About the Tutorial

Apache Kafka was originated at LinkedIn and later became an open sourced Apache project in 2011, then First-class Apache project in 2012. Kafka is written in Scala and Java. Apache Kafka is publish-subscribe based fault tolerant messaging system. It is fast, scalable and distributed by design.

This tutorial will explore the principles of Kafka, installation, operations and then it will walk you through with the deployment of Kafka cluster. Finally, we will conclude with real-time applications and integration with Big Data Technologies.

Audience

This tutorial has been prepared for professionals aspiring to make a career in Big Data Analytics using Apache Kafka messaging system. It will give you enough understanding on how to use Kafka clusters.

Prerequisites

Before proceeding with this tutorial, you must have a good understanding of Java, Scala, Dis- tributed messaging system, and Linux environment.

Copyright and Disclaimer

All the content and graphics published in this e-book are the property of Tutorials Point (I) Pvt.

Ltd. The user of this e-book is prohibited to reuse, retain, copy, distribute or republish any contents or a part of contents of this e-book in any manner without written consent of the publisher.

We strive to update the contents of our website and tutorials as timely and as precisely as possible, however, the contents may contain inaccuracies or errors. Tutorials Point (I) Pvt. Ltd.

provides no guarantee regarding the accuracy, timeliness or completeness of our website or its contents including this tutorial. If you discover any errors on our website or in this tutorial, please notify us at [email protected]

(3)

ii

1. KAFKA – INTRODUCTION ... 1

What is a Messaging System? ... 1

What is Kafka? ... 2

2. KAFKA – FUNDAMENTALS ... 4

3. KAFKA – CLUSTER ARCHITECTURE ... 7

4. KAFKA – WORKFLOW ... 9

Workflow of Pub-Sub Messaging ... 9

Workflow of Queue Messaging / Consumer Group ... 10

Role of ZooKeeper ... 11

5. KAFKA – INSTALLATION STEPS ... 12

Step 1: Verifying Java Installation ... 12

Step 2: ZooKeeper Framework Installation ... 13

Step 3: Apache Kafka Installation ... 15

Step 4: Stop the Server ... 16

6. KAFKA – BASIC OPERATIONS ... 17

Single Node-Single Broker Configuration ... 17

List of Topics ... 18

Single Node-Multiple Brokers Configuration... 20

Creating a Topic ... 21

(4)

iii

Basic Topic Operations ... 22

Deleting a Topic ... 23

7. KAFKA – SIMPLE PRODUCER EXAMPLE ... 24

KafkaProducer API ... 24

Producer API ... 25

Configuration Settings ... 25

ProducerRecord API ... 26

SimpleProducer application ... 27

Simple Consumer Example ... 29

ConsumerRecord API ... 30

ConsumerRecords API ... 31

Configuration Settings ... 31

SimpleConsumer Application ... 32

8. KAFKA – CONSUMER GROUP EXAMPLE ... 34

9. KAFKA – INTEGRATION WITH STORM ... 37

About Storm ... 37

Integration with Storm ... 37

Bolt Creation ... 39

Submitting to Topology ... 42

Execution... 44

10. KAFKA – INTEGRATION WITH SPARK ... 45

About Spark ... 45

Integration with Spark ... 45

11. KAFKA – REAL-TIME APPLICATION (TWITTER) ... 50

Twitter Streaming API ... 50

(5)

iv

12. KAFKA – TOOLS ... 55

System Tools ... 55

Replication Tool ... 55

13. KAFKA – APPLICATIONS ... 56

(6)

1 In Big Data, an enormous volume of data is used. Regarding data, we have two main challenges.

The first challenge is how to collect large volume of data and the second challenge is to analyze the collected data. To overcome those challenges, you must need a messaging system.

Kafka is designed for distributed high throughput systems. Kafka tends to work very well as a replacement for a more traditional message broker. In comparison to other messaging systems, Kafka has better throughput, built-in partitioning, replication and inherent fault-tolerance, which makes it a good fit for large-scale message processing applications.

What is a Messaging System?

A Messaging System is responsible for transferring data from one application to another, so the applications can focus on data, but not worry about how to share it. Distributed messaging is based on the concept of reliable message queuing. Messages are queued asynchronously between client applications and messaging system. Two types of messaging patterns are available – one is point to point and the other is publish-subscribe (pub-sub) messaging system. Most of the messaging patterns follow pub-sub.

Point to Point Messaging System

In a point-to-point system, messages are persisted in a queue. One or more consumers can consume the messages in the queue, but a particular message can be consumed by a maximum of one consumer only. Once a consumer reads a message in the queue, it disappears from that queue. The typical example of this system is an Order Processing System, where each order will be processed by one Order Processor, but Multiple Order Processors can work as well at the same time. The following diagram depicts the structure.

Publish-Subscribe Messaging System

In the publish-subscribe system, messages are persisted in a topic. Unlike point-to-point system, consumers can subscribe to one or more topic and consume all the messages in that topic. In the Publish-Subscribe system, message producers are called publishers and message consumers are called subscribers. A real-life example is Dish TV, which publishes different channels like

(7)

2 sports, movies, music, etc., and anyone can subscribe to their own set of channels and get them whenever their subscribed channels are available.

What is Kafka?

Apache Kafka is a distributed publish-subscribe messaging system and a robust queue that can handle a high volume of data and enables you to pass messages from one end-point to another.

Kafka is suitable for both offline and online message consumption. Kafka messages are persisted on the disk and replicated within the cluster to prevent data loss. Kafka is built on top of the ZooKeeper synchronization service. It integrates very well with Apache Storm and Spark for real-time streaming data analysis.

Benefits

Following are a few benefits of Kafka:

 Reliability - Kafka is distributed, partitioned, replicated and fault tolerance.

 Scalability - Kafka messaging system scales easily without down time.

 Durability - Kafka uses “Distributed commit log” which means messages persists on disk as fast as possible, hence it is durable.

 Performance - Kafka has high throughput for both publishing and subscribing messages.

It maintains stable performance even many TB of messages are stored.

Kafka is very fast and guarantees zero downtime and zero data loss.

Use Cases

Kafka can be used in many Use Cases. Some of them are listed below:

 Metrics - Kafka is often used for operational monitoring data. This involves aggregating statistics from distributed applications to produce centralized feeds of operational data.

(8)

3

 Log Aggregation Solution - Kafka can be used across an organization to collect logs from multiple services and make them available in a standard format to multiple consumers.

 Stream Processing - Popular frameworks such as Storm and Spark Streaming read data from a topic, processes it, and write processed data to a new topic where it becomes available for users and applications. Kafka’s strong durability is also very useful in the context of stream processing.

Need for Kafka

Kafka is a unified platform for handling all the real-time data feeds. Kafka supports low latency message delivery and gives guarantee for fault tolerance in the presence of machine failures. It has the ability to handle a large number of diverse consumers. Kafka is very fast, performs 2 million writes/sec. Kafka persists all data to the disk, which essentially means that all the writes go to the page cache of the OS (RAM). This makes it very efficient to transfer data from page cache to a network socket.

