Special issue on nanoelectronics and nanoscale processing

Scanning the Issue

Special Issue on Nanoelectronics and Nanoscale Processing

produce profound impacts in many aspects of our lives, in industry, medicine, scientific research, aerospace applica-tions, business, and education. As the fabrication technology continues its rapid progress in the nanometer regime, the nanoelectronics era has arrived in the early 21st century. While the feature size of manufactured devices is further scaled down, new nanostructures or nanodevices in the scale of 0.1–50 nm are under aggressive development with the promise to supplement or overtake the real-world impacts of known silicon technologies. With the rapid developments in manufacturing technology and underlying principles of physics/chemistry/biology of nanodevices/nanostructures, advanced research on the integration of millions or even billions of these tiny devices into low-voltage, low-power, and ultrahigh-frequency gigascale nanosystems has been very intense. Meanwhile, design of nanoelectronics and/or nanoscale processing/computing systems as well as bio-logical devices using quantum/novel phenomena is being explored. The research on nanoelectronics and that on gigascale systems are closely linked. Both present exciting new challenges and opportunities to scientists and practicing engineers.

It has been several years since the prior Special Issue of the PROCEEDINGS OF THEIEEE on nanometer-scale science and technology was published in 1997. There have been nu-merous new developments and achievements in recent years in nanotubes, nanoelectronics, nanoelectromechanical sys-tems (NEMS), and the associated circuits and signal/data processing architecture. Thus, it is timely to organize a Spe-cial Issue on nanoelectronics and nanoscale processing to share the vast amount of knowledge accumulated in this fast-growing field.

According to information provided by the IEEE Nan-otechnology Council, the IEEE’s focus on nanNan-otechnology intensified in 2000 when the IEEE Nanotechnology Com-mittee was established. The ComCom-mittee was elevated to the Council status in February 2002 under Division 1—Cir-cuits and Devices. The Nanotechnology Council is com-posed of 19 member societies. The first issue of IEEE

Digital Object Identifier 10.1109/JPROC.2003.818331

TRANSACTIONS ON NANOTECHNOLOGY was published in March 2002, and the annual IEEE Nanotechnology Con-ference is a major forum for researchers to exchange new ideas and findings.1

The research activities in nanotechnology span many spe-cialty areas and generally are highly cross disciplinary. They have attracted growing interest from researchers and scien-tists, as well as engineers and investors in governmental lab-oratories, universities, and leading industrial institutions all over the world. This special issue is composed of two high-light papers and 15 focused papers that cover key issues of nanotechnology, from overview/fundamentals on nanotech-nology, nanotubes research, through self-assembled quantum dots array to interconnect/circuits/architecture of electronic and electromechanical nanosystems. In addition, the ethics issues in nanotechnology are also addressed with visionary views.

I. TWOHIGHLIGHTPAPERS

In “The Highlights in the Nano World,” C.-Y. Chang, President of National Chio Tung University, Hsin-chu, Taiwan and International Member of U.S. National Academy of Engineering, touches on key technologies and also strongly advocates for further investment in education in the nanotechnology era. He first describes spintronics, which combines the electronic charge and spin in opera-tion, then magnetic random access memory (MRAM) and quantum devices are presented. The outreach of nanotech-nology into biology will produce fruitful research results in the next several years, and is covered in detail in this paper. Existing investment in nanotechnology education in the U.S. and other regions is discussed. One novel approach taken by National Chiao Tung University is to cooperate with the University of California, Berkeley, in order to participate in the National Nanotechnology Infrastructure Network (NNIN) in the United States. This joint effort can serve as a role model to inspire other academic institutions to be innovative in sharing the resources.

C.-G. Hwang, President of the Memory Division at Samsung Electronics Co., Seoul, Korea, presents a new

1_{For additional information on the Nanotechnology Council, please visit} http://ewh.ieee.org/tc/nanotech/.

memory growth model based on nanoscale semiconductor technologies in “Nanotechnology Enables a New Memory Growth Model.” For personal computers, DRAM and SRAM semiconductor memories are highly demanded. However, for portable electronic devices, the NAND Flash memory will be the driving force due to the multibit-cell capability and easy-to-scale property. Various sub-90-nm memory technologies and a roadmap to the year 2010 are highlighted. The famous Moore’s Law predicts that the memory density will be doubled in 1.5 years, while the new growth model pioneered by C.-G. Hwang clearly indicates the doubling ofNANDFlash memory density every year.

