Solution-processed zinc oxide nanoparticles as interlayer materials

for inverted organic solar cells

Mohammed Aziz Ibrahem

a,b,c

, Hung-Yu Wei

d

, Meng-Hung Tsai

e

, Kuo-Chuan Ho

d

,

Jing-Jong Shyue

b,e

_{, Chih Wie Chu}

b,f,n

a

Department of Physics, National Taiwan University, Taipei 106, Taiwan

b

Research Center of Applied Science, Academia Sinica, Taipei 115, Taiwan

c

Nanoscience and Technology Program, Taiwan International Graduate Program, Academia Sinica, Taipei 115, Taiwan

d

Institute of Polymer Science and Engineering, National Taiwan University, Taipei 10617, Taiwan

e_{Department of Material Science and Engineering, National Taiwan University, Taipei 106, Taiwan} f

Department of Photonics, National Chiao Tung University, Hsinchu, 300, Taiwan

a r t i c l e

i n f o

Article history: Received 28 June 2012 Received in revised form 27 August 2012

Accepted 4 September 2012 Available online 17 October 2012 Keywords:

Polymer solar cells ZnO

Nanoparticles Wet grinding Buffer layer

a b s t r a c t

This paper describes inverted bulk heterojunction organic solar cells featuring solution-processed zinc oxide nanoparticles (ZnO NPs) as an electron extraction layer, prepared at relatively low annealing temperatures (r150 1C). A solution of ZnO NPs (average size: 25 nm) was prepared using a wet grinding method. When the ZnO interlayer was present in the solar cell, the vertical phase separation of the active layers prepared with and without solvent annealing exhibited similar gradient concentra-tions and, therefore, similar photocurrent generation, both of which were superior to those of conventional devices incorporating a poly(3,4-ethylenedioxythiophene):poly(styrene sulfonic acid) (PEDOT:PSS) hole extraction layer. We attribute this vertical phase separation to the similar surface energies of the fullerene derivative and the ZnO interlayer. Under simulated air mass (AM) 1.5 G illumination at 100 mW cm2_{, the power conversion efﬁciency of the optimized device was}

approxi-mately 4%.

1. Introduction

Over the past decades, much effort has been exerted in the quest to improve energy efﬁciency, to develop renewable energy and clean fuel sources, and to decrease overall greenhouse gas emissions. In particular, the abundance of clean energy from the sun has drawn much attention [1]. Recently, organic solar cells have attracted considerable interest as potential next-generation solar cells because they can be prepared at low cost, with low environmental load and ﬂexibility, and as lightweight alternatives to currently used silicon solar cells [2]. Conducting organic compounds are at the heart of bulk-heterojunction (BHJ) solar cells, which feature an interpenetrating blend of optically active polymers and electron-accepting molecules. The combination of poly(3-hexylthiophene) (P3HT) and [6,6]-phenyl-C61-butyric acid

methyl ester (PCBM) in organic blends exhibits particularly promising photovoltaic performance [3]. The traditional BHJ architecture has limited device stability because it features an

air-sensitive, low-work-function metal cathode (e.g., calcium), at which oxygen can diffuse into the active layer through pinholes and grain boundaries, leading to its degradation[4]. Furthermore, the traditional BHJ architecture assembles into an undesirable component distribution, with the P3HT-rich region partitioning to the top (air) surface and the PCBM-rich region remaining at the bottom (substrate) surface, as a result of the different surface energies of the photoactive components[5,6]. To improve charge collection, the architecture of BHJ devices can be modiﬁed with functional layers inserted at the interfaces between the active layers and the electrodes[7]. Such so-called ‘‘inverted’’ structures can overcomes problems with both the interface instability and the degradation of the indium tin oxide (ITO)-poly(3,4-ethylene-dioxythiophene):poly(styrene sulfonic acid) (PEDOT:PSS) inter-face an inevitability because of the strongly acidic nature of PEDOT:PSS[8]. Further improvements in the performance of the inverted architecture can be expected by reducing the resistivity of the functional buffer layer and optimizing the energy align-ment at the acceptor–buffer layer interfaces[9].

