Appendix A
Instruction Set Principles
Computer Architecture
A Quantitative Approach, Fifth Edition
4
Outline
Instruction Set Architecture
5 stage pipelining
Structural and Data Hazards
Forwarding
Branch Schemes
Exceptions and Interrupts
Conclusion
Instruction Set Architecture
Instruction set architecture is the structure of a computer that a machine language
programmer must understand to write a
correct (timing independent) program for that machine.
The instruction set architecture is also the
machine description that a hardware designer must understand to design a correct
implementation of the computer.
Evolution of Instruction Sets
Single Accumulator (EDSAC 1950) Accumulator + Index Registers
(Manchester Mark I, IBM 700 series 1953) Separation of Programming Model
from Implementation
High-level Language Based Concept of a Family
(B5000 1963) (IBM 360 1964)
General Purpose Register Machines
Complex Instruction Sets Load/Store Architecture
RISC
(Vax, Intel 432 1977-80) (CDC 6600, Cray 1 1963-76)
(Mips,Sparc,HP-PA,IBM RS6000,PowerPC . . .1987) LIW/”EPIC”? (IA-64. . .1999)
Evolution of Instruction Sets
Major advances in computer architecture are typically associated with landmark instruction set designs
Ex: Stack vs GPR (System 360)
Design decisions must take into account:
technology
machine organization
programming languages
compiler technology
operating systems
And they in turn influence these
Instructions Can Be Divided into 3 Classes (I)
Data movement instructions
Move data from a memory location or register to another memory location or register without changing its form
Load—source is memory and destination is register
Store—source is register and destination is memory
Arithmetic and logic (ALU) instructions
Change the form of one or more operands to produce a result stored in another location
Add, Sub, Shift, etc.
Branch instructions (control flow instructions)
Alter the normal flow of control from executing the next instruction in sequence
Br Loc, Brz Loc2,—unconditional or conditional branches
Classifying ISAs
Accumulator (before 1960):
1 address add A acc <- acc + mem[A]
Stack (1960s to 1970s):
0 address add tos <- tos + next
Memory-Memory (1970s to 1980s):
2 address add A, B mem[A] <- mem[A] + mem[B]
3 address add A, B, C mem[A] <- mem[B] + mem[C]
Register-Memory (1970s to present):
2 address add R1, A R1 <- R1 + mem[A]
load R1, A R1 <_ mem[A]
Register-Register (Load/Store) (1960s to present):
3 address add R1, R2, R3 R1 <- R2 + R3 load R1, R2 R1 <- mem[R2]
store R1, R2 mem[R1] <- R2
Classifying ISAs
Stack Architectures
Instruction set:
add, sub, mult, div, . . . push A, pop A
Example: A*B - (A+C*B)
push A push B mul push A push C push B mul add sub
A B
A
A*B
A*B
A*B
A*B A
A C
A*B
A A*B
A C B B*C A+B*C result
Stacks: Pros and Cons
Pros
Good code density (implicit operand addressing top of stack)
Low hardware requirements
Easy to write a simpler compiler for stack architectures
Cons
Stack becomes the bottleneck
Little ability for parallelism or pipelining
Data is not always at the top of stack when need, so additional instructions like TOP and SWAP are needed
Difficult to write an optimizing compiler for stack architectures
Accumulator Architectures
• Instruction set:
add A, sub A, mult A, div A, . . . load A, store A
• Example: A*B - (A+C*B)
load B mul C add A store D load A mul B sub D
B B*C A+B*C A+B*C A A*B result
Accumulators: Pros and Cons
• Pros
– Very low hardware requirements – Easy to design and understand
• Cons
– Accumulator becomes the bottleneck
– Little ability for parallelism or pipelining
– High memory traffic
Memory-Memory Architectures
• Instruction set:
(3 operands) add A, B, C sub A, B, C mul A, B, C
• Example: A*B - (A+C*B)
– 3 operands
mul D, A, B
mul E, C, B
add E, A, E
sub E, D, E
Memory-Memory: Pros and Cons
• Pros
– Requires fewer instructions (especially if 3 operands) – Easy to write compilers for (especially if 3 operands)
• Cons
– Very high memory traffic (especially if 3 operands)
– Variable number of clocks per instruction (especially if
2 operands)– With two operands, more data movements are required
Register-Memory Architectures
• Instruction set:
add R1, A sub R1, A mul R1, B load R1, A store R1, A
• Example: A*B - (A+C*B)
load R1, A
mul R1, B /* A*B */
store R1, D load R2, C
mul R2, B /* C*B */
add R2, A /* A + CB */
sub R2, D /* AB - (A + C*B) */
Memory-Register: Pros and Cons
• Pros
– Some data can be accessed without loading first – Instruction format easy to encode
– Good code density
• Cons
– Operands are not equivalent (poor orthogonality) – Variable number of clocks per instruction
– May limit number of registers
Load-Store Architectures
• Instruction set:
add R1, R2, R3 sub R1, R2, R3 mul R1, R2, R3 load R1, R4 store R1, R4