II. NANOTUBES

In the paper “Carbon Nanotube Electronics,” by P. Avouris

et al.. the authors evaluate the potential of carbon nanotubes

(CNTs) as the basis for a new nanoelectronic technology. After briefly reviewing the electronic structure and transport properties of CNTs, they then focus on the fabrication and performance characteristics of CNT field-effect transistors (CNTFETs). Comparison of the CNTFET characteristics with those of analogous silicon devices shows that CNT-FETs are very competitive with state-of-the-art conventional devices. They also discuss the switching mechanism of CNTFETs and show that it involves the modulation by the gate field of potential energy barriers at the metal–CNT junctions. The potential for integration is demonstrated by fabricating a logic gate alongside a single nanotube molecule.

One of the ultimate limits of nanotechnology is molec-ular electronics, where devices may consist of individual molecules. Before this can be achieved, experimental methods to probe the electronic characteristics of single molecules must be explored and a theoretical understanding of how electrons traverse and interact with these molecules must be acquired. The paper by B. A. Mantooth and P. S. Weiss, “Fabrication, Assembly, and Characterization of Molecular Electronic Components,” is focused on deter-mining the electronic characteristics, mechanisms of action, and possibilities of single-molecule devices. The most recent methods and theories used to probe the electronic characteristics of the leading potential molecular electronics components are discussed. The authors use scanning probe methods to address single molecules and measure their environment. These methods are compared to others that yield less information on the system under study.

The well-defined geometries, exceptional mechanical properties, and extraordinary electric characteristics, among other outstanding physical properties of CNTs, qualify them for many potential applications, especially in nano-electronics, NEMS, and other nanodevices. Nanorobotic manipulations, which are characterized by multiple degrees of freedom (DOFs) with both position and orientation control, independently actuated multiprobes, and real-time observation systems, are one of the most promising

technologies for assembling complex nanodevices in three–dimensional (3-D) space and providing a potential route toward the application of such devices. In “As-sembly of Nanodevices with Carbon Nanotubes Through Nanorobotic Manipulations,” T. Fukuda et al. present a 16-DOF nanorobotic manipulation system, and demonstrate a nano laboratory, a prototype nanomanufacturing system based on the manipulation system, which is designed for the assembly of nanodevices with multiwalled CNTs (MWNTs), with the abilities of in situ property characteriza-tion and nanofabricacharacteriza-tion. Key techniques for nanoassembly, including the preparation of nano building blocks and property characterization of them, the positioning of the building blocks with nanometer-scale resolution, and the connection of them, have been shown to be effective with their nano laboratory. Nanotube-based building blocks are prepared by directly picking up, in situ property character-ization, destructive fabrication, and shape modifications. Kinds of nanotube junctions, the fundamental elements for both nanoelectronics and NEMS, have been constructed by positioning the building blocks together under real-time observation with a field-emission scanning electron micro-scope (FESEM), connecting them with naturally existing van der Waals forces, electron-beam-induced deposition (EBID), or mechanochemical bonding.

In “Nanotube Electronics: Non-CMOS Routes,” J. Xu reviews the recent advances in controlled fabrication of CNTs of uniform diameter, length, and spacing, and dis-cusses their fundamental properties. He also presents some possible applications in the broad content of nanotube elec-tronics. Special attention is paid to the underlying physics and engineering applications in acquisition and execution of the information. The traditional information-processing roles of electronics and CMOS-like routes are excluded. Directions and prospects of nanotube technologies are illus-trated with several examples.

