NCTU / UNICODE, team of National Chiao Tung University, is taking Solar Decathlon Europe as the opportunity to develop a prototype house for co-existing with nature by focusing on the green house technology that has been developed for cultivating orchid in Taiwan combining with the research institute here in NCTU. The university’s main campus is located at the center of the Hsinchu Science Park, Taiwan’s national research center. The area is referred to as the Silicon Valley of Asia. More than 400 technology companies have been established in the park.
Taiwan is located on the eastern edge of the Asian continental shelf with complex geological and topographical surroundings where the rivers are short and swift and natural disasters such as typhoons, flooding and earthquakes are a frequent occurrence. In essence, Taiwan is an island whose ecosystem is both vulnerable and isolated. With its high population density and scarce land and natural resources, the rapid development that it has undergone in the past decades has inflicted much damage on its natural environment and posed a great threat to the habitats of its diverse fauna and flora.
Since the limited land resources of an island country constitute an innate limitation on its development, the most important issue for its sustainable development should be to make optimum use of such land resources as it possesses. And that is especially so in Taiwan’s case, as two thirds of its land area is mountainous and only one quarter is suitable for agricultural production, which further limits the supply of land that can be used for farming and socio-economic activities apart from forestry, water resources, and mining.
Our house design concept is based on the Taiwanese local conditions, however, we believe those systems are
a p p l i c a b l e t o a ny o t h e r locations of earth. Here are the sustainable approaches to the house, which we have incorporated during the design process:
NCTU Unicode concerns that how to develop a prototype house for co-ex¬isting with nature by focusing on the green house technology that has been developed for cultivating orchid in Taiwan. In order to create comfort living space, the high temperature and humidity is biggest issue to solve. We believe that less energy usage for climate control in the house bring the project more sustainable development and helps the house to find market not also in Taiwan but other countries as well. We want to find solar house solution with the local condition, but also be able to apply in wider range of locations as well.
Concept
We take the most of design concept for project from the local conditions in Taiwan, such as island climate, available technology, industrialization methods, and social housing issues.
Island climate
Taiwan lies on the Tropic of Cancer, and its climate is marine tropical. The northern part of the island has a rainy season that lasts from January through late March during the northeast monsoon. The entire island experiences hot, humid weather from June through September. In order to create comfort living space, the high temperature and humidity is biggest issue to solve. We believe that less energy usage for climate control in the house bring the project more sustainable development and helps the house to find market in Taiwan.
Project
Green house technology
When we start developing our house concept, we look into the green house technologies that are available in Taiwan, especially for the orchid house. Taiwan is one of the most famous countries for the orchid and holds huge industry for it. We noticed how advance the green house technology is and realized it is ideal for our house to implement them for temperature and humidity control of our inside space.
Social housing issues
We are also aware of the issues in social housing in Taiwan and trying to adopt our house to improve the condition. The housing system in Taiwan has been fully commercialized. Public housing originally fulfilled a social function, but almost every unit has since been sold off and privatized. As a result, public housing policy has been likened to a lottery. The system ignores disadvantaged groups, social justice and low-income housing: rented housing accounts for only 0.08 percent of public housing. We realize that the system we develop for the Solar Decathlon Europe is also applicable for the social housing for the renewable energy to reduce the utility cost as well as the comfortable living space.
Industrialization methods
The advantage of integrating green house technology to our house is the existing industrialized market in Taiwan, which is necessary for lowering the construction cost and market price of the house.
We can all learn from Nature. A house is like a plant. The leaves create dewdrops, and the root absorbs water, circulate in the stems, and the leaves performs photosynthesis. This cycle creates water and energy, properly stored, then supply to the entire plant. Our house will function the same, as the solar panels absorb light from the sun, converted and stored in the battery, then supply to the rest of the house. We can also harvest our own water, circulate, recycle and reuse.