Inverted architectures featuring various electron-selective layers, including cesium carbonate (Cs2O3)[10], titanium dioxide

(TiOx) [11,12], calcium (Ca) [7], titanium chelate (TIPD) [13],

rhenium oxide [14], and ZnO [15–19], have been prepared to Contents lists available atSciVerse ScienceDirect

journal homepage:www.elsevier.com/locate/solmat

Solar Energy Materials & Solar Cells

n

Corresponding author at: Research Center of Applied Science, Academia Sinica, Taipei 115, Taiwan.

(2)

improve electron transport and extraction. Applying the same interlayer concept to the opposite electrode, several transition metal oxides, including vanadium oxide (V2O5) [20–22] and

molybdenum oxide (MoO3) [23,24], have been exploited as

interfacial hole extraction layers between the positive electrode and the photoactive layer in organic photovoltaic (OPVs). Among the transition metal oxides, ZnO is a promising candidate because of its relatively high electron mobility, environmental stability, and optical transmittance in the visible range[25], its wide and direct band gap (3.37 eV), and its large exciton binding energy (60 meV)[26]. Moreover, thin ﬁlms of ZnO are readily prepared through deposition using solution processing and subsequent thermal annealing treatment.

Although many fabrication methods can be employed to prepare ZnO nanoparticles (NPs), including sol–gel processes[11,27,28], vapor phase synthesis [29], simple solution combusting [26], and spray pyrolysis[30], these methods generally require complex equipment and complicated operational procedures; therefore, the challenge remains to develop simple routes for the synthesis of metal oxide NPs in high yield. In this paper, we report a wet grinding method for the preparation of ZnO NPs, using ethylene glycol (EG) as the solvent. Unlike the approaches mentioned above, this solution-based method is relatively simple and convenient; very cheap and facile; environ-mentally friendly; and provides the resulting NP solutions in a pure and well-dispersed form (stable for hundreds of hours without precipitation) without the need for surfactants. These clean NP solutions are processable through spin coating at low temperature (150 1C) to form high-quality, continuous ﬁlms free from cracks and pinholes. In addition, layers of P3HT:PCBM deposited through spin-coating on top of ZnO interlayers prepared with and without solvent annealing exhibit similar phase separation morphologies determined from X-ray photoelectron spectroscopy (XPS) depth proﬁles of the concentration gradients of the donor and acceptor moieties in the vertical direction while maintaining very smooth surfaces. Notably, the performance of inverted-structure devices featuring ZnO inter-facial layers prepared with or without solvent annealing was better than that of conventional devices featuring a PEDOT:PSS buffer layer.

2. Experimental methods

2.1. ZnO NPs and thin ﬁlm preparation

Different types of surfactant have been used to stabilize ZnO NPs prepared using various methods. Huang et al. stabilized ZnO NPs in EG solvent by adding a silane coupling agent[31]; Ni et al.

synthesized ZnO NPs using a simple solution-combusting method employing a mixture of EtOH and EG as starting solvents [26]; and Krebs stabilized ZnO NP ink with methoxyethoxyacetic acid (MEA) in 1 solvent and chlorobenzene with o-xylene and WS-1 [32]. In this study, ZnO powder (UniRegion Bio-Tech) was dispersed in pure EG (J.T. Baker) at a concentration of 5 wt%, without any surfactant or modiﬁcation, for use as the starting material for grinding. High-energy ball milling was performed at room temperature using a batch-type grinder (JBM-B035) oper-ated at a rate of 2000 rpm. The milling duration was typically in the range 60–420 min. The resultant solution could be diluted to a lower concentration without any precipitation. Prior to spin-coating with thin ZnO ﬁlms, ITO-coated glass substrates (o10

