A Novel Adaptive Scaffolding Scheme for Self-Regulated Science

Learning in Hypermedia-based Learning Environments

A Novel Adaptive Scaffolding Scheme for Self-Regulated Science

Learning in Hypermedia-based Learning Environments

Student

Huan-Yu Lin

Advisor

Shian-Shyong Tseng

A Dissertation

Submitted to Department of Computer Science College of Computer Science

National Chiao Tung University in partial Fulfillment of the Requirements

for the Degree of Doctor of Philosophy

in

Computer Science

November 2012

I

A Novel Adaptive Scaffolding Scheme for Self-Regulated Science Learning in

Hypermedia-based Learning Environments

student

Huan-Yu Lin

Advisors

Dr. Shian-Shyong Tseng

Department of Computer Sciecne

National Chiao Tung University

ABSTRACT

Science education aims to build learners' scientific knowledge structure and varied

process skills. The scientific learners who have various prior knowledge and learning

styles usually need various learning processes to master the concepts or skills. This

learning requirement can be fulfilled by Hypermedia-based Learning Environments,

where the free learning environments can provide a non-linear learning process for

various learning needs. In the non-linear learning process, learners can freely select

appropriate learning paths to achieve the learning goal and the diversified presentation

can demonstrate varied process skills. However, the large number of learning choices

provided by this kind of flexible learning environment usually make learning more

difficult if learners lack self-regulated learning (SRL) abilities to decide their learning

processes and strategies. Thus, scaffoldings, which suggest or guide learners when

learners cannot self-regulate their learning, are usually used to help low-SRL-ability

learners. According to previous researches, adaptive scaffoldings, which dynamically

provide learners assistance according to learners' status, can improve learning

performance and facilitate SRL behaviors better than fixed ones, but providing

adaptive scaffoldings would cause heavy loads on teachers. Although some of existing

Intelligent Tutoring System (ITS) approaches can provide adaptive scaffoldings,

applying these approaches in the non-linear learning processes is still difficult. This is

because the diverse portfolios and prior knowledge generated by various processes

cause the teaching strategies more complex than ones for linear learning processes.

Thus, In this dissertation, three subproblems about representing non-linear learning

plans, adapting learning content to diverse learners' requirements, and diagnosing

learners' status by heterogeneous portfolios are defined. For solving these

subproblems, a novel adaptive scaffolding scheme is proposed, where a generalized

finite state machine, a multi-granularity learning content model, and an

ontology-based knowledge structure are designed to solve the three subproblems,

respectively. The evaluation results and the applying cases are also provided in this

dissertation.
