Calcified Carotid Artery Imaged by Computed Tomography

(1)

J Oral Maxillofac Surg 68:218-220, 2010

Calcified Carotid Artery Imaged by Computed Tomography

Charley Levy, BA,* and Louis Mandel, DDS†

Cerebrovascular accident, or stroke, is the third leading cause of death in the United States, causing more than 150,000 deaths each year; it also is the leading cause of adult disability. Each year, approximately 780,000 strokes occur in the United States, of which 75% are first-time cerebrovascular accidents.¹ It has been estimated that in 2008, stroke-related medical costs to Americans totaled 65.5 billion dollars.¹ The risk factors include hypertension, hyperlipidemia, diabetes, smoking, and obesity.^2-4

Strokes are classified as either ischemic or hemorrhagic. During both ischemic and hemorrhagic strokes, the brain is deprived of critical blood and oxygen, causing rapid cell death. Ischemic strokes, comprising approximately 85% of all strokes, are due to the blockage of arteries by either blood clots or the gradual build up of fatty plaque, which consists of fat and cholesterol, with calcification often occurring. This accumulation of plaque within the arteries is known as atherosclerosis. Carotid artery atherosclerosis is a contributor to ischemic stroke and myocardial infarction. A study by Prab- hakaran et al⁵ found that patients with carotid calcified plaques were more than twice as likely to experience vascular events compared with those without carotid plaques.

Imaging facilitates the detection of carotid artery disease and is critical in identifying those at risk of cerebrovascular accidents. Typically, a physician will diagnose carotid artery disease using carotid ultra- sonography.⁶ If the ultrasound scan shows signs of carotid artery disease, more advanced imaging in the

form of angiography, computed tomography (CT) angiography, or magnetic resonance angiography is used to better quantify the extent of the disease. Once carotid artery disease has been diagnosed, patients will receive a range of treatment options. For less severe cases, medication and lifestyle modifications may be recommended. This includes smoking cessa- tion, the treatment of hypertension, high cholesterol, and diabetes, and the use of blood thinning medica- tions. For more severe cases, surgical intervention might be recommended. The 2 accepted surgical techniques for carotid artery disease are carotid end- arterectomy and carotid stenting.⁶

Carotid artery calcification can often be detected by the oral surgeon on a routine panoramic film.^7-9This incidental finding of radiopacity can indicate a previ- ously undiagnosed and potentially harmful condition.

Panoramic films serve as a very popular radiographic prescription for a patient’s initial visit. Among general dentists, about 10% of all radiographs taken on dentate patients are panoramic films, with this number being much greater for edentulous patients.^10,11 Ad- ditionally, panoramic films are very frequently used for implant dentistry. More than 80% of all implant patients undergo panoramic radiography during the course of their treatment.¹²

On a panoramic film, calcifications of the carotid artery are located posterior and inferior to the angle of the mandible, at about 45° from the angle of the mandible (Fig 1). They are present adjacent to cervical vertebrae 3 and 4.¹³This is the point at which the carotid artery bifurcates into the internal and external carotid arteries. It represents a critical area for the formation of carotid atheromas, which can be circu- lar, ovoid, linear, or irregular in shape.¹³

Studies have shown that 2.5% to 5% of older individuals, with a mean age of 55 to 65 years, have carotid artery calcifications evident on routine panoramic radiographs.^3,4 In a younger population, with a mean age of 32 to 35 years, the incidence has been reported to range from 0.4% to 0.8%.^13,14 Although some studies have suggested an increased prevalence in women, the statistical significance has been disputed.¹³

*Research Assistant, Salivary Gland Center, and Fourth Year Student, Columbia University College of Dental Medicine, New York, NY.

†Director, Salivary Gland Center, and Assistant Dean and Clinical Professor, Division of Oral and Maxillofacial Surgery, Columbia University College of Dental Medicine, New York, NY.