O

sq1_{, RiTdisplay) were cleaned through ultrasonication}

in detergent-containing water and twice with deionized (DI) water (15 min each), dried in an oven, and then treated with ultraviolet (UV)/ozone for 15 min. The ZnO NP solution was coated on top of the ITO glass through spin-coating at 4000 rpm for 60 s and then thermally annealed at 150 1C for 60 min, providing a thin ﬁlm having a thickness of approximately 40 nm. 2.2. ZnO thin ﬁlm characterization

The average particle size was measured using a particle size analyzer (Brookhaven 90 plus Sn11408). The absorption and transmittance spectra of the ZnO thin films were recorded using a Jasco V-670 UV–vis–NIR spectrophotometer. The surface morphologies of the thin films were measured through scanning electron microscopy (SEM; FEI Nova200) and atomic force micro-scopy (AFM; Veeco di Innova). The thickness of the thin film was measured using a Veeco Dektak 150 alpha step surface profiler. The valence band maximum (VBM) of the ZnO film was measured using ultraviolet photoelectron spectroscopy (UPS; PHI 5000 Versa Probe scanning ESCA microprobe); the band gap (Eg) was

obtained from the UV absorption edge. Contact angles and surface energies were measured using a Slideaway instrument.

2.3. PSC fabrication and characterization

Devices featuring a ZnO interfacial layer in an inverted structure (ITO/ZnO/P3HT:PCBM/V2O5/AL; displayed inFig. 1along with a basic

energy level diagram of the component materials) were fabricated using different mechanisms for solidiﬁcation of the active layer. Device A was prepared with ‘‘slow-growth’’ deposition of the active layer, spin-coated from a solution containing P3HT:PCBM (1:1, w/w) in 1,2-dichlorobenzene on top of the ZnO ﬁlm, and then it was dried

(3)

for 30 min in a covered Petri glass dish for solvent evaporation; subsequently, the ﬁlms were annealed at 130 1C for 30 min. Device B, featuring the ‘‘fast-grown’’ active layer, was directly thermally

annealed at 130 1C for 30 min without solvent evaporation. The active layer of device C was prepared without solvent or thermal annealing, while the active layer of device D was prepared as in the case of device A, but on the ITO surface (i.e., without a ZnO interlayer). For the regular device E (ITO/PEDOT:PSS/P3HT:PCBM/V2O5/AL), the active

layer was prepared in manner similar to that of device A. The thickness of the active layer in each device was approximately 200 nm. Layers of V2O5(99.6% Alfa Aesar; 10 nm) and Al (100 nm)

were sequentially thermally evaporated through a shadow mask under vacuum (pressure: o6 106_{Torr). The active area of each}

device was 10 mm2_{; its performance was tested inside a glove box}

under simulated AM 1.5 G irradiation conditions (100 mW cm2₎

using a Xenon (Xe) lamp-based solar simulator (Thermal Oriel1000W). The external incident photon-to-current efﬁciency (IPCE) spectra were recorded under short-circuit conditions. The devices were encapsulated in UV gel and transparent glass before they were removed from the glove box. The light source was a 450 W Xe lamp (Oriel Instruments, Model 6123NS). The light output from the monochromator (Oriel Instruments, Model 74100) was focused on the photovoltaic cell being tested.

3. Results and discussion

The ZnO NPs exhibited size-dependent dissolution behavior, with the smallest ZnO NPs exhibiting the greatest tendency for

Fig. 2. Particle sizes in ZnO powders obtained after different grinding times. Inset: Sedimentation from ZnO solutions before and after grinding for 420 min.

Fig. 3. (a) and (b) SEM images of thin ﬁlms formed through spin-coating (4000 rpm) and annealing (150 1C, 60 min) of (a) the non-ground powder and (b) the ground 3 wt% ZnO solution. (c) Corresponding XRD patterns of ZnO powders prepared with and without grinding for 420 min.