(9)

4 Before moving deep into the Kafka, you must aware of the main terminologies such as topics, brokers, producers and consumers. The following diagram illustrates the main terminologies and the table describes the diagram components in detail.

In the above diagram, a topic is configured into three partitions. Partition 1 has two offset factors 0 and 1. Partition 2 has four offset factors 0, 1, 2, and 3. Partition 3 has one offset factor 0. The id of the replica is same as the id of the server that hosts it.

Assume, if the replication factor of the topic is set to 3, then Kafka will create 3 identical replicas of each partition and place them in the cluster to make available for all its operations. To balance a load in cluster, each broker stores one or more of those partitions. Multiple producers and consumers can publish and retrieve messages at the same time.

2. Kafka – Fundamentals

(10)

5

Components Description

Topics A stream of messages belonging to a particular category is called a topic. Data is stored in topics.

Partition

Topics are split into partitions. For each topic, Kafka keeps a minimum of one partition. Each such partition contains messages in an immutable ordered sequence. A partition is implemented as a set of segment files of equal sizes.

Topics may have many partitions, so it can handle an arbitrary amount of data.

Partition offset Each partitioned message has a unique sequence id called as

“offset”.

Replicas of partition Replicas are nothing but “backups” of a partition. Replicas are never read or write data. They are used to prevent data loss.

Brokers

i) Brokers are simple system responsible for maintaining the published data. Each broker may have zero or more partitions per topic.

Assume, if there are N partitions in a topic and N number of brokers, each broker will have one partition.

ii) Assume if there are N partitions in a topic and more than N brokers (n + m), the first N broker will have one partition and the next M broker will not have any partition for that particular topic.

iii) Assume if there are N partitions in a topic and less than N brokers (n-m), each broker will have one or more partition sharing among them. This scenario is not recommended due to unequal load distri- bution among the broker.

Kafka Cluster

Kafka’s having more than one broker are called as Kafka cluster. A Kafka cluster can be expanded without downtime. These clusters are used to manage the persistence and replication of message data.

Producers

Producers are the publisher of messages to one or more Kafka topics.

Producers send data to Kafka brokers. Every time a producer publishes a message to a broker, the broker simply appends the message to the last segment file. Actually, the message will be appended to a partition. Producer can also send messages to a partition of their choice.

(11)

6 Consumers

Consumers read data from brokers. Consumers subscribes to one or more topics and consume published messages by pulling data from the brokers.

Leader "Leader" is the node responsible for all reads and writes for the given partition. Every partition has one server acting as a leader.

Follower

Node which follows leader instructions are called as follower. If the leader fails, one of the follower will automatically become the new leader. A follower acts as normal consumer, pulls messages and updates its own data store.

(12)

7 Take a look at the following illustration. It shows the cluster diagram of Kafka.

(13)

8 The following table describes each of the components shown in the above diagram.

Components Description

Broker

Kafka cluster typically consists of multiple brokers to maintain load balance. Kafka brokers are stateless, so they use ZooKeeper for maintaining their cluster state. One Kafka broker instance can handle hundreds of thousands of reads and writes per second and each broker can handle TB of messages without performance impact. Kafka broker leader election can be done by ZooKeeper.

ZooKeeper

ZooKeeper is used for managing and coordinating Kafka broker.

ZooKeeper service is mainly used to notify producer and consumer about the presence of any new broker in the Kafka system or failure of the broker in the Kafka system. As per the notification received by the Zookeeper regarding presence or failure of the broker then producer and consumer takes decision and starts coordinating their task with some other broker.

Producers

Producers push data to brokers. When the new broker is started, all the producers search it and automatically sends a message to that new broker. Kafka producer doesn’t wait for acknowledgements from the broker and sends messages as fast as the broker can handle.

Consumers

Since Kafka brokers are stateless, which means that the consumer has to maintain how many messages have been consumed by using partition offset. If the consumer acknowledges a particular message offset, it implies that the consumer has consumed all prior messages.

The consumer issues an asynchronous pull request to the broker to have a buffer of bytes ready to consume. The consumers can rewind or skip to any point in a partition simply by supplying an offset value.

Consumer offset value is notified by ZooKeeper.

(14)

9 As of now, we discussed the core concepts of Kafka. Let us now throw some light on the workflow of Kafka.

Kafka is simply a collection of topics split into one or more partitions. A Kafka partition is a linearly ordered sequence of messages, where each message is identified by their index (called as offset). All the data in a Kafka cluster is the disjointed union of partitions. Incoming messages are written at the end of a partition and messages are sequentially read by consumers. Durability is provided by replicating messages to different brokers.

Kafka provides both pub-sub and queue based messaging system in a fast, reliable, persisted, fault-tolerance and zero downtime manner. In both cases, producers simply send the message to a topic and consumer can choose any one type of messaging system depending on their need.

Let us follow the steps in the next section to understand how the consumer can choose the messaging system of their choice.

Workflow of Pub-Sub Messaging

Following is the step wise workflow of the Pub-Sub Messaging:

 Producers send message to a topic at regular intervals.

 Kafka broker stores all messages in the partitions configured for that particular topic. It ensures the messages are equally shared between partitions. If the producer sends two messages and there are two partitions, Kafka will store one message in the first partition and the second message in the second partition.

 Consumer subscribes to a specific topic.

 Once the consumer subscribes to a topic, Kafka will provide the current offset of the topic to the consumer and also saves the offset in the Zookeeper ensemble.

 Consumer will request the Kafka in a regular interval (like 100 Ms) for new messages.

 Once Kafka receives the messages from producers, it forwards these messages to the consumers.

 Consumer will receive the message and process it.

 Once the messages are processed, consumer will send an acknowledgement to the Kafka broker.

 Once Kafka receives an acknowledgement, it changes the offset to the new value and updates it in the Zookeeper. Since offsets are maintained in the Zookeeper, the consumer can read next message correctly even during server outrages.

 This above flow will repeat until the consumer stops the request.

(15)

10

 Consumer has the option to rewind/skip to the desired offset of a topic at any time and read all the subsequent messages.

Workflow of Queue Messaging / Consumer Group

In a queue messaging system instead of a single consumer, a group of consumers having the same "Group ID" will subscribe to a topic. In simple terms, consumers subscribing to a topic with same "Group ID" are considered as a single group and the messages are shared among them. Let us check the actual workflow of this system.

 Producers send message to a topic in a regular interval.

 Kafka stores all messages in the partitions configured for that particular topic similar to the earlier scenario.

 A single consumer subscribes to a specific topic, assume "Topic-01" with "Group ID” as

“Group-1”.

 Kafka interacts with the consumer in the same way as Pub-Sub Messaging until new consumer subscribes the same topic, "Topic-01" with the same “Group ID” as “Group-1”.

 Once the new consumer arrives, Kafka switches its operation to share mode and shares the data between the two consumers. This sharing will go on until the number of consumers reach the number of partition configured for that particular topic.

