Profiles by Time Delay Boolean Networks
Tung-Hung Chueh1, Henry Horng-Shing Lu2*
1 Green Energy and Environment Research Laboratories, Industrial Technology Research Institute, Chutung, Hsinchu, Taiwan, Republic of China, 2 Institute of Statistics, National Chiao Tung University, Hsinchu, Taiwan, Republic of China
Abstract
One great challenge of genomic research is to efficiently and accurately identify complex gene regulatory networks. The development of high-throughput technologies provides numerous experimental data such as DNA sequences, protein sequence, and RNA expression profiles makes it possible to study interactions and regulations among genes or other substance in an organism. However, it is crucial to make inference of genetic regulatory networks from gene expression profiles and protein interaction data for systems biology. This study will develop a new approach to reconstruct time delay Boolean networks as a tool for exploring biological pathways. In the inference strategy, we will compare all pairs of input genes in those basic relationships by their corresponding p-scores for every output gene. Then, we will combine those consistent relationships to reveal the most probable relationship and reconstruct the genetic network. Specifically, we will prove that O( log n) state transition pairs are sufficient and necessary to reconstruct the time delay Boolean network of n nodes with high accuracy if the number of input genes to each gene is bounded. We also have implemented this method on simulated and empirical yeast gene expression data sets. The test results show that this proposed method is extensible for realistic networks.
Citation: Chueh T-H, Lu HH-S (2012) Inference of Biological Pathway from Gene Expression Profiles by Time Delay Boolean Networks. PLoS ONE 7(8): e42095. doi:10.1371/journal.pone.0042095
Editor: Frank Emmert-Streib, Queen’s University Belfast, United Kingdom Received February 21, 2012; Accepted July 2, 2012; Published August 31, 2012
Copyright: ß 2012 Chueh, Lu. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.
Funding: The authors acknowledge support from the National Science Council, National Center for Theoretical Sciences, Shing-Tung Yau Center, and Center of Mathematical Modeling and Scientic Computing at the National Chiao Tung University in Taiwan. The funders had no role in study design, data collection and analysis, decision to publish, or preparation of the manuscript.
Competing Interests: The authors have declared that no competing interests exist. * E-mail: [email protected]
Introduction
In order to understand complex biological networks and pathways, we need to investigate global structures instead of individual behaviors since there are interactions and associations between genes. Due to the invention of high throughput technology, genome-wide expression profiles can be measured simultaneously [1]. However, it is still a great challenge to identify complex biological networks from genome-wide data because the number of gene interactions is huge [2]. In recent years, there has been a significant progress in research concerning genetic network models and network reconstruction problems.
Clustering and dimension reduction are important methods for grouping genes that have similar expression profiles [3,4]. In the framework of clustering, it is important to define the degree of similarity between genes. By the method of clustering, we can group genes that have similar expressions. However, we still cannot find the causal relationship between genes. Hence, apart from the relationship of similarity, we will also have to consider another causal relationship between genes.
There have been many methods proposed in the literature to tackle the problem of genetic regulatory network reconstruction. For instance, the steady state approach have been used to model gene regulatory networks [5]. In addition, the Bayesian network model is an important technique that has been studied extensively in the past two decades [6–11]. A Bayesian network is a directed acyclic graph (DAG) comprised of two components. The first
component is comprised of nodes that correspond to a set of variables and a set of directed edges between variables with Markov properties. The second component describes a conditional distribution for each variable given its parents in the graph. Recently, Bayesian network models have been applied to analyze microarray expression and biological data [12–15]. However, Bayesian network algorithms have limitations when dealing with large-scale gene regulatory networks because of their complex modeling structure [16]. Although algorithms for reconstructing Bayesian networks have already been developed [17,18], the algorithms’ computational costs remain a concern for the searching of all potential network structures on the genome-wide expression data.
Therefore, we are considering a simpler model: Boolean networks, which have been studied extensively in a variety of contexts. Boolean networks [19,20] can effectively explain the dynamic behaviors of living systems. Moreover, for large-scale gene regulatory networks, Kim et al. [21] have used Boolean network with chi-square test on the yeast cell cycle microarray gene expression data sets. The chaos and attractors of Boolean network are also discussed widely from the aspect of power spectrum [22–24]. Recently, Boolean network also have been used as a discrete model for the lac operon [25].
