Abnormal temperature-dependent floating-body effect on Hot-Carrier Degradation in PDSOI n-MOSFETs

(1)

Abnormal temperature-dependent

ﬂoating-body effect on Hot-Carrier

Degradation in PDSOI n-MOSFETs

Kuan-Ju Liu

a

, Ting-Chang Chang

a,b,

⁎

, Ren-Ya Yang

c

, Ching-En Chen

d

, Szu-Han Ho

d

, Jyun-Yu Tsai

a

,

Tien-Yu Hsieh

a

, Osbert Cheng

e

, Cheng-Tung Huang

e

a

Department of Physics, National Sun Yat-Sen University, 70 Lien-hai Road, Kaohsiung 80424, Taiwan

b

Advanced Optoelectronics Technology Center, National Cheng Kung University, Taiwan

c

Department of Photonics, National Sun Yat-Sen University, 70 Lien-hai Road, Kaohsiung 80424, Taiwan

d

Department of Electronics Engineering, National Chiao Tung University, Hsinchu, Taiwan

e_{Device Department, United Microelectronics Corporation, Tainan Science Park, Taiwan}

a b s t r a c t

a r t i c l e i n f o

Available online 30 August 2014 Keywords:

Floating body effect (FBE) Hot carrier effect (HCE) Silicon-on-insulator (SOI)

This letter investigates abnormal degradation behavior after hot-carrier stress in partially-depleted silicon-on-insulator n-channel metal-oxide-semiconductorfield effect transistors. It is found that the hot-carrier-induced degradation underfloating body (FB) operation is more serious than that under grounded body (GB) operation due to thefloating body effect (FBE). Furthermore, the degradation is independent on temperature under GB op-eration, because impact ionization is virtually independent on temperature under large VD. However, the

degra-dation under FB operation becomes less serious with increasing temperature. This is due to a smaller source/body PN junction band offset at a high temperature, which causes fewer accumulated holes at the body terminal and reduces the FBE.

1. Introduction

Recently, electronic products combining display panels

[1

–6]

,

memory devices

[7

–34]

, and portable devices have become more

popu-lar for consumers. These electronic products are mostly composed of

MOSFETs. However, there are many problems in conventional bulk-Si

MOSFETs, such as latch-up, parasitic junction capacitances, short

chan-nel leakage and punch-through. The silicon-on-insulator (SOI) structure

is a valid solution to these problems. The main advantages of SOI are

re-lated to the improved isolation and reduced parasitic junction

capaci-tance, resulting in a reduced subthreshold swing, low leakage current,

high operation speed, and low power consumption. Nevertheless,

there are some drawbacks of the SOI structure, such as self-heating

and the

ﬂoating body effect (FBE)

[35

–37]

. In addition, as the devices

are scaled down, the SOI structure also suffers from severe hot-carrier

effects (HCE). HCE in SOI MOSFETs has been extensively researched

under grounded body (GB) operation

[38,39]

. Since the

ﬂoating body

potential may interact with the impact-ionization phenomenon, HCE

is even more complicated in SOI MOSFETs

[40

–43]

. Consequently, it is

essential to clarify the mechanism of hot-carrier-induced degradation

under FB operation.

In this letter, to investigate the in

ﬂuence of FB potential,

hot-carrier-induced degradations under GB and FB operations are compared in

partially depleted (PD) SOI MOSFETs. Experimental data show that the

hot-carrier-induced degradation has different temperature dependence

under FB and GB operations, indicating that a different mechanism

dominates the degradation under FB and GB operations. The

mecha-nism of FBE on hot-carrier-induced degradation is proposed and

veri-ﬁed in this paper.

2. Experiment

Using 65-nm SOI CMOS technology, PD SOI n-type MOSFETs are

employed with a T-gate structure to investigate the hot-carrier

degrada-tion at different temperatures under GB and FB operadegrada-tions. The silicon

ﬁlm and buried oxide thicknesses for the devices are 75 and 145 nm,

respectively. The gate oxide with a thickness of 1.2 nm was grown by

in situ steam generation, with the channel doping concentration being

about 3 × 10

18

_cm

−3

_{. The channel currents follow in the}

_b110N

direc-tion on (100) substrates. In this letter, devices with a channel width of

1 μm and a length of 0.15 μm were selected. Hot-carrier stress was

car-ried out with either GB or FB operation to study the hot-carrier-induced

degradation. To further investigate the impacts of FB operation, I

D

–V

D

output curves and the PN junction across the source and body terminals

are characterized at temperatures ranging from 140 K to 385 K. All I

_–V

curves were measure during an Agilent B1500 semiconductor

parame-ter analyzer.

