Quasi-Stranski-Krastanow growth mode of self-assembled CdTe quantum dots grown on ZnSe by molecular beam epitaxy

(1)

Journal of Crystal Growth 301–302 (2007) 301–305

Quasi-Stranski–Krastanow growth mode of self-assembled CdTe

quantum dots grown on ZnSe by molecular beam epitaxy

C.S. Yang

a

, Y.J. Lai

a

, W.C. Chou

a

, D.S. Chen

b

, J.S. Wang

b,

, K.F. Chien

c

, Y.T. Shih

c

a_{Department of Electrophysics, National Chiao Tung University, Hsin-Chu 30010, Taiwan, Republic of China}

b_{Department of Physics, Center for Nano-Technology and R&D Center for Membrane Technology, Chung Yuan Christian University, Chung-Li 32023,}

Taiwan, Republic of China

c

Department of Physics, National Changhua University of Education, Changhua 50058, Taiwan, Republic of China Available online 16 January 2007

Abstract

This study investigates the growth mode of highly lattice-mismatch (14%) CdTe self-assembled quantum dots grown on a ZnSe buffer-layer by molecular beam epitaxy. Two growth processes were used to prepare the samples. For the group-I samples, Te and Cd sources were alternately used to deposit a CdTe coverage layer of 0.6 to 8.0 mono-layers on a Zn-stabilized ZnSe buffer layer. The growth process of group-II samples was reversed; that is, the Cd beam was supplied ﬁrst on a Se-stabilized ZnSe buffer layer. The optical spectra, including the power-dependent, time-resolved photoluminescence (PL) and PL excitation measurement, demonstrate a ZnTe-like and a CdSe-ZnTe-like two-dimensional precursor layer (wetting layer) in the group-I and group-II samples, respectively. Following the formation of the precursor layer, three-dimensional highly strained CdTe quantum dots were formed. Accordingly, the growth of CdTe self-assembled quantum-dot structures was attributed to the quasi-Stranski–Krastanow mode.

PACS: 78.47.þp; 78.55.Et; 81.05.Dz; 81.15.Hi

Keywords: A1. Growth models; A3. Molecular beam epitaxy; A3. Quantum dots; B1. Cadmium compounds; B2. Semiconducting II–VI materials

1. Introduction

II–VI self-assembled quantum dots (SAQDs) have attracted much interest for their potential in opto-electro-nic applications in the visible and ultraviolet spectral regions. Much of the research in this area has focused on II–VI SAQDs, CdSe/ZnSe [1–5], ZnTe/ZnSe [6,7] and CdTe/ZnTe [8–10] SAQDs, whose lattice mismatches are approximately 7%. Their growth modes are conﬁrmed to be Stranski–Krastanow (SK) growth mode, implying that a two-dimensional wetting-layer is present between the dots and the matrix. However, in the CdTe/ZnSe hetero-structure, which has a large conduction band (0.58 eV) and valence band off-set (0.61 eV)[11], the lattice mismatch between CdTe and ZnSe is approximately 14.4%. The large lattice mismatch leads to the Volmer–Weber (VW) growth

mode, according to both theoretical calculation [12] and experimental data[13–15]. The carrier capture efﬁciency of SK dots exceeds that of VW dots. Matsumura et al. pioneered the study of CdTe/ZnSe SAQDs [13,14], and obtained similar results using an alternating supply (AS) and general molecular beam epitaxy (MBE) growth processes. No photoluminescence (PL) spectrum of a sample with a 0.5-cycle supply and the broad PL spectra of samples with a supply of 1.0 cycle or more were observed. In reference 14, the Zn-stabled buffer and Te-irradiation process was used. In other works, Cd was supplied ﬁrst on the Se-stabled buffer [15]. Regardless of the growth processes, similar PL spectra were obtained. Chang et al. explained that bright and broad luminescence was associated with the compositional heterogeneity [15]. Dao et al.[16]found CdTe/ZnSe QDs have two PL decay times. The short time is attributed to the migration and tunneling of photo-excited carriers to neighboring QDs. The long time is associated with the lifetime of excitons in
