Synthesis, Characterization, and Photophysical Properties of

Luminescent Gallium and Indium Complexes Constructed using

Tridentate 6-Azolyl-2,2

′

-bipyridine Chelates

Yi-Hwa Song, Yuan-Chieh Chiu, and Yun Chi*

Department of Chemistry, National Tsing Hua UniVersity, Hsinchu 30013, Taiwan

Pi-Tai Chou,* Yi-Ming Cheng, Chun-Wei Lin, and Gene-Hsiang Lee

Department of Chemistry and Instrumentation Center, National Taiwan UniVersity, Taipei 10617, Taiwan

Arthur J. Carty*

Steacie Institute for Molecular Sciences, National Research Council, Ontario K1A 0R6, Canada ReceiVed June 12, 2007

Three systematically functionalized 6-azolyl-2,2′-bipyridine ligands were prepared from reactions initiated by 6-cyano-2,2′-bipyridine. These ligands readily reacted with the metal alkyl reagents GaMe3

and InMe3 to afford the pentacoordinate complexes [(fpzbpy)MMe2] (1a, M ) Ga; 1b, M ) In),

[(ftzbpy)MMe2] (2a, M ) Ga; 2b, M ) In), and [(N4bpy)MMe2] (3a, M ) Ga; 3b, M ) In), in which

(fpzbpy)H, (ftzbpy)H, and (N4bpy)H denote 6-pyrazolyl-, 6-triazolyl-, and 6-tetrazolyl-substituted 2,2′ -bipyridine, respectively. These complexes exhibited moderate blue-green emission ranging from 412 to 493 nm. On the other hand, treatment of the bidentate 2-pyridyl tetrazole ligand (pyN4)H with InMe3

afforded the bridged dimer [Me2In(pyN4)]2(4). Calculation based on time-dependent density function

theory (TDDFT) showed that the S1state of complexes 1-3 is mainly attributed to an allowed intraligand π f π* electronic transition located at tridentate chelating moieties, together with a small contribution (<10%) of gallium (or indium) fπ* (ligand) charge transfer transition. Accordingly, the corresponding emission properties of 1a-3a (or 1b-3b) can be rationalized using the correlation between the substituent effect of azolyl groups and the relative HOMO/LUMO energy level.

1. Introduction

Luminescent main-group-metal compounds have recently received considerable attention, due to their potential use in various applications such as organic light-emitting diodes (OLEDs),1 electroluminescence, and fluorescence probes for detection of various anion, cation, or even neutral molecules.2 As for the group III metal complexes utilized in the fabrication of OLEDs, the best known family to date should be credited to aluminum-containing molecules such as tris(8-quinolinolate)alu-minum(III) (AlQ3).3Their functionalized derivatives have shown bright fluorescence ranging from blue to green to red.4 AlQ3

also serves as an electron-transporting and host material currently used in many commercialized light-emitting devices.5 In yet another approach, highly luminescent materials were also synthesized for their isoelectronic boron congeners. The synthetic route generally incorporates the treatment of bidentate organicπ-chromophores with boron reagents such as BPh3and BF3· OEt2.6During these reactions, the incoming chromophore interacted with the central boron atom and caused the elimination of 1 equiv of benzene or HF, giving air-stable, tetrahedral complexes with one chelating π-conjugated chromophore. Selected examples of such emissive boron complexes include dipyrromethene dyes (BODIPY) and derivatives,7

dibenzometha-* To whom correspondence should be addressed. Fax: +886 3 572 0864 (Y.C.); +886 2 2369 5208 (P.-T.C.); +1 613 953 7592 (A.J.C.). E-mail: [email protected] (Y.C.); [email protected] (P.-T.C.); carty.arthur@ ic.gc.ca (A.J.C.).

(1) (a) Wang, S. Coord. Chem. ReV. 2001, 215, 79. (b) Anderson, S.; Weaver, M. S.; Hudson, A. J. Synth. Met. 2000, 111–112, 459. (c) Li, Y.; Liu, Y.; Bu, W.; Guo, J.; Wang, Y. Chem. Commun. 2000, 1551.

(2) (a) Beer, G.; Daub, J.; Rurack, K. Chem. Commun. 2001, 1138. (b) Rurack, K.; Kollmannsberger, M; Resch-Genger, U.; Daub, J. J. Am. Chem.

Soc. 2000, 122, 968. (c) Rurack, K.; Kollmannsberger, M.; Daub, J. Angew. Chem., Int. Ed. 2001, 40, 385.

(3) (a) Tang, C. W.; VanSlyke, S. A. Appl. Phys. Lett. 1987, 51, 913. (b) Sapochak, L. S.; Padmaperuma, A.; Washton, N.; Endrino, F.; Schmett, G. T.; Marshall, J.; Fogarty, D.; Burrows, P. E.; Forrest, S. R. J. Am. Chem.

Soc. 2001, 123, 6300.

(4) Montes, V. A.; Pohl, R.; Shinar, J.; Anzenbacher, P. J. Chem. Eur.

J. 2006, 12, 4523.

(5) Shinar, J. Organic Light-Emitting DeVisessA SurVey; Springer: Berlin, 2003.

(6) (a) Albrecht, K.; Kaiser, V.; Boese, R.; Adams, J.; Kaufmann, D. E.

J. Chem. Soc. Perkin Trans. 2, 2000, 2153. (b) Wu, Q.; Esteghamatian,

M.; Hu, N.-X.; Popovic, Z.; Enright, G.; Tao, Y.; D’Iorio, M.; Wang, S.

Chem. Mater. 2000, 12, 79. (c) Jia, W.-L.; Song, D.; Wang, S. J. Org. Chem. 2003, 68, 701. (d) Cheng, C.-C.; Yu, W.-S.; Chou, P.-T.; Peng,

S.-M.; Lee, G.-H.; Wu, P.-C.; Song, Y.-H.; Chi, Y. Chem. Commun. 2003, 2628. (e) Klappa, J. J.; Geers, S. A.; Schmidtke, S. J.; MacManus-Spencer, L. A.; McNeill, K. Dalton Trans. 2004, 883. (f) Chen, H.-Y.; Chi, Y.; Liu, C.-S.; Yu, J.-K.; Cheng, Y.-M.; Chen, K.-S.; Chou, P.-T.; Peng, S.-M.; Lee, G.-H.; Carty, A. J.; Yeh, S.-J.; Chen, C.-T. AdV. Funct. Mater. 2005,

15, 567.

(7) (a) Chen, J.; Burghart, A.; Derecskei-Kovacs, A.; Burgess, K. J.

Org. Chem. 2000, 65, 2900. (b) Wan, C.-W.; Burghart, A.; Chen, J.;

Bergstroem, F.; Johansson, L. B.-A.; Wolford, M. F.; Kim, T. G.; Topp, M. R.; Hochstrasser, R. M.; Burgess, K. Chem. Eur. J. 2003, 9, 4430. (c) Goze, C.; Ulrich, G.; Mallon, L. J.; Allen, B. D.; Harriman, A.; Ziessel, R

J. Am. Chem. Soc. 2006, 128, 10231.

10.1021/om700577y CCC: $40.75 2008 American Chemical Society Publication on Web 12/13/2007

Downloaded by NATIONAL TAIWAN UNIV on July 27, 2009

(2)

natoboron difluoride ((DBM)BF2),8and even [(2-pyin)BPh2] (2-pyin ) 2-(2-pyridyl)indole) (see Chart 1),9_{for which the BPh}

2 or BF2 fragment serves as an anchor to stabilize the planar arrangement of theπ-chromophore and their lowest lying excited states are dominated by the singletππ* transition character.