⁎ Corresponding author at: Department of Physics, National Sun Yat-Sen University, 70 Lien-hai Road, Kaohsiung 80424, Taiwan.

http://dx.doi.org/10.1016/j.tsf.2014.08.031

Contents lists available at

ScienceDirect

Thin Solid Films

(2)

3. Results and discussion

Hot carrier stress (HCS) is carried out with V

G

at the maximum of

body current and V

D

= 2.4 V.

Fig. 1

shows hot-carrier-induced

degradation of saturation I

D

measured with V

D

= 1 V under

reverse-operation mode (source/drain interchanged) (I

D,sat

(r)) versus stress

time at different temperatures for the PD SOI MOSFETs.

Fig. 1

(a) shows

that I

D,sat

(r) degradation after GB

–HCS is independent on temperature,

whereas

Fig. 1

(b) shows that the degradation after FB

–HCS becomes

less signi

ﬁcant with increasing temperature. It can be clearly observed

that the I

D,sat

(r) degradation under FB

–HCS is more serious than that

under GB

–HCS at lower temperatures, becoming insigniﬁcant at high

temperature, shown in the inset of

Fig. 1

(b).

To further verify the mechanism of greater degradation under FB

than that of GB, fast I

–V measurement is performed. Compared with

DC I

–V, fast I–V measurement can shorten the measurement period

from a few milliseconds to a few microseconds. Before stress, DC I

–V

and fast I

–V measurements are both carried out under FB operation,

and the initial characteristics are found to be identical. After 10 s of

stress, fast I

–V is performed instantaneously at the end of stress to

in-vestigate the transient phenomenon right after HCS, and then followed

by a DC I

–V measurement.

Fig. 2

shows these fast I

–V and DC I–V

measurements before and after stress under FB operation. Unlike the

conventional DC I

–V that reveals a drain current deterioration after

stress, as shown in

Fig. 2

(b), fast I

–V shows a drain current rise after

FB

–HCS, shown in

Fig. 2

(a). This can be attributed to the fact that

impact-ionization-generated holes are injected into the

ﬂoating

substrate, and the increase of substrate potential gives rise to a

reduc-tion of threshold voltage which leads to transient drain current increase

in fast I

–V measurement. Since the measurement is fast enough, the

increase of drain current due to the FBE can be detected via fast I

–V, as

in

Fig. 2

(a). Because the accumulation of holes in the body reduces

threshold voltage and results in the extra injection of electrons into

the channel for impact ionization, degradation under FB is more serious

than that under GB operation.

To further verify the effects of temperature on HCE under GB

opera-tion, body current with V

D

= 2.4 V (stress condition) is measured and

Fig. 1. Hot-carrier-induced degradation of saturation IDmeasured with VD= 1 V under

reverse-operation mode (source/drain interchanged) versus stress time at different temperatures under (a) GB and (b) FB operations. The inset of (b) shows the comparison of saturation IDdegradation between GB and FB operations under reverse-operation as a

function of temperature.

Fig. 2. ID–VGtransfer characteristic curves by fast I–V measurement with drain voltage of

50 mV under hot carrier stress for 0 s and 10 s at 30 °C under (a) fast I–V and (b) DC I–V measurements.

Fig. 3. IB–VGat different temperatures with VD= 2.4 V under GB operation. Inset shows

(3)

shown in

Fig. 3

. Corresponding to the I

D

degradation which is

indepen-dent on temperature, it can be clearly observed that body current with

V

D

= 2.4 V is also independent on temperature. Accordingly, the degree

of hot-carrier-induced degradation is dominated by impact-ionization

rate. On the contrary, I

B

measured with V

D

= 1 V increases with

increas-ing temperature, shown in the inset of

Fig. 3

. This is because channel

electrons do not have suf

ﬁcient energy for impact ionization, and

tem-perature signi

ﬁcantly enhances impact-ionization at low V

D

[44]

.

There-fore, at high temperature, even though carrier mobility and I

D

are

degraded, I

B

still increases. Nevertheless, since channel electrons have

suf

ﬁcient energy for impact-ionization under high V

D

, the impact

ioni-zation rate is insensitive to temperature. As a result, it is clear that

hot-carrier-induced degradation under GB operation at different

tem-peratures is dominated by the degree of impact ionization. However

the origin of the temperature dependence of hot-carrier-induced

degra-dation under FB operation is not yet clear.