Boolean networks were originally introduced by Kauffman, and received attention in the studies of gene regulatory networks because of their simple structures [26]. In a Boolean network
model, nodes represent the gene expression states. The status of a gene is quantized to one of the two states: on or off, representing a gene as active or inactive respectively. The wiring of rules between nodes in the graph represents a functional link between genes and determines the expressions of target genes after giving a series of input genes. Under the structure of Boolean networks, the target gene is determined by a set of genes with specific rules. For each gene, if the indegree (i.e., the number of input genes to each gene) is bounded by a constant K, only O( log n) pairs of state transition are necessary and sufficient to reconstruct the original network with n nodes [27,28]. However, Boolean networks have been criticized for their deterministic nature. The assumption that every affected gene would be expressed immediately at the next time step may be unsound.
Another point of view of constructing genetic network is to focus on the indication the pairwise relationships between genes. Most of the works is to find the gene-pairs with similarity relationship [29– 33]. The similarity of a gene-pair represents the two genes with the same expression or opposite expression. In 2005, Li and Lu proposed directed acyclic Boolean network and the statistical reconstruction method of SPAN to infer the pair wise relations of every element [34]. The proposed method can reconstruct Boolean networks from noisy array data by assigning an s-p-score for every pair of genes. In the study, they proposed another relationship between two genes: relationship of prerequisite under the Boolean network model. If gene A is a prerequisite for gene B, then the ‘‘on’’ status of gene A is necessary for the ‘‘on’’ status of
gene B. Boolean implication network, with the similar aspect, investigated all Boolean implication between pairs of gene for large scale genome microarray datasets [35]. Following the model, Wang et al.[36] proposed a two step counting approach for constructing biological pathways with Boolean network. However, most of these methods only consider pair wise relationship in order to decrease the time complexity. Therefore, if the structure of network is a combination of a set of genes to affect another gene, the algorithms will lose some information and rules in the genetic network reconstruction.
In this study, we will consider a much more generalized model by combining the structure of the above two models. If a Boolean function with one or several genes is a prerequisite for a target gene, then the induction of the Boolean function with input genes is necessary for the expression of the target gene. Hence, the target will be influenced by the Boolean function with several input genes. However, the induction of the Boolean function may not activate the target gene immediately, but at a future time. Therefore, the target gene may not have been influenced right now and we will treat these relationships as time delay affection. In this study, we will infuse these additional relationships for more generalized systems.
Boolean Network
Boolean networks were introduced by Kauffman (1969) forty years ago to represent genetic regulatory networks. First, we will review the definition of a Boolean network. A Boolean network G(V ,F ) is a directed graph consisting of two components: a set of nodes V ~fv1,v2, . . . ,vng that corresponds to genes, and a list of
Boolean functions F ~ff1,f2, . . . ,fng that corresponds to the rule
of interaction and combination of several genes. For every node vi[V , its expression is simplified to two levels: on and off,
representing a gene as active or inactive. For every Boolean function fi(vi1,vi2, . . . ,vik)[F , k specified input nodes vi1,vi2, . . . ,vik are assigned to the node viin the graph and represent the rules of
regulatory mechanisms between genes. The expression of a gene is determined by the expression of the gene directly affecting it with a
Boolean function. Therefore, the state of each node vi[V is
determined by the Boolean function fi(vi1,vi2, . . . ,vik).
For each node vi, the gene expression state at time t is assumed
to take either 0 (not-expressed) or 1 (expressed) and is expressed as yt(vi). In a Boolean network, every gene expression profile at time
tz1 is completely determined by the expression profile of a set of genes vi1,vi2, . . . ,vik at time t and the corresponding Boolean
function fi[F . That is, we can write
ytz1(vi)~fi(yt(vi1),yt(vi2), . . . ,yt(vik)).
Figure 1. Boolean networkG(V,F), wiring diagramG9(V9,F9) and its input/output. doi:10.1371/journal.pone.0042095.g001
Figure 2. One example of time delay Boolean network and its input/output.
For convenience, we converted the Boolean network G(V ,F ) to the wiring diagram G’(V ’,F ’) (See Figure 1) [37]. For each node vi[V , suppose vi1,vi2, . . . ,vik are the input nodes assigned to vi. Then we construct an additional node v’
iand connected the edge
from vij to vi’ for each 1ƒjƒk. That is, the set of fv1, . . . ,vng represents the gene expression profile at time t and the set of fv’
1, . . . ,v’ng corresponds to the gene expression profile at time
tz1. Hence we can treat the set offv1, . . . ,vng as the input values
and the set of fv’
1, . . . ,v’ng as the corresponding output values.