From the viewpoint of molecular design, another class of boron-containing emitter is also obtained by treatment of BF3 with tridentate ligand derived from 1,6-bis(2-hydroxyphenyl)py-ridine (H2bhppy). Due to the presence of two acidic phenol functional groups, the reaction proceeded with simultaneous elimination of 2 equiv of HF, giving the tridentate, pseudoplanar complex [(bhppy)BF] as the major product.1c_{The advantages} of the aforementioned boron complexes are their good solubility in organic solvents, excellent luminous efficiencies, readily fine-tuned emission peak wavelength, and facile deposition on substrate surface by means of direct thermal evaporation techniques.

As for their heavy analogues, it has been reported that the gallium metal atom can likewise form the coordinatively saturated complexes tris(8-hydroxyquinaldine)gallium(III)3_and bis(8-hydroxyquinaldine)gallium(III) (Q2GaX with X ) acetate, dimethylpropionate, benzoate, chloro), which have been proved to be useful as the host material, electron-transporting material, and emitter for OLED devices capable of showing good electroluminescent efficiencies at low drive currents.10 Nowa-days, the emissive gallium complexes have even been extended to other systems; selective examples involve the coordination ofβ-ketoiminato chromophores to a single GaMe2unit11or the formation of the dinuclear gallium complex [Ga2(saph)2Q2] with both chelating salicylidene-o-aminophenolato ligands (saph) and bridging 8-quinolinolato ligands (Q).12_{Furthermore, the} five-coordinated complexes Sn(bip)Ph2and Pb(bip)Ph2(bipH2) 2,6-bis(2′-indolyl)pyridine) have been synthesized, showing the versatility of heavy members of the group 14 elements in assembling the potentially useful emitters in OLEDs.13

In this article, we wish to report the synthesis, characteriza-tion, and theoretical investigation of a new class of gallium and indium complexes bearing substituted 6-azolyl-2,2′-bipyridine ligands. We anticipate that these ligands would serve as excellent tridentateπ-chromophores upon treatment with group III metal

alkyl reagents such as GaMe3and InMe3under mild conditions, affording a planar, rigid, and highly conjugated π-system perfectly tailored to enhance their luminescent properties. The tridentate and monoanionic nature of these ligands is expected to facilitate the formation of the pentacoordination mode, which should fit into gallium and indium with a much larger atomic size, as opposed to the smaller boron and aluminum elements, rendering relatively more stable products. In sharp contrast, reaction with a bidentate ligand would afford a dimeric structure, although the same type of pentacoordinate environment can be achieved.14_{In addition, we anticipate that such a design strategy} might conceptually lead to the development of new luminescent molecules with good fluorescence quantum yields3,15_{and tunable} emission hue, potentially suited to the current search for highly luminescent main-group-metal complexes.

2. Experimental Section

2.1. General Information and Materials. Mass spectra were obtained on a JEOL SX-102A instrument operating in the electron impact (EI) mode. The1_{H NMR spectra were recorded on Varian}

Mercury-400 or INOVA-500 instruments. Elemental analyses were carried out at the NSC Regional Instrumentation Center at National Chiao Tung University, Hsinchu, Taiwan. The group 13 metal alkyl reagents GeMe3and InMe3were provided by Rohm and Haas Co.

as free gifts. All reactions were performed under an inert atmosphere using anhydrous solvents or solvents treated with appropriate drying reagents.

2.2. Spectroscopic Measurements. Steady-state absorption and emission spectra were recorded by using a Hitachi (U-3310) spectrophotometer and an Edinburgh (FS920) fluorimeter, respec-tively. Both the wavelength-dependent excitation and emission responses of the fluorimeter had been calibrated. Lifetime measure-ments were performed with an Edinburgh FL 900 photocounting system by using a hydrogen-filled or a nitrogen lamp as the excitation source. Data were analyzed by using a nonlinear least-squares procedure in combination with an iterative convolution method. The emission decays were analyzed by the sum of exponential functions, which allows partial removal of the instru-ment time broadening and consequently renders a temporal resolu-tion of about 200 ps. Quinine sulfate in 1.0 N sulfuric acid soluresolu-tion was used as a reference, assuming the quantum yieldΦf) 0.54,16

to determine fluorescence quantum yields of the studied compounds in solution. Solution samples were degassed by three freez-e–pump–thaw cycles. To acquire the phosphorescence spectrum in the 77 K CH3CN matrix, an Nd:YAG (355 nm, 8 ns, Continuum

Surlite II) pumped optical parametric oscillator was tuned between 620 and 800 nm and was then frequency doubled by BBO crystals to obtain a 310–400 nm excitation frequency. The resulting luminescence was detected by an intensified charge-coupled detector (ICCD; Princeton Instruments, Model 576G/1) coupled with a polychromator in which the grating is blazed with a maximum at 700 nm. Typically, the gate of the ICCD was opened at a delay time of 100 ns to avoid scattering light and prompt fluorescence.

2.3. Experimental Procedures. Preparation of (ftzbpy)H. A 25 mL round-bottom flask was charged with ethyl trifluoroacetate (315 mg, 2.22 mmol), hydrazine hydrate (102µL, 2.11 mmol), and

15 mL of THF. The mixture was refluxed for 1 h. After the solution was cooled to room temperature, bipyridine carboximidamide hydrochloride (535 mg, 2.28 mmol) and sodium hydroxide (91 mg,

(8) Chow, Y. L.; Liu, Z.-L.; Johansson, C. I.; Ishiyama, J.-I. Chem. Eur.

J. 2000, 6, 2942.

(9) Liu, S.-F.; Wu, Q.; Schmider, H. L.; Aziz, H.; Hu, N.-X.; Popovic, Z.; Wang, S. J. Am. Chem. Soc. 2000, 122, 3671.

(10) (a) Hamada, Y.; Kanno, H.; Sano, T.; Fujii, H.; Nishio, Y.; Takahashi, H.; Usuki, T.; Shibata, K. Appl. Phys. Lett. 1998, 72, 1939. (b) Sapochak, L. S.; Burrows, P. E.; Garbuzov, D.; Ho, D. M.; Forrest, S. R.; Thompson, M. E. J. Phys. Chem. 1996, 100, 17766. (c) Crispini, A.; Aiello, I.; La Deda, M.; De Franco, I.; Amati, M.; Lelj, F.; Ghedini, M. Dalton

Trans. 2006, 5124.

(11) Shen, Y.; Han, J.; Gu, H.; Zhu, Y.; Pan, Y. J. Organomet. Chem.

2004, 689, 3461.