1. Light weight structure with BIPV (Building Integrated Photovoltaic) system
2. Highly insulated structural panel for living space 3. Solar thermal water device for radiant flooring 4. Humidity and temperature control system develop upon the green house technology. 5. Water circulation systems
Team NCTU UNICODE | Orchild House | Solar Decathlon Europe 2014
5
Design Approach
Our house design concept is based on the Taiwanese local conditions, however, we are confident that those systems are applicable to any other locations of earth. We are expecting much drier climate condition during the Solar Decathlon Europe 2014 in Versailles, France, which is almost opposite climate from one in Taiwan. It will be challenging for us to archive the house to function in the both dry and wet condition well, however, this experience will lead us to market our house in different cities and countries.
The envelop of house is composed with light weight structure with BIPV (Building Integrated Photovoltaic) system, solar thermal water device, and humidity and temperature control system develop upon the green house technology. The green house space is not only to control indoors temperate and humidity, but also to create semi-outdoor space for comfortable living experience. The key element for this envelop is “WATER” that is circulating within the lightweight structure. The solar thermal system will be heated up the water during the day and stored for shower and radiant floor, while green house system will use the water for cooling the space. The lightweight structure will allow the easy and short time construction, and also low construction budget.
Objectives
Social Housing Application
At last, but not least, we like to talk about the possible development of our solar house to new type of Taiwanese social housing system. Due to the lack of social housing number, the government is eager to solve housing issue in Taiwan. We believe that our industrialization manufacturing process will reduce the load of construction worker and shorten the construction time, which ends up with lowering the construction budget. In order to transform our single dwelling design into multi-floor collective housing, we will introduce the vertical wind tunnel, which also act as main load bearing wall of the building. This wall will incorporate water filtering system as well as thermal water system for the cooling and heating of the units. Even though we will try to run all the electricity from the PV system for the prototype house, the social housing will mainly utilize the harvested electricity for common area and building utilities for not over budgeting the project. The report, which includes the data from Solar Decathlon Europe 2014, will be submitted as a proposal to the housing ministry of Taiwan after the competition of the project.
Rooftop
People owning the top floor in Taiwan would utilize the rooftop space for extending their living space. However, water tanks and the metal roof create an unpleasant visual impression of culture landscape which has been seemed the special characteristic of Taiwan.
In order to change the culture landscape caused by living necessity, NCTU Unicode takes serious consideration to not only make an improvement of the visual part but also make benefit through creating a sustainable system which could increase the energy conservation and cuts down the house utility costs. Since this sustainable roof system could be beneficial for environment, there are more potential possibility and feasibility of marketing in the future Taiwan. The best and most intension of NCTU Unicode is to create a single dwelling prototype focusing on the environment issue, which is able to reduce the heat island effect and build a feasible drain system as a role of cleaning the city which is the most necessary part in the future Taiwan. We care about the "green rooftop system" and intend to create the passive wind ventilation system; the drain system and the passive solar system to respond energy saving. Thus, these strategies of focusing on the environment may accelerate the speed of reaching the goal of sustainability.
Team NCTU UNICODE | Orchild House | Solar Decathlon Europe 2014
7
Even though our house will be designed as a single dwelling for Solar Decathlon Europe competition, we also set our goal up for the housing structure to be configured as collective social housing. In order to archive our goal, the structural system has to be extendable to multi-floor building and adopted certain modular units. We will utilize BIM (Building Information Modeling) software for the complex building system and create most efficient but strong structure system. The social housing will be self-sufficient not only for the energy supply, but also food that will be harvested in the green house. The housing complex will be proposed to Taiwanese housing ministry after completing the prototype at Solar Decathlon Europe 2014.
NCTU / UNICODE’s “Orchid House” will incorporate all of the high technologies that available in the NCTU research lab, Hsinchu science and technology industrial park, as well as the market in Taiwan, including green house technologies, digital environmental control interfaces, solar thermal collectors, and high efficiency photovoltaic panels. However, if we totally rely on those technologies, the construction cost may exceed the limit of market availability. We aim to lower our house cost by distributing and mixing those technologies, for example incorporating active and passive solar system, and also recycling and harvesting water for radiant flooring and green house wall’s water filter system. In order to archive our goal, we have focused our technological research on following topics.