Fig. 4

(a) shows dual sweep of the I

D

–V

D

output curves at low and

high temperatures under FB operation. Because of the FBE, I

D

suddenly

rises in the saturation region

[45]

. Since the holes generated due to

im-pact ionization at the body terminal cannot be recombined

instanta-neously, there is a drain current difference between the forward- and

reverse-sweep, which is de

ﬁned as I

kink

. In order to understand the

im-pact of temperature on FBE, I

kink

is investigated at different

tempera-tures. Obviously, I

kink

is large at low temperature and is small at high

temperature. It can be inferred that there are more holes at the body

ter-minal at low temperature. However, the smaller I

B

at low temperature,

shown in

Fig. 3

, contradicts with this inference of more generated holes

at low temperature in

Fig. 4

(a), since a smaller I

B

should theoretically

result in fewer holes.

Fig. 4

(b) shows the I

–V characteristics of the PN

junction across the source (N) and body (P) terminals at different

tem-peratures with V

S

=

−0.3 to 0.8 V, V

B

= 0 V and

ﬂoating gate and drain.

The V

on

is de

ﬁned as the source voltage when the forward-bias junction

current equals 1 nA, and V

on

difference at different temperatures is

de

_{ﬁned as ϕ}

B

.

The equation of drain current in the saturation region can be

simpli-ﬁed and expressed as:

I

D

¼

W

2L

μC

ox

ð

V

G

−V

T

Þ

2

ð1Þ

ffiffiffiffiffi

I

D

p

∝V

G

−V

T

ð2Þ

ffiffiffiffiffiffiffiffiffi

I

kink

p

∝ϕ

B

;

ð3Þ

where W and L is the channel width and length, respectively,

μ is the

carrier mobility, C

ox

is the gate oxide capacitance per unit area, and V

T

is the threshold voltage. Eq.

3 shows that I

kink

is proportional to

ϕ

B

,

and the relationship between I

kink

and

ϕ

B

is plotted, as shown in

Fig. 5

.

Fig. 5

shows the I

kink

− ϕ

B

plot at different temperatures ranging from

140 K to 385 K, and the result exhibits an obvious linear dependence.

Thus, based on the aforementioned investigation, the anomalous

tem-perature dependence of FB

–HCS-induced degradation can be elucidated

as follows. The Fermi-levels both in the source and body are far from the

intrinsic Fermi-level at low temperature, and approaches the intrinsic

Fermi-level with increasing temperature, as in the inset of

Fig. 5

.

There-fore, the PN junction is wider and

ϕ

B

is large at low temperature and

vice versa at high temperature. Furthermore, because of small

ϕ

B

at

high temperature, the ability of the PN junction to retain holes is poor

and therefore the kink effect is less signi

ﬁcant. As a result, the degree

of hot-carrier-induced degradation under FB operation at different

tem-peratures is dominated by the ability to retain holes at the source/body

PN junction.

4. Conclusion

This paper investigates the behavior of hot

carrier-induced-degradation at different temperatures under GB and FB operations in

PD SOI n-MOSFETs, and

ﬁnds that the degradation under FB is more

serious than that under GB operation due to the

ﬂoating body effect.

The hot-carrier-induced degradation is independent on temperature

under GB operation, whereas the degradation under FB operation

be-comes less signi

ﬁcant with increasing temperature. This is due to the

Fig. 4. (a) Dual ID–VDsweeps at low and high temperatures under FB operation, and

(b) source/body PN junction with VS=−0.3 to −0.8 V, VB= 0 V andﬂoating gate and

drain at different temperatures.

Fig. 5. ffiffiffiffiffiffiffiffiffiIkink

p

versus PN junctionϕBwith temperature ranging from 140 K to 315 K at

increments of 35 K. The inset shows the band diagram of PN junction at low and high temperatures.

(4)

lessened ability to retain holes at the source/body PN junction at high

temperature and the resultant insigni

ﬁcant FBE. According to this study,

hot-carrier-induced degradation under GB operation at different

temper-atures is dominated by the impact ionization rate, while the degree of

degradation under FB operation is dominated by the ability to retain

holes at the source/body PN junction.

