Chapter 7: Synchronization
Examples
Chapter 7: Synchronization Examples
Explain the bounded-buffer, readers-writers, and dining philosophers synchronization problems.
Describe the tools used by Linux and Windows to solve synchronization problems.
Illustrate how POSIX and Java can be used to solve
process synchronization problems.
Classical Problems of Synchronization
Classical problems used to test newly-proposed synchronization schemes
Bounded-Buffer Problem
Readers and Writers Problem
Dining-Philosophers Problem
Bounded-Buffer Problem
n buffers, each can hold one item
Semaphore mutex initialized to the value 1
Semaphore full initialized to the value 0
Semaphore empty initialized to the value n
Bounded Buffer Problem (Cont.)
The structure of the producer process
while (true) { ...
/* produce an item in next_produced */
...
wait(empty);
wait(mutex);
...
/* add next produced to the buffer */
...
signal(mutex);
signal(full);
}
Bounded Buffer Problem (Cont.)
The structure of the consumer process
while (true) { wait(full);
wait(mutex);
...
/* remove an item from buffer to next_consumed */
...
signal(mutex);
signal(empty);
...
/* consume the item in next consumed */
...
Readers-Writers Problem
A data set is shared among a number of concurrent processes
Readers – only read the data set; they do not perform any updates
Writers – can both read and write
Problem – allow multiple readers to read at the same time
Only one single writer can access the shared data at the same time
Several variations of how readers and writers are considered – all involve some form of priorities
Shared Data
Data set
Semaphore
rw_mutex
initialized to 1 Semaphore
mutex
initialized to 1 Integer
read_count
initialized to 0Readers-Writers Problem (Cont.)
The structure of a writer process
while (true) {
wait(rw_mutex);
...
/* writing is performed */
...
signal(rw_mutex);
}
Readers-Writers Problem (Cont.)
The structure of a reader process
while (true){
wait(mutex);
read_count++;
if (read_count == 1) wait(rw_mutex);
signal(mutex);
...
/* reading is performed */
...
wait(mutex);
read count--;
if (read_count == 0) signal(rw_mutex);
signal(mutex);
Readers-Writers Problem Variations
First variation – no reader kept waiting unless writer has permission to use shared object
Second variation – once writer is ready, it performs the write ASAP
Both may have starvation leading to even more variations
Problem is solved on some systems by kernel providing
reader-writer locks
Dining-Philosophers Problem
Philosophers spend their lives alternating thinking and eating
Don’t interact with their neighbors, occasionally try to pick up 2 chopsticks (one at a time) to eat from bowl
Need both to eat, then release both when done
In the case of 5 philosophers
Shared data
Bowl of rice (data set)
Semaphore chopstick [5] initialized to 1
Dining-Philosophers Problem Algorithm
Semaphore Solution
The structure of Philosopher i:
while (true){
wait (chopstick[i] );
wait (chopStick[ (i + 1) % 5] );
/* eat for awhile */
signal (chopstick[i] );
signal (chopstick[ (i + 1) % 5] );
/* think for awhile */
}
What is the problem with this algorithm?
Monitor Solution to Dining Philosophers
monitor DiningPhilosophers {
enum { THINKING; HUNGRY, EATING) state [5] ; condition self [5];
void pickup (int i) { state[i] = HUNGRY;
test(i);
if (state[i] != EATING) self[i].wait;
}
void putdown (int i) {
state[i] = THINKING;
// test left and right neighbors test((i + 4) % 5);
test((i + 1) % 5);
}
Solution to Dining Philosophers (Cont.)
void test (int i) {
if ((state[(i + 4) % 5] != EATING) &&
(state[i] == HUNGRY) &&
(state[(i + 1) % 5] != EATING) ) { state[i] = EATING ;
self[i].signal () ; }
}
initialization_code() {
for (int i = 0; i < 5; i++) state[i] = THINKING;
} }
Each philosopher i invokes the operations
pickup()
andputdown()
in the following sequence:DiningPhilosophers.pickup(i)
;/** EAT **/
DiningPhilosophers.putdown(i)
; No deadlock, but starvation is possible
Solution to Dining Philosophers (Cont.)
