Robustness

 What happens to data if an OSD fails?

 What happens to data if a Metadata Server fails?

•

Performance

 What if thousands of objects are access concurrently?

 What if big objects have to be transferred really fast?

General Principle

•

Architecture

 File = one or more groups of objects

 Usually on different OSDs

 Clients access Metadata Servers to locate data

 Clients transfer data directly to/from OSDs

•

Address

 Capacity

 Robustness

 Performance

Capacity

•

Add OSDs

 Increase total system capacity

 Support bigger files

 Files can span OSDs if necessary or desirable

Robustness

•

Add metadata servers

 Resilient metadata services

 Resilient security services

•

Add OSDs

 Failed OSD affects small percentage of system resources

 Inter-OSD mirroring and RAID

 Near-online file system checking

Advantage of Reliability

•

Declustered Reconstruction

 OSDs only rebuild actual data (not unused space)

 Eliminates single-disk rebuild bottleneck

 Faster reconstruction to provide high protection

Performance

•

Add metadata servers

 More concurrent metadata operations

 Getattr, Readdir, Create, Open, …

•

Add OSDs

 More concurrent I/O operations

 More bandwidth directly between clients and data

Additional Advantages

•

Optimal data placement

 Within OSD: proximity of related data

 Load balancing across OSDs

•

System-wide storage pooling

 Across multiple file systems

•

Storage tiering

 Per-file control over

performance and resiliency

Per-file tiering in OSDs: striping

Per-file tiering in OSDs: RAID-4/5/6

Per-file tiering in OSDs: mirroring(RAID-1)

Flat namespace

Hierarchical File System Vs. Flat Address Space

• Hierarchical file system organizes data in the form of files and directories

• Object-based storage devices store the data in the form of objects

 It uses flat address space that enables storage of large number of objects

 An object contains user data, related metadata, and other attributes

 Each object has a unique object ID, generated using specialized algorithm

Filenames/inodes

Hierarchical File System

Object IDs

Flat Address Space

Object Object Object Object

Object Object

Data

Attributes Object ID

Metadata Object

Virtual View / Virtual File Systems

Traditional FS Vs. Object-based FS (1)

Traditional FS Vs. Object-based FS (2)

• File system layer in host manages

 Human readable namespace

 User authentication, permission checking, Access Control Lists (ACLs)

 OS interface

• Object Layer in OSD manages

 Block allocation and placement

 OSD has better knowledge of disk geometry and characteristic so it can do a better job of file

placement/optimization than a host-based file system

Accessing Object-based FS

• Typical Access

 SCSI (block), NFS/CIFS (file)

• Needs a client component

 Proprietary

 Standard

Standard NFS v4.1

• A standard file access protocol for OSDs

Scaling Object-based FS (1)

Scaling Object-based FS (2)

• App servers (clients) have direct access to storage to read/write file data securely

 Contrast with SAN where security is lacking

 Contrast with NAS where server is a bottleneck

• File system includes multiple OSDs

 Grow the file system by adding an OSD

 Increase bandwidth at the same time

 Can include OSDs with different performance characteristics (SSD, SATA, SAS)

• Multiple File Systems share the same OSDs

 Real storage pooling

Scaling Object-based FS (3)

• Allocation of blocks to Objects handled within OSDs

 Partitioning improves scalability

 Compartmentalized managements improves reliability through isolated failure domains

• The File Server piece is called the MDS

 Meta-Data Server

 Can be clustered for scalability

Why Objects helps Scaling

•

90% of File System cycles are in the read/write path

 Block allocation is expensive

 Data transfer is expensive

 OSD offloads both of these from the file server

 Security model allows direct access from clients

•

High level interfaces allow optimization

 The more function behind an API, the less often you have to use the API to get your work done

•

Higher level interfaces provide more semantics

 User authentication and access control

 Namespace and indexing

Object Decomposition

Object-based File Systems

•

Lustre

 Custom OSS/OST model

 Single metadata server

•

PanFS

 ANSI T10 OSD model

 Multiple metadata servers

•

Ceph

 Custom OSD model

 CRUSH metadata distribution

•

pNFS

 Out-of-band metadata service for NFSv4.1

 T10 Objects, Files, Blocks as data services

•

These systems scale

 1000’s of disks (i.e., PB’s)