Address correspondence and reprint requests to Dr Mandel:

Division of Oral and Maxillofacial Surgery, Columbia University College of Dental Medicine, 630 West 168th Street, New York, NY 10032; e-mail:LM7@Columbia.edu

doi:10.1016/j.joms.2009.04.083

218 CALCIFIED CAROTID ARTERY IMAGING WITH CT

(2)

The reference standard for diagnosing carotid artery calcifications is CT.¹⁵CT has the ability to illus- trate the quantitative extent of the calcifications and stenosis within the artery. In the present report, we studied the value of CT in diagnosing the presence of carotid artery calcification when CT was used for the investigation of an unrelated oral problem. A CT scan

was performed as a part of an evaluation of a patient with a right submandibular sialolith. An incidental finding clearly demonstrated the presence of bilateral common carotid artery calcifications.

Report of a Case

A 55-year-old man was referred to the College of Dental Medicine’s Salivary Gland Center (Columbia University, New York, NY) because of a 2-year history of sporadic right submandibular salivary gland swellings associated with eat- ing. His medical history indicated that the patient was tak- ing medication for mild hypertension, but he had no other medical problems. The patient was moderately obese and admitted to smoking 1 pack of cigarettes each day.

At the examination, palpation revealed a slightly swollen, firm, and tender right submandibular salivary gland. In- traorally, the right mouth floor was erythematous and ele- vated. Saliva manually expressed from the right Wharton’s duct was cloudy. Intraoral palpation demonstrated a significant hardness in the third molar area of the mouth floor. A tentative diagnosis of a sialolith in the posterior segment of the right Wharton’s duct was made.

To clearly define the size of the sialolith, its exact loca- tion, and its effect on the submandibular gland, a CT scan was requested. The CT scan confirmed the existence of a 1.2-cm stone in the proximal portion of the duct and associated sialadenitis (Fig 2). Of great interest was the simulta- neous and incidental finding of bilateral common carotid artery calcifications (Figs 2,3). The clearly delineated calcific plaques involved the left artery more extensively than the right vessel. The patient was informed that a medical consultation would be indicated after removal of the sialolith.

FIGURE 1. Cropped panoramic film demonstrating carotid artery calcification (arrow). Courtesy of Dr Steven Singer.

Levy and Mandel. Calcified Carotid Artery Imaging With CT.

J Oral Maxillofac Surg 2010.

FIGURE 2. CT scan (axial view, no contrast) showing sialolith (A arrow) in posterior segment of right Wharton’s duct and B, bilateral calcifications (B arrows) in common carotid artery.

FIGURE 3. CT scan (axial view, no contrast) at lower level than seen inFigure 2revealing significant bilateral carotid artery calci- fications (B arrows), most marked on left side. Note tip of greater horn of hyoid bone (C arrows).

LEVY AND MANDEL 219

(3)

Discussion

The CT scan is exquisitely sensitive to minute amounts of calcium. Therefore, it can be instrumental in the diagnosis of any carotid artery calcification or a poorly calcified sialolith.¹⁶ Indisputably, the CT scan is superior to the panoramic radiograph in both sensitivity and specificity for detecting calcifications. The drawbacks of CT are its high cost, its high level of radiation, and the technicality of the procedure.

Two different studies^17,18 investigated how effi- cient panoramic radiographs are in detecting cervical calcifications compared with CT scans. These studies found that if a patient showed calcification on the CT scan, it would only be visible on the panoramic radiograph 22% to 32% of the time. This is referred to as the sensitivity of the panoramic radiograph. The studies also considered the specificity of panoramic radiographs, or the likelihood that if no calcification is seen on the CT scan, no calcification will appear on the panoramic radiograph. They found the specificity to be 87.5% to 90%. A more general statistical parameter used to compare the results of the panoramic radiographs with those of the reference standard of CT is accuracy. Accuracy is defined as the likelihood that the results from the panoramic radiographs will agree with the results obtained from the CT scans. The accuracy of panoramic radiography has been reported to be 50% to 62.5%.^17,18From these findings, it is clear that the panoramic film is not as reliable as the CT scan for detecting calcifications. Confusion can occur from the presence of other pathologic radiopacities such as calcified lymph nodes, phleboliths, submandibular salivary gland sialoliths, fractured osteophytes, tonsilloliths, calcified acne lesions, calcified ligaments, or an ex- tended styloid.^19,20

We are not advocating the use of CT to uncover the presence of carotid artery calcifications. However when an oral problem requires CT, the dental practi- tioner is in the unique position to diagnose the presence of these calcifications. The oral surgeon has the ability to detect this condition as an incidental finding when ordering a CT scan for suspicion of a sialolith, treatment planning for implants, or investigating a pathologic swelling. The present case report high- lights the unrelated CT scan discovery of bilateral carotid artery calcifications in a patient with a submandibular sialolith. Such a finding underlines the dentist’s role in the systemic health of the patient and requires a medical referral.

