High-performance 30-period quantum-dot infrared photodetector
Shu-Ting Chou
Department of Electrical Engineering, National Tsing Hua University, Hsinchu, Taiwan Shih-Yen Lina兲
Nanophotonics Center, Opto-Electronics and Systems Laboratories, Industrial Technology Research Institute, Hsinchu, Taiwan
Ru-Shang Hsiao
Department of Electrophysics, National Chiao Tung University, Hsinchu, Taiwan Jim-Yong Chi and Jyh-Shyang Wang
Nanophotonics Center, Opto-Electronics and Systems Laboratories, Industrial Technology Research Institute, Hsinchu, Taiwan
Meng-Chyi Wu
Department of Electrical Engineering, National Tsing Hua University, Hsinchu, Taiwan Jenn-Fang Chen
Department of Electrophysics, National Chiao Tung University, Hsinchu, Taiwan
共Received 27 October 2004; accepted 7 March 2005; published 7 June 2005兲
In this article, quantum-dot infrared photodetectors 共QDIPs兲 with 10- and 30-period InAs/GaAs quantum-dot structures are investigated. High responsivity of 2.37 A / W and detectivity of 2.48
⫻1010cm Hz1/2/ W for 30-period QDIPs under 10 K are observed at −2.7 and 1.2 V, respectively. Almost symmetric photocurrents and dark currents under positive and negative biases are observed for both devices, which indicate a minor influence of the wetting layer on the performance of QDIPs. Lower dark current and increased photocurrent for the 30-period QDIPs would predict a better performance for devices with over a 30-period QD structure. © 2005 American Vacuum
Society. 关DOI: 10.1116/1.1900730兴
With self-assembled InAs/ GaAs quantum dots 共QDs兲 as the absorption medium, QD infrared photodetectors共QDIPs兲 have revealed its potential in the application of infrared共IR兲 detection.1–11Compared with conventional quantum-well in-frared photodetectors, normal-incident absorption, wider de-tection window, and higher-temperature operation are reported.1–7However, the influences of sample structures on the device performances are not optimized yet. In this article, the influence of InAs/ GaAs QD layer number on the perfor-mances of QDIPs is investigated. Compared with a 10-period QDIP, higher responsivity and detectivity are observed for a 30-period QDIP. Also observed is the symmetric photo- and dark currents for both devices, which implies the minor in-fluence of a wetting layer on the performances of the QDIPs. A discontinuity observed in the dark current measurement for a 30-period QDIP is attributed to the occurrence of se-quential resonant tunneling under appropriate voltage.12
The InAs/ GaAs QD samples are prepared by Riber Epineat solid-source molecular-beam epitaxy on semi-insulating GaAs substrates. 10- or 30-period 2.63 monolayer
共ML兲 InAs/30 nm GaAs QDIP samples, referred to as
De-vices A or B are sandwiched between 0.5 and 1m thick GaAs contact layers with n = 1⫻1018cm−3. The InAs QD region is n-type doped to 1⫻1018cm−3. The growth tem-perature for the InAs QDs is 495 ° C, while a higher growth temperature, 600 ° C, is adopted for the GaAs barrier layers.
After mesa formation and metal evaporation, 100
⫻100m2 devices are fabricated. The device structure is shown in Fig. 1. and the insert in the figure shows the atomic force microscopy共AFM兲 image of the InAs QDs grown un-der the same growth condition. Uniform QD distribution is observed from the AFM image. According to the AFM mea-surements, the QD density is ⬃7⫻1010cm−2. The 1
⫻1018cm−3 doping density at the InAs QD region would therefore correspond to a Si donor at each QD on average. The measurement of spectral responses is performed under an edge-coupling scheme.4–6 For this purpose, the devices are 45° polished at one side of the sample. The measurement system for spectral responses consists of a Spectral One Fou-rier transformation spectroscopy coupling with ARC
cryo-a兲Electronic mail: [email protected] Fimage of the InAs QDs grown under the same growth condition.IG. 1. Device structures of Devices A and B. The inset shows the AFM
1129 J. Vac. Sci. Technol. B 23„3…, May/Jun 2005 0734-211X/2005/23„3…/1129/3/$22.00 ©2005 American Vacuum Society 1129 Redistribution subject to AVS license or copyright; see http://scitation.aip.org/termsconditions. Download to IP: 140.113.38.11 On: Thu, 01 May 2014 03:04:25
genics and a MODEL SR570 current preamplifier. Temperature-dependent dark current-voltage characteristics are measured with a Keithley 236 source measure unit at the same ARC cryogenics.