(12) Qiao, J.; Wang, L. D.; Duan, L.; Li, Y.; Zhang, D. Q.; Qiu, Y.

Inorg. Chem. 2004, 43, 5096.

(13) Jia, W.-L.; Liu, Q.-D.; Wang, R.; Wang, S. Organometallics 2003,

22, 4070.

(14) Examples for the formation of dimeric group III metal complexes showing a pentacoordinated geometry: (a) Park, J. T.; Kim, Y.; Kim, J.; Kim, K.; Kim, Y. Organometallics 1992, 11, 3320. (b) Zhou, Y.; Richeson, D. S. Organometallics 1995, 14, 3558.

(15) Chen, C. H.; Shi, J. Coord. Chem. ReV. 1998, 171, 161. (16) (a) Melhuish, W. H. J. Phys. Chem. 1961, 65, 229. (b) Demas, J. N.; Crosby, G. A. J. Phys. Chem. 1971, 75, 991.

Chart 1

(3)

2.28 mmol) were added into this flask. The reaction mixture was refluxed for another 8 h, the solvent was removed, and the residue was dissolved in ethyl acetate (40 mL). The organic layer was washed with deionized water (3× 20 mL), dried over anhydrous sodium sulfate, and concentrated to dryness, giving a colorless powdery solid (275 mg, 45%).

Spectral data of (ftzbpy)H:1_{H NMR (400 MHz, d}

6-acetone, 294

K):δ 8.72-8.70 (m, 2H), 8.61 (dd, J ) 8.0, 1.2 Hz, 1H), 8.23

(dd, J ) 7.6, 1.2 Hz, 1H), 8.17 (t, J ) 7.6 Hz, 1H), 7.94 (m, 1H), 7.46 (ddd, J ) 7.4, 4.6, 1.2 Hz, 1H).

Preparation of (N4bpy)H. A 25 mL reaction flask was charged with 6-cyano-2,2′-bipyridine (500 mg, 2.76 mmol), sodium azide (270 mg, 4.14 mmol), ammonium chloride (220 mg, 4.14 mmol), and 10 mL of DMF. The mixture was stirred at 130°C for 3 h. After that, the solution was cooled to room temperature and the solvent removed under vacuum. Addition of excess 0.1 N HCl solution resulted in formation of a colorless precipitate, which was collected by filtration; yield 460 mg, 2.04 mmol, 74%.

Spectral data of (N4bpy)H:1_{H NMR (300 MHz, d}

6-acetone, 294

K):δ 8.77-8.71 (m, 2H), 8.67 (dd, J ) 8.0, 1.0 Hz, 1H), 8.34

(dd, J ) 7.2, 1.0 Hz, 1H), 8.23 (t, J ) 8.0 Hz, 1H), 7.98 (td, J ) 8.0, 3.6 Hz, 1H), 7.51-7.46 (m, 1H).

Preparation of [(fpzbpy)GaMe2] (1a). A 25 mL reaction flask

was charged with (fpzbpy)H (132 mg, 0.46 mmol) and 10 mL of anhydrous diethyl ether. To this solution was added GaMe3(50

µL, 0.50 mmol), and the mixture was stirred at room temperature

for 1 h. After that, the white precipitate was collected by filtration and washed with diethyl ether. It was then recrystallized using a layered solution of acetone and hexane, giving 130 mg of rhomboidal crystals (0.33 mmol, 73%).

Spectral data of 1a: MS (EI) m/z 373, (M - Me)+;1_{H NMR}

(400 MHz, d6-acetone, 294 K) δ 8.87 (dd, J ) 5.2, 1.6 Hz, 1H, CH), 8.62 (d, J ) 8.0 Hz, 1H, CH), 8.51 (dd, J ) 8.0, 0.8 Hz, 1H, CH), 8.41 (t, J ) 8.0 Hz, 1H, CH), 8.28 (td, J ) 8.0, 1.6 Hz, 1H, CH), 8.14 (dd, J ) 8.0, 0.8 Hz, 1H, CH), 7.83 (ddd, J ) 7.6, 5.2, 1.2 Hz, 1H, CH), 7.17 (s, 1H, CH), -0.26 (s, 6H, Me);13_{C NMR} (100 MHz, d6-acetone, 294 K)δ 151.2 (s, 1C, CN), 149.7 (s, 1C, CN), 148.3 (s, 1C, CN), 147.8 (s, 1C, CN), 145.9 (q, JCF) 35 Hz, 1C, CCF3), 144.3 (s, 1C, CN), 143.8 (s, 1C, CH), 140.6 (s, 1C, CH), 127.6 (s, 1C, CH), 123.9 (q, JCF) 267 Hz, 1C, CF3), 122.6 (s, 1C, CH), 121.5 (s, 1C, CH), 120.1 (s, 1C, CH), 101.3 (s, 1C, CH), -4.5 (s, 6C, CH3). Anal. Calcd for C16H14F3GaN4: N, 14.40;

C, 49.40; H, 3.63. Found: N, 14.11; C, 49.32; H, 3.92.

Preparation of [(fpzbpy)InMe2] (1b). A 25 mL reaction flask

was charged with (fpzbpy)H (132 mg, 0.46 mmol) and 10 mL of anhydrous diethyl ether. To this solution was added dropwise InMe3

(80 mg, 0.50 mmol) dissolved in diethyl ether (3 mL), and the mixture was stirred at room temperature for 1 h. After that, the white precipitate was collected by filtration and washed with diethyl ether, giving 125 mg of white product (0.29 mmol, 63%).

Spectral data of 1b: MS (EI) m/z 419, (M - Me)+;1_{H NMR}

(400 MHz, d6-acetone, 294 K) δ 8.86 (dd, J ) 4.8, 2.0 Hz, 1H, CH), 8.64 (d, J ) 8.0 Hz, 1H, CH), 8.47 (dd, J ) 8.0, 0.8 Hz, 1H, CH), 8.33 (t, J ) 8.0 Hz, 1H, CH), 8.30 (td, J ) 8.0, 2.0 Hz, 1H, CH), 8.06 (dd, J ) 8.0, 0.8 Hz, 1H, CH), 7.84 (ddd, J ) 7.2 , 4.8, 0.8 Hz, 1H, CH), 7.18 (s, 1H, CH), -0.24 (s, 6H, Me);13_{C NMR} (100 MHz, d6-acetone, 294 K)δ 152.0 (s, 1C, CN), 149.9 (s, 1C, CN), 149.6 (s, 1C, CN), 148.6 (s, 1C, CN), 146.2 (s, 1C, CN), 145.8 (q, JCF) 35 Hz, 1C, CCF3), 142.9 (s, 1C, CH), 141.1 (s, 1C, CH), 127.6 (s, 1C, CH), 124.1 (q, JCF) 267 Hz, 1C, CF3), 123.2 (s, 1C, CH), 122.0 (s, 1C, CH), 120.4 (s, 1C, CH), 102.0 (s, 1C, CH), -7.3 (s, 6C, CH3). Anal. Calcd for C16H14F3InN4: N,

12.91; C, 44.27; H, 3.25. Found: N, 12.81; C, 44.07; H, 3.62. Preparation of [(ftzbpy)GaMe2] (2a). A 25 mL reaction flask

was charged with (ftzbpy)H (80 mg, 0.27 mmol) and 10 mL of anhydrous ether. To this solution was added GaMe3(30µL, 0.30

mmol), and the mixture was stirred at room temperature for 2 h.

