Big Data and Internet Thinking

Chentao Wu

Associate Professor

Dept. of Computer Science and Engineering [email protected]

(2)

Download lectures

• ftp://public.sjtu.edu.cn

• User: wuct

• Password: wuct123456

• http://www.cs.sjtu.edu.cn/~wuct/bdit/

(3)

Schedule

• lec1: Introduction on big data, cloud computing & IoT

• Iec2: Parallel processing framework (e.g., MapReduce)

• lec3: Advanced parallel processing techniques (e.g., YARN, Spark)

• lec4: Cloud & Fog/Edge Computing

• lec5: Data reliability & data consistency

• lec6: Distributed file system & objected-based storage

• lec7: Metadata management & NoSQL Database

• lec8: Big Data Analytics

(4)

Collaborators

(5)

Contents

Introduction to Map-Reduce 2.0

1

(6)

Classic Map-Reduce Task (MRv1)

•

MapReduce 1 (“classic”) has three main components

 API→for user-level programming of MR applications

 Framework→runtime services for running Map and Reduce processes, shuffling and sorting, etc.

 Resource management→infrastructure to monitor nodes, allocate resources, and schedule jobs

(7)

MRv1: Batch Focus

HADOOP 1.0

Built for Web-Scale Batch Apps

Single App

BATCH

HDFS Single App

INTERACTIVE

Single App

BATCH

HDFS

All other usage patterns MUST leverage same infrastructure

Forces Creation of Silos to Manage Mixed Workloads

Single App

BATCH

HDFS Single App

ONLINE

(8)

YARN (MRv2)

•

MapReduce 2 move resource management to YARN

 MapReduce originally architecture at Yahoo in 2008

 “alpha” in Hadoop 2 (pre-GA)

 YARN promoted to sub-project in Hadoop in 2013 (Best Paper in SOCC 2013)

(9)

Why YARN is needed? (1)

•

MapReduce 1 resource management issues

 Inflexible “slots” configured on nodes → map or reduce, not both

 Underutilization of cluster when more map or reduce tasks are running

 Cannot share resources with non-MR applications

running on Hadoop cluster (e.g., impala, apache giraph)

 Scalability → one Job Tracker per cluster – limit of about 4000 nodes per cluster

(10)

Busy JobTracker on a large Apache

Hadoop cluster (MRv1)

(11)

Why YARN is needed? (2)

•

YARN Solutions

 No slots

 Nodes have “resources” → memory and CPU cores – which are allocated to applications when requested

 Supports MR and non-MR applications running on the same cluster

 Most Job Tracker functions moved to Application Master → one cluster can have many Application Masters

(12)

YARN: Taking Hadoop Beyond Batch

Applications Run Natively in Hadoop

HDFS2 (Redundant, Reliable Storage)

YARN

(Cluster Resource Management)

BATCH (MapReduce)

INTERACTIVE (Tez)

STREAMING (Storm, S4,…)

GRAPH (Giraph)

IN-MEMORY (Spark)

HPC MPI (OpenMPI) ONLINE

(HBase)

OTHER (Search) (Weave…)

Store ALL DATA in one place…

Interact with that data in MULTIPLE WAYS

with Predictable Performance and Quality of Service

(13)

YARN: Efficiency with Shared Services

Yahoo! leverages YARN

40,000+ nodes running YARN across over 365PB of data

~400,000 jobs per day for about 10 million hours of compute time Estimated a 60% – 150% improvement on node usage per day using YARN

Eliminated Colo (~10K nodes) due to increased utilization

For more details check out the YARN SOCC 2013 paper

(14)

YARN and MapReduce

•

YARN does not know or care what kind of application is running

 Could be MR or something else (e.g., Impala)

•

MR2 uses YARN

 Hadoop includes a MapReduce ApplicationMaster (AM) to manage MR jobs

 Each MapReduce job is a new instance of an application

(15)

Running a MapReduce Application in MRv2 (1)

(16)

Running a MapReduce Application in MRv2 (2)

(17)

Running a MapReduce Application in MRv2 (3)

(18)

Running a MapReduce Application in MRv2 (4)

(19)

Running a MapReduce Application in MRv2 (5)

(20)

Running a MapReduce Application in MRv2 (6)

(21)

Running a MapReduce Application in MRv2 (7)

(22)

Running a MapReduce Application in MRv2 (8)

(23)

Running a MapReduce Application in MRv2 (9)

(24)

Running a MapReduce Application in MRv2 (10)

(25)

The MapReduce Framework on YARN

•

In YARN, Shuffle is run as an auxiliary service

 Runs in the NodeManager JVM as a persistent service

(26)

Contents

Introduction to Spark

2

(27)

What is Spark?