III. NOVELCIRCUITMODELS ANDSILICONDEVICES

In “Nonlinear Circuit Foundations for Nano Devices ,” L. Chua describes the nonlinear circuit foundations for nanodevices. A nanodevice cannot perform computation or information processing unless it is locally active—a deep circuit-theoretic property which can only be determined from the circuit model of the device. Modeling nonlinear high-frequency nanodevices requires the introduction of a high-order family of nonlinear circuit elements which are capable of emulating such exotic quantum-mechanical ef-fects as Coulomb blockade, Kondo resonance, quasiparticle interactions, Aharonov–Bohm nonlocality, etc. These model building blocks are defined axiomatically and represented periodically via a four-element torus.

The paper “Extremely Scaled Silicon Nano-CMOS Devices,” by L. Chang, et al., is focused on the extremely scaled silicon nano-CMOS devices. As CMOS technology enters the sub-90-nm regime, the adoption of new

tran-sistor structures, such as the ultrathin-body single-gate and double-gate MOSFETs, is highly desirable. Short-channel effects can be controlled by the thickness of the silicon body, thus relaxing requirements on gate oxide thickness scaling and dopant-profile engineering. In this work, thin-body devices are demonstrated down to 15-nm gate lengths. Practical fabrication of the double-gate device is realized by introduction of the FinFET structure. Key technological challenges, including gate work function engineering and sublithographic patterning, are described. Scaling limits and performance projections are also presented.

IV. QUANTUMDEVICES

The paper “Modeling and Prospects for a Solid State Quantum Computer,” by H. Ruda and B. Qiao, is focused on the modeling and prospects for building a quantum computer. Moore’s law is steadily driving the scaling of current integrated circuit technology to ever smaller char-acteristic dimensions. Before the next decade is through, it is clear that the classical transport of charge underlying the operation of today’s devices and circuits will be se-verely challenged by quantum effects. These effects may be seen as hurdles or as a catalyst to working with purely quantum or perhaps hybrid devices and architectures. At the same time, such quantum phenomena may be explored as a means to implementing so-called quantum information systems provided practical issues are surmounted—the key issues being to manufacture the appropriate structures and to implement them. Not the least of the problems in the latter case is so-called decoherence. The authors present a vision for this emerging field, discussing limitations and potential approaches to overcoming them with the hope of ushering in a new era for computing based on harnessing the natural quantum processes emergent on the nanometer scale.

In “Variable Optical Buffer Using Slow Light in Semi-conductor Nanostructures,” C. Chang-Hasnain et al. pro-pose and analyze a compact variable all-optical buffer using semiconductor quantum dot structures. Buffering is effectively achieved by varying the group velocity of the optical signal using an external light source to create an electromagnetically induced transparency effect in the quantum dots. This technique would increase the variability (or storage capacity) by five to six orders of magnitude comparing other semiconductor waveguide or resonator techniques.

In “Self-Organized Anisotropic Strain Engineering: A New Concept for Quantum Dot Ordering,” R. Nötzel et

al. introduce a new concept for creating ordered arrays of

quantum dots by self-organized epitaxy. Self-organized anisotropic strain engineering of InGaAs/GaAs multilayer templates produces distinct strain patterns for the ordering of quantum dots on top in one- and two-dimensional nanoscale arrays and networks due to local strain recognition. The quantum dot arrays exhibit excellent structural and

op-tical properties to establish the functional building blocks required for the realization of quantum computing and information technology in solid state.

V. NEMS

In “Nanoelectromechanical Quantum Circuits and Sys-tems,” H. De Los Santos introduces the novel field of nanoelectromechanical quantum circuits and systems. The field derives from exploiting progress in techniques for fabricating, down to nanometer-length scales, freestanding device structures that incorporate mechanical motion and that may be designed to perform a variety of functions, such as optical, electrical, and, in particular, mechanical and mixed-domain. Since novel quantum mechanical ef-fects, for instance, quantized heat flow, manifestation of charge discreteness, and the quantum electrodynamical (QED) Casimir effect, become operative in this regime, exciting new paradigms for circuit modeling and design must be invoked in order to fully exploit the potential of this technology in sensing, computation, and signal processing applications.

