A modified high-performance liquid chromatography method for analysis of PSP toxins in dinoflagellate, Alexandrium minutum, and shellfish from Taiwan

(1)

A modiﬁed high-performance liquid chromatography method

for analysis of PSP toxins in dinoﬂagellate,

Alexandrium minutum, and shellﬁsh from Taiwan

Chih Yu Chen

a,

_{*, Hong Nong Chou}

b

a_{Science and Technology Information Center, National Science Council, 16F, No. 106 Hoping ERoad,}

Section 2, Taipei, 106 36, Taiwan, ROC

b_{Institute of Fisheries Science, National Taiwan University, Taipei, 10617, Taiwan, ROC}

Received 15 August 2001; received in revised form 3 December 2001; accepted 18 December 2001

Abstract

Paralytic shellfish poisoning (PSP) toxins are highly toxic natural compounds produced by dinoflagellates commonly present in marine phytoplankton. Shellfish accumulate PSP toxins during toxic algal blooms. PSP poses a significant public health threat and economic loss to the shellfish industry. For this reason, many methods have been developed to analyse PSP toxins in suspected toxic shellfish samples. In our study, we simplified the sample preparation method and set up a rapid and accurate high-performance liquid chromatography (HPLC) system to detect PSP toxins in algae and shellfish on a routine basis. The toxins profile of two strains of dinoflagellate Alexandrium minutum and shellfish samples collected from southwestern locations in Taiwan has been analysed with this HPLC method. Only A. minutum and purple clam Hiatula rostrata contained PSP toxins, with GTX-1, 2, 3, 4 being the major toxins. # 2002 Elsevier Science Ltd. All rights reserved.

Keywords:HPLC; PSP toxins; Alexandrium minutum; Purple clams

1. Introduction

Paralytic shellﬁsh poisoning (PSP) toxins are potent marine neurotoxins which block the sodium channels of the neuron cell membrane of animals (Long, Sargent, & Hammer, 1990). In Taiwan, Alexandrium minutum is a species of dinoﬂagellate producing PSP toxins. GTX-1, 2, 3, 4 are the major toxins that occur in the above toxigenic species of algae and in the purple clam (Hwang et al., 1999). The purple clam Hiatula rostrata Lighttoot is known to retain and accumulate high PSP toxin levels (Chen & Chou, 2001; Hwang, Noghchi, Ngashima, Liao, & Hashimoto, 1987). Two food poi-soning incidents due to ingesting the purple clam occurred in Tungkang, Pingtung Prefecture in 1986 and in Tung-shih, Chia-yi Prefecture in 1991 (Hwang et al., 1995).

The determination of PSP toxins has been performed using the mouse assay method. The mouse assay developed

for PSP toxins monitoring has been used for toxicity determination among shellfish (AOAC, 1995). To achieve the high sensitivity and specificity in PSP toxins monitoring and to avoid the excessive killing of mice, Sullivan, Wekell, and Kentala (1985) and Nagashima, Maruyama, Noguchi, and Hashimoto (1987) developed high-performance liquid chromatography (HPLC) methods of PSP toxins analysis. The HPLC system of Oshima (1995) has become recently quite popular because it can separate all PSP toxins. However, it is not a very useful method for shellfish surveillance in mon-itoring situations, because it involves a time consuming solid phase extraction procedure. Furthermore, three independent isocratic runs required for the separation of C-toxins, GTX toxins and NEO/dcSTX/STX toxins make this method labour-intensive.

This paper reports a modified HPLC method to ana-lyse PSP toxins in Taiwan. We fed purple clams with the toxic dinoflagellate A. minutum sufficient for the accu-mulated toxins to be measured clearly, and then set up a HPLC method, modified from Nagashima et al. (1987), to detect PSP toxins. Furthermore, we compared the

www.elsevier.com/locate/foodres

*Corresponding author. Tel.: +77729; fax: 886-2-273-77448.

(2)

HPLC system with the mouse bioassay method and the HPLC system of Oshima (1995).