 Once the number of consumer exceeds the number of partitions, the new consumer will not receive any further message until any one of the existing consumer unsubscribes.

This scenario arises because each consumer in Kafka will be assigned a minimum of one partition and once all the partitions are assigned to the existing consumers, the new consumers will have to wait.

 This feature is also called as "Consumer Group". In the same way, Kafka will provide the best of both the systems in a very simple and efficient manner.

(16)

11

Role of ZooKeeper

A critical dependency of Apache Kafka is Apache Zookeeper, which is a distributed configuration and synchronization service. Zookeeper serves as the coordination interface between the Kafka brokers and consumers. The Kafka servers share information via a Zookeeper cluster. Kafka stores basic metadata in Zookeeper such as information about topics, brokers, consumer offsets (queue readers) and so on.

Since all the critical information is stored in the Zookeeper and it normally replicates this data across its ensemble, failure of Kafka broker / Zookeeper does not affect the state of the Kafka cluster. Kafka will restore the state, once the Zookeeper restarts. This gives zero downtime for Kafka. The leader election between the Kafka broker is also done by using Zookeeper in the event of leader failure.

To learn more on Zookeeper, please refer http://www.tutorialspoint.com/zookeeper/

Let us continue further on how to install Java, ZooKeeper, and Kafka on your machine in the next chapter.

(17)

12 Following are the steps for installing Java on your machine.

Step 1: Verifying Java Installation

Hopefully you have already installed java on your machine right now, so you just verify it using the following command.

$ java -version

If java is successfully installed on your machine, you could see the version of the installed Java.

Step 1.1: Download JDK

If Java is not downloaded, please download the latest version of JDK by visiting the following link and download latest version.

http://www.oracle.com/technetwork/java/javase/downloads/index.html

Now the latest version is JDK 8u 60 and the file is “jdk-8u60-linux-x64.tar.gz”. Please download the file on your machine.

Step 1.2: Extract Files

Generally, files being downloaded are stored in the downloads folder, verify it and extract the tar setup using the following commands.

$ cd /go/to/download/path

$ tar -zxf jdk-8u60-linux-x64.gz

Step 1.3: Move to Opt Directory

To make java available to all users, move the extracted java content to “/usr/local/java” folder.

$ su

password: (type password of root user)

$ mkdir /opt/jdk

$ mv jdk-1.8.0_60 /opt/jdk/

Step 1.4: Set path

To set path and JAVA_HOME variables, add the following commands to ~/.bashrc file.

export JAVA_HOME =/usr/jdk/jdk-1.8.0_60 export PATH=$PATH:$JAVA_HOME/bin

5. Kafka – Installation Steps

(18)

13 Now apply all the changes into current running system.

$ source ~/.bashrc

Step 1.5: Java Alternatives

Use the following command to change Java Alternatives.

update-alternatives --install /usr/bin/java java /opt/jdk/jdk1.8.0_60/bin/java 100 Step 1.6: Now verify java using verification command (java -version) explained in Step 1.

Step 2: ZooKeeper Framework Installation

Step 2.1: Download ZooKeeper

To install ZooKeeper framework on your machine, visit the following link and download the latest version of ZooKeeper.

http://zookeeper.apache.org/releases.html

As of now, latest version of ZooKeeper is 3.4.6 (ZooKeeper-3.4.6.tar.gz).

Step 2.2: Extract tar file

Extract tar file using the following command

$ cd opt/

$ tar -zxf zookeeper-3.4.6.tar.gz

$ cd zookeeper-3.4.6

$ mkdir data

Step 2.3: Create Configuration File

Open Configuration File named “conf/zoo.cfg” using the command vi “conf/zoo.cfg” and all the following parameters to set as starting point.

$ vi conf/zoo.cfg tickTime=2000

dataDir=/path/to/zookeeper/data clientPort=2181

initLimit=5 syncLimit=2

Once the configuration file has been saved successfully and return to terminal again, you can start the zookeeper server.

(19)

14

Step 2.4: Start ZooKeeper Server

$ bin/zkServer.sh start

After executing this command, you will get a response as shown below:

$ JMX enabled by default

$ Using config: /Users/../zookeeper-3.4.6/bin/../conf/zoo.cfg

$ Starting zookeeper ... STARTED

Step 2.5: Start CLI

$ bin/zkCli.sh

After typing the above command, you will be connected to the zookeeper server and will get the below response.

Connecting to localhost:2181 ...

...

Welcome to ZooKeeper!

...

WATCHER::

WatchedEvent state:SyncConnected type: None path:null [zk: localhost:2181(CONNECTED) 0]

Step 2.6: Stop Zookeeper Server

After connecting the server and performing all the operations, you can stop the zookeeper server with the following command:

$ bin/zkServer.sh stop

Now you have successfully installed Java and ZooKeeper on your machine. Let us see the steps to install Apache Kafka.

(20)

15

Step 3: Apache Kafka Installation

Let us continue with the following steps to install Kafka on your machine.

Step 3.1: Download Kafka

To install Kafka on your machine, click on the below link:

https://www.apache.org/dyn/closer.cgi?path=/kafka/0.9.0.0/kafka_2.11-0.9.0.0.tgz

Now the latest version i.e., – kafka_2.11_0.9.0.0.tgz will be downloaded onto your machine.

Step 3.2: Extract the tar file

Extract the tar file using the following command:

$ cd opt/

$ tar -zxf kafka_2.11.0.9.0.0 tar.gz

$ cd kafka_2.11.0.9.0.0

Now you have downloaded the latest version of Kafka on your machine.

Step 3.3: Start Server

You can start the server by giving the following command:

$ bin/kaka-server-start.sh config/server.properties

After the server starts, you would see the below response on your screen:

$ bin/kaka-server-start.sh config/server.properties [2016-01-02 15:37:30,410] INFO KafkaConfig values:

request.timeout.ms = 30000 log.roll.hours = 168

inter.broker.protocol.version = 0.9.0.X log.preallocate = false

security.inter.broker.protocol = PLAINTEXT

……….

(21)

16

Step 4: Stop the Server

After performing all the operations, you can stop the server using the following command –

$ bin/kaka-server-stop.sh config/server.properties

Now that we have already discussed the Kafka installation, we can learn how to perform basic operations on Kafka in the next chapter.

(22)

17 First let us start implementing “single node-single broker” configuration and we will then migrate our setup to single node-multiple brokers configuration.

Hopefully you would have installed Java, ZooKeeper and Kafka on your machine by now. Before moving to the Kafka Cluster Setup, first you would need to start your ZooKeeper because Kafka Cluster uses ZooKeeper.

Start ZooKeeper

Open a new terminal and type the following command:

bin/zookeeper-server-start.sh config/zookeeper.properties To start Kafka Broker, type the following command:

bin/kafka-server-start.sh config/server.properties

After starting Kafka Broker, type the command “jps” on ZooKeeper terminal and you would see the following response:

821 QuorumPeerMain 928 Kafka

931 Jps

Now you could see two daemons running on the terminal where QuorumPeerMain is ZooKeeper daemon and another one is Kafka daemon.