References

1. Rosamond W, Flegel K, Furie K, et al: Heart disease and stroke statistics—2008 Update: A report from the American Heart Asso- ciation Statistics Committee and Stroke Statistics Subcommittee.

Circulation 117:e25, 2008

2. Cohen SN, Friedlander AH, Jolly DA, et al: Carotid calcification on panoramic radiographs: An important marker for vascular risk. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 94:510, 2002

3. Tamura T, Inui M, Nakase M, et al: Clinicostatistical study of carotid calcification on panoramic radiographs. Oral Dis 11:

314, 2005

4. Pornprasertsuk-Domrongsri S, Thanakun S: Carotid artery calcification detected on panoramic radiographs in a group of Thai population. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 101:110, 2006

5. Prabhakaran S, Singh R, Zhou X, et al: Presence of calcified carotid plaque predicts vascular events; the northern Manhat- tan study. Atherosclerosis 195:e197, 2007

6. Sobieszczyk P, Beckman J: Carotid artery disease. Circulation 114:e244, 2006

7. Friedlander AH, Lande A: Panoramic radiographic identification of carotid arterial plaques. Oral Surg Oral Med Oral Pathol 52:102, 1981

8. Friedlander AH, Gratt BM: Panoramic dental radiography as an aid in detecting patients at risk for stroke. J Oral Maxillofac Surg 52:1257, 1994

9. Friedlander AH, Baker JD: Panoramic radiography: An aid in detecting patients at risk of cerebrovascular accident. J Am Dent Assoc 125:1598, 1994

10. Kogon S, Bohay R, Stephens R: A survey of the radiographic practices of general dentists for edentulous patients. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 80:365, 1995 11. Gilbert GH, Weems RA, Shelton BJ: Incidence of dental radio-

graphic procedures during a 48-month population-based study of dentate adults. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 96:243, 2003

12. Sakakura CE, Morais JAND, Loffredo LCM, et al: A survey of radiographic prescription in dental implant assessment. Den- tomaxillofac Radiol 32:397, 2003

13. Lewis DA, Brooks SL: Carotid artery calcification in a general dental population: A retrospective study of panoramic radiographs. Gen Dent 47:98, 1999

14. Hubar JS: Carotid artery calcification in the black population: A retrospective study on panoramic radiographs. Dentomaxillo- fac Radiol 28:348, 1999

15. Bellasi A, Raggi P: Techniques and technologies to assess vascular calcification. Semin Dial 20:129, 2007

16. Mandel L, Hatzis G: The role of computerized tomography in the diagnosis and therapy of parotid stones: A case report. J Am Dent Assoc 131:479, 2000

17. Madden RP, Hodges JS, Salmen CW, et al: Utility of panoramic radiographs in detecting cervical calcified carotid atheroma.

Oral Surg Oral Med Oral Pathol Oral Radiol Endod 10:543, 2007 18. Yoon S-J, Yoon W, Kim O-S, et al: Diagnostic accuracy of panoramic radiography in the detection of calcified carotid artery. Dentomaxillofac Radiol 37:104, 2008

19. Almog DM, Tsmidis K, Moss ME, et al: Evaluation of training program for detection of carotid artery calcifications on panoramic radiographs. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 90:111, 2000

20. Chicano RR, Sanchez REO, Castano FL, et al: Panoramic radiograph as a method for detecting calcified atheroma plaques:

Review of literature. Med Oral Patol Oral Cir Bucal 11:e261, 2006

220 CALCIFIED CAROTID ARTERY IMAGING WITH CT