In the paper “Nanorobots, NEMS, and Nanoassembly,” A. Requicha discusses the state of the art in nanorobot de-sign and construction. Nanorobots are typical NEMS and raise all the important issues that arise in NEMS, from sensing and actuation to control, communications, power and interfacing. Artificial nanorobots do not exist yet, but nanoscale robot components such as sensors and actua-tors are beginning to appear. After nanorobots and NEMS, the paper changes its focus to the assembly of nanoscale building blocks with macroscopic robots, which typically are atomic force microscopes (AFMs). Here the state of the art is more advanced. Nanomanipulation with AFMs is now done routinely in several labs, and nanostructures are being built by positioning components and then con-necting them by various chemical and physical processes. Nanoassembly is a promising process for building and in-vestigating device prototypes, and may become a practical fabrication technique if current work on multitip arrays comes to fruition.

VI. INTERCONNECTS/CIRCUITS/ARCHITECTURES

Is terascale integration possible? In “Limits to Binary Logic Switch Scaling—A Gedanken Model,” V. Zhirnov and colleagues consider device scaling and speed limitations on von Neumann computing that are derived from the requirement of “least energy computation” at maximum device densities and speed. They consider computational systems whose material realizations utilize electrons and energy barriers to represent and manipulate their binary representations of state. The analysis is based on the concept of distinguishability of binary state(s). It is shown that for nanometer-scale devices, where tunneling plays a significant role, the fundamental limit on the energy of a single binary

switching transition is larger than . The article sug-gests that even if entirely different electron transport devices are invented for digital logic, their potential for density and performance may not go much beyond the ultimate limits obtainable with CMOS technology, due primarily to limits on heat removal capacity.

In their paper, “Molecular Electronics: From Devices and Interconnect to Circuits and Architecture,” M. Stan

et al. address molecular electronics from devices and

interconnects to circuits and architecture. Most existing studies were focused on the devices and interconnections. The authors extend the efforts to discuss issues at the circuit and architectural levels. Based on the proposed nanoscale interconnect and device structures, the authors explore the design space available to the nanoelectronic circuit designers and system architects.

In “An Ab Initio Approach to the Calculation of Current-Voltage Characteristics of Programmable Molecular De-vices,” J. Seminario et al. present a scenario for molecular electronics (moletronics) whereby microelectronics can further be scaled down below its minimum feature size making use of the programmability feature of molecular devices. Since the minimum feature size also determines the smallest addressable distances in the fabrication of electronic circuits, any potential molecular device in the nanometer size would be discarded, except if this device could be programmed remotely to perform a specific function. The authors demonstrate with examples based on ab initio quantum calculations how molecules with high nonlinear behavior able to be assembled on an array by chemical (as opposed to lithographic) means can have multivalued responses and, thus, are able to be programmed. Molecular programmability compensates for the inability to address feature sizes in the range of one nanometer and, therefore, complements and expands the capabilities of present microelectronics to the nanometer domain. They analyze and propose the solution to the critical point for the development of molecular electronics, i.e., the pro-grammability of the electronic devices to compensate for the inability to perfectly address chemically assembled molecules. The paper also includes a description and usage of the methods and techniques that compose the molecular electronics design automation (MEDA) tools.

VII. ETHICS

In her paper, “Zeroing in on Ethical Issues in the Nano Area,” V. Weil discusses ethical issues in the nano era. Set-ting aside exaggerated notions of both the benefits and harm to be expected from nanotechnologies, we need to focus eth-ical investigation on specific initiatives at the nanoscale that are already underway or planned. The aims are to antici-pate ethical issues likely to arise in specific cases, to foster sensitivity to ethical issues and responsibility among nano specialists and policy makers, and to stimulate interchange between members of the public and nano specialists so that

the public can become involved. After clarifying what the term “nanotechnology” embraces and looking at cautionary lessons from experience with the information technologies and biotechnology, the discussion turns to the importance of anticipating consequences, intended and unintended. Al-though there is a lack of specific nano options to consider, a brief survey indicates the issues to watch out for: preventable harms, conflicts about justice and fairness, respect for per-sons, and more specifically, safeguards for workers in new production processes, intellectual property concerns, preser-vation of university values in university/industry relation-ships, and conflicts of interest. Three main fronts of activity are needed to address ethical issues: 1) incorporating ethics research into nano research and development enterprises; 2) devising mechanisms to involve the public so that their per-spectives and concerns feed back into research and devel-opment; and 3) initiating educational efforts at every level addressing both technical aspects and ethics and social im-plications aspects.