Building envelop and passive solar system
In order to utilize the passive solar system, which uses 90% less energy for heating and cooling compared to existing building and archives 75% overall energy savings, the plan layout of house needs to be considered. We placed living/dining space toward south side and north side of house will host bathroom, kitchen, storage, and machine room to be the layer of protection for thermal lost during the wintertime. The south side living space could be extended to the green house space for the flexible and comfortable living style.Temperature controlling space
The air temperature will be controlled through the green house space to minimize the energy consumption for cooling and heating the living space. The hot air will travel through the water filter and also the funning system on ceiling to cool down before going through HVAC system during the summer time.
On the other hand, during the winter time, the green house space will
stop the over flow of air and heat up with the sun. Also the solar thermal system on the roof will provide hot water for radiate floor. The house will be analysed with solar access calculation software, such as Ecotect from the early development stage to generate environmental feedback.
Lighting system
Lighting design will be an integral element of the house and its energy system. Taiwan is currently one of the largest manufacturers of LED in the world and NCTU research institute is also taking part of the industry. We will use the most efficient light source on the market and integrate all lighting with the house sensor system to monitor the room brightness comfort and temperature. Our electrical lighting will work with the mechanical system to increase system efficiency. All the heat generated by the light source will be paired with the performance of air delivery systems to avoid waste heat by lighting source.
PV system
We have been investigating photovoltaic system for the house, especially from the manufacture in Taiwan. Among many companies, we have paid attention to Neo Solar Power Corporation, the industry leading
PV manufacturer in Taiwan. The highest efficiency panel from Neo Solar Power, Black19+, archives 19.4% efficiency, which allows fewer panels for meeting energy harvesting requirement for the competition. Our design team will work with Neo Solar Power research team closely to develop the most efficient PV system for the house. The PV panels are attached to the building envelop with thermal water tubes behind, which also gives panels air space for avoiding overheat to lose the efficiency of the system. The PV system is not only the prime power generator, but also the key element for the architectural aesthetic.
Control system and Digital fabrication
As one of expertise of Graduate Institute of Architecture, we will apply advanced digital technologies to the house components, especially interactive mechanism and CAD/CAM fabrication. The interactive technology will possibly be a sunshade device of the house or sensory device for the human activities in the house integrated in the house control system. The system will be able to monitor through wireless network within the house and visible in web format to check through personal computer and smart phone devices. Also digital fabrication gives the house interior space to be very unique but constructed with minimum waste of material.
Team NCTU UNICODE | Orchild House | Solar Decathlon Europe 2014
9
Dissemination Activities and Current Impact
In the past one month, NCTU Unicode team attended several conference, organized several field trip, and introduced itself and the Solar Decathlon Competition on several presentations.
One day internship in Ruentex Group –
MARCH 20 2013, TAIPEI
NCTU Unicode team participated in Ruentex Group’s internal "Innovation and Technology Committee Meeting" , hosted by the chairman Dr. Samuel Yin. As a result, we had a better understanding of on-going projects, cross-functional operations and innovative construction/material development.
Study Tour of Green Factory – MARCH 20 2013, TAINAN
NCTU Unicode team arranged a study tour to visit Green house as well as Taiwan International Orchid Show 2013 in Tainan. In this tour, we observed the architectural elements of green house, such as shelter, waterproof system, cooling system, fan and artificial lake…etc..
Field trip in Grand Biotechnology – MARCH 21 2013, HSINCHU
To gain knowledge of orchid nursery industry, NCTU Unicode team organized a field trip to Grand Biotechnology, a professional orchid grower company, which is involved in the research and development of orchid tissue culture, through the adoption of biotechnology and high tech bio-processes.
潤泰集團
RUENTEX GROU P RUENTEX
Communication Info
For more information, please contact with us at: National Chiao Tung University
Graduate Institute of Architecture NCTU UNICODE TEAM
E-mail: [email protected] Tel: +886.3.573.1977 Fax: +886.3.575.2308 Mailing address:
1001 Ta Hsueh Road, Hsinchu City 300, Taiwan We set up our Official Web Site in English and Mandarin,
please scan the flash code or link to http://sde.tw to check out our latest updates. We also have a Facebook fan page to attract more people to be interest in our project.