Therefore, the output values of fv’
1, . . . ,v’ng are determined by
v’
i~fi(vi1, . . . ,vik).
The Structure of Time Delay Boolean Network
In the previous subsection, we found that given the values of the node (V ) at time t, the expressions at time tz1 will be updated immediately by specific Boolean function (F ). That is, for every
gene vi[V , if the expression profile of a set of genes
fvi1,vi2, . . . ,vikg at time t and the corresponding Boolean function fiis observed, the gene expression of viat time tz1 is determined
by ytz1(vi)~fi(yt(vi1),yt(vi2), . . . ,yt(vik)). However, in real genetic regulatory situations, the deterministic system has been criticized due to the existence of misclassification error and noise. In addition, some of the gene expression may result in time delay when the gene is influenced by one or several input genes. That is, the induction of Boolean function may not activate the target gene immediately, but in the future. Hence, it would have been much more flexible to use a non-deterministic network system. In this
subsection, we will consider two relationships between the Boolean function and the target gene instead of the deterministic relation. First, we will introduce the structure of time delay Boolean networks. Suppose there are n elements, v1,v2, . . . ,vnin a Boolean
network. For any elements viwith specific Boolean function fi, we
have two kinds of pair wise relationship: prerequisite and similarity. We say that a Boolean function fi with specific k input genes
vi1,vi2, . . . ,vik at time t is the prerequisite for the target gene viat time tz1, if the on-status of Boolean function at time t is necessary for the on-status of gene viat time tz1. This relationship is denoted
by fi(yt(vi1),yt(vi2), . . . ,yt(vik))[ytz1(vi). In other words, if the
Boolean function fiis not active at time t, gene viwill be inactive at
time tz1. If it does not cause confusion, we will omit the notation of y and input genes as denoted by fi[vi. Moreover, for every gene vi,
we use vvi as its dual (from 0 to 1, or from 1 to 0) in this paper.
Therefore, for any Boolean function and target gene with a prerequisite relationship there are a total of two possible relation-ships: fi[vi and fi[vvi. In this model, we do not consider the
situation of a dual of Boolean function prerequisite to the target gene, that is ffi[viand ffi[vvi. Since for any Boolean function whose
dual is a prerequisite to the target gene, there must exist another Boolean function that is a prerequisite to the target gene. For instance, if ffi(v1,v2)[v3, where fi(v1,v2)~(v1and v2), then
f’
i(v1,v2)[v3, where fi’(v1,v2)~(vv1or vv2). Therefore, for the
prerequisite relationship, we only consider the Boolean function that is a prerequisite to target gene and the dual of target gene.
The other type of relationship between Boolean function and target gene is similarity. We say that the Boolean function fiand
Table 1. Count and probabilities table for vj, vhand v’iassuming no misclassification error.
v9i/vjvh 00 01 10 11 v9i/vjvh 00 01 10 11
0 m000 m010 m100 m110 0 q000 q010 q100 q110
1 m001 m011 m101 m111 1 q001 q011 q101 q111
doi:10.1371/journal.pone.0042095.t001
Table 2. Count profiles for the basic eight relationships without misclassification error.
(vjorvh)[v9i (vjorvh)[vv0i v9i/vjvh 00 01 10 11 v9i/vjvh 00 01 10 11 0 + + + + 0 0 + + + 1 0 + + + 1 + + + + (vjor vvh)[v’i (vjor vvh)[vv0i vjvhv’i/ 00 01 10 11 vjvhv’i/ 00 01 10 11 0 + + + + 0 + 0 + + 1 + 0 + + 1 + + + + (vvjor vh)[v’i (vvjor vh)[vv0i vjvhv’i/ 00 01 10 11 vjvhmiv’i/ 00 01 10 11 0 + + + + 0 + + 0 + 1 + + 0 + 1 + + + + (vvjor vvh)[v’i (vvjor vvh)[vv0i vjvhv’i/ 00 01 10 11 vjvhv’i/ 00 01 10 11 0 + + + + 0 + + + 0 1 + + + 0 1 + + + + doi:10.1371/journal.pone.0042095.t002
target gene viare similar if the status of the Boolean function and
the status of the target gene are in the same expression, and we denoted this by fi,vi. In the same way, we do not consider the situation of Boolean function similar to the dual of target gene such as fi,vviin this study. Since if there is one Boolean function
that is similar to the dual of target gene, there must exist another Boolean function that is similar to the target gene.