After that, the precipitate was filtered and washed with diethyl ether. The sample was recrystallized using a layered solution of acetone and hexane, giving 88 mg of colorless crystal (0.22 mmol, 82%). Spectral data of 2a: MS (EI) m/z 374, (M - Me)+;1_{H NMR}

(400 MHz, d6-acetone, 294 K) δ 8.92 (dd, J ) 5.2, 0.8 Hz, 1H,

CH), 8.73-8.70 (m, 2H, CH), 8.58 (t, J ) 8.0 Hz, 1H, CH), 8.34-8.32 (m, 2H, CH), 7.90 (dd, J ) 7.2, 5.2 Hz, 1H, CH), -0.21 (s, 6H, Me). Anal. Calcd for C15H13F3GaN5: N, 17.96; C, 46.19;

H, 3.36. Found: N, 17.58; C, 46.25; H, 3.70.

Preparation of [(ftzbpy)InMe2] (2b). A 25 mL reaction flask

was charged with (ftzbpy)H (100 mg, 0.34 mmol) and 10 mL of anhydrous ether. To this solution was slowly added InMe3(60 mg,

0.38 mmol) dissolved in ether (3 mL), and the mixture was stirred at room temperature for 1 h. After the reaction was stopped, the solvent was removed and the pale yellow residue was dissolved in acetone. The insoluble precipitate was filtered, and the filtrate was concentrated to dryness, giving a pale yellow powder which was further recrystallized from a layered solution of acetone and hexane; yield 110 mg, 0.24 mmol, 72%.

Spectral data of 2b: MS (EI) m/z 420, (M - Me)+;1_{H NMR}

CH), 8.72-8.66 (m, 2H, CH), 8.48 (t, J ) 8.0 Hz, 1H, CH), 8.37-8.32 (m, 2H, CH), 7.88 (dd, J ) 7.6, 5.2 Hz, 1H, CH), -0.18 (s, 6H, Me). Anal. Calcd for C15H13F3InN5: N, 16.10; C, 41.41; H,

3.01. Found: N, 15.61; C, 41.36; H, 3.30.

Preparation of [(N4bpy)GaMe2] (3a). Following the previously

mentioned procedure, 3a was prepared by combining (N4bpy)H (140 mg, 0.62 mmol) and GaMe3(69µL, 0.69 mmol) in 10 mL of

diethyl ether, and the mixture was stirred at room temperature for 2 h. After removal of the solvent, the product was recrystallized using a layered solution of acetone and hexane, giving 140 mg of colorless crystals (0.43 mmol, 69%).

Spectral data of 3a: MS (EI) m/z 307, (M - Me)+;1_{H NMR}

CH), 8.77-8.73 (m, 2H, CH), 8.62 (t, J ) 8.0 Hz, 1H, CH), 8.46 (d, J ) 8.4 Hz, 1H, CH), 8.37 (td, J ) 8.0, 1.6 Hz, 1H, CH), 7.92 (dd, J ) 7.6, 4.8 Hz, 1H, CH), -0.18 (s, 6H, Me). Anal. Calcd for C13H13GaN6: N, 26.02; C, 48.34; H, 4.06. Found: N, 26.12; C,

48.39; H, 4.59.

Preparation of [(N4bpy)InMe2] (3b). Following the previously

mentioned procedure, 3b was prepared by combining (N4bpy)H (102 mg, 0.46 mmol) and InMe3(80 mg, 0.50 mmol) in 10 mL of

diethyl ether, and the mixture was stirred at room temperature for 2 h. After removal of the solvent, purification was conducted by recrystallization using a layered solution of acetone and hexane, giving 115 mg of colorless crystals (0.32 mmol, 69%).

Spectral data of 3b: MS (EI) m/z 353, (M - Me)+.;1_{H NMR}

CH), 8.73 (d, J ) 8.0 Hz, 1H, CH), 8.71 (dd, J ) 8.0, 1.2 Hz, 1H, CH), 8.53 (t, J ) 8.0 Hz, 1H, CH), 8.47 (dd, J ) 8.0, 1.2 Hz, 1H, CH), 8.36 (td, J ) 8.0, 1.6 Hz, 1H, CH), 7.90 (ddd, J ) 8.0, 4.8, 0.8 Hz, 1H, CH), -0.16 (s, 6H, Me). Anal. Calcd for C13H13InN6:

N, 22.83; C, 42.42; H, 3.56. Found: N, 22.66; C, 42.25; H, 3.97. Preparation of [Me2In(pyN4)]2(4). Following the previously

mentioned procedure, 4 was prepared by combining (N4py)H (147 mg, 1.0 mmol) and InMe3(176 mg, 1.1 mmol) in 15 mL of diethyl

ether, and the mixture was stirred at room temperature for 1 h. After removal of the solvent, the sample was recrystallized from acetone at room temperature, giving 123 mg of colorless crystals (0.43 mmol, 85%).

Spectral data of 4: MS (EI) m/z 567, (M - Me)+;1_{H NMR}

(400 MHz, d6-acetone, 294 K)δ 8.90 (d, J ) 4.4 Hz, 1H, CH),

8.41 (d, J ) 8.0 Hz, 1H, CH), 8.29 (td, J ) 8.0, 1.6 Hz, 1H, CH), 7.78 (ddd, J ) 8.0, 4.4, 1.2 Hz, 1H, CH), -0.05 (s, 6H, Me);13_C

NMR (100 MHz, d4-methanol, 294 K)δ 161.1 (s, 2C, CN), 149.3

(s, 2C, CN), 146.7 (s, 2C, CN), 141.4 (s, 2C, CH), 127.0 (s, 2C, CH), 122.9 (s, 2C, CH), -6.2 (s, 12C, CH3). Anal. Calcd for

(4)

C16H20In2N10: N, 24.07; C, 33.02; H, 3.46. Found: N, 23.60; C,

33.21; H, 3.70.

2.4. Structural Determination. Single-crystal X-ray diffraction data were measured on a Bruker SMART CCD diffractometer (2θmax e55.0°, ω scan mode) equipped with a graphite mono-chromator. The data collection was executed using the SMART program. Cell refinement and data reduction were accomplished using the SAINT program. The structures were solved using the SHELXTL/PC package and refined using full-matrix least squares. An empirical absorption correction was applied with the SADABS routine (part of the SHELXTL program). The structure was solved by direct methods using the SHELXTL suite of programs. All non-hydrogen atoms were refined anisotropically by full-matrix least squares on F2_{. Hydrogen atoms were placed in calculated positions}

and allowed to ride on the parent atoms.

