Effects of periodontal bone loss on the natural
frequency of human canine: a three-dimensional finite
element analysis.
黃豪銘
Shen LK;Huang HM;Yu JJ;Lee SY;Lee CM;Hsieh SC
Abstract
Background/PurposeAssessing periodontal conditions has always been a concern for dental researchers. In this study, we evaluated the potential of a natural frequency (NF) analysis to detect the health status of natural human canine teeth.
Materials and methods
Three-dimensional finite element models of the human maxillary canine were constructed. NF values of the canine model were calculated with one-, two- and three-sided vertical bone loss.
Results
By simulating a modal testing experiment, the NF value for a healthy canine was found to be 2581 Hz. As the bone level was lowered, a strong linear relationship between the frequency and attachment level was demonstrated in all three models. Results from this study demonstrated that the change in the NF was < 12% in canines with a one-sided defect when the bone level varied by 10 mm from the cementoenamel junction. However, when a three-sided bony defect was simulated, the change in NF ranged from 20% to 60%.
Conclusion
This study demonstrates that the NF of the human canine decreases with various degrees of periodontal bone height loss.