•

Fast, expressive cluster computing system compatible with Apache Hadoop

 Works with any Hadoop-supported storage system (HDFS, S3, Avro, …)

•

Improves efficiency through:

 In-memory computing primitives

 General computation graphs

•

Improves usability through:

 Rich APIs in Java, Scala, Python

 Interactive shell

Up to 100× faster

Often 2-10× less code

(28)

How to Run It & Languages

•

Local multicore: just a library in your program

•

EC2: scripts for launching a Spark cluster

•

Private cluster: Mesos, YARN, Standalone Mode

•

APIs in Java, Scala and Python

•

Interactive shells in Scala and Python

(29)

Spark Framework

Spark + Hive Spark + Pregel

(30)

Key Idea

•

Work with distributed collections as you would with local ones

•

Concept: resilient distributed datasets (RDDs)

 Immutable collections of objects spread across a cluster

 Built through parallel transformations (map, filter, etc)

 Automatically rebuilt on failure

 Controllable persistence (e.g. caching in RAM)

(31)

Spark Runtime

•

Spark runs as a library in your program

•

(1 instance per app)

•

Runs tasks locally or on Mesos

 new SparkContext ( masterUrl, jobname, [sparkhome], [jars] )

 MASTER=local[n] ./spark-shell

 MASTER=HOST:PORT ./spark-shell

(32)

Example: Mining Console Logs

•

Load error messages from a log into memory, then interactively search for patterns

lines = spark.textFile(“hdfs://...”)

errors = lines.filter(lambda s: s.startswith(“ERROR”)) messages = errors.map(lambda s: s.split(‘\t’)[2])

messages.cache()

Block 1

Block 2 Block 3

Worker

Worker Driver

messages.filter(lambda s: “foo” in s).count() messages.filter(lambda s: “bar” in s).count() . . .

tasks results

Cache 1

Cache 2 Cache 3

Base RDD

Transformed RDD

Action

Result: full-text search of Wikipedia in <1 sec (vs 20 sec for on-disk data)

Result: scaled to 1 TB data in 5-7 sec (vs 170 sec for on-disk data)

(33)

RDD Fault Tolerance

RDDs track the transformations used to build them (their lineage) to recompute lost data

E.g: messages = textFile(...).filter(lambda s: s.contains(“ERROR”)) .map(lambda s: s.split(‘\t’)[2])

HadoopRDD

path = hdfs://…

FilteredRDD

func = contains(...)

MappedRDD

func = split(…)

(34)

Which Language Should I Use?

•

Standalone programs can be written in any, but console is only Python & Scala

•

Python developers: can stay with Python for both

•

Java developers: consider using Scala for console (to learn the API)

•

Performance: Java / Scala will be faster (statically typed), but Python can do well for numerical work with NumPy

(35)

Iterative Processing in Hadoop

(36)

Throughput Mem vs. Disk

• Typical throughput of disk: ~ 100 MB/sec

• Typical throughput of main memory: 50 GB/sec

• => Main memory is ~ 500 times faster than disk

(37)

Spark→ In Memory Data Sharing

(38)

Spark vs. Hadoop MapReduce (3)

(39)

Spark vs. Hadoop MapReduce (4)

(40)

On-Disk Sort Record Time to sort 100TB

2100 machines

2013 Record:

Hadoop

2014 Record:

Spark

Source: Daytona GraySort benchmark, sortbenchmark.org

72 minutes 207 machines 23 minutes

Also sorted 1PB in 4 hours

(41)

Powerful Stack – Agile Development (1)

0 20000 40000 60000 80000 100000 120000 140000

Hadoop MapReduce

Storm (Streaming)

Impala (SQL)

Giraph (Graph)

Spark

non-test, non-example source lines

(42)

Powerful Stack – Agile Development (2)

non-test, non-example source lines 0

20000 40000 60000 80000 100000 120000 140000

Hadoop MapReduce

Storm (Streaming)