Single Node-Single Broker Configuration

In this configuration you have a single ZooKeeper and broker id instance. Following are the steps to configure it:

Creating a Kafka Topic: Kafka provides a command line utility named “kafka-topics.sh” to create topics on the server. Open new terminal and type the below example.

Syntax

bin/kafka-topics.sh --create --zookeeper localhost:2181 --replication-factor 1 -- partitions 1 --topic topic-name

Example

bin/kafka-topics.sh --create --zookeeper localhost:2181 --replication-factor 1 -- partitions 1 --topic Hello-Kafka

We just created a topic named “Hello-Kafka” with a single partition and one replica factor. The above created output will be similar to the following output:

(23)

18 Output: Created topic “Hello-Kafka”

Once the topic has been created, you can get the notification in Kafka broker terminal window and the log for the created topic specified in “/tmp/kafka-logs/“ in the config/server.properties file.

List of Topics

To get a list of topics in Kafka server, you can use the following command:

Syntax

bin/kafka-topics.sh --list --zookeeper localhost:2181 Output

Hello-Kafka

Since we have created a topic, it will list out “Hello-Kafka” only. Suppose, if you create more than one topics, you will get the topic names in the output.

Start Producer to Send Messages

Syntax

bin/kafka-console-producer.sh --broker-list localhost:9092 --topic topic-name

From the above syntax, two main parameters are required for the producer command line client:

Broker-list - The list of brokers that we want to send the messages to. In this case we only have one broker. The Config/server.properties file contains broker port id, since we know our broker is listening on port 9092, so you can specify it directly.

Topic name – Here is an example for the topic name.

Example

bin/kafka-console-producer.sh --broker-list localhost:9092 --topic Hello-Kafka

The producer will wait on input from stdin and publishes to the Kafka cluster. By default, every new line is published as a new message then the default producer properties are specified in

“config/producer.properties” file. Now you can type a few lines of messages in the terminal as shown below.

(24)

19 Output

$ bin/kafka-console-producer.sh --broker-list localhost:9092 --topic Hello-Kafka [2016-01-16 13:50:45,931] WARN property topic is not valid (kafka.utils.Verifia- bleProperties)

Hello

My first message

My second message

Start Consumer to Receive Messages

Similar to producer, the default consumer properties are specified in “config/consumer.properties” file. Open a new terminal and type the below syntax for consuming messages.

Syntax

bin/kafka-console-consumer.sh --zookeeper localhost:2181 —topic topic-name --from- beginning

Example

bin/kafka-console-consumer.sh --zookeeper localhost:2181 —topic Hello-Kafka --from- beginning

Output

Hello

My first message My second message

Finally, you are able to enter messages from the producer’s terminal and see them appearing in the consumer’s terminal. As of now, you have a very good understanding on the single node cluster with a single broker. Let us now move on to the multiple brokers configuration.

(25)

20

Single Node-Multiple Brokers Configuration

Before moving on to the multiple brokers cluster setup, first start your ZooKeeper server.

Create Multiple Kafka Brokers – We have one Kafka broker instance already in con- fig/server.properties. Now we need multiple broker instances, so copy the existing server.properties file into two new config files and rename it as server-one.properties and server-two.properties. Then edit both new files and assign the following changes:

config/server-one.properties

# The id of the broker. This must be set to a unique integer for each broker.

broker.id=1

# The port the socket server listens on port=9093

# A comma seperated list of directories under which to store log files log.dirs=/tmp/kafka-logs-1

config/server-two.properties

# The id of the broker. This must be set to a unique integer for each broker.

broker.id=2

# The port the socket server listens on port=9094

# A comma seperated list of directories under which to store log files log.dirs=/tmp/kafka-logs-2

Start Multiple Brokers – After all the changes have been made on three servers then open three new terminals to start each broker one by one.

Broker1

bin/kafka-server-start.sh config/server.properties Broker2

bin/kafka-server-start.sh config/server-one.properties Broker3

bin/kafka-server-start.sh config/server-two.properties

Now we have three different brokers running on the machine. Try it by yourself to check all the daemons by typing “jps” on the ZooKeeper terminal, then you would see the response.

(26)

21

Creating a Topic

Let us assign the replication factor value as three for this topic because we have three different brokers running. If you have two brokers, then the assigned replica value will be two.

Syntax

bin/kafka-topics.sh --create --zookeeper localhost:2181 --replication-factor 3 -partitions 1 --topic topic-name

Example

bin/kafka-topics.sh --create --zookeeper localhost:2181 --replication-factor 3 -partitions 1 --topic Multibrokerapplication

Output

created topic “Multibrokerapplication”

The “Describe” command is used to check which broker is listening on the current created topic as shown below:

bin/kafka-topics.sh --describe --zookeeper localhost:2181 --topic Multibrokerappli- cation

Output

bin/kafka-topics.sh --describe --zookeeper localhost:2181 --topic Multibrokerappli- cation

Topic:Multibrokerapplication PartitionCount:1 ReplicationFactor:3 Configs:

Topic:Multibrokerapplication Partition:0 Leader:0 Replicas:0,2,1 Isr:0,2,1 From the above output, we can conclude that first line gives a summary of all the partitions, showing topic name, partition count and the replication factor that we have chosen already. In the second line, each node will be the leader for a randomly selected portion of the partitions.

In our case, we see that our first broker (with broker.id 0) is the leader. Then Replicas:0,2,1 means that all the brokers replicate the topic finally “Isr" is the set of “in-sync” replicas. Well, this is the subset of replicas that are currently alive and caught up by the leader.

Start Producer to Send Messages

This procedure remains the same as in the single broker setup.

Example

bin/kafka-console-producer.sh --broker-list localhost:9092 --topic Multibrokerappli- cation

(27)

22 Output

bin/kafka-console-producer.sh --broker-list localhost:9092 --topic Multibrokerappli- cation

[2016-01-20 19:27:21,045] WARN Property topic is not valid (kafka.utils.Verifia- bleProperties)

This is single node-multi broker demo This is the second message

Start Consumer to Receive Messages

This procedure remains the same as shown in the single broker setup.

Example

bin/kafka-console-consumer.sh --zookeeper localhost:2181 —topic Multibrokerapplica- tion --from-beginning

Output

bin/kafka-console-consumer.sh --zookeeper localhost:2181 —topic Multibrokerapplica- tion —from-beginning

This is single node-multi broker demo This is the second message

Basic Topic Operations

In this chapter we will discuss the various basic topic operations.

Modifying a Topic

As you have already understood how to create a topic in Kafka Cluster. Now let us modify a created topic using the following command

Syntax

bin/kafka-topics.sh —zookeeper localhost:2181 --alter --topic topic_name --partitions count

Example

We have already created a topic “Hello-Kafka” with single partition count and one replica factor. Now using “alter” command we have changed the partition count.

bin/kafka-topics.sh --zookeeper localhost:2181 --alter --topic Hello-kafka --partitions 2

(28)

23 Output

WARNING: If partitions are increased for a topic that has a key, the partition logic or ordering of the messages will be affected

Adding partitions succeeded!