Acknowledgment

This work was performed at the National Science Council Core

Facil-ities Laboratory for Nano-Science and Nano-Technology in Kaohsiung

–

Pingtung area, NSYSU Center for Nanoscience and Nanotechnology,

and was supported by the National Science Council of the Republic of

China under Contract No. NSC-102-2120-M-110-001.

References

[1] K. Nomura, H. Ohta, A. Takagi, T. Kamiya, M. Hirano, H. Hosono, Room-temperature fabrication of transparentﬂexible thin-ﬁlm transistors using amorphous oxide semiconductors, Nature (London) 432 (2004) 488.

[2] C.T. Tsai, T.C. Chang, S.C. Chen, I. Lo, S.W. Tsao, M.C. Hung, J.J. Chang, C.Y. Wu, C.Y. Huang, Inﬂuence of positive bias stress on N2O plasma improved InGaZnO thin

ﬁlm transistor, Appl. Phys. Lett. 96 (2010) 242105.

[3] T.C. Chen, T.C. Chang, C.T. Tsai, T.Y. Hsieh, S.C. Chen, C.S. Lin, M.C. Hung, C.H. Tu, J.J. Chang, P.L. Chen, Behaviors of InGaZnO thinﬁlm transistor under illuminated posi-tive gate-bias stress, Appl. Phys. Lett. 97 (2010) 112104.

[4] W.F. Chung, T.C. Chang, H.W. Li, C.W. Chen, Y.C. Chen, S.C. Chen, T.Y. Tseng, Y.H. Tai, Inﬂuence of H2O dipole on subthreshold swing of amorphous

Indium-Gallium-Zinc-Oxide thinﬁlm transistors, Electrochem. Solid-State Lett. 14 (3) (2011) H114.

[5] H.Y. Lu, P.T. Liu, T.C. Chang, S. Chi, Enhancement of brightness uniformity by a new voltage-modulated pixel design for AMOLED displays, IEEE Electron. Device Lett. 27 (9) (2006) 743.

[6] S.C. Chen, T.C. Chang, P.T. Liu, Y.C. Wu, P.S. Lin, B.H. Tseng, J.H. Shy, S.M. Sze, C.Y. Chang, C.H. Lien, A novel nanowire channel poly-Si TFT functioning as transis-tor and nonvolatile SONOS memory, IEEE Electron. Device Lett. 28 (9) (2007) 809.

[7] K.C. Chang, T.M. Tsai, T.C. Chang, K.H. Chen, R. Zhang, Z.Y. Wang, J.H. Chen, T.F. Young, M.C. Chen, T.J. Chu, S.Y. Huang, Y.E. Syu, D.H. Bao, S.M. Sze, Dual ion effect of the lithium silicate resistance random access memory, IEEE Electron Device Lett. 35 (5) (2014) 530.

[8] R. Zhang, K.C. Chang, T.C. Chang, T.M. Tsai, S.Y. Huang, W.J. Chen, K.H. Chen, J.C. Lou, J.H. Chen, T.F. Young, M.C. Chen, H.L. Chen, S.P. Liang, Y.E. Syu, S.M. Sze, Characteri-zation of oxygen accumulation in Indium-Tin-Oxide for resistance random access memory, IEEE Electron. Device Lett. 35 (6) (2014) 630.

[9] C.C. Shih, K.C. Chang, T.C. Chang, T.M. Tsai, R. Zhang, J.H. Chen, K.H. Chen, T.F. Young, H.L. Chen, J.C. Lou, T.J. Chu, S.Y. Huang, D.H. Bao, S.M. Sze, Resistive switching mod-iﬁcation by ultraviolet illumination in transparent electrode resistive random access memory, IEEE Electron. Device Lett. 35 (5) (2014) 633.

[10] T.J. Chu, T.M. Tsai, T.C. Chang, K.C. Chang, R. Zhang, K.H. Chen, J.H. Chen, T.F. Young, J. W. Huang, J.C. Lou, M.C. Chen, S.Y. Huang, H.L. Chen, Y.E. Syu, D.H. Bao, S.M. Sze, Tri-resistive switching behavior of hydrogen induced resistance random access memo-ry, IEEE Electron. Device Lett. 35 (2) (2014) 217.