Impala (SQL)

Giraph (Graph)

Spark

Streaming

(43)

Powerful Stack – Agile Development (3)

20000 40000 60000 80000 100000 120000 140000

Hadoop MapReduce

Storm (Streaming)

Impala (SQL)

Giraph (Graph)

Spark

SparkSQL Streaming

(44)

Powerful Stack – Agile Development (4)

20000 40000 60000 80000 100000 120000 140000

Hadoop MapReduce

Storm (Streaming)

Impala (SQL)

Giraph (Graph)

Spark

SparkSQL Streaming

(45)

Powerful Stack – Agile Development (5)

20000 40000 60000 80000 100000 120000 140000

Hadoop MapReduce

Storm (Streaming)

Impala (SQL)

Giraph (Graph)

Spark

GraphX StreamingSparkSQL

(46)

Powerful Stack – Agile Development (6)

20000 40000 60000 80000 100000 120000 140000

Hadoop MapReduce

Storm (Streaming)

Impala (SQL)

Giraph (Graph)

Spark

GraphX StreamingSparkSQL Your fancy

SIGMOD technique here

(47)

Contents

Spark Programming

3

(48)

Learning Spark

•

Easiest way: Spark interpreter (spark-shell or pyspark)

 Special Scala and Python consoles for cluster use

•

Runs in local mode on 1 thread by default, but can control with MASTER environment var:

MASTER=local ./spark-shell # local, 1 thread MASTER=local[2] ./spark-shell # local, 2 threads

MASTER=spark://host:port ./spark-shell # Spark standalone cluster

(49)

First Step: SparkContext

•

Main entry point to Spark functionality

•

Created for you in Spark shells as variable sc

•

In standalone programs, you’d make your own (see later for details)

(50)

Creating RDDs

# Turn a local collection into an RDD sc.parallelize([1, 2, 3])

# Load text file from local FS, HDFS, or S3 sc.textFile(“file.txt”)

sc.textFile(“directory/*.txt”)

sc.textFile(“hdfs://namenode:9000/path/file”)

# Use any existing Hadoop InputFormat

sc.hadoopFile(keyClass, valClass, inputFmt, conf)

(51)

Basic Transformations

nums = sc.parallelize([1, 2, 3])

# Pass each element through a function

squares = nums.map(lambda x: x*x) # => {1, 4, 9}

# Keep elements passing a predicate

even = squares.filter(lambda x: x % 2 == 0) # =>

{4}

# Map each element to zero or more others

nums.flatMap(lambda x: range(0, x)) # => {0, 0, 1, 0, 1, 2}

Range object (sequence of

numbers 0, 1, …, x-1)

(52)

Basic Actions

nums = sc.parallelize([1, 2, 3])

# Retrieve RDD contents as a local collection nums.collect() # => [1, 2, 3]

# Return first K elements nums.take(2) # => [1, 2]

# Count number of elements nums.count() # => 3

# Merge elements with an associative function nums.reduce(lambda x, y: x + y) # => 6

# Write elements to a text file

nums.saveAsTextFile(“hdfs://file.txt”)

(53)

Working with Key-Value Pairs

• Spark’s “distributed reduce” transformations act on RDDs of key-value pairs

• Python:

pair = (a, b)

pair[0] # => a pair[1] # => b

• Scala:

val pair = (a, b)

pair._1 // => a pair._2 // => b

• Java:

Tuple2 pair = new Tuple2(a, b); // class scala.Tuple2

pair._1 // => a pair._2 // => b

(54)

Some Key-Value Operations

pets = sc.parallelize([(“cat”, 1), (“dog”, 1), (“cat”, 2)])

pets.reduceByKey(lambda x, y: x + y)

# => {(cat, 3), (dog, 1)}

pets.groupByKey()

# => {(cat, Seq(1, 2)), (dog, Seq(1)}

pets.sortByKey()

# => {(cat, 1), (cat, 2), (dog, 1)}

reduceByKey also automatically implements combiners on the map side

(55)

Example: Word Count

lines = sc.textFile(“hamlet.txt”)

counts = lines.flatMap(lambda line:

line.split(“ ”)) \

.map(lambda word: (word, 1)) \ .reduceByKey(lambda x, y: x + y)

