國立臺灣大學理學院海洋研究所 碩士論文
Institute of Oceanography College of Science
National Taiwan University Master Thesis
2018 年馬登-朱利安振盪(Madden-Julian Oscillation)活躍 期下風所引發之混合層加深
Wind-Induced Mixed Layer Deepening under the Active Phase of Madden-Julian Oscillations (MJOs) in 2018
葉伏家 Fu-Chia Yeh
指導教授：許哲源 博士 Advisor: Je-Yuan Hsu, Ph.D.
中華民國 111 年 12 月 December 2022
致謝
時間很快來台大也超過兩年了，在海研所的期間，修了不少課也參與五次的 航次，讓我對海洋更了解了不少，今天能完成論文，受到許多老師、同學們的幫 助，其中最感謝的莫過於我的指導教授許哲源老師，從暑假一開始找老師就給我 許多論文上的啟發，也循序漸進的帶領我了解論文所關注的議題與方向，這讓我 學習到如何去思考物理海洋上的問題，與做一個研究的過程，研究過程中老師也 給予我很大的彈性與自由規劃我自己的研究歷程，這都是我能在物理海洋學習的 一大助力。此外也要感謝張明輝老師和鄭宇昕老師，在每周的 meeting 中總是能 給我不同專業的觀點，讓我能從更多元的角度來討論我的研究，並最後擔任我的 口試委員，也謝謝曾于恒老師在模式上給予的建議，碩一跟曾老師修的課十分受 用。最後要謝謝清森跟芳瑜，雖然研界領域差比較多，但你們總是能抽空一起練 習報告或分享研究生活大小事，能和你們一路從中山來台大當同學十分的幸運，
我也會珍惜這段和你們一起學習的時光。
摘要
在北半球冬季，馬登-朱利安振盪 (MJO) 為季節內天氣系統具有顯著的深對 流，從印度洋西部開始沿著赤道向東移動。2018 年 11 月在澳洲西北所佈放的兩個 EM-APEX floats、兩個 ALAMO floats 和一個 FIO buoy，測量 2018 年 12 月中旬 MJO 通過期間的海洋溫度、鹽度、水平流速與基本大氣參數。自 12 月 14 日以來，
浮標量測到混合層在五天內從25m 快速加深到 50m，並且該段時間內 MJO 所帶來
的西風維持9 ms-1以上，引起高達0.4 ms-1的海流，破壞上層海洋的穩定。透過計
算梯度理查森數(Ri)以發現不穩定性，由於經常觀測到小於 0.25 的 Ri，因此推測
在強風作用下，上層海洋可能會出現不穩定和強烈的紊流混合。本研究使用Thorpe
scale 方法估算紊流耗散率，結果顯示混合層的紊流耗散率約為 10-7 Wkg-1至 10-6
Wkg-1，大於典型溫躍層內的紊流耗散率。在MJO 連續幾天的風力作用下，剪切不
穩定可能會發生強烈的紊流混合，從而使混合層加深。混合層加深導致海表溫度
(SST)冷卻約 1.1°C，SST 的變化改變了潛熱加顯熱量由 100 Wm-2增至400Wm-2，
並有可能影響MJO 的發展。由於混合層加深可能有助於海表冷卻，因此 MLD 變
化在模式模擬中至關重要，研究中模式結果顯示，在MJO 下使用 COARE 3.0 算法
計算的風應力可能低估。因此通過觀測資料測量與估算正確風應力，可以在模式中
更好地模擬MJO 觀測的特徵，並進一步改進 MJO 的預報。
關鍵詞：馬登-朱利安振盪(MJO)、混合層加深、海表溫度冷卻、COARE 3.0、風 應力
Abstract
During the boreal winter, Madden–Julian Oscillations (MJOs) as organized deep
convections and intra-seasonal weather systems propagate eastward along the equator,
starting from the west of the Indian Ocean. Two EM-APEX, two ALAMO floats, and an
FIO buoy were deployed in the northwest coast of Australia, which captured the ocean
responses of temperature, salinity, and horizontal current velocity during the passage of
one MJO in the middle of December 2018. The four floats captured a rapid deepening of
mixed layer depth (MLD) from 25 m to 50 m since 14th Dec in five days. At the same
time, strong westerly wind associated with MJO was mostly > 9 m s-1. The wind-induced
a strong current up to 0.4 m s-1 for destabilizing the upper ocean. The gradient Richardson
number (Ri) was computed for identifying the instability. Because the low Ri < 0.25 was
frequently observed, instability and strong turbulence might occur in the upper ocean
under the strong wind forcing. Using the Thorpe-scale method, the turbulent dissipation
rate was approximately 10-7 to 10-6 W kg-1 in the MLD, which was larger than those within
the typical thermocline. Strong turbulent mixing might occur via shear instability under
the consecutive days of wind forcing, thereby MLD deepening. MLD deepening
contributed to cooling sea surface temperature (SST) by about 1.1 °C. The heat fluxes
were modulated by SST variation from 100 to 400 W m-2. The heat flux variation might
affect the development of MJOs. Because MLD deepening may contribute to the cooling
of SST, the simulation of MLD variation is critical in models. In the study, model results
demonstrate that the computation of the wind stress using the COARE 3.0 algorithm may
be underestimated under MJO. Therefore, with correct wind stress based on the float
measurements, several features of the observations can be better captured in models and further improve MJOs’ forecasts.
Keywords: Madden–Julian Oscillations, Mixed layer deepening, SST cooling, COARE
3.0 algorithm, wind stress.