 1000’s of clients

 100’s GB/sec

 All in one file system

Lustre (1)

•

Supercomputing focus emphasizing

 High I/O throughput

 Scalability in the Pbytes of data and billions of files

•

OSDs called OSTs (Object Storage Targets)

•

Only RAID-0 supported across Objects

 Redundancy inside OSTs

•

Runs over many transports

 IP over ethernet

 Infiniband

•

OSD and MDS are Linux based & Client Software supports Linux

 Other platforms under consideration

•

Used in Telecom/Supercomputing Center/Aerospace/National Lab

Lustre (2) Architecture

Lustre (3) Architecture-MDS

•

Metadata Server (MDS)

 Node(s) that manage namespace, file creation and layout, and locking.

Directory operations

 File open/close

 File status

 File creation

 Map of file object location

 Relatively expensive serial atomic transactions to maintain consistency

•

•Metadata Target (MDT)

 Block device that stores metadata

Lustre (3) Architecture-OSS

• Object Storage Server (OSS)

 Multiple nodes that manage network requests for file objects on disk.

• Object Storage Target (OST)

 Block device that stores file objects

Lustre (4) Simplest Lustre File System

Lustre (5) File Operation

•

When a compute node needs to create or access a file, it requests the associated storage locations from the MDS and the associated MDT.

•

I/O operations then occur directly with the OSSs and OSTs associated with the file bypassing the MDS.

•

For read operations, file data flows from the OSTs to the compute node.

Lustre (6) File I/Os

•

Single stream

•

Single stream through a master

•

Parallel

Lustre (7) File Striping

•

A file is split into segments and consecutive segments are stored on different physical storage devices (OSTs).

Lustre (8) Aligned and Unaligned Stripes

•

Aligned stripes is where each segment fits fully onto a single OST.

Processes accessing the file do so at corresponding stripe boundaries.

•

Unaligned stripes means some file segments are split across OSTs.

Lustre (9) Striping Example

Lustre (10) Advantages/Disadvantages

•

Striping will not benefit ALL applications

Ceph (1)

• What is Ceph?

Ceph is a distributed file system that provides excellent performance, scalability and reliability.

Features

Decoupled data and metadata

Dynamic distributed metadata management

Reliable autonomic distributed object storage

Goals

Easy scalability to peta- byte capacity

Adaptive to varying workloads

Tolerant to node failures

Ceph (2) – Architecture

• Decoupled Data and Metadata

Ceph (3) – Architecture

Ceph (4) – Components

Object Storage

cluster Clients

Metadata Server cluster

Cluster monitor

Metadata I/O

Ceph (5) - Components

Meta Data cluster Clients

Object Storage cluster

Capability Management

CRUSH is used to map Placement Group (PG) to OSD.

Ceph (6) – Components

• Client Synchronization

POSIX Semantics

Relaxed Consistency

 Synchronous I/O.

performance killer

 Solution: HPC extensions to POSIX

 Default: Consistency / correctness

 Optionally relax

 Extensions for both data and metadata

Ceph (7) – Namespace Operations

Ceph optimizes for most common meta-data

access scenarios

(readdir followed by stat)

But by default “correct”

behavior is provided at some cost.

Stat operation on a file opened by multiple writers

Applications for which coherent behavior is unnecessary use

extensions Namespace

Operations

Ceph (8) – Metadata

Per-MDS journals Eventually pushed to

OSD Sequential

Update More efficient

Reducing re- write workload.

Optimized on- disk storage layout for future

read access

Easier failure recovery. Journal

can be rescanned for

recovery.

• Metadata Storage

• Advantages

Ceph (9) – Metadata

• Dynamic Sub-tree Partitioning

 Adaptively distribute cached metadata hierarchically across a set of nodes.

 Migration preserves locality.

 MDS measures popularity of metadata.

