EI 338: Computer Systems Engineering
(Operating Systems & Computer Architecture)
Dept. of Computer Science & Engineering Chentao Wu
[email protected]
Download lectures
• ftp://public.sjtu.edu.cn
• User: wuct
• Password: wuct123456
• http://www.cs.sjtu.edu.cn/~wuct/cse/
3
Chapter 2
Memory Hierarchy Design
Computer Architecture
A Quantitative Approach, Fifth Edition
Introduction
Programmers want unlimited amounts of memory with low latency
Fast memory technology is more expensive per bit than slower memory
Solution: organize memory system into a hierarchy
Entire addressable memory space available in largest, slowest memory
Incrementally smaller and faster memories, each
containing a subset of the memory below it, proceed in steps up toward the processor
Temporal and spatial locality insures that nearly all references can be found in smaller memories
Gives the allusion of a large, fast memory being presented to the processor
Memory Hierarchy
Memory Performance Gap
Memory Hierarchy Design
Memory hierarchy design becomes more crucial with recent multi-core processors:
Aggregate peak bandwidth grows with # cores:
Intel Core i7 can generate two references per core per clock
Four cores and 3.2 GHz clock
25.6 billion 64-bit data references/second +
12.8 billion 128-bit instruction references
= 409.6 GB/s!
DRAM bandwidth is only 6% of this (25 GB/s)
Requires:
Multi-port, pipelined caches
Two levels of cache per core
Shared third-level cache on chip
Performance and Power
High-end microprocessors have >10 MB on-chip cache
Consumes large amount of area and power budget
Memory Hierarchy Basics
When a word is not found in the cache, a
miss occurs:
Fetch word from lower level in hierarchy, requiring a higher latency reference
Lower level may be another cache or the main memory
Also fetch the other words contained within the block
Takes advantage of spatial locality
Place block into cache in any location within its set, determined by address
block address MOD number of sets
Memory Hierarchy Basics
n sets => n-way set associative
Direct-mapped cache => one block per set
Fully associative => one set
Writing to cache: two strategies
Write-through
Immediately update lower levels of hierarchy
Write-back
Only update lower levels of hierarchy when an updated block is replaced
Both strategies use write buffer to make writes asynchronous
Memory Hierarchy Basics
Miss rate
Fraction of cache access that result in a miss
Causes of misses
Compulsory
First reference to a block
Capacity
Blocks discarded and later retrieved
Conflict
Program makes repeated references to multiple
addresses from different blocks that map to the same location in the cache
Note that speculative and multithreaded processors may execute other instructions during a miss
Reduces performance impact of misses
Memory Hierarchy Basics
Equations on Appendix B-4
13
Example on B-5
14
Answer on B-5
15
Example on B-6
16
B-7 Q1: where can a block be placed in a cache?
17
B-7 Q2: how is a block found if it is in the cache?
18
B-9 Q2: how is a block found if it is in the cache? (contd.)
19
B-9 Q3: which block should be replaced on a cache miss?
20
B-10 Q4: what happens on a write?
21
B-10 Q4: what happens on a write?
(contd.)
22
B-10 Q4: what happens on a write?
(contd.)
23
AMD Opteron Processor
24
B-16 Cache Performance
25
B-16 Cache Performance (contd.)
26
27
B-17 Avg. Memory Access Time and Processor Performance
28
B-17 Avg. Memory Access Time and Processor Performance
29
B-20 Miss Penalty and Out-of-Order Execution Processors
30
B-20 Miss Penalty and Out-of-Order Execution Processors
31
Six basic cache optimizations
32
Six basic cache optimizations
33
Memory Hierarchy Basics
Six basic cache optimizations:
Larger block size
Reduces compulsory misses
Increases capacity and conflict misses, increases miss penalty
Larger total cache capacity to reduce miss rate
Increases hit time, increases power consumption
Higher associativity
Reduces conflict misses
Increases hit time, increases power consumption
Higher number of cache levels
Reduces overall memory access time
Giving priority to read misses over writes
Reduces miss penalty
Avoiding address translation in cache indexing
Reduces hit time
Ten Advanced Optimizations
Small and simple first level caches
Critical timing path:
addressing tag memory, then
comparing tags, then
selecting correct set
Direct-mapped caches can overlap tag compare and transmission of data
Lower associativity reduces power because fewer cache lines are accessed
L1 Size and Associativity
Access time vs. size and associativity
L1 Size and Associativity
Energy per read vs. size and associativity
Way Prediction
To improve hit time, predict the way to pre-set mux
Mis-prediction gives longer hit time
Prediction accuracy
> 90% for two-way
> 80% for four-way
I-cache has better accuracy than D-cache
First used on MIPS R10000 in mid-90s
Used on ARM Cortex-A8
Extend to predict block as well
“Way selection”
Increases mis-prediction penalty
Pipelining Cache
Pipeline cache access to improve bandwidth
Examples:
Pentium: 1 cycle