The spectral responses measured at 10 K with different applied voltages are shown in Fig. 2. Higher peak responsiv-ity 2.37 A / W at −2.7 V is observed for Device B while De-vice A shows a peak of 0.98 A / W at −0.7 V. The photocur-rent for Device B is three times higher than that of Device A for the same electrical field. This increase indicated a non-saturated photocurrent up to a 30-period QD structure. Higher responsivity with more than a 30-period QD structure is expected. Another phenomenon observed in Fig. 2 is the symmetric photocurrents for both devices under positive and negative biases. According to a previous report,13the spectral response of a InAs/ GaAs QDIP consists of several transition mechanisms involving QD confinement states to wetting layer photoexcitation. The wetting layer-to-continuum transi-tion is not observed either under an edge-coupling scheme or normal-incident condition. And, due to the fact that the mul-tistacked QD structure is always adopted for QDIPs, the in-cident IR light has to go through multi-QD and wetting layer regions either under normal-incident or edge-coupling con-ditions. Therefore, the phenomena of symmetric phocurrents are attributed to the minor influences of the wetting layer and the three-dimensional character of the InAs QDs on the per-formance of the QDIPs.
The spectral responses of Device B under 10, 50, and 100 K at an applied voltage of 0.5 V are shown in Fig. 3. Increasing spectral responses with increasing temperature is observed, where a more pronounced increase in the wave-length range of 3 – 6m is observed. This phenomenon is attributed to the depopulation of electrons at the excited states with increasing temperature, such that the ground-to-excited state transition is increased.4 The detectivity D* is determined following the equation that detectivity D* = R共AB兲1/2/ i
n, where R, A, in, and B are the peak
responsiv-ity, device area, noise current, and measurement bandwidth, respectively. The noise current, in, could be derived through the relation in2= 4egIdB, where Idis the current under the dark environment and g is the gain assumed to be 1.3–6 The 6.2m peak detectivities for Device B at 0.5 V under 10, 50, and 100 K are 6.25⫻108, 3.82⫻107, and 2.66
⫻107cm Hz1/2/ W, respectively. Although high responsivity of 8 A / W is observed with increasing temperature up to 100 K, the peak detectivities at 6.2m decrease due to the more rapid increase of dark current with increasing tempera-ture compared with the case for photocurrent.
The dark current densities for Devices A and B under 10 K are shown in Fig. 4. The lower dark current for Device B is attributed to the increase of QD period such that the total barrier thickness is increased. Also shown in Fig. 4 is the abrupt dark current increase for Device B at ⬃1.5 and −1 V, respectively, which is attributed to the sequential
reso-FIG. 2. 10 K spectral responses of Devices A and B at +0.7 and +2.7 V,
respectively. Fvoltage 0.5 V.IG. 3. Spectral response of Device B under 10, 50, and 100 K at applied
FIG. 4. Dark current density of Devices A and B under 10 K. The inset shows the schematic diagram for the phenomenon of SRT.
1130 Chouet al.: High-performance 30-period quantum-dot infrared 1130
J. Vac. Sci. Technol. B, Vol. 23, No. 3, May/Jun 2005
nant tunneling共SRT兲 at an appropriate voltage as shown in the inset of Fig. 4.12 Since the dominant dark current com-ponent for a temperature higher than 60 K is the thermionic emission current,10,11 the activation energies under different biases can be derived through the curve fitting for the dark currents with the equation ID⬃T2e−Ea/kT, where T is
tem-perature and Ea is the activation energy which equals 共⌬Ec
− EF兲.
6 ⌬E
c is the conduction-band discontinuity and EF is
the Fermi level. The derived zero-bias activation energies are 25 and 112 meV for Devices A and B, respectively. Symmet-ric activation energies under different polarities of applied voltage are consistent with the symmetric photocurrent. Higher activation energy at zero-applied bias for Device B would indicate a lower dark current with an increasing QD layer number. Due to the higher photocurrent and lower dark current, high 6.2m detectivity of 2.48⫻1010 cm Hz1/2/ W for Device B at 10 K with responsivity 42.9 mA/ W at 1.2 V is observed. Compared with the peak detectivity 1.08
⫻109cm Hz1/2/ W with responsivity 16.4 mA/ W for Device A, Device B has⬃20 times higher peak detectivity. A higher detectivity of Device B results in a higher background-limited performance temperature of 60 K compared with 30 K for Device A.
In conclusion, symmetric photocurrents and dark currents under positive and negative biases are observed for both de-vices, which indicate a minor influence of the wetting layer and the three-dimensional character of the InAs QDs on the performance of QDIPs. And due to the increase of dark cur-rents usually being more pronounced than photocurcur-rents, the
phenomenon would result in different applied voltages for peak detectivity and peak responsivity to occur. Therefore, for a 30-period QDIP under 10 K, peak responsivity of 2.37 A / W and detectivity of 2.48⫻1010cm Hz1/2/ W are ob-served at −2.7 and 1.2 V, respectively. Lower dark current and nonsaturated photocurrent for the 30-period QDIP would indicate that better performance could be obtained for de-vices with a layer number over 30. A discontinuity observed in the dark current measurement at ⬃1.5 and −1 V for the 30-period QDIP is attributed to the occurrence of SRT.