Kernel Synchronization - Windows
Uses interrupt masks to protect access to global resources on uniprocessor systems
Uses spinlocks on multiprocessor systems
Spinlocking-thread will never be preempted
Also provides dispatcher objects user-land which may act mutexes, semaphores, events, and timers
Events
An event acts much like a condition variable
Timers notify one or more thread when time expired
Dispatcher objects either signaled-state (object available) or non-signaled state (thread will block)
Kernel Synchronization - Windows
Mutex dispatcher object
Linux Synchronization
Linux:
Prior to kernel Version 2.6, disables interrupts to implement short critical sections
Version 2.6 and later, fully preemptive
Linux provides:
Semaphores
atomic integers
spinlocks
reader-writer versions of both
On single-CPU system, spinlocks replaced by
enabling and disabling kernel preemption
Linux Synchronization
Atomic variables
atomic_t is the type for atomic integer
Consider the variables atomic_t counter;
int value;
POSIX Synchronization
POSIX API provides
mutex locks
semaphores
condition variable
Widely used on UNIX, Linux, and macOS
POSIX Mutex Locks
Creating and initializing the lock
Acquiring and releasing the lock
POSIX Semaphores
POSIX provides two versions – named and unnamed.
Named semaphores can be used by unrelated
processes, unnamed cannot.
POSIX Named Semaphores
Creating an initializing the semaphore:
Another process can access the semaphore by referring to its name SEM.
Acquiring and releasing the semaphore:
POSIX Unnamed Semaphores
Creating an initializing the semaphore:
Acquiring and releasing the semaphore:
POSIX Condition Variables
Since POSIX is typically used in C/C++ and these
languages do not provide a monitor, POSIX condition
variables are associated with a POSIX mutex lock to
provide mutual exclusion: Creating and initializing the
condition variable:
POSIX Condition Variables
Thread waiting for the condition a == b to become true:
Thread signaling another thread waiting on the condition variable:
Java Synchronization
Java provides rich set of synchronization features:
Java monitors
Reentrant locks
Semaphores
Condition variables
Java Monitors
Every Java object has associated with it a single lock.
If a method is declared as synchronized, a calling thread must own the lock for the object.
If the lock is owned by another thread, the calling thread must wait for the lock until it is released.
Locks are released when the owning thread exits the synchronized method.
Bounded Buffer – Java Synchronization
Java Synchronization
A thread that tries to acquire an unavailable lock is placed in the object’s entry set:
Java Synchronization
Similarly, each object also has a wait set.
When a thread calls wait():
1. It releases the lock for the object
2. The state of the thread is set to blocked
3. The thread is placed in the wait set for the object
Java Synchronization
A thread typically calls wait() when it is waiting for a condition to become true.
How does a thread get notified?
When a thread calls notify():
1. An arbitrary thread T is selected from the wait set
2. T is moved from the wait set to the entry set
3. Set the state of T from blocked to runnable.
T can now compete for the lock to check if the condition it was waiting for is now true.
Bounded Buffer – Java Synchronization
Bounded Buffer – Java Synchronization
Java Reentrant Locks
Similar to mutex locks
The finally clause ensures the lock will be released in case an exception occurs in the try block.
Java Semaphores
Constructor:
Usage:
Java Condition Variables
Condition variables are associated with an ReentrantLock.
Creating a condition variable using newCondition() method of ReentrantLock:
A thread waits by calling the await() method, and signals by calling the signal() method.
Java Condition Variables
Example:
Five threads numbered 0 .. 4
Shared variable turn indicating which thread’s turn it is.
Thread calls doWork() when it wishes to do some work. (But it may only do work if it is their turn.
If not their turn, wait
If their turn, do some work for awhile …...
When completed, notify the thread whose turn is next.
Necessary data structures:
Java Condition Variables
Alternative Approaches
Transactional Memory
OpenMP
Functional Programming Languages
Consider a function update() that must be called atomically.
One option is to use mutex locks:
A memory transaction is a sequence of read-write operations to memory that are performed atomically. A transaction can be completed by adding atomic{S} which ensure statements in S are executed atomically:
Transactional Memory
OpenMP is a set of compiler directives and API that support parallel progamming.
void update(int value) {
#pragma omp critical {
count += value }
}
The code contained within the #pragma omp critical directive is treated as a critical section and performed atomically.
OpenMP
Functional programming languages offer a different paradigm than procedural languages in that they do not maintain state.
Variables are treated as immutable and cannot change state once they have been assigned a value.
There is increasing interest in functional languages such as Erlang and Scala for their approach in handling data races.
Functional Programming Languages
Homework
Exercises at the end of Chapter 7 (OS book)