VIII. SPECIALTHANKS

Successful publication of this Special Issue would not be possible without the enthusiastic support of many volunteers and IEEE professionals. Great thanks go to J. Calder and M. Scanlon at the office of PROCEEDINGS OF THEIEEE. The Guest Editors would like to express deep appreciation to L. Terman, R. Trew, C. Lau, T. Theis, H. T. Kung, H. C. Lin, W. Porod, A. Csurgay, E. Friedman, C. Toumazou, A. An-dreou, G. Cauwenburghs, and many tireless reviewers and supporters.

Continuous advances in nanotechnology enable human beings with the ability to manipulate at the atomic level in mass quantity. It is important that we live in good harmony with the earth, the sun, and the universe for many more generations to enjoy. Advocation and inspiration on such from S. A. Sheu, J. C. Sheu, and R. J. Sheu of the Pasadena, CA, area; from C.-L. T. Wu, C. C.-Y. Wu, and A. Y.-H. Wu of the Hsin-Chu, Taiwan, R.O.C., area; and T. Sze of the Silicon Valley, CA, area are highly appreciated.

BINGSHEU, Guest Editor National Chiao Tung University College of Electrical Engineering and

Computer Science

Hsin-chu 30050, Taiwan R.O.C. PETERCHUNG-YUWU, Guest Editor National Chiao Tung University College of Electrical Engineering and

Computer Science

Hsin-chu 30050, Taiwan, R.O.C. SIMONM. SZE, Guest Editor National Chiao Tung University College of Electrical Engineering and

Computer Science

Bing Sheu (Fellow, IEEE) received the B.S. degree (first among 180 graduates) in electrical engineering from National Taiwan University, Taipei, in 1978 and the Ph.D. degree in elec-trical engineering from the University of California, Berkeley.

In 1988, he joined the faculty of the Department of Electrical Engineering, University of Southern California, Los Angeles, and was promoted to Full Professor in 1997. From 1999 to 2000, he was with Avant! Corp., Fremont, CA. He is currently Director of Technology Rela-tionships and Device Modeling with Nassda Corp., Santa Clara, CA. He is also an Honorary Professor with National Chiao Tung University, Hsin-chu, Taiwan, R.O.C. He has published more than 195 technical papers, and co-authored or co-edited several books.

Dr. Sheu received the Engineering Initiation Award from the National Science Foundation in 1987, and the 1991 and 1992 Best Presenter Awards at the IEEE International Conference on Computer Design. He was a Co-Recipient of the IEEE TRANSACTIONS ONVLSI SYSTEMS

Best Paper Award in 1995, the IEEE Guillemin–Cauer Award in 1997, and the IEEE Circuits and Systems (CAS) Society Golden Jubilee Award in 2000. He was Technical Program Chair and General Chair of the IEEE ICCD Conference in 1997 and 1998, respectively, and Technical Program Chair of the 1996 IEEE International Conference on Neural Networks, Washington, DC. He was CAS Editor of IEEE Circuits and Devices Magazine in 1995 and 1996, Editor-in-Chief of IEEE TRANSACTIONS ONVLSI SYSTEMSin 1997 and 1998, and Founding Editor-in-Chief of IEEE TRANSACTIONS ON

MULTIMEDIAin 1999. He served on the Board of Governors for the IEEE CAS Society in 1996 and 1997, and as Vice-President on Conferences in 1998. He was President-Elect, President, and Past President of the IEEE CAS Society in 1999, 2000, and 2001, respectively. In 2000, Dr. Sheu served on the Technical Activities Board of IEEE. In 2001, he served on the Executive Committee of the IEEE/ACM Design Automation Conference.