Selected crystal data of 1a: C16H14F3GaN4, Mr ) 389.03,

monoclinic, space group P21/c, a ) 8.9197(5) , b ) 14.9354(8), c

) 12.4181(7) Å, β ) 100.740(1)°, V ) 1625.35(16) Å3, Z ) 4, F_calcd_{) 1.590 g cm}-3_{, F(000) ) 784, crystal size 0.45}_{× 0.30 ×}

0.25 mm,λ(Mo KR) ) 0.710 73 Å, T ) 150(2) K, µ ) 1.729

mm-1, index ranges -11 e h e 11, -19 e k e 19, -16 e l e 16, 14 245 reflections collected, 3745 with R(int) ) 0.0319, final wR2 (all data) ) 0.0744, R1 (I > 2σ(I)) ) 0.0309.

Selected crystal data of 4: C16H20In2N10, Mr) 582.06, triclinic,

space group P1j, a ) 6.8471(6) Å, b ) 8.6997(7) Å, c ) 9.0856(7) Å, R ) 88.128(2)°,β ) 82.900(2)°,γ ) 70.894(2)°, V ) 507.46(7) Å3, Z ) 1, Fcalcd) 1.905 gcm-1,µ ) 2.296 mm-1, F(000) ) 284,

crystal size: 0.30× 0.25 × 0.10 mm, λ(Mo KR) ) 0.710 73 Å, T ) 150(2) K, index ranges -8 e h e 8, -11 e k e 11, -11 e l e11, 6633 reflections collected, 2322 with R(int) ) 0.0212, final wR2 (all data) ) 0.0435. R1 (I > 2σ(I)) ) 0.0171.

2.5. Theoretical Approach. Calculations on the electronic ground state of complexes 1a-3a and 1b-3b were carried out by using B3LYP density functional theory.17_{A “double-}_{ζ” quality}

basis set consisting of the Hay and Wadt effective core potentials (LANL2DZ)18_{was employed for the In and Ga atoms and 6-31G*}

basis for H, C, N, and F atoms.19_{Time-dependent DFT (TDDFT)}

calculations using the B3LYP functional were then performed on the basis of the structural optimized geometries in combination with an integral equation formalism-polarizable continuum model (in acetonitrile), IEF-PCM, implemented in Gaussian 03.20_Oscillator

strengths (f) were deduced from the dipole transition matrix elements (for singlet states only). The ground-state B3LYP and excited-state TDDFT calculations were carried out by using Gaussian 03.21_{In the frontier region, neighboring orbitals are often}

closely spaced. In such cases, consideration of only the HOMO and LUMO may not yield a realistic description. For this reason, partial density of states (PDOS) diagrams, which incorporate a degree of overlap between the curves convoluted from neighboring energy levels, can give a more representative picture. The contribu-tion of a group to a molecular orbital was calculated within the framework of Mulliken population analysis. The PDOS spectra were created by convoluting the molecular orbital information with Gaussian curves of unit height and fwhm of 0.5 eV. The PDOS diagrams for 1a and 1b, shown in this work, are generated using the AOMix program.22

3. Results and Discussion

3.1. Ligand Syntheses. As depicted in Scheme 1, synthesis of all the tridentate ligands (fpzbpy)H, (ftzbpy)H, and (N4bpy)H required the key starting material 6-cyano-2,2′-bipyridine, which was best prepared by partial oxidation of commercially available 2,2′-bipyridine with m-chloroperbenzoic acid to afford 2,2′ -bipyridine N-oxide, followed by treatment with trimethylsilyl cyanide.23The pyrazolyl ligand (fpzbpy)H was best obtained by sequential reactions involving the treatment of methylmag-nesium iodide with 6-cyano-2,2′-bipyridine to afford 6-acetyl-2,2′-bipyridine, followed by condensation of 6-acetyl-2,2′ -bipyridine with ethyl trifluoroacetate, and finally with an excess of hydrazine hydrate in refluxing ethanol solution.24,25 _The preparation of the triazolyl ligand (ftzbpy)H was conducted by the condensation of trifluoroacetic acid hydrazide with bipyridine carboximidamide hydrochloride; the latter was synthesized by mixing 6-cyano-2,2′-bipyridine with sodium methoxide, fol-lowed by reacting with ammonium chloride in refluxing ethanol solution.26_{The tetrazolyl ligand (N4bpy)H was prepared readily} by combining 6-cyano-2,2′-bipyridine with sodium azide and ammonium chloride in DMF solution.27

3.2. Preparation and Characterization. Treatment of these 6-azolyl-2,2′-bipyridine ligands with the gallium reagent GaMe3 in anhydrous diethyl ether at room temperature afforded the target GaMe2complexes 1a-3a in yields of g70%, while the indium analogues 1b-3b were synthesized using the indium alkyl reagent InMe3under similar conditions (Chart 2). All six metal complexes were found to be soluble in common organic solvents such as THF, acetonitrile, and acetone. Moreover, they turned much less stable upon dissolving in chlorinated solvents

(17) (a) Becke, A. D. Phys. ReV. A 1988, 38, 3098. (b) Lee, C.; Yang, W.; Parr, R. G. Phys. ReV. B 1988, 37, 785. (c) Miehlich, B.; Savin, A.; Stoll, H.; Preuss, H. Chem. Phys. Lett. 1989, 157, 200.

(18) (a) Hay, P. J.; Wadt, W. R. J. Chem. Phys. 1985, 82, 270. (b) Wadt, W. R.; Hay, P. J. J. Chem. Phys. 1985, 82, 284. (c) Hay, P. J.; Wadt, W. R.

J. Chem. Phys. 1985, 82, 299.

(19) Hariharan, P. C.; Pople, J. A. Mol. Phys. 1974, 27, 209.

(20) Cances, E.; Mennucci, B.; Tomasi, J. J. Chem. Phys. 1997, 107, 3032.

(21) Gaussian 03, reVision C.02; Gaussian, Inc.: Wallingford, CT, 2004. (22) (a) Gorelsky, S. I. AOMix, reVision 6.33; http://www.sg-chem.net/. (b) Gorelsky, S. I.; Lever, A. B. P. J. Organomet. Chem. 2001, 635, 187.

(23) Norrby, T.; Borje, A.; Zhang, L.; Akermark, B. Acta Chem. Scand.

1998, 52, 77.

(24) Constable, E. C.; Heirtzler, F.; Neuburger, M.; Zehnder, M. J. Am.

Chem. Soc. 1997, 119, 5606.

(25) (a) Chen, K.; Cheng, Y.-M.; Chi, Y.; Ho, M.-L.; Lai, C.-H.; Chou, P.-T.; Peng, S.-M.; Lee, G.-H. Chem. Asian J. 2007, 2, 155. (b) Chen, K.-S.; Liu, W.-H.; Wang, Y.-H.; Lai, C.-H.; Chou, P.-T.; Lee, G.-H.; Chen, K. ; Chen, H.-Y.; Chi, Y.; Du, C.-C. AdV. Funct. Mater. 2007,in press.

(26) Funabiki, K.; Noma, N.; Kuzuya, G.; Matsui, M.; Shibata, K.

J. Chem. Res. (Miniprint) 1999, 1301.

(27) Facchetti, A.; Abbotto, A.; Beverina, L.; Bradanante, S.; Mariani, P.; Stern, C. L.; Marks, T. J.; Vacca, A.; Pagani, G. A. Chem. Commun.