2. Materials and methods

2.1. Materials and culture environment

Strain AMTK-1 of A. minutum Halim was isolated in 1986 from the Tungkang area where PSP occurred due to the ingestion of purple clams. The unialgal isolates were batch cultured in K-medium (Keller & Guillard, 1985) and illuminated with continuous light of 60 mE m 2_s 1_{at 20–22} _{C. Algal cells of AMTK-1 were}

har-vested for feeding experiments in exponential growth phase. Natural population strain AMTK-7 of A. minu-tum was isolated in 1997 from the Tungkang milkﬁsh (Chanos chanos) culture pond. The AMTK-7 was col-lected in vertical hauls of a 20-mm mesh plankton net.

The following commercial shellﬁsh species were used for the experiment: purple clams (H. rostrata), oysters (Crassostrea gigas), and the hard clam (Meretrix lusoria), which were cultured outdoor and collected in southwestern ﬁshmarkets of Taiwan. All animal sam-ples were kept alive during transportation from the col-lection sites to the laboratory.

Purple clams, which averaged 6.75 cm (S.E.=0.52, n=100) in shell length (mean tissue wet weight=8.78g, S.E.=1.08), were collected from an aquaculture pond in Tungkang, Pingtung Prefecture. The clams were brought to the laboratory and placed in a 130-l tank with ﬁltered seawater (20 ppt salinity). Continuous

aeration was carried out at 17 2 _{C throughout the}

holding period. During the exposure period, lasting 20 days, the clams were fed with A. minutum at 2-day intervals and exposed each time to 5.81 0.42108_cells.

2.2. Assay of toxicity and HPLC

Authentic PSP components (GTX1–4 mixture), pre-pared from A. minutum, were used as reference stan-dards; the toxicity and amount were also certified by Oshima (personal communication). The method of extraction of PSP toxins was according to Chen and Chou (1998). Toxic algae samples were counted and then trapped in fiber glass, the retained algal cells were extracted with 95% acetic alcohol (pH=2). The extracts were concentrated and transferred to vials by means of 0.03 N acetic acid, defatted with chloroform, and the aqueous layer was ultrafiltered (10,000 MW cut-off) by centrifugation at 3000 rpm. Purple clam tissues were homogenized with 15 ml 0.1 M HCl, the extracts were defatted and ultrafiltered by centrifugation. Subse-quently, 10 ml of the supernatant of algae and shellfish from centrifugation was injected into the HPLC with a post-column reaction system (modified from Nagashima et al., 1987). All solvents used were HPLC grade. Other chemicals were analytical grade. Water used for HPLC was purified with a Millipore-QRG Ultra Pure Water System (Millipore, Milford, USA). HPLC was run by a combination of Hitachi 6200 Intelligent pump and L-6000 Reagent pump (Tokyo). Fig. 1 shows our HPLC system for PSP toxins analysis. The pH of mobile phase was then adjusted to 7.0 with 0.05 M K2HPO4and 0.05

(3)

M KH2PO4, phosphate buﬀer contained 2 mM

hepta-nesulfonic acid (HSA). The column used was a 5 mm, 2504.6 mm Cosmosil 5C18-AR column (Nacalai Tes-que Inc, Kyoto) at a ﬂow rate of 0.8 ml/min. Fluor-escent PSP toxin derivatives were detected using a Hitachi F-1000 spectrophotometer with excitation at 336 nm and emission at 390 nm. There are two solutions used for post-column derivatization, which contained (A) periodic acid solution (0.05 M) and (B) alkaline solution (0.2 N KOH plus 1 M ammonium formate in 50% formamide). Oshima’s method (1995) is summar-ized in Table 1.

2.3. Mouse bioassay

The mouse bioassay was performed according to the method described by Chou (1999). Mice of ICR strains (19–21 g) used in the toxicity assay were purchased from the Animal Laboratory of National Taiwan University Hospital. Purple clam extracts of 20 samples with var-ious known toxicity levels by HPLC analysis were dilu-ted and injecdilu-ted intraperitoneally into a group of four mice. The lethal potency was calculated as the time required to kill the mice and was expressed in mouse units (MU) according to the formulation deﬁned by Chou (1999). Sample toxicities obtained from both mouse bioassay and HPLC analysis were compared with each other.