(4)

dispersion, while the aggregated NPs displayed decreased pro-pensity for dispersion, attributable to differences in surface tension, which is size- and shape-dependent[33,34]. To obtain much smaller, more uniformly shaped, and better-dispersed NPs, longer grinding times were required. The particle size decreased upon increasing the grinding time, with the initially non-uniform particles ( 4250 nm) reaching approximately 25 nm after 420 min of grinding (Fig. 2). We performed sedimentation tests by storing ZnO solutions (prepared with and without grinding) in EG for more than six months. The ZnO NPs prepared without grinding precipitated completely after a few hours, but the ZnO NPs prepared with grinding were highly stable without any precipitation (see inset to Fig. 2). Thus, the grinding process increased the compatibility between the ZnO NPs and the organic solvent, increased the repulsive forces among the particles, and prevented the ZnO NPs from aggregating. We obtained a dis-continuous ﬁlm with very large grains (5

m

m) from the non-ground ZnO solution (Fig. 3a); in contrast, a uniform continuous film without pinholes or cracks was formed from the ground ZnO NP solution (Fig. 3b). Thus, the uniform and smaller particles formed more-compact and denser films, without pinholes or cracks, thereby presumably decreasing the potential barrier and, accordingly, increasing the degree of electron extraction from the interface with the polymer blend film. The X-ray diffraction (XRD) patterns inFig. 3(c) reveal the stoichiometries of the ZnO powders prepared with and without grinding. The nearly identical values of 2

y

the XRD peaks imply the same crystallinity, with the decreased intensity and broadening of the peaks after grinding being consistent with decreased grain and lattice sizes.

Thermal and solvent annealing are currently the most popular methods for controlling the morphologies of polymeric active layers, particularly to increase a material’s crystallinity and to develop suitably phase-separated domains for efficient carrier transport. It was not until 2005 that the combination of thermal and solvent annealing was demonstrated to significantly enhance PSC efficiency [35]. Rapid solidification of the BHJ generally produces devices exhibiting poor power conversion efficiencies

(PCEs). The challenge remains to develop simple methods, with-out the need for solvent annealing, to obtain high efﬁciencies. In this study, we observed comparable PCEs both with and without solvent annealing when using the ZnO NPs as interlayer ﬁlms in the inverted device structure. Fig. 4(a) displays the current density–voltage (J–V) characteristics of the devices; Table 1

summarizes their extracted device parameters. The variations in device performance were not signiﬁcant in terms of open-circuit voltage (Voc), short-current density (Jsc), or ﬁll factor (FF)between

device A (‘‘slow grown’’; PCE¼3.98%) and device B (‘‘fast grown without solvent annealing’’; PCE ¼3.8%); these comparable per-formance parameters resulted from vertical phase segregation of the P3HT:PCBM blend ﬁlm after insertion of ZnO as an electron extraction layer. In contrast, device C (‘‘fast grown without solvent and thermal annealing’’; PCE ¼2.2%) and the conventional device E (‘‘slow grown’’ with PEDOT:PSS buffer layer; PCE¼3.65%) exhibited comparable values of Voc, but lower values of Jscand FF,

relative to devices A and B. Because device C, with and without solvent annealing of the active layer given a similar performances PCEo2.2%, annealing of the active layer (at 130 1C for 30 min) enhanced the phase separation and crystallinity of the P3HT chains, leading to signiﬁcant improvement in the values of Jsc

and FF and, therefore, the device performance. Device D (‘‘slow grown without ZnO interlayer’’; PCE¼0.8%) exhibited tremendous

Fig. 4. (a) J–V characteristics and (b) IPCE spectra of the inverted solar cell devices A (‘‘fast growth’’), B (‘‘slow growth’’ of active layer), C (fast grown without thermal annealing), and D (without ZnO layer).

Table 1

Device performance parameters of inverted P3HT:PCBM solar cells fabricated with a ZnO ﬁlm as the electron extraction layer.