2004, 15, 1770.

Scheme 1

Chart 2

(5)

such as CH2Cl2 and CHCl3, as demonstrated by the gradual formation of an insoluble white precipitate over a period of∼2 h. While the fundamental approach of this class of compounds can be fully accessed with good accuracy, their poor stability may limit their practical applications.

All of these metal complexes were characterized using routine spectroscopic methods as well as elemental analyses. Their spectroscopic data, particularly the high-field1H NMR signals observed in the regionδ -0.16 to -0.26, are in good agreement with the chemical shifts shown for the group 13 MMe2 fragment.28 _{This structural feature was also confirmed by a} single-crystal X-ray diffraction study on 1a. As shown in Figure 1, the central gallium atom exhibits a distorted trigonal-bipyramidal geometry, with two equatorial methyl substituents (Ga-C(1) ) 1.967(2) Å and Ga-C(2) ) 1.954(2) Å) and two distinctive Ga-N separations (Ga-N(1) ) 2.287(2) Å and Ga-N(3) ) 2.086(2) Å) at the axial sites. The bond angle between these axial coordination atoms showed significant deviation from linearity (∠N(1)-Ga-N(3) ) 148.14(7)°), which is due to the formation of two highly constrained chelate rings. Interestingly, the gross structure of 1a is akin to that of the indium complex [(keim)InMe2],29 where (keim)H is a tridentate ketoimine ligand with the empirical formula OdC(CF3)CH2C(CF3)dNCH2CH2NMe2, as well as the β-dike-tonate gallium complex [(hfac)GaMe2(py)],30 for which the combined bonding pattern of ligated pyridine (py) and hexafluo-roacetylacetonate (hfac) resembles that of the tridentate fpzbpy chelate observed in 1a.

With a goal of extending the reaction scope, as depicted in Chart 3, we have also examined the condensation of GaMe3 and InMe3 with the corresponding bidentate 2-pyridyl azole ligands such as (pyfpz)H, (pyftz)H,and (pyN4)H. Interesting, only the reaction of (pyN4)H27 _{and InMe}

3 produced the anticipated, air-stable complex [Me2In(pyN4)]2 (4). Other synthetic attempts employing both (pyfpz)H and (pyftz)H ligands have afforded products that decomposed upon removing the N2 atmosphere during workup. A single-crystal X-ray diffraction study on 4 was performed in order to establish its molecular structure.

As shown in Figure 2, complex 4 consists of a dimeric arrangement, in which the framework is linked by a pair of bridging tetrazolate ligands. The overall molecular geometry and its symmetric In2N4core arrangement resembles that of the dinuclear indium(III) complex with two bridging 3-(2-py-ridyl)pyrazolate ligands,31_{while each indium metal atom adopts} a distorted-trigonal-bipyramidal geometry with the equatorial methyl groups residing above and below with respect to the central In2N4pseudohexagon. It is notable that the Me-In-Me angles of∼143°in 4 are significantly larger than the Me-In-Me angle observed in 1b (∼130°). The bridging tetrazolate groups span both axial and equatorial positions of In atoms, with the In-Neq distances (In-N(5) ) 2.273(2) Å) being shorter compared with the In-Naxdistances (In-N(4A) ) 2.427(3) Å). The In-Npybond occupies the nonbridged axial positions with In-N(1) ) 2.474(3) Å.

On the basis of the crystal structure of 4, it becomes obvious that the 3-CF3substituent on the pyfpz and pyftz ligands should introduce significant steric interference with the methyl groups of adjacent GaMe2or InMe2units, if the anticipated pyrazolate and triazolate analogues [Me2M(pyfpz)]2 and [Me2M(pyftz)]2 (M ) Ga, In) can be generated from the treatment of the corresponding 2-pyridyl azole ligands with the alkyl reagents GaMe3and InMe3. This hypothesis could perhaps explain the high reactivity of these complexes. However, the poor chemical stability of the Ga analogue of 4, i.e. [(pyN4)GaMe2]2, cannot be attributed to this aforementioned steric interaction but is rather due to the greater bond strain imposed by the relatively smaller Ga metal atom.

3.3. Photophysical Properties. The absorption spectra of complexes 1a-3b in CH3CN are shown in Figure 3. The strong absorption bands ( >104 _M-1 _cm-1_{) in the UV region are} assigned to the spin-allowed1_{ππ* transitions of the bipyridyl} azolate ligands. It is notable that all complexes with the same core atom have very similar absorption spectral features, except that the absorption peak wavelengths are blue-shifted with respect to the tridentate ligand in the order fpzbpy < ftzbpy < N4bpy. For example, the peak wavelength tends to decrease from 1a (∼344 nm) to 3a (324 nm) as well as from 1b (340 nm) to 3b (321 nm). Such a spectral difference for both the a and b series manifests the intrinsic properties of the azolate moiety (i.e., pyrazolate, triazolate, or tetrazolate), which imposes a major influence on the photophysical properties of the associated complexes (vide infra). Moreover, for Ga and In complexes possessing the same ligands, a gradual blue shift of a few hundreds of cm-1 for the In complexes was generally observed (see Table 1). Similar to those of the absorption spectra, the emission peaks (in term of wavelength) of 1a-3a (28) Chi, Y.; Chou, T.-Y.; Wang, Y.-J.; Huang, S.-F.; Carty, A. J.;

Scoles, L.; Udachin, K. A.; Peng, S.-M.; Lee, G.-H. Organometallics 2004,

23, 95.

(29) Chou, T.-Y.; Huang, S.-F.; Chi, Y.; Liu, C.-S.; Carty, A. J.; Scoles, L.; Udachin, K. A. Inorg. Chem. 2003, 42, 6041.

(30) Beachley, O. T. J.; Gardinier, J. R.; Churchill, M. R.; Toomey,

L. M. Organometallics 1998, 17, 1101. Acta Crystallogr., Sect. C 1998, C54, 601(31) Ward, M. D.; Mann, K. L. V.; Jeffery, J. C.; McCleverty, J. A.. Figure 1. ORTEP diagram of 1a, with thermal ellipsoids shown at

the 50% probability level. Selected bond distances (Å) and angles (deg): Ga-C(1) ) 1.967(2), Ga-C(2) ) 1.954(2), Ga-N(1) ) 2.287(2), Ga-N(2) ) 2.100(2), Ga-N(3) ) 2.086(2); N(1)-Ga-N(3) ) 148.14(7), C(1)-Ga-C(2) ) 124.49(9).

Chart 3

(6)

follows a trend of 1a (493 nm) > 2a (459 nm) > 3a (450 nm) as well as 1b (466 nm) > 2b (432 nm) > 3b (412 nm) (see Table 1).