Deleting a Topic

To delete a topic, you can use the following syntax.

Syntax

bin/kafka-topics.sh --zookeeper localhost:2181 --delete --topic topic_name Example

bin/kafka-topics.sh --zookeeper localhost:2181 --delete --topic Hello-kafka

Output

> Topic Hello-kafka marked for deletion

Note: This will have no impact if delete.topic.enable is not set to true.

(29)

24 Let us create an application for publishing and consuming messages using a Java client. Kafka producer client consists of the following API’s.

KafkaProducer API

Let us understand the most important set of Kafka producer API in this section. The central part of the KafkaProducer API is “KafkaProducer” class. The KafkaProducer class provides an option to connect a Kafka broker in its constructor with the following methods.

 KafkaProducer class provides send method to send messages asynchronously to a topic.

The signature of send() is as follows

producer.send(new ProducerRecord<byte[],byte[]>(topic, partition, key1, value1) , callback);

 ProducerRecord - The producer manages a buffer of records waiting to be sent.

 Callback - A user-supplied callback to execute when the record has been acknowl- edged by the server (null indicates no callback).

 KafkaProducer class provides a flush method to ensure all previously sent messages have been actually completed. Syntax of the flush method is as follows:

public void flush()

 KafkaProducer class provides partitionFor method, which helps in getting the partition metadata for a given topic. This can be used for custom partitioning. The signature of this method is as follows:

public partitionsFor(string topic) It returns the metadata of the topic.

 KafkaProducer class provides metrics method that is used to return a map of metrics maintained by the producer. The signature of this method is as follows:

public Map metrics()

It returns the map of internal metrics maintained by the producer.

 public void close() – KafkaProducer class provides close method blocks until all previously sent requests are completed.

7. Kafka – Simple Producer Example

(30)

25

Producer API

The central part of the Producer API is “Producer” class. Producer class provides an option to connect Kafka broker in its constructor by the following methods.

The Producer Class

The producer class provides send method to send messages to either single or multiple topics using the following signatures.

public void send(KeyedMessage<k,v> message) - sends the data to a single topic,partitioned by key using either sync or async producer.

public void send(List<KeyedMessage<k,v>> messages) - sends data to multiple topics.

Properties prop = new Properties();

prop.put(producer.type,”async”)

ProducerConfig config = new ProducerConfig(prop);

There are two types of producers – Sync and Async.

The same API configuration applies to “Sync” producer as well. The difference between them is a sync producer sends messages directly, but sends messages in background. Async producer is preferred when you want a higher throughput. In the previous releases like 0.8, an async producer does not have a callback for send() to register error handlers. This is available only in the current release of 0.9.

public void close()

Producer class provides close method to close the producer pool connections to all Kafka bro- kers.

Configuration Settings

The Producer API’s main configuration settings are listed in the following table for better understanding:

client.id identifies producer application

producer.type either sync or async

acks The acks config controls the criteria under producer requests are considered complete.

retries If producer request fails, then automatically retry with specific value.

bootstrap.servers bootstrapping list of brokers.

(31)

26 linger.ms if you want to reduce the number of requests you can set linger.ms to

something greater than some value.

key.serializer Key for the serializer interface

value.serializer value for the serializer interface

batch.size Buffer size

buffer.memory controls the total amount of memory available to the producer for buffering.

ProducerRecord API

ProducerRecord is a key/value pair that is sent to Kafka cluster.ProducerRecord class constructor for creating a record with partition, key and value pairs using the following signature.

public ProducerRecord (string topic, int partition, k key, v value)

 Topic - user defined topic name that will appended to record.

 Partition - partition count.

 Key - The key that will be included in the record.

 Value - Record contents.

public ProducerRecord (string topic, k key, v value)

ProducerRecord class constructor is used to create a record with key, value pairs and without partition.

 Topic - Create a topic to assign record.

 Key - key for the record.

 Value - record contents.

public ProducerRecord (string topic, v value)

ProducerRecord class creates a record without partition and key.

 Topic - create a topic.

 Value - record contents.

(32)

27 The ProducerRecord class methods are listed in the following table:

public string topic() Topic will append to the record.

public K key() Key that will be included in the record. If no such key, null will be returned here.

public V value() Record contents.

partition() Partition count for the record

SimpleProducer application

Before creating the application, first start ZooKeeper and Kafka broker then create your own topic in Kafka broker using create topic command. After that create a java class named “Sim- pleProducer.java” and type in the following coding.

import java.util.Properties;

//import util.properties packages

import org.apache.kafka.clients.producer.Producer;

//import simple producer packages

import org.apache.kafka.clients.producer.KafkaProducer;

//import KafkaProducer packages

import org.apache.kafka.clients.producer.ProducerRecord;

//import ProducerRecord packages public class SimpleProducer {

//Create java class named “SimpleProducer”

public static void main(String[] args) throws Exception { if(args.length == 0)

// Check arguments length value {

System.out.println("Enter topic name”);

return;

}

String topicName = args[0].toString();

//Assign topicName to string variable

Properties props = new Properties();

// create instance for properties to access producer configs

(33)

28

props.put("bootstrap.servers", “localhost:9092");

//Assign localhost id

props.put("acks", “all");

//Set acknowledgements for producer requests.

props.put("retries", 0);

//If the request fails, the producer can automatically retry,

props.put("batch.size", 16384);

//Specify buffer size in config

props.put("linger.ms", 1);

//Reduce the no of requests less than 0

props.put("buffer.memory", 33554432);

//The buffer.memory controls the total amount of memory available to the producer for buffering.

props.put("key.serializer", "org.apache.kafka.common.serializa- tion.StringSerializer");

props.put("value.serializer", "org.apache.kafka.common.serializa- tion.StringSerializer");

Producer<String, String> producer = new KafkaProducer<String, String>(props);

for(int i = 0; i < 10; i++)

producer.send(new ProducerRecord<String, String>(topicName, Integer.toString(i), Integer.toString(i)));

System.out.println(“Message sent successfully”);

producer.close();

} }

Compilation – The application can be compiled using the following command.

(34)

29 javac -cp “/path/to/kafka/kafka_2.11-0.9.0.0/lib/*” *.java

Execution – The application can be executed using the following command.

java -cp “/path/to/kafka/kafka_2.11-0.9.0.0/lib/*”:. SimpleProducer <topic-name>

Output

Message sent successfully

To check the above output open new terminal and type Consumer CLI command to receive messages.

>> bin/kafka-console-consumer.sh --zookeeper localhost:2181 —topic <topic-name> — from-beginning

1 2 3 4 5 6 7 8 9 10

Simple Consumer Example

As of now we have created a producer to send messages to Kafka cluster. Now let us create a consumer to consume messages form the Kafka cluster. KafkaConsumer API is used to consume messages from the Kafka cluster. KafkaConsumer class constructor is defined below.

public KafkaConsumer(java.util.Map<java.lang.String,java.lang.Object> configs) configs - Return a map of consumer configs.