In the diagram, if a Boolean function fiis a prerequisite to vi, we
draw a directed arrow from the vertex fito viand if fiis similar to
vi, we use an undirected line to connect fiand vi.
In the model of time delay Boolean network we proposed, the output of the gene expression is not completely determined by the input state and Boolean function. The output expression may have more than one possible result in the time delay Boolean network. We illustrate the above construction by an example in Figure 2. It has three elements, one similarity and two prerequisite relation-ships. The possible outputs for every input state are listed in the right part of the graph. If we knew the network structure, some of the inputs would have more than one possible output expression in the time delay Boolean network.
Methods
Identification Algorithm
First, we only consider Boolean networks in which the maximum number of input genes is bounded by a constant K for every target gene, because it has been proven that the number of profiles required grows exponentially if K is not bounded [38]. For simplicity, we only show algorithms for the case of K~2. However, the algorithm can be intuitively generalized to any K in a straightforward way. For the inference of genetic network, we need to clarify the following questions for each target gene.
N
Which input genes will affect the target gene?N
What kind of Boolean functions will be used for combiningthose input genes?
N
What kind of relationship exists between the Boolean function and the target gene?In this subsection, we propose an algorithm to clarify the above questions. The algorithm below is conceptually very simple since it simply uses output Boolean functions with input genes and relationships with target genes that are consistent with the data. First, for each output gene expression at time tz1 such as v’
i, we
consider all the pairs of elements in V at time t, for instance vjand
vh. Then we count the eight incidents of (vj,vh,v’i) being (0,0,0),
(0,0,1), . . ., (1,1,1) from the sample and arrange them in a 2|4 table; see the left part of Table 1. We mark a cell ‘‘+’’ if the count is positive and mark it ‘‘0’’ otherwise.
For detecting whether there exists a Boolean function which is a prerequisite to the target gene, we will compare the 2|4 output table with the left four basic relationships in Table 2. We consider the basic relationships to be consistent with the output table if the position of 0 cell in the basic relationships is also 0 in the output table. By comparing the output table with the four basic relationships, we can find relationships that are consistent with the output tables. If there is more than one relationship that is consistent with the output tables, we would use the Boolean logic gate ‘‘and’’ to combine the Boolean function and transfer the result to another Boolean function. Hence, the final Boolean function is the prerequisite to the target gene. Similarly, by comparing the 2|4 output table with the right four basic relations in Table 2, we could get another Boolean function which is the prerequisite to the dual of target gene.
Moreover, if only one Boolean function occurred in above relationship, that is, if there is only one Boolean function that is the prerequisite to the target gene or the dual of target gene, we will treat that relationship as our final relationship between the Boolean function and the target gene. However, if both of the two prerequisite relationships happened (i.e. Afiand f ’is:t: fi[v’iand
f ’i[vv’i), we need to check whether these two relationships are in
conflict. If the dual of fi is equivalent to f ’i, our conclusion for
inference will be that fiis similar to the target gene (that is, fi*v’i);
Table 3. Count and probabilities table for vj, vhand vi’with misclassification error.
v9i/vjvh 00 01 10 11 v9i/vjvh 00 01 10 11
0 n000 n010 n100 n110 0 r000 r010 r100 r110
1 n001 n011 n101 n111 1 r001 r011 r101 r111
doi:10.1371/journal.pone.0042095.t003
Table 4. Splitting counts caused by misclassification error.
v9i/vjvh 00 01 10 11 m000,000 m000,001 m010,000 m010,001 m100,000 m100,001 m110,000 m110,001 0 m000,010 m000,011 m010,010 m010,011 m100,010 m100,011 m110,010 m110,011 m000,100 m000,101 m010,100 m010,101 m100,100 m100,101 m110,100 m110,101 m000,110 m000,111 m010,110 m010,111 m100,110 m100,111 m110,110 m110,111 m001,000 m001,001 m011,000 m011,001 m101,000 m101,001 m111,000 m111,001 1 m001,010 m001,011 m011,010 m011,011 m101,010 m101,011 m111,010 m111,011 m001,100 m001,101 m011,100 m011,101 m101,100 m101,101 m111,100 m111,101 m001,110 m001,111 m011,110 m011,111 m101,110 m101,111 m111,110 m111,111 doi:10.1371/journal.pone.0042095.t004
otherwise, we will treat it as if there is no relationship between the input genes and the target gene because we did not gather enough information to judge true relationships between v’i and (vj,vh) at
this moment. By the above identification procedure, we can find the corresponding input genes, Boolean function and their relationship for every target gene.
