15 Optical Instruments

"Gemini Observatory at sunset" by Mailseth

"Gemini South 01"

by Denys

(2)

Sections

15.1 Two lens system 15.2 Simple Magnifiers

15.3 Compound Microscope s 15.4 Refracting Telescope 15.5 Cameras

15.6 Eyes

(3)

15.1 Two Lens System

Total magnification:

If M is positive, the final image has same the orientation as the object.

(4)

Image produced by a system of two thin lenses

(5)

Image produced by a system of two thin lenses

Lens 1

Lens 2

(6)

15.2 Simple Magnifiers

q ≈ h/25

q’

≈ h/f

(7)

15.3 Compound Microscope

(8)

15.4 Refracting Telescope

q

ey

/q

ob

q

ob ≈ h

/

fob and

q

ey ≈ h/fey

(9)

The astronomical telescope

The optical system of an astronomical refracting telescope.

(10)

The reflecting telescope

Three designs for reflecting telescopes. Part (d) shows the Gemini North telescope, which uses the design in (c) with an objective mirror 8 meters in diameter.

(11)

SPHERICAL ABERRATION

• The Hubble Space Telescope

(12)

15.5 Cameras

(13)

A digital Camera

(14)

Camera lens basics

(15)

15.6 The eye

• The optical behavior of the eye is similar to that of a camera.

(16)

Defects of vision

The near point typically recedes with age, as shown in Table 34.1.

Figure at right shows a normal, a myopic, and a hyperopic eye.

(17)

Farsighted correction

• Figure below shows how to correct a hyperopic (farsighted) eye using a converging lens.

(18)

Nearsighted correction

• Figure below shows how to correct a myopic (nearsighted) eye using a diverging lens.

(19)

Correcting for farsightedness

1 1 1 1 1

2.5cm 100cm

33cm power = 1 3 diopters

f p i

f f

  

 

(20)

Correcting for nearsightedness

1 1 1 1 1

48cm

48cm power = 1 2.1 diopters

f p i

f f

  

 

   

(21)

Correcting for Astigmatism

(22)