Device Voc(volt) Jsc(mA cm2) FF (%) PCE (%)

Best Averagea A 0.6170.012 10.6570.23 61.2670.5 3.98 3.74 B 0.670.011 10.470.2 61.2270.6 3.8 3.58 C 0.5970.023 7.7970.4 48.1570.8 2.2 2.04 D 0.2570.027 8.6670.5 3770.67 0.8 0.72 E 0.670.015 9.2470.18 65.870.5 3.65 3.5 a

(5)

decreases in Voc, FF, and performance, revealing the important

role that the ZnO interlayer played in the device performance. The IPCE spectra inFig. 4(b) reveal that the maximum IPCE (63%) was that for device A, indicative of efﬁcient photon-to-electron con-version with a higher value of Jsc. The improvement in

short-circuit current density is consistent with the greater incident photon-to-current conversion efficiency, and of a device featuring a more highly transparent ZnO film near the absorption spectrum of P3HT:PCBM providing a higher photocurrent. A sharp drop in IPCE at wavelengths below 400 nm is clearly evident, with small increases in the UV region, for all devices incorporating a ZnO layer, due to the strong absorption of the film near the band edge of ZnO. This observation suggests that the blend layer morphol-ogies and charge carrier percolation networks were affected by the choice of processing method[36]. The advantages of vertical segregation and of the inverted structure over the regular struc-ture are apparent under the same spin-coating parameters.

It is believed that the surface morphology of a ZnO film, in term of its wettability and adhesion with the polymer layer, will affect the performance of the corresponding device. Small contact angles generally indicate hydrophilic properties, with good wet-ting and adhesion[37]. Therefore, we measured surface morphol-ogies, roughnesses, and contact angles to investigate the surface qualities of our ZnO films at the blend interface (with and without solvent annealing). In a fluid medium, P3HT molecules will move

toward the relatively hydrophobic side, causing the top surface air-blend interface region to be P3HT-rich and the bottom surface ITO-blend interface region to be PCBM-rich [38]. Table 2 sum-marizes the average surface energies and contact angles of blend films featuring a ZnO interlayer and pure P3HT and PCBM layers. The surface energy of the ZnO film was higher than those of the pure P3HT layer and of the reference blend film without a ZnO layer, but it was similar to that of the pure PCBM layer. The surface energies of the blend films featuring ZnO layers grown with and without solvent annealing were similar, and they were closer to that of pure P3HT than they were to that of PCBM. Based on contact angle measurements, we conclude that the ZnO interlayer induced the diffusion of PCBM toward the bottom surface, rather than to the top surface, with either mechanism for growing the blend film, producing similar degrees of vertical phase separation.

To further investigate the vertical phase separation, we mea-sured the depth profiles of the blend P3HT:PCBM active layer on top of the ZnO/ITO surface (Fig. 5). Here, sulfur (S) atoms represent the relative amount of P3HT within the photoactive layer, zinc (Zn) atoms represent ZnO, and indium (In) atoms represent ITO. The vertical gradients of P3HT in the blend films with and without solvent annealing exhibited similar behavior, with the concentra-tion distribuconcentra-tion (P3HT-rich on the surface; PCBM-rich near the ZnO adjacent to the cathode) indicating vertical segregation on the ZnO-coated ITO side. A small difference appeared, however, in the gradients of the two curves, namely of the P3HT gradients in the blend films prepared using the two growing methods. The atomic concentration of S atoms in the case of the slowly grown film was lower than that of the rapidly grown film, indicating a higher concentration of PCBM; in contrast, the P3HT:PCBM blend film prepared without a ZnO interlayer did not reveal such a clear concentration gradient. We conclude that a slow rate of solvent evaporation facilitates the growth of highly crystalline P3HT; under such conditions, a portion of the PCBM molecules, with a faster rate of crystallization than that of the polymer, were gradually expelled from the P3HT domains, resulting in the formation of P3HT- and PCBM-rich domains. These results are consistent with the surface energies and contact angles listed inTable 2. Because P3HT is a hole-conducting p-type semiconductor and PCBM is an

electron-Fig. 5. Depth proﬁles of In, Zn, and S atoms (representing ITO, ZnO, and P3HT, respectively) in the P3HT:PCBM blend ﬁlms of inverted-structure BHJ solar cells. Table 2

Surface energies and contact angles of ZnO thin ﬁlms and the components of the active layer blend.