Identification Algorithm with Noisy Array
In previous subsection, we discussed an identification method for data without noise. In this section we will consider the situation of noisy array data. We assume that every element in the entry of (Iij, Oij), j~1,2, . . . ,m switches to its reverse status with a
misclassification probability p independently; that is
Iij~ Iij with probability 1{p ;
1{Iij with probability p :
ð1Þ
Oij~ Oij with probability 1{p ;
1{Oij with probability p :
ð2Þ
Thus, the observed array (Iij, Oij) contains misclassification error. Our goal is to reconstruct time delay Boolean network from noisy array of binary data (Iij,Oij).
Similar to section 2, we assume that the maximum number of input genes is bounded by 2 for every target gene. We treat the data in the 2|4 table as a multinomial distribution with eight cells whose probabilities are q000,q001, . . . ,q111 as shown in the right
part of Table 1, where q000zq001z . . . zq111~1. Similarly, we
extract the data with misclassification error for every output gene and each pair of input genes as the 2|4 table. Now the observed data n000,n001, . . . ,n111 are not generated from the multinomial
q000,q001, . . . ,q111, but from another multinomial r000,r001, . . . ,r111
as shown in Table 3, where r000zr001z . . . zr111~1.
Because of the misclassification error, a portion of the samples of m000may change to the other seven cells. We use the notations
of m000,000,m000,001, . . . ,m000,111 to represent the counts of eight
cells changed from m000. Analogous notations are defined for
m001,m010, . . . ,m111. The splitting is shown in Table 4.
Conse-quently, the generated probabilities (q000,q001, . . . ,q111) are
calcu-lated as follows: qi1i2i3,j1j2j3~p
I (i,j)(1{p)3{I (i,j)q
i1i2i3, where I (i,j)~P3k~1Dik{jkD. Here, we adopt the notation qi1i2i3,j1j2j3 analogous to mi1i2i3,j1j2j3. The above parameters and splits are
shown in Table 4. In the table, it is easy to find that the correspondence between two sets of counts and probabilities is the following: nj1j2j3~ P i1,i2,i3~0,1 mi1i2i3,j1j2j3 rj1j2j3~ P i1,i2,i3~0,1 qi1i2i3,j1j2j3 8 > < > : and ð3Þ mi1i2i3~ P j1,j2,j3~0,1 mi1i2i3,j1j2j3 qi1i2i3~ P j1,j2,j3~0,1 qi1i2i3,j1j2j3 8 > < > :
For the complete datafmi1i2i3,j1j2j3g, the log-likelihood is given by
L~ X
i1,i2,i3,j1,j2,j3~0,1
mi1i2i3,j1j2j3log qi1i2i3,j1j2j3 ð4Þ
where qi1i2i3,j1j2j3 are those splitting probabilities. Since the complete datafmi1i2i3,j1j2j3g are not observable, we use the EM algorithm to maximize the log-likelihood. In the E-step, the splitting counts of complete datafmi1i2i3,j1j2j3g are evaluated by the conditional expectations using the current values of the parameters by the following formula
Ep,q000,q001,...,q111(mi1i2i3,j1j2j3Dnj1j2j3)~ nPj1j2j3qi1i2i3,j1j2j3
i’1i’2i’3~0,1
qi’1i’2i’3,j1j2j3 ð5Þ
where i1,i2,i3,j1,j2,j3~0,1. One probabilities of q000,q001, . . . ,q111
are zero in those different hypotheses specified in Table 5. In the M-step, we maximize the conditional expectation of the log-likelihood for the complete data to obtain the maximum log-likelihood estimates (MLEs) of the parameters. According to the MLEs, we can compute the p-score for every pair of input genes and target gene, which are obtained by estimating for the misclassification probability under every prerequisite relationship.
For the first step, we would like to determine the most probable relationships between every pair of input genes and one output gene. Next, we find the most probable Boolean function with pair input genes for every output gene and select candidate pairs of input genes and output gene for the watch list. Finally, we reconstruct a time delay Boolean network by integrating the relationship of those genes selected.