KafkaConsumer class has the following significant methods that are listed in the table below.

public java.util.Set<TopicPar- tition> assignment()

Get the set of partitions currently assigned by the consumer.

public string subscription() Subscribe to the given list of topics to get dynamically assigned partitions.

(35)

30 public void sub-

scribe(java.util.List<java.lang .String> topics, ConsumerRe- balanceListener listener)

First argument topics refers to subscribing topics list and second argument listener refers to get notifications on partition assignment/revocation for the subscribed topics.

public void unsubscribe() Unsubscribe the topics from the given list of partitions.

public void sub-

scribe(java.util.List<java.lang .String> topics)

Subscribe to the given list of topics to get dynamically assigned partitions. If the given list of topics is empty, it is treated the same as unsubscribe().

public void sub-

scribe(java.util.regex.Pattern pattern, ConsumerRebalanceLis- tener listener)

The argument pattern refers to the subscribing pattern in the format of regular expression and the listener argument gets notifications from the subscribing pattern.

public void as-

sign(java.util.List<TopicParti- tion> partitions)

Manually assign a list of partitions to the customer.

poll()

Fetch data for the topics or partitions specified using one of the subscribe/assign APIs. This will return error, if the topics are not subscribed before the polling for data.

public void commitSync()

Commit offsets returned on the last poll() for all the subscribed list of topics and partitions. The same operation is applied to commitAsyn().

public void seek(TopicPartition partition, long offset)

Fetch the current offset value that consumer will use on the next poll() method.

public void resume() Resume the paused partitions.

public void wakeup() Wakeup the consumer.

ConsumerRecord API

The ConsumerRecord API is used to receive records from the Kafka cluster. This API consists of a topic name, partition number, from which the record is being received and an offset that points to the record in a Kafka partition. ConsumerRecord class is used to create a consumer record with specific topic name, partition count and <key, value> pairs. It has the following signature.

public ConsumerRecord(string topic,int partition, long offset,K key, V value)

 Topic - The topic name for consumer record received from the Kafka cluster.

 Partition - Partition for the topic.

 Key - The key of the record, if no key exists null will be returned.

(36)

31

 Value - Record contents.

ConsumerRecords API

ConsumerRecords API acts as a container for ConsumerRecord. This API is used to keep the list of ConsumerRecord per partition for a particular topic. Its Constructor is defined below.

public ConsumerRecords(java.util.Map<TopicPartition,java.util.List<Consumer- Record<K,V>>> records)

 TopicPartition - Return a map of partition for a particular topic.

 Records - Return list of ConsumerRecord.

ConsumerRecords class has the following methods defined.

public int count() The number of records for all the topics.

public Set partitions() The set of partitions with data in this record set (if no data was returned then the set is empty).

public Iterator iterator() Iterator enables you to cycle through a collection, obtaining or re- moving elements.

public List records() Get list of records for the given partition.

Configuration Settings

The configuration settings for the Consumer client API main configuration settings are listed below:

bootstrap.servers Bootstrapping list of brokers.

group.id Assigns an individual consumer to a group.

enable.auto.commit Enable auto commit for offsets if the value is true, otherwise not committed.

auto.commit.interval.ms Return how often updated consumed offsets are written to ZooKeeper.

session.timeout.ms

Indicates how many milliseconds Kafka will wait for the ZooKeeper to respond to a request (read or write) before giving up and continuing to consume messages.

(37)

32

SimpleConsumer Application

The producer application steps remain the same here. First, start your ZooKeeper and Kafka broker. Then create a “SimpleConsumer” application with the java class named “SimpleCon- sumer.java” and type the following code.

import java.util.Arrays;

import org.apache.kafka.clients.consumer.KafkaConsumer;

import org.apache.kafka.clients.consumer.ConsumerRecords;

import org.apache.kafka.clients.consumer.ConsumerRecord;

public class SimpleConsumer {

public static void main(String[] args) throws Exception { if(args.length == 0)

{

System.out.println("Enter topic name");

return;

}

String topicName = args[0].toString();

//Kafka consumer configuration settings

props.put("bootstrap.servers", "localhost:9092");

props.put("group.id", "test");

props.put("enable.auto.commit", "true");

props.put("auto.commit.interval.ms", "1000");

props.put("session.timeout.ms", "30000");

props.put("key.deserializer", "org.apache.kafka.common.serializa- tion.StringDeserializer");

props.put("value.deserializer", "org.apache.kafka.common.serializa- tion.StringDeserializer");

KafkaConsumer<String, String> consumer = new KafkaConsumer<String, String>(props);

consumer.subscribe(Arrays.asList(topicName));

//KafkaConsumer subscribes list of topics here.

System.out.println("Subscribed to topic " + topicName); //print the topic name

int i = 0;

while (true) {

(38)

33 ConsumerRecords<String, String> records = con-

sumer.poll(100);

for (ConsumerRecord<String, String> record : records) System.out.printf("offset = %d, key = %s, value

= %s\n", record.offset(), record.key(), record.value());

// print the offset,key and value for the consumer records.

} }

}

Compilation – The application can be compiled using the following command.

javac -cp “/path/to/kafka/kafka_2.11-0.9.0.0/lib/*” *.java

Execution – The application can be executed using the following command.

java -cp “/path/to/kafka/kafka_2.11-0.9.0.0/lib/*”:. SimpleConsumer <topic-name>

Input – Open the producer CLI and send some messages to the topic. You can put the smple input as ‘Hello Consumer’.

Output – Following will be the output.

Subscribed to topic Hello-Kafka

offset = 3, key = null, value = Hello Consumer

(39)

34 Consumer group is a multi-threaded or multi-machine consumption from Kafka topics.

Consumer Group

 Consumers can join a group by using the same “group.id”.

 The maximum parallelism of a group is that the number of consumers in the group <=

no of partitions.

 Kafka assigns the partitions of a topic to the consumer in a group, so that each partition is consumed by exactly one consumer in the group.

 Kafka guarantees that a message is only ever read by a single consumer in the group.

 Consumers can see the message in the order they were stored in the log.