Film H2O contact angle

(degree) EG contact angle (degree) Surface energy (mN cm2 ) ZnO 86.1 55 38.24 Pure PCBM 73.05 60.3 37.87 Pure P3HT 95.87 70.1 25.53 P3HT:PCBM 96.7 87.4 30.43 ZnO þ P3HT:PCBM slow growth 87.88 78.75 26.32 ZnO þ P3HT:PCBM fast growth 90.92 79.65 26.95

(6)

conducting n-type semiconductor, this vertical inhomogeneous distribution is more congruous in the inverted device structure than in the regular one.

We further investigated the effect of the inserted ZnO inter-layer on the device performance as well as the morphology by varying concentration of the ZnO solution from 1 to 5 wt%.

Fig. 6(a) displays the J–V characteristics of inverted devices prepared with different concentrations of ZnO in the ﬁlms. The

highest PCE (3.98%) was that obtained from the 3 wt% solution, with values of Jsc, Voc, and FF of 10.65 mA cm2, 0.61 V, and

61.26%, respectively; the other concentrations provided lower device performance parameters. We believe that this behavior is related to the transparency of the 3 wt% film near the absorption spectrum of P3HT:PCBM being higher than those of the films prepared at the other concentrations (Fig. 6b). The transparency of the films changed as a result of variations in film morphology

Fig. 7. Tapping-mode AFM topographic images of (a) bare ITO and (b–f) ZnO ﬁlms prepared through spin-coating (4000 rpm) onto ITO glass from ZnO NP solutions of various concentrations [(b) 1, (c) 2, (d) 3, (e) 4, and (f) 5 wt%] and subsequent thermal annealing (150 1C, 60 min).

Fig. 6. (a) J–V characteristics and (b) transmittance spectra of inverted-structure solar cells incorporating ZnO ﬁlms prepared through spin-coating (4000 rpm) of ZnO NP solutions of various concentrations and subsequent annealing (150 1C, 60 min).

(7)

when prepared at the different concentrations. To investigate the changes in morphology and surface roughness, we recorded AFM images of the ZnO films deposited from solutions at different concentrations.Fig. 7reveals that the grain size increased upon increasing the concentration of the ZnO solution, presumably because a greater amount of solute increased the probability of solute clustering to form larger grains. The grain sizes revealed in SEM images (not shown) were consistent with the measured surface roughnesses, with larger grain sizes resulting in rougher films. The surface roughnesses (root-mean-square values) of the films prepared from ZnO NP solutions at concentrations of 1, 2, 3, 4, and 5 wt% were 10.02, 10.93, 12.33, 14.23, and 15.48 nm, respectively. These small variations in surface roughness and grain size of the ZnO films cannot be correlated with the variations in device performance, suggesting that the vertical phase separation in the blend film was maintained because the surface properties remained unchanged. We conclude that the concentration of ZnO solutes in the film should be controlled to maximize PCE.

4. Conclusion

We have successfully synthesized ZnO NPs through a simple, cheap, and clean wet-grinding method. Corresponding solution-processed ZnO interlayers effectively block holes and collect electrons from PCBM. This fabrication approach requires no vacuum processing, a relatively low annealing temperature (150 1C), and removes the need for PEDOT:PSS. Furthermore, the degree of vertical phase separation in the rapidly grown active layer was independent of the surface morphology of the ZnO layer and provided a device with efﬁciency comparable to that of slow growth, thereby decreasing the fabrication time and the cost of the resulting solar cell. Thus, our method for preparing NPs is a very promising one that might contribute to decreasing the cost of PV technologies.

Acknowledgment

We thank Tian-wey Lan and Professor Yuan-Yang Chen of the Institute of Physics at Academia Sinica for the XRD measure-ments. Dr. Chu thanks the National Science Council (NSC), Taiwan (NSC100-2221-E-001–009), and the Thematic Project of Academia Sinica, Taiwan (AS-100-TP-A05), for ﬁnancial support.