For one output gene v0iand a pair of input genes vjand vk, we
define the p-scores p(v
jor vk)[vv0i, p(vjor vvk)[vv0i, p(vvjor vvk)[vv0i, p(v
jor vk)[v0i, p(vvjor vk)[v0i, p(vjor vvk)[v0i, p(vvjor vvk)[v0i are, respective-ly, the maximum likelihood estimates of p under the triangular model: q000~0, q010~0, q100~0, q110~0, q001~0, q011~0,
q101~0, q111~0.
According to the EM algorithm described above, we can evaluate the p-score for every output gene. We use the MLE ^pp to measure how well each hypothesis fits: the smaller the score is, the more likely that the corresponding hypothesis could be true.
If the samples are generated from a time delay Boolean network, p-score are quite useful for the discovery of true Table 5. The eight basic relationships and their probabilistic
hypotheses and p-scores.
Relation Hypothesis Scores
(vjor vh)[vv0i q000= 0 p(vjor vh)[vv0i (vjor vvh)[vv0i q010= 0 p(vjor vvh)[vv0 i (vvjor vh)[vv0i q100= 0 p(vvjor vh)[vv0i (vvjor vvh)[vv0i q110= 0 p(vvjor vvh)[vv0 i (vjor vh)[v’i q001= 0 p(vjor vh)[v’i (vjor vvh)[v’i q011= 0 p(vjor vvh)[v’i (vvjor vh)[v’i q101= 0 p(vvjor vh)[v’i (vvjor vvh)[v’i q111= 0 p(vvjor vvh)[v’i doi:10.1371/journal.pone.0042095.t005 ð3Þ
relationships. Here we can consider the maximum compatibility criterion: to choose the maximum threshold value so that the selected relationships contain no conflicts [34]. We collect those relationships whose p-scores are smaller than a threshold. Known biological results are helpful for the determination of a threshold. For example, if we know the relationship (v1 or v2)[v3 is true,
then the p-scores smaller than p(v1or v2)[v3 should be in our watch list. As more relationships are included in the watch list, the more likely we are to observe incompatible ones. In general, we can choose the threshold that allows the maximum number of relationships with no conflicting relationships. Next we will demonstrate the method by illustration examples.
Results and Discussion Theoretical Results
First, we will analyze the number of input/output pairs required for the network reconstruction of time delay Boolean network to be unique. The theoretical results of classical Boolean networks only consider the similar relationship [27,38,39]. The following results prove the theoretical results time delay Boolean networks that has a more flexible structure and consider both similar and prerequisite relationship.
Proposition 1. For all subsets of V with 2K genes, if all assignments (i.e., 22K assignments) of Boolean values appear in input expression patterns
and all of its possible output expression patterns of the target gene are present, the identification of genetic network is determined to be unique, if it exists.
(Proof) Let z be any gene in V and suppose z is controlled by a Boolean function g(xi1, . . . ,xik) with similarity or prerequisite relationship (i.e., g*z or g[z). If the Boolean function g is similar to z, the case is proved for the classical Boolean networks in Akutsu et al. (1998). Next, we consider the case of Boolean function g as a prerequisite to z. In this case, there must exist a specific input value fa1, . . . ,akg for fxi1, . . . ,xikg such that z have two possible values 0 and 1. Hence, any other genes would not control z because all assignments of Boolean values are appearance. Let us illustrate the above statement by the example for the case of K~1 and K~2. If K~1 and x[z, when the input of x is 1, the outcome of z being both 0 and 1 will appearance. Therefore, given the input of x~1, the outcome of z is not deterministic no matter the value of any other gene y is 1 or 0. Hence, any other gene y would not affect gene z. If K~2 and g(x1,x2)[z for some Boolean function g,
there must exist an input (a1,a2) such that g(a1,a2)~1. Then, for
any other pair of genefy1,y2g where fy1,y2g\fx1,x2g~w, the
outcome of z is not deterministic for any input offy1,y2g, if the
input offx1,x2g is fa1,a2g. In a case of fy1,y2g\fx1,x2g=w, we
can prove that gene yiwhich does not belong tofx1,x2g would
not affect the gene z in a similar way.
Proposition 2. The probability that one sub-assignment with all of its possible results in the target gene does not appear among m random input expression pattern is at most 2(1{ 1
22Kz1) m.