Re-balancing of a Consumer

Adding more processes/threads will cause Kafka to re-balance. If any consumer or broker fails to send heartbeat to ZooKeeper, then it can be re-configured via the Kafka cluster. During this re-balance, Kafka will assign available partitions to the available threads, possibly moving a partition to another process.

import java.util.Arrays;

import org.apache.kafka.clients.consumer.KafkaConsumer;

import org.apache.kafka.clients.consumer.ConsumerRecords;

import org.apache.kafka.clients.consumer.ConsumerRecord;

public class ConsumerGroup {

public static void main(String[] args) throws Exception { if(args.length < 2)

{

System.out.println("Usage: consumer <topic> <groupname>");

return;

}

String topic = args[0].toString();

String group = args[1].toString();

props.put("bootstrap.servers", "localhost:9092");

props.put("group.id", group);

8. Kafka – Consumer Group Example

(40)

35 props.put("enable.auto.commit", "true");

props.put("auto.commit.interval.ms", "1000");

props.put("session.timeout.ms", "30000");

props.put("key.deserializer", "org.apache.kafka.common.serializa- tion.StringDeserializer");

props.put("value.deserializer", "org.apache.kafka.common.serializa- tion.StringDeserializer");

KafkaConsumer<String, String> consumer = new KafkaConsumer<String, String>(props);

consumer.subscribe(Arrays.asList(topic));

System.out.println("Subscribed to topic " + topic);

int i = 0;

while (true) {

ConsumerRecords<String, String> records = consumer.poll(100);

for (ConsumerRecord<String, String> record : records) System.out.printf("offset = %d, key = %s, value

= %s\n", record.offset(), record.key(), record.value());

} }

}

Compilation

javac -cp “/path/to/kafka/kafka_2.11-0.9.0.0/libs/*" ConsumerGroup.java

Execution

>>java -cp “/path/to/kafka/kafka_2.11-0.9.0.0/libs/*":. ConsumerGroup <topic-name>

my-group

>>java -cp "/home/bala/Workspace/kafka/kafka_2.11-0.9.0.0/libs/*":. ConsumerGroup

<topic-name> my-group

Here we have created a sample group name as “my-group” with two consumers. Similarly, you can create your group and number of consumers in the group.

(41)

36

Input

Open producer CLI and send some messages like –

Test consumer group 01 Test consumer group 02

Output of the First Process

Subscribed to topic Hello-kafka

offset = 3, key = null, value = Test consumer group 01

Output of the Second Process

Subscribed to topic Hello-kafka

offset = 3, key = null, value = Test consumer group 02

Now hopefully you would have understood SimpleConsumer and ConsumeGroup by using the Java client demo. Now you have an idea about how to send and receive messages using a Java client. Let us continue Kafka integration with big data technologies in the next chapter.

(42)

37 In this chapter, we will learn how to integrate Kafka with Apache Storm.

About Storm

Storm was originally created by Nathan Marz and team at BackType. In a short time, Apache Storm became a standard for distributed real-time processing system that allows you to process a huge volume of data. Storm is very fast and a benchmark clocked it at over a million tuples processed per second per node. Apache Storm runs continuously, consuming data from the configured sources (Spouts) and passes the data down the processing pipeline (Bolts). Com- bined, Spouts and Bolts make a Topology.

Integration with Storm

Kafka and Storm naturally complement each other, and their powerful cooperation enables real- time streaming analytics for fast-moving big data. Kafka and Storm integration is to make easier for developers to ingest and publish data streams from Storm topologies.

Conceptual flow

A spout is a source of streams. For example, a spout may read tuples off a Kafka Topic and emit them as a stream. A bolt consumes input streams, process and possibly emits new streams.

Bolts can do anything from running functions, filtering tuples, do streaming aggregations, streaming joins, talk to databases, and more. Each node in a Storm topology executes in parallel.

A topology runs indefinitely until you terminate it. Storm will automatically reassign any failed tasks. Additionally, Storm guarantees that there will be no data loss, even if the machines go down and messages are dropped.

Let us go through the Kafka-Storm integration API’s in detail. There are three main classes to integrate Kafka with Storm. They are as follows –

BrokerHosts - ZkHosts & StaticHosts

BrokerHosts is an interface and ZkHosts and StaticHosts are its two main implementations.

ZkHosts is used to track the Kafka brokers dynamically by maintaining the details in ZooKeeper, while StaticHosts is used to manually / statically set the Kafka brokers and its details. ZkHosts is the simple and fast way to access the Kafka broker.

The signature of ZkHosts is as follows –

public ZkHosts(String brokerZkStr, String brokerZkPath) public ZkHosts(String brokerZkStr)

Where brokerZkStr is ZooKeeper host and brokerZkPath is the ZooKeeper path to maintain the Kafka broker details.

(43)

38

KafkaConfig API

This API is used to define configuration settings for the Kafka cluster. The signature of KafkaCon- fig is defined as follows

public KafkaConfig(BrokerHosts hosts, string topic)

 Hosts - The BrokerHosts can be ZkHosts / StaticHosts.

 Topic - topic name.

SpoutConfig API

Spoutconfig is an extension of KafkaConfig that supports additional ZooKeeper information.

public SpoutConfig(BrokerHosts hosts, string topic, string zkRoot, string id)

 Hosts - The BrokerHosts can be any implementation of BrokerHosts interface

 Topic - topic name.

 zkRoot - ZooKeeper root path.

 id - The spout stores the state of the offsets its consumed in Zookeeper. The id should uniquely identify your spout.

SchemeAsMultiScheme

SchemeAsMultiScheme is an interface that dictates how the ByteBuffer consumed from Kafka gets transformed into a storm tuple. It is derived from MultiScheme and accept implementation of Scheme class. There are lot of implementation of Scheme class and one such implementation is StringScheme, which parses the byte as a simple string. It also controls the naming of your output field. The signature is defined as follows.

public SchemeAsMultiScheme(Scheme scheme)

 Scheme - byte buffer consumed from kafka.

KafkaSpout API

KafkaSpout is our spout implementation, which will integrate with Storm. It fetches the messages from kafka topic and emits it into Storm ecosystem as tuples. KafkaSpout get its configuration details from SpoutConfig.

Below is a sample code to create a simple Kafka spout.

BrokerHosts hosts = new ZkHosts(zkConnString);

// ZooKeeper connection string

SpoutConfig spoutConfig = new SpoutConfig(hosts, topicName, "/" + topicName UUID.randomUUID().toString());

/*ZooKeeper connection info,topic name,Zkroot will be used as root to store your consumer's offset,id should uniquely identify your spout.*/

spoutConfig.scheme = new SchemeAsMultiScheme(new StringScheme());

(44)

39 //convert the ByteBuffer to String.

KafkaSpout kafkaSpout = new KafkaSpout(spoutConfig);

//Assign SpoutConfig to KafkaSpout.

Bolt Creation

Bolt is a component that takes tuples as input, processes the tuple, and produces new tuples as output. Bolts will implement IRichBolt interface. In this program, two bolt classes WordSplitter- Bolt and WordCounterBolt are used to perform the operations.

IRichBolt interface has the following methods:

 Prepare − Provides the bolt with an environment to execute. The executors will run this method to initialize the spout.

 Execute − Process a single tuple of input.

 Cleanup − Called when a bolt is going to shut down.

 declareOutputFields − Declares the output schema of the tuple.

Let us create SplitBolt.java, which implements the logic to split a sentence into words and CountBolt.java, which implements logic to separate unique words and count its occurrence.