Ceph (10) – Metadata

• Traffic Control for metadata access

• Challenge

• Partitioning can balance workload but can’t deal with hot spots or flash crowds

• Ceph Solution

 Heavily read directories are selectively replicated across multiple nodes to distribute load

 Directories that are extra large or experiencing heavy write workload have their contents hashed by file name across the cluster

Ceph (11) – Distributed Object Storage

Ceph (11) – CRUSH

• CRUSH(x)  (osd

_n1

, osd

_n2

, osd

_n3

)

• Inputs

• x is the placement group

• Hierarchical cluster map

• Placement rules

• Outputs a list of OSDs

• Advantages

• Anyone can calculate object location

• Cluster map infrequently updated

Ceph (12) – Replication

• Objects are replicated on OSDs within same PG

• Client is oblivious to replication

Ceph (13) – Conclusion

• Strengths:

• Easy scalability to peta-byte capacity

• High performance for varying work loads

• Strong reliability

• Weaknesses:

• MDS and OSD Implemented in user-space

• The primary replicas may become bottleneck to heavy write operation

• N-way replication lacks storage efficiency

• References

• Ceph: A Scalable, High Performance Distributed File System.

In Proc. of OSDI’06

Contents

Object-based Storage in Cloud

4

Web Object Features

•

RESTful API (i.e., web-based)

•

Security/Authentication tied to Billing

•

Metadata capabilities

•

Highly available

•

Loosely consistent

•

Data Storage

 Blobs

 Tables

 Queues

•

Other related APIs (compute, search, etc.)

 Storage API is relatively simple in comparison

Simple HTTP example

HTTP and objects

•

Request specifies method and object:

 Operation: GET, POST, PUT, HEAD, COPY

 Object ID (/index.html)

•

Parameters use MIME format borrowed from email

 Content-type: utf8;

 Set-Cookie: tracking=1234567;

•

Add a data payload

 Optional

 Separated from parameters with a blank line (like email)

•

Response has identical structure

 Status line, key-value parameters, optional data payload

This is a method call on an object

These are parameters

This is data

OpenStack REST API for Storage

•

GET v1/account HTTP/1.1

 Login to your account

•

HEAD v1/account HTTP/1.1

 List account metadata

•

PUT v1/account/container HTTP/1.1

 Create container

•

PUT v1/account/container/object HTTP/1.1

 Create object

•

GET v1/account/container/object HTTP/1.1

 Read object

•

HEAD v1/account/container/object HTTP/1.1

 Read object metadata

Create an object

Update metadata

Ali OSS (1)

•

Access URL: http://<bucket>.oss-cn-beijing.aliyuncs.com/<object>

Access Layer Restful Protocol

LB LVS

Partition Layer Key-Value Engine

Persistent Layer Pangu FS

Load Balancing

Protocol Manager &

Access Control Partition & Index

Persistent, Redundancy

& Fault-Tolerance

Ali OSS (2) Architecture

•

WS: Web Server PM: Protocol Manager

Persistent Layer

M

M

Paxos M OS

OS

OS

OS

OS

Nuwa LockService

KVServer KVServer KVServer KVMaster

WS+PM WS+PM WS+PM WS+PM

Access Layer（RESTful API）

Partition Layer（LSM Tree）

Request ACK

Ali OSS (3) Partition Layer

•

Append/Dump/Merge

MemFile

Block

Cache Block Index Cache Bloomfilter Cache Memory

Pangu

Youchao Files Redo Log File

Log Data Files

Ali OSS (4) Partition Layer

•

Read/Write Process

MemFile

Redo Log File

Memory Read

Youchao Files

Dump memfile to youchao file

Write

Pangu Merge

Ali OSS (5) Persistent Layer

•

Write Pangu Normal File

Paxos Pangu client

M

M

M

OS OS OS OS

Create Chunk Chunk Location

Append Data ACK

Append Append

ACK ACK

Ali OSS (6) Persistent Layer

•

Write Pangu Log File

Paxos Pangu client

M

M

M

OS OS OS OS

Create Chunk Chunk Location

Flush Data ACK

The Evolution of Data Storage

Thank you!