2.4. Calculation

The conversion of peak areas of HPLC-resolved toxins into mouse units was according to the following formula: Toxicity (MU/ml)=(19.7A1+0.57A2+1.61A3

+8.11-A4)10 6, where MU=1 mouse unit and A1, A2, A3, A4

represented the peak areas of the resolved toxins, GTX-1, 2, 3 and 4, respectively. The use of the formula was justified on the basis that there were no resolved peaks other than those corresponding to the earlier four toxins in the tested material. The calibration factors for each toxin were adopted from mouse assays of partially pur-ified toxin mixtures with the reported specific toxicity (Genenah & Shimizu, 1981) and the reported specific fluorescent response (Sullivan et al., 1985). This pro-vides a way to convert the HPLC data to the generally accepted mouse toxicity units as STX equivalents (AOAC, 1995). In our case it was observed that 1 MU (ICR strain, male, 20 g) was equivalent to 0.259 mg/ml STX by the calibration procedure suggested by the AOAC (Chou, 1999). According to the earlier formula and the corresponding mouse responses to each toxin, the specific amount (mmol) of each individual toxin could thus be calculated from its peak area. Correlation factors for each toxin were 1.210 10_{, 7.210} 12_,

7.210 12_{, and 1.210} 10 _{for GTX-1, 2, 3 and 4,}

respectively.

3. Results and discussion

Twenty purple clam extracts of diﬀerent PSP toxin amount known from HPLC analysis were also analysed for toxicity by mouse assay. MU data converted from HPLC peak areas were compared with data obtained from the mouse assay for each toxic sample and showed a slight overestimate of toxicity (Fig. 2). The possible reason of toxicity overestimate might be the higher sen-sitivity of HPLC and dilution factor of HPLC values

Table 1

HPLC conditions used for the analysis of PSP toxins according to Oshima (1995)a

Parameter Condition or description

Column Reversed-phase, C8-bonded silica gel, Develosil C8–5 or Inertsil C8–5, (4.6 mm i.d.150 mm l)

Mobile phase

Flow rate 0.8 ml/min

For GTX1–4 Sodium 1-heptanesulfonate (2 mM) in 10 mM ammonium phosphate, pH 7.1

Oxidizing reagent

Composition Periodic acid (7 mM) in 50 mM potassium phosphate buﬀer, pH 9.0 Reaction 10 m Teﬂon tubing (0.5 mm i.d.) at 85_{C in a drying oven}

Acidifying reagent

Composition 0.5 M acetic acid

Detection

Excitation 330 nm

Emission 390 nm

(4)

used to convert to mouse assay values. The mouse assay method often underestimates toxin contents in low-toxicity shellﬁsh (Oshima, 1995). A regression line, Y=0.4987 X+0.3286 (R2_{=0.8764) was plotted on all}

MU data in Fig. 2 to show a good correlation between these two methods.

A comparison between the toxin proﬁle obtained from the HPLC system used in analysis and Oshima’s system, showed that our system does not need the time consuming solid phase extraction procedure and has shorter analysis time. Furthermore, the numbers of theoretical plate of two HPLC systems are similar (Table 2). Both systems show good separations of GTX1, GTX2, GTX3, and GTX4 (Fig. 3). The detec-tion limit of Oshima’s system is 1.7 1710 3_MU/ml

(GTX-1, 2, 3 and 4, respectively) compared with our system’s detection limit of 1310 3_{MU/ml (GTX-1–4}

standard mixture). This corresponds to a detection limit of 0.2 MU (5.1810 2_{mg STX equiv.)/g shellﬁsh meat}

for our HPLC system. Our HPLC column produced reproducible results after the analysis of 1000 samples without prior clean-up process. Such a HPLC system is suitable for a routine PSP toxins (GTX-1–4) survey in Taiwan. The HPLC system of Oshima is suitable for analyzing the toxigenic algae or shellﬁsh that contains many analogues of PSP toxins, such as C-toxins, NEO/ dcSTX/STX toxins.