Pentium Pro – Pentium III: 2 cycles
Pentium 4 – Core i7: 4 cycles
Increases branch mis-prediction penalty
Makes it easier to increase associativity
Nonblocking Caches
Allow hits before previous misses complete
“Hit under miss”
“Hit under multiple miss”
L2 must support this
In general,
processors can hide L1 miss
penalty but not L2 miss penalty
Multibanked Caches
Organize cache as independent banks to support simultaneous access
ARM Cortex-A8 supports 1-4 banks for L2
Intel i7 supports 4 banks for L1 and 8 banks for L2
Interleave banks according to block address
Critical Word First, Early Restart
Critical word first
Request missed word from memory first
Send it to the processor as soon as it arrives
Early restart
Request words in normal order
Send missed work to the processor as soon as it arrives
Effectiveness of these strategies
depends on block size and likelihood of another access to the portion of the
block that has not yet been fetched
Merging Write Buffer
When storing to a block that is already pending in the write buffer, update write buffer
Reduces stalls due to full write buffer
Do not apply to I/O addresses
No write buffering
Write
buffering
Compiler Optimizations
Loop Interchange
Swap nested loops to access memory in sequential order
Blocking
Instead of accessing entire rows or
columns, subdivide matrices into blocks
Requires more memory accesses but improves locality of accesses
Hardware Prefetching
Fetch two blocks on miss (include next sequential block)
Pentium 4 Pre-fetching
Compiler Prefetching
Insert prefetch instructions before data is needed
Non-faulting: prefetch doesn’t cause exceptions
Register prefetch
Loads data into register
Cache prefetch
Loads data into cache
Combine with loop unrolling and
software pipelining
Summary
Memory Technology
Performance metrics
Latency is concern of cache
Bandwidth is concern of multiprocessors and I/O
Access time
Time between read request and when desired word arrives
Cycle time
Minimum time between unrelated requests to memory
DRAM used for main memory, SRAM
used for cache
Memory Technology
SRAM
Requires low power to retain bit
Requires 6 transistors/bit
DRAM
Must be re-written after being read
Must also be periodically refeshed
Every ~ 8 ms
Each row can be refreshed simultaneously
One transistor/bit
Address lines are multiplexed:
Upper half of address: row access strobe (RAS)
Lower half of address: column access strobe (CAS)
Memory Technology
Amdahl:
Memory capacity should grow linearly with processor speed
Unfortunately, memory capacity and speed has not kept pace with processors
Some optimizations:
Multiple accesses to same row
Synchronous DRAM
Added clock to DRAM interface
Burst mode with critical word first
Wider interfaces
Double data rate (DDR)
Multiple banks on each DRAM device
Memory Optimizations
Memory Optimizations
Memory Optimizations
DDR:
DDR2
Lower power (2.5 V -> 1.8 V)
Higher clock rates (266 MHz, 333 MHz, 400 MHz)
DDR3
1.5 V
800 MHz
DDR4
1-1.2 V
1600 MHz
GDDR5 is graphics memory based on
DDR3
Memory Optimizations
Graphics memory:
Achieve 2-5 X bandwidth per DRAM vs.
DDR3
Wider interfaces (32 vs. 16 bit)
Higher clock rate
Possible because they are attached via soldering instead of socketted DIMM modules
Reducing power in SDRAMs:
Lower voltage
Low power mode (ignores clock, continues to refresh)
Memory Power Consumption
Flash Memory
Type of EEPROM
Must be erased (in blocks) before being overwritten
Non volatile
Limited number of write cycles
Cheaper than SDRAM, more expensive than disk
Slower than SRAM, faster than disk
Memory Dependability
Memory is susceptible to cosmic rays
Soft errors : dynamic errors
Detected and fixed by error correcting codes (ECC)
Hard errors : permanent errors
Use sparse rows to replace defective rows
Chipkill: a RAID-like error recovery
technique
Virtual Memory
Protection via virtual memory
Keeps processes in their own memory space
Role of architecture:
Provide user mode and supervisor mode
Protect certain aspects of CPU state
Provide mechanisms for switching between user mode and supervisor mode
Provide mechanisms to limit memory accesses
Provide TLB to translate addresses
Virtual Machines
Supports isolation and security
Sharing a computer among many unrelated users
Enabled by raw speed of processors, making the overhead more acceptable
Allows different ISAs and operating systems to be presented to user programs
“System Virtual Machines”
SVM software is called “virtual machine monitor” or
“hypervisor”
Individual virtual machines run under the monitor are called “guest VMs”
Impact of VMs on Virtual Memory
Each guest OS maintains its own set of page tables
VMM adds a level of memory between physical and virtual memory called “real memory”
VMM maintains shadow page table that maps guest virtual addresses to physical addresses
Requires VMM to detect guest’s changes to its own page table
Occurs naturally if accessing the page table pointer is a privileged operation
Example on Page 80
61
Example on Page 82
62
Example on Page 83
63
Example on Page 83 (contd.)
64
Homework
2.8, B.1