[11] K.C. Chang, J.H. Chen, T.M. Tsai, T.C. Chang, S.Y. Huang, R. Zhang, K.H. Chen, Y.E. Syu, G.W. Chang, T.J. Chu, G.R. Liu, Y.T. Su, M.C. Chen, J.H. Pan, K.H. Liao, Y.H. Tai, T.F. Young, S.M. Sze, C.F. Ai, M.C. Wang, J.W. Huang, Improvement mechanism of resis-tance random access memory with supercritical CO2ﬂuid treatment, J. Supercrit.

Fluids 85 (2014) 183.

[12]K.C. Chang, J.W. Huang, T.C. Chang, T.M. Tsai, K.H. Chen, T.F. Young, J.H. Chen, R. Zhang, J.C. Lou, S.Y. Huang, Y.C. Pan, H.C. Huang, Y.E. Syu, D.S. Gan, D.H. Bao, S.M. Sze, Space electricﬁeld concentrated effect for Zr:SiO2RRAM devices using porous

SiO2buffer layer, Nanoscale Res. Lett. 8 (2013) 523.

[13] R. Zhang, T.M. Tsai, T.C. Chang, K.C. Chang, K.H. Chen, J.C. Lou, T.F. Young, J.H. Chen, S. Y. Huang, M.C. Chen, C.C. Shih, H.L. Chen, J.H. Pan, C.W. Tung, Y.E. Syu, S.M. Sze, Mechanism of power consumption inhibitive multi-layer Zn:SiO2/SiO2structure

re-sistance random access memory, J. Appl. Phys. 114 (2013) 234501.

[14] Y.T. Su, K.C. Chang, T.C. Chang, T.M. Tsai, R. Zhang, J.C. Lou, J.H. Chen, T.F. Young, K.H. Chen, B.H. Tseng, C.C. Shih, Y.L. Yang, M.C. Chen, T.J. Chu, C.H. Pan, Y.E. Syu, S.M. Sze, Appl. Phys. Lett. 103 (2013) 163502.

[15] K.C. Chang, T.M. Tsai, R. Zhang, T.C. Chang, K.H. Chen, J.H. Chen, T.F. Young, J.C. Lou, T.J. Chu, C.C. Shih, J.H. Pan, Y.T. Su, Y.E. Syu, C.W. Tung, M.C. Chen, J.J. Wu, Y. Hu, S.M. Sze, Electrical conduction mechanism of Zn:SiOx resistance random access memory with supercritical CO2ﬂuid process, Appl. Phys.

Lett. 103 (2013) 083509.

[16] T.M. Tsai, K.C. Chang, R. Zhang, T.C. Chang, J.C. Lou, J.H. Chen, T.F. Young, B.H. Tseng, C.C. Shih, Y.C. Pan, M.C. Chen, J.H. Pan, Y.E. Syu, S.M. Sze, Performance and character-istics of double layer porous silicon oxide resistance random access memory, Appl. Phys. Lett. 102 (2013) 253509.

[17] K.C. Chang, R. Zhang, T.C. Chang, T.M. Tsai, J.C. Lou, J.H. Chen, T.F. Young, M.C. Chen, Y.L. Yang, Y.C. Pan, G.W. Chang, T.J. Chu, C.C. Shih, J.Y. Chen, C.H. Pan, Y.T. Su, Y.E. Syu, Y.H. Tai, S.M. Sze, Origin of hopping conduction in Graphene-Oxide-Doped silicon

oxide resistance random access memory devices, IEEE Electron. Device Lett. 34 (5) (2013) 677.

[18]K.C. Chang, C.H. Pan, T.C. Chang, T.M. Tsai, R. Zhang, J.C. Lou, T.F. Young, J.H. Chen, C.C. Shih, T.J. Chu, J.Y. Chen, Y.T. Su, J.P. Jiang, K.H. Chen, H.C. Huang, Y.E. Syu, D.S. Gan, S.M. Sze, Hopping effect of hydrogen-doped silicon oxide insert RRAM by supercritical CO2ﬂuid treatment, IEEE Electron. Device Lett.

34 (5) (2013) 617.

[19] K.C. Chang, T.M. Tsai, T.C. Chang, Senior Member, H.H. Wu IEEE, K.H. Chen, J.H. Chen, T.F. Young, T.J. Chu, J.Y. Chen, C.H. Pan, Y.T. Su, Y.E. Syu, C.W. Tung, G.W. Chang, M.C. Chen, H.C. Huang, Y.H. Tai, D.S. Gan, J.J. Wu, Y. Hu, S.M. Sze, Low temperature im-provement method on Zn:SiOx resistive random access memory devices, IEEE Elec-tron. Device Lett. 34 (4) (2013) 511.