A comparison of HPLC methods based on ion-pair elution of PSP toxins reveal some striking diﬀerences between the methods proposed (Franco & Fernandez-Vila, 1993; Lawrence, Wong, & Menard, 1996; Oshima, 1995; Sullivan et al., 1985; Yu, Hummert, Luckas, Qian,

Fig. 2. Correlation between mouse unit (MU) data converted from high-performance liquid chromatography (HPLC) analysis and mouse assay. The dotted line represents good correlation between the two assay methods.

Table 2

Comparison of HPLCa_{systems with that of Oshima (1995) and conditions used in this analysis}

Solid phase extraction

Separation time (min)

Resolution (Rs) No. of theoretical plate (N)

Rs (GTX4&1) Rs (GTX1&3) Rs (GTX3&2) NGTX4 NGTX1 NGTX3 NGTX2 NAVG. Our HPLC system No 15 0.63 1.24 1.29 401 478 932 1950 940 Oshima’s HPLC system Yes 20 0.87 2.03 1.76 271 1104 329 1863 892

a _{HPLC, high-performance liquid chromatography.}

Fig. 3. High-performance liquid chromatograms (HPLC) of GTX-1–4 standard mixture. (A) experimental system (B) Oshima (1995).

(5)

Li, & Zhou, 1998). These methods show that the buffer concentration used does not have a large influence on the separation of PSP toxins, but ensures high stability of the chromatography irrespective of the injection of extracts obtained from different sample materials.

Fig. 4 shows the HPLC chromatograms of purple clams fed toxic algae in the laboratory and purple clams collected from Tungkang fishmarkets. Fig. 5 shows the HPLC chromatograms of A. minutum extracts from the laboratory stock culture AMTK-1 and the natural populations AMTK-7 from milkfish culture pond. Figs. 4 and 5 shows that the percentage of GTX3 and GTX2 in laboratory cultured algae and purple clams was lower than that of fishpond collected algae and outdoor cultured purple clam. The result of the toxin profiles from fishpond collected algae and outdoor cul-tured purple clams are similar with that of previous report (Hwang, Tsai, Cheng, & Jeng, 1992).

Negative results were obtained for most of oysters (Crassostrea gigas) and hard clams (M. lusoria), which indicates that PSP toxin contamination is not common in the southwestern part of Taiwan. Only the Taiwanese purple clams (H. rostrata) were ever conﬁrmed to be contaminated with PSP toxins. Compared with the PSP toxin level stipulated by most countries (80 mg STX equiv./100 g shellﬁsh meat), the levels found in most of

the samples were less than this allowable amount. Recently, a massive mortality of milkfish and other fish species occurred in southwestern area of Taiwan due to A. minutum blooming in the culture ponds (Chou, 1999). We used our HPLC system to analyse the fish samples. The stomach and intestine tissue of milk-fish were contaminated with PSP toxins (GTX-1–4), but the gill, liver, muscle tissues, and the blood was not contaminated (data not shown). The results indicate that we should not only care about the food poisoning incidents from purple clams but pay more attention to the potential hazard of fish contaminated with A. minutum.

4. Conclusion

The modified HPLC system could qualitatively and quantitatively analyse the PSP toxins in algae and shellfish from Taiwan. This method is time-saving and avoids animal sacrifice in the bioassay method.

Fig. 4. High-performance liquid chromatograms (HPLC) of paralytic shellfish poisoning (PSP) toxin profiles of (A) laboratory cultured purple clams (B) purple clams collected from fishmarkets.

Fig. 5. High-performance liquid chromatograms (HPLC) of paralytic shellfish poisoning (PSP) toxin profiles of Alexandrium minutum. (A) laboratory cultured AMTK-1 (B) milkfish culture pond collected AMTK-7.

(6)

Acknowledgements

This work was supported by grants from the National Science Council (Grant No. NSC86–2113-M002–014) awarded to H. N. Chou.