In view of the luminescent intensity, all Ga complexes (1a-3a) exhibit moderate (∼0.08-0.11) emission quantum yield in CH3CN, while it is relatively weaker (∼0.01–0.03) in

the In complexes (1b-3b) under identical condition. The emission intensity is independent of aerated or degassed solution, and the observed lifetimes,τobs, were measured to be <3 ns (see Table 1). The radiative lifetime calculated byτf) τobs/Φ, where Φ denotes the emission yield, is deduced to be s few tenths of nanosecondd for 1a-3b. Accordingly, for all com-plexes, the assignment of the emission to a spin-allowed transition, i.e. fluorescence, is unambiguous.

For the dimeric tetrazolate complex 4, the lowest lying singlet absorption and emission peak wavelengths were found to be located at 283 and 347 nm, respectively (see Table 1). In comparison with the case for the tridentate analogue 3b, such a large energy gap for absorption (emission) can be tentatively rationalized by the lack of a third pyridyl group to further reduce the LUMO energy level in complex 4. Obviously, complex 4 belongs to an unusual class of UV-emitting materials.32_Since our main focus in this study is on the visible emission, a detailed correlation between structure and photophysical properties for 4 was not further pursued.

As concluded for numerous pyridyl-azolate/late-transition-metal complexes,33_{if one assumes that the lowest lying singlet} excited state is mainly associated with a charge-transfer character from azolate (HOMO) to the pyridyl (LUMO) moiety, the resulting absorption and emission spectra for both Ga and In complexes may be qualitatively rationalized by a gradual increase of the number of electron-withdrawing nitrogen atoms inside the azolate ring, namely from fpzbpy (two nitrogens), ftzbpy (three nitrogens) to N4bpy (four nitrogens), resulting in the lowering of HOMO energy and hence an increase in the HOMO—LUMO energy gap. In addition, comparison of different metal elements possessing the same ligand environ-ment, a trend of blue-shifted emission from Ga to In complexes in terms of the peak wavelength is more obvious than that of the absorption spectra. For example, an emission spectral blue shift of 1175 cm-1was resolved from 1a to 1b, while it becomes as large as 2050 cm-1from 3a to 3b. The results simply indicate that the metal core, i.e. Ga versus In atom, in part, may play an important role in the observed electronic transition. Details on this issue are given in Theoretical Approach.

Another experimental result that has attracted our attention is the relatively low emission quantum efficiencies for both Ga (∼0.1) and In (e0.03) complexes, considering that the title compounds are all fairly rigid according to the chelating ligand configuration. Moreover, with the same anchoring ligands, the emission quantum yield for the In complexes is apparently lower than that of the Ga complexes by nearly 1 order of magnitude (see Table 1). Since In element has an atomic number of 49, which is apparently heavier than the gallium value of 31, the results lead us to propose that the S1fT_nintersystem crossing in these In complexes may serve as one major radiationless deactivating channel to compete with the S1 f S₀ radiative decay. For this case, the heavier In atom should enhance the spin–orbit coupling, resulting in a fast S1 f T_n intersystem crossing rate. Likewise, the T1 f S₀ radiative lifetime is expected to be shorter in the In complexes, rendering it feasible to resolve the phosphorescence. Support of this viewpoint is given by the phosphorescence measurements, in which the intensified charge coupled detector (ICCD) was electronically (32) (a) Wu, P.-C.; Yu, J.-K.; Song, Y.-H.; Chi, Y.; Chou, P.-T.; Peng, S.-M.; Lee, G.-H. Organometallics 2003, 22, 4938. (b) Chao, T.-C.; Lin, Y.-T.; Yang, C.-Y.; Hung, T. S.; Chou, H.-C.; Wu, C.-C.; Wong, K.-T.

AdV. Mater. 2005, 17, 992.

(33) (a) Chou, P.-T.; Chi, Y. Chem. Eur. J. 2007, 13, 380. (b) Chou, P.-T.; Chi, Y. Eur. J. Inorg. Chem. 2006, 3319. (c) Chi, Y.; Chou, P.-T.

Chem. Soc. ReV. 2007, 36, 1421. Figure 2. ORTEP diagram of 4, with thermal ellipsoids shown at

the 50% probability level. Selected bond distances (Å) and angles (deg): In-C(1) ) 2.138(3), In-C(2) ) 2.127(3), In-N(5) ) 2.273(2), In-N(4A) ) 2.427(3), In-N(1) ) 2.474(3); N(4A)-In-N(1) ) 154.69(5), C(1)-In-C(2) ) 143.78(8).

Figure 3. Normalized absorption and luminescence spectra of 1a-3b in CH3CN recorded at room temperature (solid lines) and

the phosphorescence spectrum of 1b in a 77 K CH3CN matrix

(-0-), for which the data was acquired at a delay time of 100 ns (see the Experimental Section). Note that the phosphorescence of 1b is not normalized, to emphasize its transition in different multiplicities.

Table 1. Photophysical Data of Complexes 1a-3b, Measured in Degassed CH3CN solution at Room Temperature

absλmax(nm) (×10-3) emλmax(nm) QY τobs(ns) kr 1a 282 (14.8), 344 (11.2) 493 0.11 2.01 5.5× 107 2a 271 (14.8), 330 (12.1) 459 0.077 0.32 2.4× 108 3a 263 (13.1), 324 (13.1) 450 0.073 0.86 8.5× 107 1b 281 (13.4), 340 (10.4) 466 0.03 1.26 2.4× 107 2b 271 (15.0), 327 (13.0) 432 0.008 0.76 1.5× 107 3b 265 (12.3), 321 (13.4) 412 0.01 <0.3 4.2× 107 4 241 (18.6), 283 (15.4) 347 0.046 1.8 2.6× 107

(7)

gated at 1 ms with a delay time of 100 ns with respect to the excitation pulse to eliminate the prompt fluorescence and (see the Experimental Section). As a result, phosphorescence was resolved in the cases of 1b-3b, with peak wavelengths centered at 510, 485, and 475 nm, respectively (see Figure 3 for the phosphorescence spectrum of 1b). On the other hand, under the same experimental conditions, phosphorescence was ob-scured for the Ga counterparts 1a-3a, manifesting their much lower efficiency in both S1fT₁intersystem crossing and T₁ f S₀ radiative processes. Of course, for both Ga and In complexes, other radiationless deactivation pathways cannot be ignored. One prominent channel may be tentatively attributed to the shallow potential energy surface (PES) that arises from the distorted, highly strained trigonal-bipyramidal geometry, resulting in a possible intersection with respect to the ground-state PES and hence the radiationless deactivation.

3.4. Theoretical Approach. Theoretical confirmation of the underlying basis for the photophysical properties of compounds 1a-3a and 1b-3b was provided by DFT calculations. By using the TD-B3LYP/6-31G* and LANL2DZ method based on the fully optimized geometries, the vertical (i.e., Franck–Condon) excitation energy from the ground state to low-lying excited states was calculated. Figure 4 depicts the features of the lowest unoccupied (LUMO) and the highest occupied (HOMO) frontier orbitals for the studied representative complexes 1a,b involved in the lowest lying singlet transition, while the pertinent descriptions and the energy gap of all complexes are listed in Table 2. When the experimental results are compared (Table 1), the energy gaps for all complexes estimated from the theoretical approaches show the consistent tendency. For example, the calculated S0-S1energy gap increases in the order 1a < 2a < 3a and 1b < 2b < 3b. Also, in good agreement with the experimental results, the S0-S1energy gap is larger in the In complexes in comparison to its Ga counterparts bearing identical ligands. In view of the quantitative approach, it is worth noting that the rather small deviation of the current theoretical approach from the experimental results may support the suitability of the theoretical level adopted here for studying the photophysical properties of Ga and In complexes 1a-3a and 1b-3b.