Peter Chung-Yu Wu (Fellow, IEEE) received the M.S. and Ph.D. degrees in electronics en-gineering from National Chiao-Tung University (NCTU), Hsin-Chu, Taiwan, R.O.C., in 1976 and 1980, respectively.

From 1980 to 1984, he was an Associate Professor at NCTU. From 1984 to 1986, he was on the faculty in electronics engineering at Portland State University, Portland, OR. Since 1987, he has been a Full Professor at NCTU. He is currently Centennial Honorary Chair Professor serving as Dean of College of Electrical Engineering and Computer Science. From 1991 to 1995, he was also Executive Director of Engineering Division at the National Science Council (counterpart to the National Science Foundation). From 1995 to 1998, he was also Dean of Research Development and co-sponsored many joint activities with four other campuses of the Chiao-Tung University system in Shanghai, China, and Xi’an, China. He has published more than 210 technical papers and holds 18 patents, including nine U.S. patents. His research interests include nanometer integrated circuits and gigascale systems, sensor chips, radio fre-quency communication circuits, and computer-aided design analysis.

Dr. Wu has received numerous awards in Taiwan, R.O.C. He is a Recipient of the IEEE Third Millennium Medal. He is also a Member of Eta Kappa Nu and Phi Tau Phi. He served as VLSI Track Chair of the 1999 ISCAS in Orlando, FL, and gave tutorial talks at ISCAS in the 1990s. He was General Chair of 1994 APCCAS Conference for researchers from the United States, Japan, and all over the world. He is the Founding Chair of the Technical Committee on Nanoelectronics and Giga-scale Systems. He served as Chair of the Neural Technical Committee and as Chair of the Multimedia Technical Committee. He is a Board of Governors Member of the IEEE Circuits and Systems (CAS) Society. He was Guest Editor of the August 1997 Multimedia Special Issue for IEEE TRANSACTIONS ONCIRCUITS ANDSYSTEMS FOr VIDEOTECHNOLOGY, and was Associate Editor for IEEE TRANSACTIONS ONCIRCUITS ANDSYSTEMS—PARTII, IEEE TRANSACTIONS ONVLSI SYSTEMS, and IEEE TRANSACTIONS ON

MULTIMEDIA. He is currently CAS Editor for IEEE Circuits and Devices Magazine. He is CAS Representative to the IEEE Neural Networks Society. He has served as CAS Taipei Chapter Chair and IEEE Taipei Section Chair. In 2000 and 2001, he served as a Distinguished Lecturer in the IEEE CAS Society.

Simon M. Sze (Life Fellow, IEEE) received the B. S. degree in electrical engineering from the National Taiwan University, Taipei, in 1957, the M.S. degree in electrical engineering from the University of Washington, Seattle, in 1960, and the Ph.D. degree in electrical engineering from Stanford University, Stanford, CA, in 1963.

From 1963 to 1989, he was with Bell Laboratories. In 1990, he joined the faculty of Electronics Engineering Department, National Chiao Tung University (NCTU), Hsin-Chu, Taiwan, R.O.C., and is currently UMC Chair Professor of NCTU, and President of the National Nano Device Laboratories.He has made pioneering contributions to metal-semicon-ductor contacts, microwave and photonic devices, and submicrometer MOSFET technology. Of particular importance is his invention of the nonvolatile semiconductor memory, such as electrically erasable programmable ROM and Flash memory. This memory is a key component for the cellular phone, notebook computer, smart IC card, digital camera, and a host of portable electronic systems. He has authored or coauthored over 150 technical papers and has written, edited, and contributed to 24 books. His book Physics of Semiconductor Devices (New York: Wiley, 1969, 2nd ed. 1981) is the most cited work in contemporary engineering and applied science publications (over 12 000 citations from ISI Press).

Dr. Sze has received the IEEE Ebers Award. In Taiwan, he has received the Sun Yet-Sen Award, the National Science and Technology Award, and the National Chair Professor Award. He is a Member of the Academia Sinica in Taiwan; the Chinese Academy of Engineering, Beijing, China; and the U.S. National Academy of Engineering.