• Example: A*B - (A+C*B)
load R1, &A load R2, &B load R3, &C load R4, R1 load R5, R2 load R6, R3
mul R7, R6, R5 /* C*B */
add R8, R7, R4 /* A + C*B */
mul R9, R4, R5 /* A*B */
sub R10, R9, R8 /* A*B - (A+C*B) */
Load-Store: Pros and Cons
• Pros
– Simple, fixed length instruction encoding – Instructions take similar number of cycles – Relatively easy to pipeline
• Cons
– Higher instruction count
– Not all instructions need three operands
– Dependent on good compiler
Registers:
Advantages and Disadvantages
• Advantages
– Faster than cache (no addressing mode or tags) – Deterministic (no misses)
– Can replicate (multiple read ports) – Short identifier (typically 3 to 8 bits) – Reduce memory traffic
• Disadvantages
– Need to save and restore on procedure calls and context switch
– Can’t take the address of a register (for pointers)
– Fixed size (can’t store strings or structures efficiently) – Compiler must manage
General Register Machine and Instruction Formats
M e m ory
O p1 Addr: O p1 loa d
N e xti P rogra m
counte r
loa d R 8 , O p1 (R 8 ฌ O p1 ) C P U
R e giste rs
R 8
R 6
R 4
R 2
In struction form a ts
R 8
loa d O p1 A ddr
a dd R 2 , R 4 , R 6 (R 2 ฌ R 4 + R 6 ) R 2
a dd R 4 R 6
General Register Machine and Instruction Formats
It is the most common choice in today’s general-purpose computers
Which register is specified by small “address”
(3 to 6 bits for 8 to 64 registers)
Load and store have one long & one short address: One and half addresses
Arithmetic instruction has 3 “half” addresses
Real Machines Are Not So Simple
Most real machines have a mixture of 3, 2, 1, 0, and 1- address instructions
A distinction can be made on whether
arithmetic instructions use data from memory
If ALU instructions only use registers for operands and result, machine type is load- store
Only load and store instructions reference memory
Other machines have a mix of register-
memory and memory-memory instructions
Alignment Issues
• If the architecture does not restrict memory accesses to be aligned then
– Software is simple
– Hardware must detect misalignment and make 2 memory accesses
– Expensive detection logic is required – All references can be made slower
• Sometimes unrestricted alignment is required for backwards compatibility
• If the architecture restricts memory accesses to be aligned then
– Software must guarantee alignment
– Hardware detects misalignment access and traps – No extra time is spent when data is aligned
• Since we want to make the common case fast, having restricted alignment is often a better choice, unless compatibility is an issue
Types of Addressing Modes (VAX)
1. Register direct Ri 2. Immediate (literal)#n
3. Displacement M[Ri + #n]
4. Register indirect M[Ri]
5. Indexed M[Ri + Rj]
6. Direct (absolute) M[#n]
7. Memory Indirect M[M[Ri] ] 8. Autoincrement M[Ri++]
9. Autodecrement M[Ri - -]
10. Scaled M[Ri + Rj*d + #n]
memory
reg. file
Summary of Use of Addressing
Modes
Distribution of Displacement Values
Frequency of Immediate Operands
Types of Operations
Arithmetic and Logic: AND, ADD
Data Transfer: MOVE, LOAD, STORE
Control BRANCH, JUMP, CALL
System OS CALL, VM
Floating Point ADDF, MULF, DIVF
Decimal ADDD, CONVERT
String MOVE, COMPARE
Graphics (DE)COMPRESS
Distribution of Data Accesses by Size
Relative Frequency of Control
Instructions
Control instructions (contd.)
Addressing modes
PC-relative addressing (independent of
program load & displacements are close by)
Requires displacement (how many bits?)
Determined via empirical study. [8-16 works!]
For procedure returns/indirect
jumps/kernel traps, target may not be known at compile time.
Jump based on contents of register
Useful for switch/(virtual) functions/function ptrs/dynamically linked libraries etc.
Branch Distances (in terms of
number of instructions)
Frequency of Different Types of
Compares in Conditional Branches
Encoding an Instruction set
a desire to have as many registers and addressing mode as possible
the impact of size of register and addressing
mode fields on the average instruction size and hence on the average program size
a desire to have instruction encode into
lengths that will be easy to handle in the
implementation
Three choice for encoding the
instruction set
Compilers and ISA
Compiler Goals
All correct programs compile correctly
Most compiled programs execute quickly
Most programs compile quickly
Achieve small code size
Provide debugging support
Multiple Source Compilers
Same compiler can compiler different languages
Multiple Target Compilers
Same compiler can generate code for different
machines
Compilers Phases
Compiler Based Register Optimization
Assume small number of registers (16-32)
Optimizing use is up to compiler
HLL programs have no explicit references to registers
usually – is this always true?