References

AOAC. (1995). Paralytic shellfish poisons biological method final action. In W. Horwitz (Ed.), Official Methods of the Association of Official Analytical Chemists, (15th ed.) (pp. 21–22). Washington, DC: Association of Official Analytical Chemists.

Chen, C. Y., & Chou, H. N. (1998). Transmission of the paralytic shellﬁsh poisoning toxins, from dinoﬂagellate to gastropod. Tox-icon, 36, 515–522.

Chen, C. Y., & Chou, H. N. (2001). Accumulation and depuration of paralytic shellﬁsh poisoning toxins by purple clam Hiatula rostrata Lighttoot. Toxicon, 39, 1029–1034.

Chou, H. N. (1999). Paralytic shellﬁsh poisoning toxins. In: N. Chou (Ed.) Manual on microalgal toxin detection in seafood products. DOH, Taipei, pp. 23–44.

Franco, J. M., & Fernandez-Vila, P. (1993). Separation of paralytic shellﬁsh toxins by reversed phase high performance liquid chroma-tography, with postcolumn reaction and ﬂuorimetric detection. Chromatographia, 35, 9–12.

Genenah, A. A., & Shimizu, Y. (1981). Speciﬁc toxicity of paralytic shellﬁsh poisons. Journal of Agricultural Food Chemistry, 29, 1289– 1291.

Hwang, D. F., Noguchi, T., Nagashima, Y., Liao, I. C., & Hashimoto, K. (1987). Occurrence of paralytic shellﬁsh poison in the purple clam Soletellina diphos (Bivalve). Nippon Suisan Gakkaishi, 53, 623– 626.

Hwang, D. F., Tsai, Y. H., Cheng, C. A., & Jeng, S. S. (1992). Com-parison of paralytic toxins in aquaculture of purple clam in Taiwan. Toxicon, 30, 669–672.

Hwang, D. F., Tsai, Y. H., Cheng, C. A., Liao, I. C., Jeng, S. S., Noguchi, T., & Hashimoto, K. (1995). Two food poisoning inci-dents due to ingesting the purple clam occurred in Taiwan. Journal of Natural Toxins, 4, 173–179.

Hwang, D. F., Tsai, Y. H., Liao, H. J., Matsuoka, K., Noguchi, T., & Jeng, S. S. (1999). Toxins of the dinoﬂagellate Alexandrium minutum Halim from the coastal waters and aquaculture ponds in southern Taiwan. Fisheries Science, 65, 171–172.

Keller, M. D., & Guillard, R. R. L. (1985). Factors significant to marine dinoflagellate culture. In D. M. Anderson, A. W. White, & D. G. Baden (Eds.), Toxic dinoflagellate (pp. 113–116). New York : Elsevier.

Lawrence, J. F., Wong, B., & Menard, C. (1996). Determination of decarbamoyl saxitoxin and its analogues in shellfish by pre-chromatographic oxidation and liquid chromatography with fluo-rescence detection. Journal of AOAC International, 79, 1111–1115. Long, R. R., Sargent, J. C., & Hammer, K. (1990). Paralytic shellfish

poisoning: a case report and serial electrophysiologic observations. Neurology, 40, 1310–1311.

Nagashima, Y., Maruyama, J., Noguchi, T., & Hashimoto, K. (1987). Analysis of paralytic shellﬁsh poison and tetrodotoxin by ion-pair-ing high performance liquid chromatography. Nippon Suisan Gak-kaishi, 53, 819–823.

Oshima, Y. (1995). Postcolumn derivatization liquid chromotographic method for paralytic shellﬁsh toxins. Journal of AOAC Inter-national, 78, 528–532.

Sullivan, J. J., Wekell, M. M., & Kentala, L. L. (1985). Application of HPLC for the determination of PSP toxins in shellﬁsh. Journal of Food Science, 50, 26–29.

Yu, R. C., Hummert, C., Luckas, B., Qian, P. Y., Li, J., & Zhou, M. J. (1998). A modiﬁed HPLC method for analysis of PSP toxins in algae and shellﬁsh from China. Chromatographoa, 48, 671–676.