Moreover, in 1a-3a and 1b-3b, the associated frontier orbital data indicate that the electron densities of the HOMO are largely located on the azolate fragments and, in very small part, the central Ga or In atom (e.g., < 1% of the metal orbital in the HOMO of 1a,b), whereas those of the LUMO are mainly

distributed on the bipyridyl segment. Since the first singlet excited state of all title complexes mainly consists of the transition from HOMO to LUMO (>80%; see Table 2) the result clearly indicates that the lowest singlet electronic transition in 1a-3a and 1b-3b is dominated byπ (azolate) f π* (pyridyl) intraligand charge transfer (ILCT), mixed with small but non-negligible metal-to-ligand charge transfer (MLCT) character. As for 3a,b, the orbital compositions of the HOMO are found to be no longer dominated by the tetrazolate fragment, the result of which may be explained by the largely decreased tetrazolate orbital energy (see Table 2 for the charge transfer character analysis). Instead, the HOMO is located on the methyl groups and the whole tridentate ligand in 3a,b, respectively. Neverthe-less, for all title 1a-3a and 1b-3b complexes, one can perceive that the nitrogen atom in the azolate moiety acts as an electron-withdrawing substituent and hence affects the HOMO energy level, giving a systematic variation of the photophysical properties. For instance, on comparison of the pyrazolate group in 1a (1b) and the triazolate moiety in 2a (2b), to which the HOMO is mainly contributed, an increase of the energy gap with a tendency of 1a < 2a (1b < 2b) is well justified. In addition, one may speculate that the substituent effect of the azolate moiety, acting as an electron-withdrawing group with respect to the bipyridyl fragment, should also lower the relative energy of the LUMO. However, this effect seems to be minor, due to the extended conjugation between two bipyridyl moieties that contribute to the LUMO. Consequently, for the title complexes it is generally true that the S0-S1energy gap, as reflected from either absorption or emission spectra, increases as the number of nitrogen atoms in the azolate moiety increases. With regard to the notable difference between Ga and In complexes bearing identical ligand configurations, one possible explanation lies in the relative energy level of the valence orbital, namely 4p for gallium and 5p for indium. However, the ionization potential of the Ga(III) orbital is found to be higher than that of the In(III) orbital.34Thus, upon mixing ππ* and MLCT states, the lowest lying absorption/emission energy gap of In complexes is expected to be smaller than that of their Ga counterparts, contradicting the experimental results. The results also indirectly indicate a rather small contribution of the metal atom to the HOMO of the title Ga and In complexes, consistent with the theoretical data. Alternatively, owing to the different bonding strengths between Ga and In, the results may be (34) Lide, D. R. CRC Handbook of Chemistry and Physics, 74th ed.; CRC Press: Boca Raton, FL, 1993; pp 10-205–10-207.

Figure 4. HOMO and LUMO of the representative complexes 1a,b.

Table 2. Calculated Energy Levels of the First Singlet Excited State for Complexes 1a-3a and 1b-3b Based on the Structural

Optimized Geometries with the Integral Equation Formalism-Polarizable Continuum Model (in Acetonitrile),

IEF-PCM

S1 calcdλmax(nm) f assignts

CT character (%)b 1a 350.3 0.1814 HOMO f LUMO (+91%)a _52.6 2a 330.2 0.1581 HOMO f LUMO (+91%) 32.7 3a 322.1 0.0505 HOMO f LUMO (+96%) 3.3 1b 349.8 0.1891 HOMO f LUMO (+91%) 51.6 2b 328.6 0.2232 HOMO f LUMO (+90%) 38.9 3b 313.8 0.2743 HOMO f LUMO (+87%) 22.5

a_{Transition probability.} b_{CT character for the HOMO f LUMO}

transition is defined according to the equation (% HOMOazolate - %

LUMOazolate) × transition probability (%). Note that details of the

molecular orbital compositions for 1a-3a and 1b-3b are provided in the Supporting Information.

(8)

rationalized by the lowering of the electron density of the azolate moiety in the In complex in comparison to that in the Ga counterpart.

A firm support of this viewpoint is given by a plot of partial density of states for 1a versus 1b extracted from the computation results. As depicted in Figure 5, the partial density of states of complexes 1a,b were intuitively divided into four fragments, namely methyl groups (fragment 1), the central metal atom (fragment 2), CF3-substituted pyrazolate (fragment 3), and bipyridyl ligand (fragment 4). For clarity, continuous Gaussian function curves are applied to represent the density of states for each fragment. The Gaussian functions appearing on the left side of Figure 5 are the electron density populations of the occupied states, while those depicted on the right-hand side are the electron density populations of the unoccupied states. Clearly, as shown by the peak location of the highest occupied orbital in Figure 5, the energy for those fragments belonging to CF3-substituted pyrazolate ligands of the indium complex 1b (-6.15 eV) was significantly lower than that of its gallium

counterpart 1a (-6.11 eV), supporting the proposed mechanism. From the viewpoint of classical chemistry, owing to a stronger ligand field strength for the heavy element, one may perceive a greater bonding strength between In and azolates (versus Ga and azolates), resulting in more electron deficiency for the HOMO and hence an increase of the corresponding S0fS₁ transition gap.

4. Conclusion

In summary, 6-azolyl-2,2′-bipyridine ligands consisting a variety of pyrazolyl, triazolyl, and tetrazolyl substituents have been synthesized. Treatment of these tridentate ligands with the group 13 metal alkyl reagents GaMe3and InMe3yielded a series of new emissive metal complexes possessing the aforementioned 6-azolyl-2,2′-bipyridine chelates. Their chemical stability ap-pears to be due to the pentacoordinate ligand environment, which is further confirmed by the formation of complex 4 via reaction of the bidentate (pyN4)H with InMe3, giving a self-assembled dimeric structure with two pentacoordinate In metal centers. Both the absorption and the corresponding emission peak positions of 1-3 can be fine-tuned via the variation of azolyl functional groups, for which a rational explanation is provided by the HOMO/LUMO correlation via the assistance of com-putational approaches. We anticipate that such a design strategy might provide new insight into the preparation of main-group fluorescent dyes with good quantum yields and tunable emission hues that particularly fit into the current interest in OLEDs and related subjects.

Acknowledgment. This work was funded by the National Science Council of Taiwan, ROC, under Grant Nos. NSC 93-2113-M-007-012 and NSC 93-2752-M-002-002-PAE.

Supporting Information Available: CIF files giving X-ray crystallographic data for complexes 1a and 4 and figures and tables giving detailed computational results for the title complexes. This material is available free of charge via the Internet at http://pubs.acs.org.

OM700577Y

Figure 5. Plot of partial density of states of the representative complexes 1a,b.