Assign symbolic or virtual register to each candidate variable
Map (unlimited) symbolic registers to real registers
Symbolic registers that do not overlap can share real registers
If you run out of real registers some variables
use memory
Allocation of Variables
Stack
used to allocate local variables
grown and shrunk on procedure calls and returns
register allocation works best for stack-allocated objects
Global data area
used to allocate global variables and constants
many of these objects are arrays or large data structures
impossible to allocate to registers if they are aliased
Heap
used to allocate dynamic objects
heap objects are accessed with pointers
never allocated to registers
Designing ISA to Improve Compilation
Provide enough general purpose registers to ease register allocation ( more than 16).
Provide regular instruction sets by keeping the operations, data types, and addressing modes orthogonal.
Provide primitive constructs rather than trying to map to a high-level language.
Simplify trade-off among alternatives.
Allow compilers to help make the common
case fast.
ISA Metrics
Orthogonality
No special registers, few special cases, all operand modes available with any data type or instruction type
Completeness
Support for a wide range of operations and target applications
Regularity
No overloading for the meanings of instruction fields
Streamlined Design
Resource needs easily determined. Simplify tradeoffs.
Ease of compilation (programming?), Ease of implementation, Scalability
Quick Review of
Design Space of ISA
Five Primary Dimensions
Number of explicit operands ( 0, 1, 2, 3 )
Operand Storage Where besides memory?
Effective Address How is memory location specified?
Type & Size of Operands byte, int, float, vector, . . . How is it specified?
Operations add, sub, mul, . . . How is it specifed?
Other Aspects
Successor How is it specified?
Conditions How are they
determined?
Encodings Fixed or variable? Wide?
Parallelism
ISA Metrics
Aesthetics:
Orthogonality
No special registers, few special cases, all operand modes available with any data type or instruction type
Completeness
Support for a wide range of operations and target applications
Regularity
No overloading for the meanings of instruction fields
Streamlined
Resource needs easily determined
Ease of compilation (programming?) Ease of implementation
Scalability
A "Typical" RISC
32-bit fixed format instruction (3 formats)
32 32-bit GPR (R0 contains zero, Double Precision takes a register pair)
3-address, reg-reg arithmetic instruction
Single address mode for load/store:
base + displacement
no indirection
Simple branch conditions
Delayed branch
see: SPARC, MIPS, MC88100, AMD2900, i960, i860 PARisc, DEC Alpha, Clipper,
CDC 6600, CDC 7600, Cray-1, Cray-2, Cray-3
MIPS data types
Bytes
characters
Half-words
Short ints, OS related data-structures
Words
Single FP, Integers
Doublewords
Double FP, Long Integers (in some
implementations)
Instruction Layout for MIPS
MIPS (32 bit instructions)
Op
31 26 25 2120 16 15 0
Rs1 Rd Immediate
Op
31 26 25 0
Op
31 26 25 2120 16 15 0
Rs1 Rs2
target
Rd Opx
1. Register-Register
5 10 6
11
2a. Register-Immediate
Op
31 26 25 2120 16 15 0
Rs1 Rs2/Opx Displacement 2b. Branch (displacement)
3. Jump / Call
MIPS (addressing modes)
Register direct
Displacement
Immediate
Byte addressable & 64 bit address
R0 always contains value 0
Displacement = 0 register indirect
R0 + Displacement=0 absolute addressing
Types of Operations
Loads and Stores
ALU operations
Floating point operations
Branches and Jumps (control-related)
Load/Store Instructions
Sample ALU Instructions
Control Flow Instructions
56
Datapath vs Control
Datapath: Storage, Functional Units, Interconnections sufficient to perform the desired functions
Inputs are Control Points
Outputs are signals
Controller: State machine to orchestrate operation on the data path
Based on desired function and signals
Datapath Controller
Control Points signals
57
Approaching an ISA
Instruction Set Architecture
Defines set of operations, instruction format, hardware supported data types, named storage, addressing modes, sequencing
Meaning of each instruction is described by RTL (register transfer language) on architected registers and memory
Given technology constraints, assemble adequate datapath
Architected storage mapped to actual storage
Function Units (FUs) to do all the required operations
Possible additional storage (eg. Internal registers: MAR, MDR, IR,
…{Memory Address Register, Memory Data Register, Instruction Register}
Interconnect to move information among registers and function units
Map each instruction to a sequence of RTL operations
Collate sequences into symbolic controller state transition diagram (STD)
Lower symbolic STD to control points
Implement controller
58
Homework
A.1, A.5, A.7
