Impact of strain on gate-induced floating body effect for partially depleted silicon-on-insulator p-type metal-oxide-semiconductor-field-effect-transistors

(1)

Impact of strain on gate-induced

ﬂoating body effect for partially depleted

silicon-on-insulator p-type metal

–oxide–semiconductor-ﬁeld-effect-transistors

Wen-Hung Lo

a

, Ting-Chang Chang

a,b,

⁎

, Chih-Hao Dai

c

, Wan-Lin Chung

a

, Ching-En Chen

d

, Szu-Han Ho

d

,

Jyun-Yu Tsai

a

, Hua-Mao Chen

e

, Guan-Ru Liu

a

, Osbert Cheng

f

, Cheng-Tung Huang

f

a

Department of Physics, National Sun Yat-Sen University, Kaohsiung, Taiwan, ROC

b

Center for Nanoscience and Nanotechnology, National Sun Yat-Sen University, Kaohsiung, Taiwan, ROC

c

Department of Photonics, National Sun Yat-Sen University, Kaohsiung, Taiwan, ROC

d

Department of Electronics Engineering, National Chiao Tung University, Hsinchu, Taiwan, ROC

e_{Department of Photonics & Institute of Electro-Optical Engineering, National Chiao Tung University, Hsinchu, Taiwan, ROC} f

Device Department, United Microelectronics Corporation, Tainan Science Park, Taiwan, ROC

a b s t r a c t

a r t i c l e i n f o

Available online 6 November 2012 Keywords: PD SOI p-MOSFETs GIFBE NBTI Strain

This work investigates impact of mechanical strain on gate-induced-floating-body-effect (GIFBE) for partially de-pleted silicon-on-insulator p-type metal–oxide–semiconductor field effect transistors (PD SOI p-MOSFETs). First part, the original mechanism of GIFBE on PD SOI p-MOSFETs is studied. The experimental results indicate that GIFBE causes a reduction in oxide electricfield (Eox), resulting in an underestimate of negative-bias temperature in-stability (NBTI) degradation. This can be attributed to the electrons tunneling from the process-induced partial n+ poly gate and anode electron injection (AEI) model, rather than the electron valence band tunneling (EVB) widely accepted as the mechanism for n-MOSFETs. And then, the second part shows that the strained FB device has less NBTI degradation than the unstrained devices. This behavior can be attributed to the fact that more electron accu-mulation was induced by strain-induced band gap narrowing, reducing NBTI significantly.

1. Introduction

Even silicon-on-insulator (SOI) CMOS devices are attractive for switching application because of their high speed, lower power dissi-pation, and the ability to restrain latch-up, SOI devices has some crit-ical issues leads instabilities such asfloating body (FB) effect. For partially depleted (PD) SOI devices, due to their relatively thick thin films, the impact ionization mechanism near the drain will cause the ionization charges to accumulate in the neutral region, leading to the instability of body potential[1]. With aggressive scaling of the gate oxide, the floating-body (FB) potential is controlled not only by well known impact ionization mechanisms but also by a grad-ual increase of the tunneling current. This new FB effect, called gate-induced-FB-effect (GIFBE), has been observed in both PD SOI MOSFETs[2,3]and fully depleted transistors[4]. However, the origin of these electrons is not clear yet due to the fact that the electron con-centration is insufficient in the p+_{poly gate of p-MOSFETs. To the}

best of our knowledge, several studies consider that the model of electron valence band (EVB) tunneling should be responsible for the GIFBE in SOI n-MOSFETs [2–4]. But, the new mechanism for SOI

n-MOSFETs has been reported which demonstrates the GIFBE is due to impact ionization, named anode hole injection (AHI)[5–7]. As de-vices turn on, inversion layer supplies carriers to result in gate tunnel-ing current, generattunnel-ing electron–hole pairs due to impact ionization within poly gate depleted region. Therefore, ionization-induced holes tunnel back toward active layer and gather at body to attribute to GIFBE.

However, there are a few studies conﬁrming the validity of EVB-induced GIFBE for p-MOSFETs. Therefore, the aim of this work is to clarify the origin of electrons on the GIFBE in PD SOI p-MOSFETs by adopting systematical operation conditions. The ex-perimental results reveal that the GIFBE in p-MOSFETs can be partial-ly attributed to the process-induced partial n+_{poly gate of body tied}

devices. However, the major electron source generated by NBTI stress is significantly related to the inversion channel supplied from the source and drain, and then reducing NBTI due to lower oxide electric field[8–10]. Therefore, GIFBE in SOI p-MOSFET is dominated by the anode electron injection (AEI) model which is similar to the anode hole injection (AHI)[5]in this work, to explain how this main elec-tron origin is generated during NBTI. In detail, AEI is a mechanism which is associated with S/D. As channel invert, channel holes come from S/D could leak toward gate by tunneling, and then inducing electron–hole pairs. After that, impact-induced electrons can tunnel back to channel again, leadingfloating body effect (FBE). In addition, strained silicon technique offers an alternative method to enhance ⁎ Corresponding author at: Department of Physics, National Sun Yat-Sen University,