(Proof) For any fixed set of nodes fvi1,vi2, . . . ,vi2Kg, the probability that a sub-assignment vi1~vi2~ . . . ~vi2K~1 does
not appear in one random input expression pattern is 1{ 1
22K.
Thus, among the m random input expressions, the probability that vi1~vi2~ . . . ~vi2K~1 appears is t times is equal to
m! t!(m{t)!( 1 22K) t(1{ 1 22K)
m{t, where tƒm. In addition, the
probability that all of the possible results in the target gene does
not appear among t times input is smaller than (1
2)
t{1
for 1ƒtƒm and equal to 1 for t~0. Hence the probability that one sub-assignment and all of its possible results does not appear
among m random input expression is smaller than
(1{ 1 22K) mzXm t~1 m! t!(m{t)!( 1 22K) t(1{ 1 22K) m{t(1 2) t{1, and
this can be bounded by 2(1{ 1
22Kz1) m
by an algebra calculation. Table 6. By the time delay Boolean network in Figure 1, we generate 100 samples with p = 0.05.
Samples Hypotheses Relation
Input Output q000= 0 q010= 0 q100= 0 q110= 0 q001= 0 q011= 0 q101= 0 q111= 0 v1,v2 v19 0.493 0.418 0.273 0.379 0.148 0.178 0.372 0.343 v1,v3 v1 9 0.438 0.147 0.248 0.222 0.016 0.245 0.182 0.241 (v1or v3)[v91 v2,v3 v19 0.318 0.260 0.571 0.214 0.189 0.293 0.138 0.374 v1,v2 v29 0.326 0.300 0.304 0.297 0.091 0.092 0.232 0.209 v1,v3 v2 9 0.338 0.216 0.349 0.197 0.039 0.069 0.038 0.243 (v1and v3)[v92 v2,v3 v29 0.326 0.253 0.390 0.174 0.052 0.141 0.017 0.169 v1,v2 v39 0.211 0.011 0.355 0.029 0.040 0.228 0.011 0.294 v1,v3 v3 9 0.338 0.290 0.402 0.734 0.669 0.291 0.379 0.360 v2,v93 v2,v3 v39 0.247 0.312 0.030 0.011 0.039 0.011 0.283 0.241 doi:10.1371/journal.pone.0042095.t006
Figure 3. Network reconstruct from the expression data of yeast Saccharomyces cerevisiae.
Next we prove the main theorem.
Theorem 1. For the identification of one time delay Boolean network of
n nodes with maximum indegree ƒK, O(22Kz1:(2Kza): log n)
uniformly and randomly sampled input patterns are sufficient for exact inference with probability at least 1{1
na.
(Proof) We consider the probability that the condition of Proposition 1 is not satisfied under m random input expression patterns.
By Proposition 2, the probability that vi1~vi2~ . . . ~vi2K~1 with all of its possible results in the target gene does not appear among the m random input expression patterns is bounded by
2(1{ 1
22Kz1) m
for any fixed set of nodesfvi1,vi2, . . . ,vi2Kg. Since the number of combinations of 2K nodes from a set of n possibilities is bounded by 22K:n2K, the probability that the
condition of Proposition 1 is not satisfied is at most
22K:n2K:2(1{ 1
22Kz1) m
. It is not difficult to see that
22K:n2K:2(1{ 1
22Kz1)
mvp holds for mw ln 2:22Kz1:(2Kz1z
2K log nz log1
p). Hence, we obtain the theorem by letting the
non-identification probability p~1 na.
Next we develop an information theoretic lower bound on the number of input/output pairs needed for the identification of a time delay Boolean network.
Theorem 2. If the maximum indegree ƒK, at least V(2KzK log n) input/output pairs are required for the identification of a
time delay Boolean network in the worst case.
(Proof) The number of time delay Boolean networks is given by all the possible combination of Boolean function with k nodes from a set of n possibilities with all possible relations between Boolean functions with target node. Since there are V(nK) possible
combinations of input nodes, 22Kpossible Boolean functions and 3 possible relations between Boolean function with each node, there are V((22K
:nK:3)n) Boolean networks whose maximum indegree is
at most K. On the other hand, there are at most 2npossible output
patterns with one input expression pattern. Therefore,
V(log2n((22 K
:nK:3)n)) which is the same as V(2KzK log n)
input/output pairs are required in the worst case.