[20] K.C. Chang, T.M. Tsai, T.C. Chang, H.H. Wu, J.H. Chen, Y.E. Syu, G.W. Chang, T.J. Chu, G. R. Liu, Y.T. Su, M.C. Chen, J.H. Pan, J.Y. Chen, C.W. Tung, H.C. Huang, Y.H. Tai, D.S. Gan, S.M. Sze, Characteristics and mechanisms of silicon oxide based resistance random access memory, IEEE Electron. Device Lett. 34 (3) (2013) 399.

[21] T.M. Tsai, K.C. Chang, T.C. Chang, G.W. Chang, Y.E. Syu, Y.T. Su, G.R. Liu, K.H. Liao, M.C. Chen, H.C. Huang, Y.H. Tai, D.S. Gan, S.M. Sze, Origin of hopping conduction in Sn-doped silicon oxide RRAM with supercritical CO2ﬂuid treatment, IEEE Electron.

De-vice Lett. 33 (12) (2012) 1693.

[22]T.M. Tsai, K.C. Chang, T.C. Chang, Y.E. Syu, S.L. Chuang, G.W. Chang, G.R. Liu, M.C. Chen, H.C. Huang, S.K. Liu, Y.H. Tai, D.S. Gan, Y.L. Yang, T.F. Young, B.H. Tseng, K.H. Chen, M.J. Tsai, C. Ye, H. Wang, S.M. Sze, Bipolar resistive RAM characteristics in-duced by Nickel Incorporated into Silicon Oxide Dielectrics for IC Applications, IEEE Electron. Device Lett. 33 (12) (2012) 1696.

[23] T.M. Tsai, K.C. Chang, T.C. Chang, Y.E. Syu, K.H. Liao, B.H. Tseng, S.M. Sze, Dehydroxyl effect of Sn-doped silicon oxide resistance random access memory with supercriti-cal CO2ﬂuid treatment, Appl. Phys. Lett. 101 (2012) 112906.

[24] K.C. Chang, T.M. Tsai, T.C. Chang, Y.E. Syu, K.H. Liao, S.L. Chuang, C.H. Li, D.S. Gan, S.M. Sze, The effect of silicon oxide based RRAM with Tin Doping, Electrochem. Solid-State Lett. 15 (3) (2012) H65.

[25] K.C. Chang, T.M. Tsai, T.C. Chang, Y.E. Syu, C.-C. Wang, S.K. Liu, S.L. Chuang, C.H. Li, D. S. Gan, S.M. Sze, Reducing operation current of Ni-doped silicon oxide resistance random access memory by supercritical CO(2)ﬂuid treatment, Appl. Phys. Lett. 99 (26) (2011) 263501.

[26] K.C. Chang, T.M. Tsai, T.C. Chang, Y.E. Syu, H.C. Huang, Y.C. Hung, T.F. Young, D.S. Gan, N.J. Ho, Low-Temperature synthesis of ZnO nanotubes by supercritical CO2ﬂuid

treatment, Electrochem. Solid-State Lett. 14 (9) (2011) K47.

[27] Y.E. Syu, T.C. Chang, J.H. Lou, T.M. Tsai, K.C. Chang, M.J. Tsai, Y.L. Wang, M. Liu, S.M. Sze, Atomic-level quantized reaction of HfOx memristor, Appl. Phys. Lett. 102 (2013) 172903.

[28] Y.E. Syu, T.C. Chang, T.M. Tsai, G.W. Chang, K.C. Chang, Y.H. Tai, M.J. Tsai, Y.L. Wang, S. M. Sze, Silicon introduced effect on resistive switching characteristics of WO(X) thin ﬁlms, Appl. Phys. Lett. 100 (2) (2012) 022904.

[29] T.J. Chu, T.C. Chang, T.M. Tsai, H.H. Wu, J.H. Chen, K.C. Chang, T.F. Young, K.H. Chen, Y.E. Syu, G.W. Chang, Y.F. Chang, M.C. Chen, J.H. Lou, J.H. Pan, J.Y. Chen, Y.H. Tai, C. Ye, H. Wang, S.M. Sze, Charge quantity inﬂuence on resistance switching characteristic during forming process, IEEE Electron. Device Lett. 34 (4) (2013) 502.