“to be or”

“not to be”

“to”

“be”

“or”

“not”

“to”

“be”

(to, 1) (be, 1) (or, 1)

(not, 1) (to, 1) (be, 1)

(be, 2) (not, 1)

(or, 1) (to, 2)

(56)

Multiple Datasets

visits = sc.parallelize([(“index.html”, “1.2.3.4”), (“about.html”, “3.4.5.6”), (“index.html”, “1.3.3.1”)]) pageNames = sc.parallelize([(“index.html”, “Home”), (“about.html”, “About”)])

visits.join(pageNames)

# (“index.html”, (“1.2.3.4”, “Home”))

# (“index.html”, (“1.3.3.1”, “Home”))

# (“about.html”, (“3.4.5.6”, “About”)) visits.cogroup(pageNames)

# (“index.html”, (Seq(“1.2.3.4”, “1.3.3.1”), Seq(“Home”)))

# (“about.html”, (Seq(“3.4.5.6”), Seq(“About”)))

(57)

Controlling the level of parallelism

• All the pair RDD operations take an optional second parameter for number of tasks

words.reduceByKey(lambda x, y: x + y, 5) words.groupByKey(5)

visits.join(pageViews, 5)

(58)

Using Local Variables

• External variables you use in a closure will automatically be shipped to the cluster:

query = raw_input(“Enter a query:”)

pages.filter(lambda x: x.startswith(query)).count()

• Some caveats:

• Each task gets a new copy (updates aren’t sent back)

• Variable must be Serializable (Java/Scala) or Pickle-able (Python)

• Don’t use fields of an outer object (ships all of it!)

(59)

Closure Mishap Example

class MyCoolRddApp { val param = 3.14

val log = new Log(...) ...

def work(rdd: RDD[Int]) {

rdd.map(x => x + param)

.reduce(...) }

}

How to get around it:

class MyCoolRddApp { ...

def work(rdd: RDD[Int]) {

val param_ = param rdd.map(x => x + param_)

.reduce(...) }

NotSerializableException: } MyCoolRddApp (or Log)

References only local variable instead of this.param

(60)

Build Spark

• Requires Java 6+, Scala 2.9.2

git clone git://github.com/mesos/spark cd spark

sbt/sbt package

# Optional: publish to local Maven cache

sbt/sbt publish-local

(61)

Add Spark into Your Project

• Scala and Java: add a Maven dependency on groupId: org.spark-project

artifactId: spark-core_2.9.1 version: 0.7.0-SNAPSHOT

• Python: run program with our pyspark script

(62)

Create a SparkContext

import spark.api.java.JavaSparkContext;

JavaSparkContext sc = new JavaSparkContext(

“masterUrl”, “name”, “sparkHome”, new String[]

{“app.jar”}));

import spark.SparkContext import spark.SparkContext._

val sc = new SparkContext(“masterUrl”, “name”, “sparkHome”, Seq(“app.jar”))

Cluster URL, or local / local[N]

App name

Spark install path on cluster List of JARs with

app code (to ship)

Sc ala Ja va

from pyspark import SparkContext

sc = SparkContext(“masterUrl”, “name”, “sparkHome”, [“library.py”]))

P ython

(63)

Complete App: Scala

import spark.SparkContext import spark.SparkContext._

object WordCount {

def main(args: Array[String]) {

val sc = new SparkContext(“local”,

“WordCount”, args(0), Seq(args(1))) val lines = sc.textFile(args(2)) lines.flatMap(_.split(“ ”))

.map(word => (word, 1)) .reduceByKey(_ + _)

.saveAsTextFile(args(3)) }

}

(64)

Complete App: Python

import sys

from pyspark import SparkContext if __name__ == "__main__":

sc = SparkContext( “local”, “WordCount”, sys.argv[0], None)

lines = sc.textFile(sys.argv[1])

lines.flatMap(lambda s: s.split(“ ”)) \ .map(lambda word: (word, 1)) \

.reduceByKey(lambda x, y: x + y) \ .saveAsTextFile(sys.argv[2])

(65)

Contents

Graph Computing

4

(66)

Graphs are very where

Program Flow Ecological

Network Biological

Network Social Network

Chemical

Network Web Graph

(67)