Example with Simulation and Real Data
We will illustrate our method by the example described in Figure 2. For the pair of samples consist of three elements list in the right part of Figure 2, we uniformly generated 100 input samples and their corresponding possible output samples with misclassification probability p~0:05. For the prerequisite rela-tionship, if the status of Boolean function with input genes is on, then we allow the output value to have equal probability of on or off. The data can be arranged as input/output sample similar to that obtained from the microarray data with time. Namely, the input of each sample can represent the gene expression at time t and the output can represent the gene expression at time tz1. For each pair of input and output genes, we compute the 8 basic p-scores that represent the 8 basic hypotheses in Table 5 for all of pair input genes and output genes. After the calculation, the simulation results of every p-score are listed in Table 6.
Beside the example with 3 elements, in order to shows the superiority of the proposed method can be applied to a larger network, a more comprehensive example with a larger network is given in Figure S1.
Next, we have to decide the threshold for choosing the relations. When we increase the threshold of the p-score, the relations whose p-score are smaller than the threshold will be chosen. Moreover, when the number is 0.138, the conflict occurs, since we have (v1or v3)[v’1and (vv2or v3)[v’1. However, in our model, there
are at most two genes that would affect an output gene. Therefore, we can choose 0.138 as our threshold and include relations whose p-score is smaller than the threshold. By these procedures, we can reconstruct the time delay Boolean network identical to Figure 2. In the area of gene regulatory network study, Schuller has summarized regulatory cis-acting elements of structural genes of the nonfermentative metabolism and described the molecular interactions among general regulators and pathway-specific factors [40]. In the gene regulation of gluconeogenesis by Sip4 and Cat8 pathway, the carbon source control could be identified for the regulator Cat8; see (Figure 6) in Schuller [40]. In this study, we apply our proposed approach to explore the expression profiles and show some exploratory result on the Cat8 pathway.
In order to demonstrate the effectiveness of reconstruction, we use the microarray expression dataset of yeast Saccharomyces cerevisiae produced by DeRisi et al. [1] and Spellman et al. [41]. In total, the data is comprised of 41 experiments after filtering out experiments with missing values. By these experimental micro-array data sets, we can use our proposed method to reconstruct the biological pathway and the genetic regulation network result is shown in Figure 3. The result is consistent with the genetic network in the literature. That is, the restraint of Mig1 or activation of Snf1 is a prerequisite for the decreasing of Cat8. Moreover, the restraint of Snf1 or Cat8 is a prerequisite for the decreasing of Mls1. However, the negative similarity between Snf1 and Mig1 is undetectable in our current model.
Conclusions
In this paper, we have introduced the model of time delay Boolean network that generalizes the Boolean network model in order to cope with dependencies that have two kinds of relationships: similarity and prerequisite. The approach for reconstruction of genetic network inference from gene expression data relies on the assumption that the expression of a gene is likely to be controlled by a relatively small number (say k) of genes. Also, some bounds on the size of data required for the identification of the time delay Boolean networks under constant of indegree are stated and discussed. Moreover, the algorithm of the network reconstruction from noisy array data is developed.
One characteristic of a Boolean network is that all the variables in the graph are binary. If the data we observed is continuous or quantized to have more than two levels, we need to discretize them. For microarray data, the ratios of expression level would be one possible approach of discretization. That is, we can treat the gene as on (active) if the log-ratio of its expression is larger than zero. We treat it as off (inactive) otherwise. In general, biological background knowledge will be helpful for setting thresholds for discretizaion. On the other hand, if the samples are obtained from a time course, then we can consider the gene as on or off by detecting whether the gene is either increasing or decreasing with time.
The work in progress is aimed at evaluating the effectiveness of the described approach for inferring genetic networks from biological gene expression time series data. Besides that, imple-mentation on some other real biological data is also an important task.
For the implement of the network reconstruction algorithm, the greatest complexity is the computation of p-score for each of the
n!
k!(n{k)! input elements and n output elements, where n is the
number of elements and k is the number of indegree. It is an iterative algorithm to compute the MLE for the p-scores by EM procedure while the common practice is to set an upper bound for iterations in numerical implementation. Consequently, this keeps the O(nkz1) complexity for the computation of MLE. In addition, the sorting algorithm for the n!
k!(n{k)!n data cost O(n
kz1log n) in
terms of time. Hence, the overall time complexity for the network reconstruction is O(nkz1log n) for this algorithm.
