Electrochemically deposited nano polyaniline films as hole transporting layers in organic solar cells

(1)

Electrochemically deposited nano polyaniline

ﬁlms as hole

transporting layers in organic solar cells

Yu-Kai Han

a,n

, Mei-Ying Chang

b

, Ko-Shan Ho

a

, Tar-Hwa Hsieh

a

, Jeng-Liang Tsai

b

,

Pei-Chen Huang

a

Department of Chemical and Materials Engineering, National Kaohsiung University of Applied Sciences, Kaohsiung 807, Taiwan, Republic of China

b

Department of Photonics, National Sun Yat-sen University, Kaohsiung 804, Taiwan, Republic of China

a r t i c l e i n f o

Article history: Received 1 July 2013 Received in revised form 3 March 2014

Accepted 27 April 2014 Available online 5 June 2014 Keywords:

Polyaniline Buffer layer

Power conversion efﬁciency Transporting layer PEDOT:PSS primary doping

a b s t r a c t

In this study, we prepared organic solar cells based on poly(3-hexylthiophene) (P3HT) and [6,6]-phenyl-C61

-butyric acid methyl ester (PCBM) with electrochemically deposited nano polyaniline (PANI) buffer layers (either PANI– 0.1 M or PANI – 0.3 M) as hole transporting layers and compared their performances with those of solar cells lacking the buffer layer (i.e., bare ITO) or featuring buffer layers of poly(3,4-ethylenedioxythio-phene):polystyrenesulfonate (PEDOT:PSS) or PEDOT:PSS-covered PANI. The power conversion efﬁciency of the device featuring PANI/PEDOT:PSS as the buffer layer (2.76%) was greater than those of devices featuring bare ITO (0.75%) or the PANI– 0.1 M (1.33%), PANI – 0.3 M (1.78%), or PEDOT:PSS (2.30%) layers. We suspect that the increased conductivity of the PANI/PEDOT:PSS composite, caused by interactions between the PANI nitrogen atoms and the functional groups of PSS, led to additional doping of PANI. This primary doping effect by PSS toward PANI lowered the series resistance of the PANI/PEDOT:PSS buffer layer and, thereby, increased the photocurrent of the device. As a result, electrochemically deposited PANI buffer layers, with or without PEDOT: PSS, appear to be promising hole transporting layers for organic electronic devices that require different candidate materials (other than PEDOT:PSS conductors) and/or different processing conditions (other than spin-coating).

1. Introduction

Although poly(3,4-ethylenedioxythiophene):polystyrenesulfonate

(PEDOT:PSS) is insoluble in organic solvents, it is often employed as

a transparent hole-transporting material in organic cells because of its

high conductivity, simple processing, and suitable work function

[1]

.

The use of PEDOT:PSS has several limitations: it degrades under UV

illumination, it introduces water into the devices' active layer, and it

retains a degree of acidity that can damage indium tin oxide (ITO) at

high temperatures, thereby affecting the long-term stability of its

devices

[2]

. Therefore, several highly conductive materials, including

carbon nanotubes (CNTs)

[3]

, polyhexylthiophene

[4]

, and polyaniline

(PANI)

[5

–7]

, have been studied as possible replacements for PEDOT:

PSS as the hole injection or transporting layer.

Doping PEDOT with PSS allows it to become soluble in aqueous

media, thereby facilitating its deposition onto ITO surfaces through

spin-coating

—the most common method employed in the fabrication

of organic devices. Even though spin-coating is an inexpensive, rapid,

and simple means of depositing liquid materials, it can waste a lot of

material, making it less attractive for manufacturing processes.

Several methods for the deposition of hole transporting (e.g.,

PEDOT:PSS, polyaniline (PANI)] and active layers

—including inkjet

printing

[8]

, spray deposition

[9]

, roll-to-roll gravure printing

[10]

,

brush painting

[11]

, and screen printing

[12]

—have been

devel-oped to enhance the manufacturing process with the goal of mass

production of organic electronics. The presence of PANI-coated ITO

electrodes can decrease the operating voltage, increase the

elec-troluminescence quantum ef

ﬁciency, and improved device

relia-bility of organic light emitting diodes (OLED) because they can

lower the injection barrier between the anode and the

hole-transporting emissive layer

[13

–21]

. Notably, the performance of

ITO/PANI-based devices can be similar to that of corresponding

ITO/PEDOT:PSS-based devices

[20

–22]

.

Recently, electrochemical polymerization was reported as an

alternative means of depositing conductive polymers onto ITO

surfaces for organic device applications

[23

–25]

. Zhau et al.

[23]

electrochemically deposited PEDOT:PSS onto an ITO surface during

the formation of a device having the con

ﬁguration ITO/PEDOT:PSS/

ZnO:MDMO-PPV/Al and obtained a power conversion ef

ﬁciency

(

η

) of 0.33% under AM 1.5 illumination. Mello et al.

[24]

used