[30] Y.E. Syu, R. Zhang, T.C. Chang, T.M. Tsai, K.C. Chang, J.C. Lou, T.F. Young, J.H. Chen, M. C. Chen, Y.L. Yang, C.C. Shih, T.J. Chu, J.Y. Chen, C.H. Pan, Y.T. Su, H.C. Huang, D.S. Gan, S.M. Sze, Endurance improvement technology with nitrogen implanted in the inter-face of WSiOx resistance switching device, IEEE Electron. Device Lett. 34 (7) (2013) 864.

[31] T.C. Chang, F.Y. Jian, S.C. Chen, Y.T. Tsai, Developments in nanocrystal memory, Mater. Today 14 (2011) 608.

[32] M.C. Chen, T.C. Chang, C.T. Tsai, S.Y. Huang, S.C. Chen, C.W. Hu, S.M. Sze, M.J. Tsai, In-ﬂuence of electrode material on the resistive memory switching property of indium gallium zinc oxide thinﬁlms, Appl. Phys. Lett. 96 (2010) 262110.

[33]Y.E. Syu, T.C. Chang, T.M. Tsai, Y.C. Hung, K.C. Chang, M.J. Tsai, M.J. Kao, S.M. Sze, Redox reaction switching mechanism in RRAM device with Pt/CoSiOX/TiN structure,

IEEE Electron. Device Lett. 32 (2011) 545.

[34] J. Jomaah, G. Ghibaudo, F. Balestra, Analysis and modeling of self-heating effects in thin-ﬁlm SOI MOSFETs as a function of temperature, Solid State Electron. 38 (1995) 615.

[35] C.H. Dai, T.C. Chang, A.K. Chu, Y.J. Kuo, S.C. Chen, C.C. Tsai, S.H. Ho, W.H. Lo, G. Xia, O. Cheng, C.T. Huang, On the origin of hole valence band injection on GIFBE in PD SOI n-MOSFETs, IEEE Electron. Device Lett. 31 (2010) 540.

[36]W.H. Lo, T.C. Chang, C.H. Dai, W.L. Chung, C.E. Chen, S.H. Ho, O. Cheng, C.T. Huang, Impact of mechanical strain on GIFBE in PD SOI p-MOSFETs as indicated from NBTI degradation, IEEE Electron. Device Lett. 33 (2012) 303.

[37] C. Hu, S.C. Tam, F.C. Hsu, P.K. Ko, T.Y. Chan, K.W. Terrill, Hot-electron-induced MOSFET degradation-model, monitor, and improvement, IEEE Electron. Device Lett. ED32 (1985) 375.

[38] P. Heremans, R. Bellens, G. Groeseneken, H.E. Maes, Consistent model for the hot-carrier degradation in n-channel and p-channel MOSFETs, IEEE Electron. Device Lett. 35 (1988) 2194.

[39] D. Munteanu, A.M. Ionescu, Modeling of drain current overshoot and recombination lifetime extraction inﬂoating-body submicron SOI MOSFETs, IEEE Electron. Device Lett. 49 (2002) 1198.

[40]Y.C. Tseng, W.M. Huang, C. Hwang, J.C.S. Woo, ACﬂoating body effects in partially depletedﬂoating body SOI nMOS operated at elevated temperature: an analog circuit prospective, IEEE Electron. Device Lett. 21 (2000) 494.

[41] M. Emam, J.C. Tinoco, D.V. Janvier, J.P. Raskin, High-temperature DC and RF behaviors of partially-depleted SOI MOSFET transistors, Solid State Electron. 52 (2008) 1924.

(5)

[42]M. Emam, J.P. Raskin, Partially depleted SOI versus deep n-well protected bulk-Si MOSFETs: a high-temperature RF study for low-voltage low-power applications, IEEE Microw. Theory Tech. Soc. 61 (2013) 1496.

[43] D.S. Jeon, D.E. Burk, A temperature-dependent SOI MOSFET model for high-temperature application (27 °C–300 °C), IEEE Trans. Electron. Devices 38 (1991) 2101.

[44] P. Aminzadeh, M. Alavi, D. Scharfetter, Temperature dependence of substrate current and hot carrier-induced degradation at low drain bias, IEEE Symp. VLSI Technol. (1998) 178.

[45]S.C. Lin, J.B. Kuo, Temperature-dependent Kink effect model for partially depleted SOI NMOS devices, IEEE Trans. Electron. Devices 46 (1999) 254.