SplitBolt.java

import java.util.Map;

import backtype.storm.tuple.Tuple;

import backtype.storm.tuple.Fields;

import backtype.storm.tuple.Values;

import backtype.storm.task.OutputCollector;

import backtype.storm.topology.OutputFieldsDeclarer;

import backtype.storm.topology.IRichBolt;

import backtype.storm.task.TopologyContext;

public class SplitBolt implements IRichBolt { private OutputCollector collector;

@Override

public void prepare(Map stormConf, TopologyContext context, OutputCollector collector) {

this.collector = collector;

}

@Override

(45)

40 public void execute(Tuple input) {

String sentence = input.getString(0);

String[] words = sentence.split(" ");

for(String word: words) { word = word.trim();

if(!word.isEmpty()) {

word = word.toLowerCase();

collector.emit(new Values(word));

} }

collector.ack(input);

}

@Override

public void declareOutputFields(OutputFieldsDeclarer declarer) { declarer.declare(new Fields("word"));

}

@Override

public void cleanup() { }

@Override

public Map<String, Object> getComponentConfiguration() { return null;

} }

CountBolt.java

import java.util.Map;

import java.util.HashMap;

import backtype.storm.tuple.Tuple;

import backtype.storm.task.OutputCollector;

import backtype.storm.topology.OutputFieldsDeclarer;

import backtype.storm.topology.IRichBolt;

import backtype.storm.task.TopologyContext;

public class CountBolt implements IRichBolt{

(46)

41 Map<String, Integer> counters;

private OutputCollector collector;

@Override

public void prepare(Map stormConf, TopologyContext context, OutputCollector collector) {

this.counters = new HashMap<String, Integer>();

this.collector = collector;

}

@Override

public void execute(Tuple input) { String str = input.getString(0);

if(!counters.containsKey(str)){

counters.put(str, 1);

}else{

Integer c = counters.get(str) +1;

counters.put(str, c);

}

collector.ack(input);

}

@Override

public void cleanup() {

for(Map.Entry<String, Integer> entry:counters.entrySet()){

System.out.println(entry.getKey()+" : " + entry.getValue());

} }

@Override

public void declareOutputFields(OutputFieldsDeclarer declarer) { }

@Override

public Map<String, Object> getComponentConfiguration() { return null;

} }

(47)

42

Submitting to Topology

The Storm topology is basically a Thrift structure. TopologyBuilder class provides simple and easy methods to create complex topologies. The TopologyBuilder class has methods to set spout (setSpout) and to set bolt (setBolt). Finally, TopologyBuilder has createTopology to create topology. shuffleGrouping and fieldsGrouping methods help to set stream grouping for spout and bolts.

Local Cluster – For development purposes, we can create a local cluster using "LocalCluster"

object and then submit the topology using "submitTopology" method of "LocalCluster" class.

KafkaStormSample.java

import backtype.storm.Config;

import backtype.storm.LocalCluster;

import backtype.storm.topology.TopologyBuilder;

import java.util.ArrayList;

import java.util.List;

import java.util.UUID;

import backtype.storm.spout.SchemeAsMultiScheme;

import storm.kafka.trident.GlobalPartitionInformation;

import storm.kafka.ZkHosts;

import storm.kafka.Broker;

import storm.kafka.StaticHosts;

import storm.kafka.BrokerHosts;

import storm.kafka.SpoutConfig;

import storm.kafka.KafkaConfig;

import storm.kafka.KafkaSpout;

import storm.kafka.StringScheme;

public class KafkaStormSample {

public static void main(String[] args) throws Exception{

Config config = new Config();

config.setDebug(true);

config.put(Config.TOPOLOGY_MAX_SPOUT_PENDING, 1);

(48)

43 String zkConnString = "localhost:2181";

String topic = "my-first-topic";

BrokerHosts hosts = new ZkHosts(zkConnString);

SpoutConfig kafkaSpoutConfig = new SpoutConfig (hosts, topic, "/" + topic, UUID.randomUUID().toString());

kafkaSpoutConfig.bufferSizeBytes = 1024 * 1024 * 4;

kafkaSpoutConfig.fetchSizeBytes = 1024 * 1024 * 4;

kafkaSpoutConfig.forceFromStart = true;

kafkaSpoutConfig.scheme = new SchemeAsMultiScheme(new StringScheme());

TopologyBuilder builder = new TopologyBuilder();

builder.setSpout("kafka-spout", new KafkaSpout(kafkaSpoutCon- fig));

builder.setBolt("word-spitter", new SplitBolt()).shuffleGroup- ing("kafka-spout");

builder.setBolt("word-counter", new CountBolt()).shuffleGroup- ing("word-spitter");

LocalCluster cluster = new LocalCluster();

cluster.submitTopology("KafkaStormSample", config, builder.create- Topology());

Thread.sleep(10000);

cluster.shutdown();

}

Before moving compilation, Kakfa-Storm integration needs curator ZooKeeper client java library.

Curator version 2.9.1 support Apache Storm version 0.9.5 (which we use in this tutorial). Down- load the below specified jar files and place it in java class path.

 curator-client-2.9.1.jar

 curator-framework-2.9.1.jar

(49)

44 After including dependency files, compile the program using the following command,

javac -cp "/path/to/Kafka/apache-storm-0.9.5/lib/*" *.java

Execution

Start Kafka Producer CLI (explained in previous chapter), create a new topic called “my-first- topic” and provide some sample messages as shown below:

hello kafka storm spark

test message

another test message

Now execute the application using the following command:

java -cp “/path/to/Kafka/apache-storm-0.9.5/lib/*”:. KafkaStormSample The sample output of this application is specified below –

storm : 1 test : 2 spark : 1 another : 1 kafka : 1 hello : 1 message : 2

(50)

45 In this chapter, we will be discussing about how to integrate Apache Kafka with Spark Streaming API.

About Spark

Spark Streaming API enables scalable, high-throughput, fault-tolerant stream processing of live data streams. Data can be ingested from many sources like Kafka, Flume, Twitter, etc., and can be processed using complex algorithms such as high-level functions like map, reduce, join and window. Finally, processed data can be pushed out to filesystems, databases, and live dashboards. Resilient Distributed Datasets (RDD) is a fundamental data structure of Spark. It is an immutable distributed collection of objects. Each dataset in RDD is divided into logical partitions, which may be computed on different nodes of the cluster.

Integration with Spark

Kafka is a potential messaging and integration platform for Spark streaming. Kafka act as the central hub for real-time streams of data and are processed using complex algorithms in Spark Streaming. Once the data is processed, Spark Streaming could be publishing results into yet another Kafka topic or store in HDFS, databases or dashboards. The following diagram depicts the conceptual flow.

Now, let us go through Kafka-Spark API’s in detail.

SparkConf API

It represents configuration for a Spark application. Used to set various Spark parameters as key- value pairs.

“SparkConf” class has the following methods:

 set(string key, string value) - set configuration variable

 remove(string key) - remove key from the configuration.

 setAppName(string name) - set application name for your application.

 get(string key) - get key

About the Tutorial
